PAX PWM100 User manual

PAX Water Mixer (PWM100)
Installation/Operation Manual

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 1
Notices
© PAX Water Technologies, Inc. 2014
WARNING: It is important that this manual be read in full prior to installation or maintenance of
the PAX Water Mixer. No part of this manual may be reproduced in any form or by any means
(including electronic storage and retrieval or translation into a foreign language) without prior
agreement and written consent from PAX Water Technologies as governed by the United
States and international copyright laws.
Manual Part Number
1101-7119-01
Edition
Revision C
April 2014
Printed in USA
PAX Water Technologies, Inc.
860 Harbour Way South, Suite C
Richmond, CA 94804
[phone]
Warranty
The material contained in this Installation/Operation Manual is provided “AS IS” and “WITH ALL
FAULTS” and the user understands and agrees that all express and implied warranties, including
those warranties implied by the Uniform Commercial Code as enacted in the state of California,
United States or such other forum as may be agreed upon by PAX and the user, are excluded with
regard to this manual and any information contained herein; and PAX and the user further exclude
all other implied warranties of merchantability and fitness for a particular purpose with respect to
this manual. The material provided in this manual is subject to change in future editions without
notice to the user.

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 2
CONTENTS
1. Before You Begin .................................................................................................................................................................... 3
Hazard of Electrical Shock, Explosion or Arc Flash
Unintended Equipment Operation
Safety Warnings
2. Overview ...................................................................................................................................................................................... 4
PAX Water Mixer Description
Quality Control Statement
3. PAX Water Mixer Specifications ..................................................................................................................................... 5
4. Installation Tools and Test Equipment ........................................................................................ 5
5. Facilities Requirements ..................................................................................................................................................... 6
6. Installation Procedure .......................................................................................................................................................... 7
Figure 1: PWM100 ...................................................................................................................................... 7
7. PAX Water Mixer Start-Up and Shut-Down Procedure ......................................................................................... 8
8. PAX Water Mixer Electrical Checks ............................................................................................................................... 9
9. Recommended Maintenance Checks ......................................................................................................................... 10
10. Replacement Parts List ................................................................................................................................................... 10

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 3
1. Before You Begin
Read and understand the following instructions before performing any procedure with this
product. Failure to follow these instructions may result in death or serious injury.
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR ARC FLASH
• Installation,adjustment,repairandmaintenancemustbeperformedbyqualiedpersonnel.
• Theuserisresponsibleforcompliancewithallinternationalandnationalelectricalcode
requirements with respect to grounding of all equipment.
UNINTENDED EQUIPMENT OPERATION
• NoresponsibilityisassumedbyPAXWaterTechnologiesforanyconsequencesarisingoutof
the use of this product.
• Donotoperateorinstallanyequipmentthatappearsdamaged.ContactyourPAX
representative to resolve any damage issues.
SAFETY WARNINGS
This is the safety alert symbol and is used to alert potential personal injury
hazards. Please obey all safety messages that follow this symbol to avoid
personal injury or death.
WARNING indicates an imminently hazardous situation, which if not avoided, can result in
death, serious injury or equipment damage.
• Aconnedspaceentryplanandoperationalproceduresmustbeusedforeveryreservoirentry.
Refer to OSHA’s confined space requirements at their website: http://www.osha.gov or your
relevant local authority.
• Liftingtoolsandequipmentarerequiredduringinstallation.RefertoOSHA’swebsiteformore
information: http://www.osha.gov or your relevant local authority.
• Fallprotectionisasafetyrequirementforworkperformedonwatertanks.Pleasereferto
OSHA’s website for fall protection safety requirements: http://www.osha.gov or your relevant
local authority.
• OnlylicensedelectricalcontractorsshouldattemptinstallationofthePAXWaterMixer.
• Avoiddroppingconstructionmaterialsortoolsintowatertankssoastopreventdamagetothe
tank’s interior coating

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 4
2. Overview
PAX WATER MIXER DESCRIPTION
The PAX Water Mixer (PWM100) is an active vortex mixer for small water storage tanks. Patented
PAX technology provides the most powerful small tank mixing to thoroughly circulate the entire
tank volume. The mixer installs easily and self-rights at the bottom of a tank, even on a sloped floor.
QUALITY CONTROL STATEMENT
PAX Water Technologies is dedicated to supplying high-quality products that meet or exceed
the needs of water customers. PAX Water Technologies’ strict quality control and continuous
improvement programs ensure the best value to customers. PAX Water Technologies manages its
business to the highest environmental and ethical standards.
NSF International provides testing and certification of water systems and components
to ensure their safety for use in drinking water systems. Certification to the health
effects requirements of NSF/ANSI Standard 61-G has been completed for these
products which include all wetted components – including the entire frame, foot,
motor, nozzle and power cable.

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 5
3. PAX Water Mixer Specifications
4. Installation Tools and Test Equipment
1. Wire Stripper/Crimper
2. Diagonal Cutter, 6” (150 mm)
3. Multimeter (Fluke #179 or equivalent)
4. Current Clamp (Fluke #10005 or equivalent)
Power Supply Required 120 VAC, 60 Hz, GFCI-protected, 20 amp circuit
Customer Supplied Power Switch 3R fused, safety disconnect switch
Motor Type 115 VAC, 60 Hz, water-filled, water-lubricated, single phase motor,
NSF 61
RPM 3450
Nominal Power Draw 1.15 kVA (670 watts)
Footprint Diameter 10” (25.4 cm)
Height 30” (76.2 cm)
Weight 40 lbs (18.1 kg)
Material: Motor Housing 316 stainless steel
Material: Motor Seals Chlorine/chloramine-resistant NBR rubber
Material: Foot Chlorine/chloramine-resistant EPDM rubber
Wiring NSF 61 & UL-listed submersible pump cable 14 AWG XLPE
Maximum Motor Wire Length 100’ (30.4 m)
NOTE: Contact your PAX Representation if you have questions on maximum motor wire length.

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 6
5. Facilities Requirements
The following requirements must be provided at the installation site. This manual is not intended
to cover the set-up of these facilities.
PWM100 ASSEMBLY
REQUIREMENT DESCRIPTION
Line Power Dedicated 120 VAC, 60 Hz, single phase, 20 amp GFCI-
protected circuit.
Safety Disconnect Switch
The safety disconnect switch must be a 3R certified type, properly
marked and installed in accordance with all electrical codes,
state, local and OSHA requirments.
Junction Box 3R located in accordance with local codes.
Electrical Conduit
The PAX Water Mixer cable is a 3 wire cable set, 0.5” (12.7 mm)
in diameter. Use electrical conduit (3/4” or 20 mm) from the
tank penetration to the junction box, and from the junction box to
the safety disconnect switch.
Strain Relief Designed for a 1.025” (26 mm) hole penetration and able to
support 50 lbs (22.7 kg).

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 7
6. Installation Procedure
WARNING: The PAX Water Mixer should always run underwater, NEVER RUN DRY.
NOTE: All electrical and conduit connections should be secure and routed in accordance with
electrical code.
FIGURE 1

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 8
1. Bring power (120 VAC, 60 Hz, GFCI-protected, 20 amp circuit) onsite to tank.
2. Install a safety disconnect switch and connect power.
NOTE: Make sure that the safety disconnect switch is in the off position; follow proper lockout/
tagout procedures.
3. Penetrate the side of the tank hatch (1.025” or 26 mm hole).
4. Run conduit (3/4” or 20mm) from the safety disconnect switch to a junction box at the tank
hatch, and then from the junction box to the penetration of the hatch lip. Pull wire from safety
disconnect switch to the junction box (copper wires min. 12 AWG (3.31 mm2), type THHN,
rated 90 °C).
5. Bring the PAX Water Mixer to the roof of the tank.
NOTE: Keep PAX Water Mixer inside its packaging for protection. The holes on the sides of the
packaging can be used to secure a rope.
6. Remove mixer from its packaging and tie off the power cord (halfway between mixer and end
of cord) to ensure that mixer cannot fall off the top of the tank. Then thread the end of the
power cord through a strain relief, the tank penetration and the conduit that connects to the
junction box.
7. Hold the mixer over the open hatch by gripping its power cord and slowly lower into the water.
a) Continue to lower the mixer, a few feet at a time, until it makes contact with the floor of
the tank.
b) After the mixer makes contact with the floor of the tank, allow 3-4 feet (1-1.5 m) of slack in
the cable.
c) If there is excess power cord, coil it up and secure it to the ladder above the water.
NOTE: The PAX Water Mixer is designed to come to rest on the floor of the tank and point upwards.
On a sloped floor, the mixer will come to rest at a low point on the tank floor.
7. PAX Water Mixer Start-Up and Shut-Down Procedure
NOTE: After the initial installation or any tank maintenance, always perform the PAX electrical
checks before placing the PAX Water Mixer in service.
Checks include:
• MeasuringMotorResistanceandGround
• MeasuringACCurrent
• MeasuringACVoltage
1. To turn the PAX Water Mixer ON, energize the GFCI breaker and turn ON the safety disconnect
switch.
2. To turn the PAX Water Mixer OFF, turn off the safety disconnect switch and de-energize the
GFCI breaker.

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 9
8. PAX Water Mixer Electrical Checks
The major hazard associated with the PAX Water Mixer is danger of electrical
shock when performing the electrical checks. Always use caution when working
with high voltage.
Following the installation of all hardware, and after all electrical connections have been made,
perform an electrical check and start the PAX Water Mixer, to make sure that PAX Water Mixer is
operating properly. The electrical checks should be completed by a licensed electrical contractor.
Electrical Test Equipment
The following equipment is to be used to perform the electrical check.
• Multimeter
• CurrentClamp
NOTE: Perform the measurements at a location in the circuit where you are able to place a clamp-
on amperage meter and where you can take a voltage reading.
NOTE: Reference Table 1 for the next steps.
Table 1 Quick Reference Chart
#WHAT TO MEASURE READING
MEASURED
NORMAL
READING
MULTIMETER
SYMBOL
TOOL FOR
MEASURING
1Wire resistance L1 to L2
(when powered down) 1.4 - 2.0 ohms ΩMultimeter
(with probes)
2Wire resistance L1 to Ground and
L2 to Ground (when powered down) >700K ohms ΩMultimeter
(with probes)
3AC input voltage 110 - 120 VAC ~Multimeter
(with probes)
4 AC current L1 to L2 9.5 – 11.5 amps
AC ~Multimeter (with clamp)

Part No. 1101-7119-01 © 2014 PAX Water Technologies, Inc.
PAX Water Mixer (PWM100)
Installation/Operation Manual 10
Measuring Motor Resistance
1. Disconnect all power by placing the safety disconnect switch in the open position.
2. Lockout and tagout the safety disconnect switch.
3. Verify the motor resistance between motor wires by measuring between L1 and L2
 •Theresistanceshouldbebetween1.4-2.0ohmsdependingonthelengthofthecable.
4. Measure the motor resistance between L1 and L2 and motor ground.
 •Theresistanceshouldbebetweengreaterthan700Kohms.
5. If all the readings are within specification, then remove any lockout/tagouts and perform the
PAX Water Mixer start-up.
Measuring AC Input Voltage
1. Power up the PAX Water Mixer.
2. Set the Multimeter to AC Volts. Place the probes across the incoming power.
 •Verifythatthevoltageisbetween110-120VAC.
Measuring AC Input Current
1. Power up the PAX Water Mixer.
2. Set the multimeter to AC amp.
3. Clamp the current meter to each of the input power wires.
 •Verifythatthecurrentisbetween9.5and11.5ACamps.
9. Recommended Maintenance Checks
NOTE: There is no preventative maintenance required for the PAX Water Mixer.
1. Perform the PAX Electrical Checks (Section 8) annually to ensure that the PAX Water Mixer
is operating within specification.
2. Pull the PAX Water Mixer by its power cord up just below the surface of water (do not pull
out of the water) to verify operation (water movement).
3. In the event that the PAX Water Mixer is not working, contact your PAX representation for
technical support.
4. It is recommended that every five years, the PAX Water Mixer motor be replaced. Contact
your PAX representative for details on the motor exchange program.
10. Replacement Parts List
The following is a replacement part number for the PAX Water Mixer.
DESCRIPTION PART NO. QUANTITY
Service Kit, PWM100 Mixer, Replacement-60’ PSK-1067 1
Service Kit, PWM100, Replacement-100’ PSK-1068 1

PAX Water Technologies, Inc.
860 Harbour Way South, Suite C
Richmond, CA 94804
For sales and service, contact:
Phone: [phone]
Email: [e-mail]
www.paxwater.com
