PCM PCMPA7400 User manual

User Manual
PCMPA7400

Pg. 3
PCMPA7400 - USER MANUAL
Thanks for purchasing PCM Home & Office Telephone PA-7400.
Please read this manual carefully before using this Telephone.
MAIN FEATURES
1. Can be used with variety of switches of 48-60 voltage
2. The voice won’t be impacted by the length of the exterior line, with
Automatic Gain Controlled (AGC) circuit
3. Use electronical musical rings to make it silvery and euphonious.
When new call comes, the Ringer LED will glitter.
INSTALLATION
1. Put the telephone in a dry, ventilation and non-erode gas place,
2. After installing the spiral cable line in the handset and the host,
connect the line port of the base unit to the line port of the room with
straight cable line.Pick up the handset and you will hear the echo from
the exchanger or PABX. That means the telephone is ready for use.

Pg. 4
PACKING ITEMS
1 Host
1 Handset
2 Keys
1 Line cable
1 Coil cable
1 User’s manual
USE METHOD
1.To Receive a call
When the phone is ringing,pick up the handset for conversation.Put
away the handset back after conversation.
2. To Make a call
Pick up the handset,when hearing the dial tone,you can dial out the
numbers and make calls.
3. REDIAL
Pick up the handset and then press REDIAL key to dial out the last
dialed number automatically.
4. PAUSE
During dialing, you can press pause key to make the next number
has a 3.6 seconds delay to active addition function when using un-
der certainpublic telephone exchanger or PABX.
5. FLASH -- 600ms
When there is an engaged tone or a wrong number, you can press
FLASH key to Recall.
6. RINGER Volume Hi/Lo
Slide the “RINGER SWITCH” to ‘LO’ or ‘HI’ position, you can adjust
the VOLUME OF THE RINGER.
7. P/T Switchable
Before the phone is put in service, you can slide the dialing mode switch
to Pulse or Tone position to be set in accordance with the dialing meth-
od used by your local public telephone exchanger:

Pg. 5
P(pulse):pulse dialing mode
T(tone):dual-tone multi-frequency dialing(DTMF) mode
8. KEY LOCK
This telephone can set the lock of making calls.
Red Point: When the key turns to the RED POINT, it is ON forall calls.
Green Point:When the key turns to the GREEN POINT, it only lock digit
key “ 0 “, all of other digit key can dial out.
Yellow Point:When the key turns to the YELLOW POINT, the callscan
not be dialed out, without any exemption.
NOTICE
1. Install and use the telephone under the guidance of the profes-
sional of the telephone company.
2. You can use the groove under the telephone if you wan to hang
it on the wall.
3. Place the telephone in the place of clean and dry and without
corrosive gas.
4. Avoid concussion and collision.
5. Please contact the local telephone company or our company
when there is something wrong with the telephone.
PCM´s RECOMENDATION.
At PCM we strive to get you new technologies that are simple
and friendly. Accordingly to that, we always try to give you exactly
what you are looking for. This is why we have compiled a list of emer-
Here they are:
In Argentina:
• Any type of emergency: 911
• Medical emergency: 107
• National Firemen Corps: 100
• Police: 101
In Chile:
• Medical emergency: 131
• National Firemen Corps: 132
• Police: 133

Pg. 6
In United Status of America:
• Any type of emergency: 911
In Uruguay:
• Any type of emergency: 911
• Medical emergency: 105
• Police: 109
• National Firemen Corps: 104
If you would like to comment about these lists and suggest new ones, you
are invited to contribute in our website: www.pcm-electronics.com

Pg. 7
INTERNATIONAL WARRANTY
Terms and Conditions
1. PCM warrants the operation of this product to be free from
any manufacturing and/or material defect for a period of 6 months
from the date of purchase by the user.
2. This warranty is limited to the repair and/or replacement of this
product, according to our own criterion, free of charge within the
stipulated term and it does not extend to consequential or incidental
damages to other products that may be used with this unit.
3. The warranty shall be voided in the following cases: a) repair or
attempt to repair by third parties not authorized by the company. b)
in case of performing any type of cut in connection cables, plugs,
connectors, or other adapters different from the original ones pro-
vided by the company.
4. To make this warranty effective, you shall contact the Authorized
Service Center of your country and they shall carry out the perti-
nent procedure; this information is available at www.panacom.com.
In order to start the necessary procedure to get the warranty, you
shall hand in the Original Purchase Invoice where the purchase date,
5. Transportation, freight, stay and/or insurance expenses, if any, are
not covered by this warranty.
