Patton electronics 6511 User manual

Optical or Electrical Egress
Choose between short-haul electrical BNC or
intermediate-range optical SC connectors
Redundant Packet Switching
Reliable packet switching architecture ensures
redundant paths for deploying mission-critical
Hot Swappable and Redundant
For critical applications use dual 6511s and get
1+1 redundancy. Hot-swap cards for fast main-
Move data rapidly with the Patton 6511 Matrix Switch and get non-blocking any-to-any TDM access,
Packet Switched Ethernet, and high-speed trunking...all in a single card
Matrix Switch with STM-1/OC-3
and Gigabit Ethernet
ForeFront™AIS
Model 6511
The Patton Model 6511 Matrix Switch is
an integrated multimedia switching
engine complete with a digital access
cross-connect, high-speed STM-1/OC-3 trunk
interface, wire-speed Ethernet packet switch,
and GUI management system.
The Model 6511’s flexible channel switching
fabric allows non-blocking switching from
any input to any output. The Channelized
STM-1/OC-3 interface integrates into a
SDH/SONET network, enabling users to
channelize an STM-1/OC-3 down to 64 kbps
timeslots. With full grooming capability the
Model 6511 DACS allows any-to-any TDM
mapping and can place any channel from any
card onto any port.
Combined with the ForeFront AIS Packet-
Switched Backplane, the Model
6511 redundantly interconnects
every slot, at wire-speed, and
aggregates traffic from each sys-
tem card onto dual-switched uplink
Ethernet ports. With increased per-
formance and throughput, the
packet backplane allows non-blocking access
to the Model 6511, other system cards, and
the uplink ports.
With the Forefront architecture, TDM and pack-
et can be used simultaneously and to full
capacity. In a system loaded with dual 6511’s,
the high speed channel switching and packet
backplane on the Model 6511 offers 1+1 redun-
dancy.
Management is a snap with VT-100, TELNET,
SNMP and WEB options. Manage traffic out-
of-band via dual 10/100/1000 Ethernet ports
or terminate PPP/FR via timeslots in-band.
With the integrated L2/L3 switch the Model
6511 provides managment access to all
cards within the chassis
Master time and space with the Model 6511
Matrix Switch and realize an unequaled level
of density and control over the new conver-
gent network.
Visit www.patton.com for more informa-
tion.
Non-Blocking I/O Fabric
Get dedicated connectivity to every input and
every output port while grooming TDM or
switching packet data
Integrated STM-1/OC-3 DACS
Resolve traffic down to 64 kbps timeslots,
switch any timeslot to any port or loop it back
6511RC Matrix
Get high speed channel-
ized DACS, timeslot
mapper, and layer 2
packet aggregation.
Use with 6511RCT and
get high speed network
access from DS-3 and
STM-1/OC-3.
6511RCT STM-1
Trunk Module
Choose intermediate
optical or short-haul
electrical channelized
STM-1/OC-3 interfaces.
Dual 10/100/1000 Mbps
switched Ethernet ports for
system packet aggregation.
WEB/SNMP Manageable
Get fault detection and resolution standard.
Use the embedded HTTP/SNMP agent to man-

07MD6511-DS4
Backplane Diagram
Patton is a registered trademark and IPLink is a trade-
mark of Patton Electronics Company in the United States
and other countries.
Specifications
ForeFront System Elements
ForeFront Next Generation DSL Network Access
The ForeFront architecture guarantees total non-blocking oper-
ation for any TDM application and for Packet switching applica-
tions over the redundant Packet Switching Bus (PSB). With the
ability to simultaneously transmit and receive on both full-
duplex 10/100/1000 Ethernet up-link ports, the 6511RC offers
unparalleled switching to any DSL, E1, STM-1/OC-3 media as
well as redundant PSB and TDM buses.
Patton’s ForeFront Access Solutions for DSL address the new point-
of-presence requirements demanded by today’s providers operating
IP and TDM networks. Using a modular approach, the ForeFront AIS
includes all system components to provide DSL access. Fully redun-
dant power and integrated cooling enable the lightweight chassis to
scale for density and services. DSL line cards offer the latest
ITU/ETSI G.SHDSL technology for true standards based connectivity.
Grooming facilities and high speed softswitch allow any-to-any
cross-connecting to T1/E1s or STM-1/OC-3 interfaces. Integrated
management gives command over the entire system end-to-end and
offers tools for fault detection, isolation, and correction.
nxT1/E1
TDM
Egress
High-Speed
Trunk Egress
IP/Packet
&
STM-1/OC-3
Complete user flexibility allows
switching of any time slot from
any interface to any port within
the system.
DSL Concentrator
3096RC T-DAC
6511 Matrix Switch
DSL Concentrator
DSL Concentrator
G.SHDSL Access
Connections
Timeslot Mapper
TDM/PSB
Backplane
DS1-SF, SLC-95, ESF, E1–G.704 basic, CRC-4 multi-
frame (G.706 framing), DS3–M23, C-bit parity formats,
E3–G.751, G.832 E3, STM-1–G.707, SONET/STS-3–Per
ANSI T1.105-2001
DS1–VT1.5 -> STS-1 SPE, TU-11 -> STM1/VC3, TU-11
-> TUG3 -> STM1/VC4, TU12 -> STM1/VC3, TU-12 ->
TUG3 -> STM1/VC4; E1–VT2 -> STS1 SPE, TU-12 ->
STM-1/VC3, TU-12 -> TUG3 -> STM-1/VC4; DS3–DS3
-> VC3 -> AU3 -> STS-1 SPE; STM-1 –G.707;
SONET/STS3– Per ANSI T1.105.02-2001
STM-1–G.813; STS-3 - ANSI T1.101-1999, T1.105.09-
1995, G4-1244
G.821 & G.826 (ES, SSES, US, EB, and BBE; T1.231 &
GR-253-CORE ES, SES, US and SEFS
PRBS per ITU-T 0.151 & 0.152; DS3/E3 Diagnostic &
Line Loopback; DS2 Demux Loopback; T1/E1 Diagnostic
& Loopback
Dual 10/100/1000 Base-T (RJ-45 connector)
Single mode dual SC fiber (20km) per G.957 using 1310
nm lasers per G.652 or Dual 75-Ohm BNC per G.703
LEDs for power, CPU, Dual Ethernet, test mode, egress
synchronization, egress trunk status
HTTP, SNMP, TELNET Ethernet, RS-232 Console Port,
SYSLOG Client, Remote Software Upgrade via FTP
Configurable alarms; Remote SNMP Traps; Front Panel
LEDs
Safety: UL/CSA per UL1950 (METS) Canadian cMET and
CS-03. EMC Directive 89/336/EEC, FCC Part 15, CE
Mark, CTR12, CTR13 FCC Part 68. Laser Safety: Class
1, IEC-825-1, 1993
Operating temperature: 14 to 140°F (0 to 60°C);
Humidity: 5 to 90%, non-condensing
Line Framing
Mapping
Clocking
Error Counts
Line Testing
Ethernet Ports
STM-1/STS-3 Ports
LED Indicators
Management
Services
Alarm Reporting
Compliance
Environment
