PEAK COMMUNICATIONS TLTR3100 User manual

Installation and Operating Handbook
TLTR3100 Test Loop Translator
Covers options: 3f, 4, 9, 12b
Document Issue v1.01, July 30, 2020
1997
Peak Communications Ltd.
Unit 1, The Woodvale Centre
Woodvale Road
Brighouse
West Yorkshire
HD6 4AB
England
Tel.: [phone]
Fax.: [phone]
IMPORTANT NOTE: THE INFORMATION AND SPECIFICATIONS CONTAINED IN THIS DOCUMENT
SUPERSEDES ALL PREVIOUSLY PUBLISHED INFORMATION CONCERNING THESE PRODUCTS
PEAK COMMUNICATIONS Ltd maintains a continuing programme of product improvement and therefore
reserves the right to change specifications without notice
PeakManual:v1.52, ODUManual:v1.55, ODUPowerConnectors:v1.26, ODURedundancy:v1.1

Installation and Operating Handbook
Contents
Contents iii
List of Tables iv
Preface v
Customer Care vi
Product Compliance vii
Safety...................................................... vii
EMC....................................................... vii
1 Unit Description 1
1.1 Specification ............................................... 1
1.2 Chassis .................................................. 1
1.3 Mounting ................................................. 1
1.4 Connections ............................................... 1
1.5 StatusLED ................................................ 3
2 Operation 4
3 Remote Control 5
3.1 Serial Communications RS232 / RS485 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 P7xxxProtocol .............................................. 6
3.2.1 Attenuator............................................. 7
3.2.1.1 Instruction 20 (Attenuator status request) . . . . . . . . . . . . . . . . . . . . . . 8
3.2.1.2 Instruction 21 (Attenuator status response) . . . . . . . . . . . . . . . . . . . . . 9
3.2.1.3 Instruction 22 (Attenuator change request) . . . . . . . . . . . . . . . . . . . . . 10
3.2.2 Unit ................................................ 11
3.2.2.1 Instruction 40 (Unit status request) . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.2.2 Instruction 41 (Unit status request response) . . . . . . . . . . . . . . . . . . . . 13
3.2.3 Serial Communications Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.3.1 Instruction 26 (Serial Communications Settings Change Request) . . . . . . . . 15
3.2.4 EthernetSettings......................................... 16
3.2.4.1 Instruction 4, Sub Instruction ’1’ (Ethernet Status Request) . . . . . . . . . . . . 17
3.2.4.2 Instruction 5, Sub Instruction ’1’ (Ethernet Status Response) . . . . . . . . . . . 18
3.2.4.3 Instruction 6, Sub Instruction ’1’ (Ethernet Change Request) . . . . . . . . . . . 19
3.2.5 TCPPortSettings ........................................ 20
3.2.5.1 Instruction 4, Sub Instruction ’2’ (TCP Port Status Request) . . . . . . . . . . . . 21
3.2.5.2 Instruction 5, Sub Instruction ’2’ (TCP Port Status Response) . . . . . . . . . . . 22
3.2.5.3 Instruction 6, Sub Instruction ’2’ (TCP Port Change Request) . . . . . . . . . . . 23
3.3 Ethernet.................................................. 23
3.3.1 Webserver ............................................ 24
3.3.2 TCP................................................ 24
3.3.3 SNMP............................................... 24
A Mounting Drawings 25
TLTR3100 Peak Communications Ltd. iii

Installation and Operating Handbook
List of Tables
1.1 Ethernetresetsettings............................................ 2
1.2 Power/Alarms/Remotepinout ...................................... 3
1.3 Relayratings ................................................. 3
1.4 Redundancypinout ............................................. 3
1.5 StatusLED .................................................. 3
3.1 P7xxxprotocol ................................................ 6
3.2 Attenuatorinstructionlist .......................................... 7
3.3 Attenuator status request message format (instruction 20) . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Attenuator status response message format (instruction 21) . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Attenuator change request message format (instruction 22) . . . . . . . . . . . . . . . . . . . . . . . 10
3.6 Unitinstructionlist .............................................. 11
3.7 Unit status request message format (instruction 40) . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.8 Unit status request response message format (instruction 41) . . . . . . . . . . . . . . . . . . . . . . 13
3.9 Serial communications settings instruction list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.10 Serial Communications Settings Change Request message format (instruction 26) . . . . . . . . . . 15
3.11 Ethernet Settings instruction list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.12 Ethernet Status Request message format (instruction 4, sub instruction ’1’) . . . . . . . . . . . . . . 17
3.13 Ethernet Status Response message format (instruction 5, sub instruction ’1’) . . . . . . . . . . . . . 18
3.14 Ethernet Change Request message format (instruction 6, sub instruction ’1’) . . . . . . . . . . . . . 19
3.15 TCP Port Settings instruction list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.16 TCP Port Status Request message format (instruction 4, sub instruction ’2’) . . . . . . . . . . . . . . 21
3.17 TCP Port Status Response message format (instruction 5, sub instruction ’2’) . . . . . . . . . . . . . 22
3.18 TCP Port Change Request message format (instruction 6, sub instruction ’2’) . . . . . . . . . . . . . 23
iv Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
Preface
The Peak Communications TLTR3100 Installation and Operating Handbook provides information on installation
and use of the TLTR3100 unit.
This manual is of a technical nature and is intended for technicians, engineers and service personal.
The main body of the manual takes the user through the unit and its uses. The appendices include, generic
overall dimensioning information (with mounting).
TLTR3100 Peak Communications Ltd. v

Installation and Operating Handbook
Customer Care
Contact the Peak Communications support department for:
• Product operation, application support or training requests
• Information for returning or upgrading a product
• Comments or suggestions on any supplied literature
Contact Information:
Peak Communications Ltd.
Unit 1, The Woodvale Centre
Woodvale Road
Brighouse
West Yorkshire
HD6 4AB
England
Tel.: [phone]
Fax.: [phone]
Email [email protected]
Via our website www.peakcom.co.uk
To return a Peak Communications product for repair:
1. Contact the Peak Communications support department and request a Return Material Authorisation
(RMA) number.
2. You will be required to provide to our support representative the model number, serial number and a
detailed description of the problem.
3. To prevent any damage to the product during shipment we recommend that the unit is returned in its
original packaging or if this is not available the packaging used must be of an equal standard.
4. Return the product back to Peak Communications and advise shipment details to sales representative for
tracking purposes. (Any shipping charges should be prepaid)
vi Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
Product Compliance
Safety
To ensure safety of the operator the TLTR3100 series of units have been designed to comply with the following
safety standard;
EN 60950: Safety of information technology equipment, including electrical business machines.
Operation of the equipment in a non standard manner will invalidate compliance to this standard. The
equipment MUST BE OPERATED WITH ITS LID ON AT ALL TIMES. If it is necessary to remove the lid for any
purpose then it is essential that the lid is fitted back correctly before normal operation.
DEPENDANT UPON UNIT TYPE, DANGEROUS VOLTAGES MAY BE PRESENT AROUND THE POWER
SUPPLY AND PRECAUTIONS MUST BE TAKEN.
THE EQUIPMENT IS MEANT TO BE OPERATED BY TRAINED PERSONNEL ONLY.
EMC
The TLTR3100 units have been designed to comply with the following standards;
Emissions
EN 55022 Class B: Limits and methods of measurement of radio interference characteristics of Information
Technology Equipment.
Immunity
EN 50082 Part 1: Generic immunity standard, part 1: Domestic, commercial and light industrial environ
ment.
Damage to the chassis, controls or interfaces will invalidate compliance; please contact the factory under
these circumstances for advice on continued operation. Interfaces to the TLTR3100 series of units must be
made with suitably screened connectors and double screened coaxial cable. Data cables must be double
screened.
TLTR3100 Peak Communications Ltd. vii

Installation and Operating Handbook
Section 1
Unit Description
The TLTR3100 remote mounted Test Loop Translator from Peak Communications are designed to be fully
compatible with a wide range of equipment, to provide a monitor path from the output of the SHF amplifier.
These high grade units are designed to accept the signal at SHF and provide a further conversion to the
appropriate output band.
The TLTR3100 are designed to operate over a wide range of SHF power level inputs. The internal con
struction of the unit is modular which gives some flexibility in accommodating customers’ requirements such as
gain and frequency. The unit is powered from the Power / Alarms / Remote connector (see section 1.4).
The incoming RF is passed to the mixer which is fed with an LO which is in turn referenced from an
internally fitted OCXO. At all stages the components have isolators and attenuators to ensure correct matching
is maintained. The receive band signal is then passed out to the RF Out connector with no filtering unless this
has been specified.
The TLTR3100 units are not fitted with amplifiers as standard and have a through loss of 20dB nominal.
Maximum input power with no damage is standard at +15dBm with a non compressed signal level of above
5dB nominal.
The TLTR3100 has an electronically variable KaBand attenuator, with a range of 0  30 dB, and a step
size of 0.125 dB.
1.1 Specification
Please refer to the TLTR3100 datasheet for the current standard performance, or contact technical support for
specific technical enquiries.
1.2 Chassis
The unit is housed in a sealed die cast aluminium box. See Appendix A for the dimensions details.
1.3 Mounting
The unit comes with two mounting options:
Flat surface
Two small brackets are supplied for fixing of the unit to a flat surface. The brackets need to be screwed
to the unit’s underside in the appropriate place.
Pole
A kit to mount the unit to a circular pole is supplied.
See Appendix A for details.
1.4 Connections
Figure 1.1 shows a connector view.
TLTR3100 Peak Communications Ltd. 1

Installation and Operating Handbook
FUSE: 20 x 5mm
2A MAX
EXT Ref.
Power/
Alarms/
Remote RF In Ethernet RF Out Redundancy
Status
Figure 1.1: Connector view
Breather
Immersion proof breather.
Fuse
The main DC power supply fuse, bulkhead mounting 20mm x 5mm 1 Amp removable by turning.
Power / Alarms / Remote
16 Way male circular on the chassis with connections as shown in table 1.2. The cable must be rated to
cope with 1 Amp continuous use. The alarm contacts are from a dry contact relay, the ratings of which
are shown in table 1.3
Redundancy
12 Way circular connector on the chassis with connections as shown in table 1.4. The ’Ethernet reset’ pin,
when shorted to Ground will flash the main unit LED for ≈5 seconds, after this time the unit will restart
with the static Ethernet IP settings as shown in table 1.1.
Note that the ethernet reset pins must not be connected to any pin other than ground or per
manent damage will occur.
Table 1.1: Ethernet reset settings
Parameter Setting
IP address 192.168.0.2
Subnet Mask 255.255.255.000
Gateway 192.168.0.1
Ethernet
Sealed RJ45 connector, the cover of which must remain in place to keep the IP rating when not in use.
RF In
KType connector.
RF Out
KType connector.
EXT Ref.
TNC connector, input at 10MHz ±3dBm.
2 Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
Table 1.2: Power / Alarms / Remote pinout
16 Way male circular
Pin Number Function
A Chassis Ground
B RS232 Rx
C RS232 Tx
D RS485 Tx +
E RS485 Tx 
F RS485 Rx 
G RS485 Rx +
HNot used
INot used
KNot used
LNot used
M Alarm N/C
N Alarm common
O Alarm N/O
P Chassis Ground
R DC supply ( +16.5 V to +35 V DC)
Table 1.3: Relay ratings
Parameter Rating
Switch voltage (max.) 100V
Switch current (max.) 0.5A
Switch power (max.) 10W
Contact resistance 0.2Ω
Operate / release 0.5mS
Table 1.4: Redundancy pinout
12 Way circular connector
Pin Number Function
ANot used
B Ground
CNot used
DNot used
E Ground
FNot used
GNot used
HNot used
JNot used
KNot used
LNot used
M Ethernet reset
1.5 Status LED
The status LED, shows the status of the TLTR3100 unit. Table 1.5 shows the different LED colours and their
associated status meaning.
Table 1.5: Status LED
Colour Status
Green OK and Online
Red Summary alarm
TLTR3100 Peak Communications Ltd. 3

Installation and Operating Handbook
Section 2
Operation
Attach the feed wire carrying the RF signal to the socket marked ’RF In’. Output of the unit is a KType socket
marked ’RF Out’. Check out all cables for shorts before connecting and ensure the connections are weather
proofed. DC must not be introduced to the RF input or output connectors.
4 Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
Section 3
Remote Control
This section describes the various ways it is possible to monitor and control the TLTR3100 unit.
3.1 Serial Communications RS232 / RS485
The TLTR3100 unit is capable of being controlled remotely using the P7xxx protocol format as described in
section 3.2, through the RS232 / 485 connection, the baudrate of which is variable and is setup via one of the
remote control interfaces.
TLTR3100 Peak Communications Ltd. 5

Installation and Operating Handbook
3.2 P7xxx Protocol
The TLTR3100 transmits and receives data serially in an asynchronous format using the ASCII character set
(includes the extended ASCII set). The serial data consists of message frames composed of the following
message characters:
STX, number of bytes, unit address, instruction number, message body, checksum, ETX.
All characters are compulsory except for the message body. The presence of a message body is deter
mined by the message type (instruction number). The total number of message characters in a message frame
may range from a minimum of 6 to a maximum of 255. All messages to and from the unit follow the protocol,
as described in table 3.1, with a character format of 8 data bits, one stop bit, no parity, baud rate selectable.
Note that all numeric values are shown as decimal unless otherwise stated.
Table 3.1: P7xxx protocol
Message
byte no. Set value / example Length (bytes) Description
102 1STX
Start of message character #02
2n1
Number of bytes
Character defining how many characters are in the
message including the STX & ETX parts
332 1Unit address
Address ranges from character 001 to 255 (decimal)
421 1
Instruction number
Used to specify the type of message to or from the
unit
... ... ...
Message body
This is an optional set of data that is used in con
junction with the instruction type. It can be 0 bytes
in length upwards, all subject to the instruction num
ber
n1 ?1
Checksum
The checksum is used to verify the accuracy of the
message frame. The checksum is defined as the
summation of all the bytes in the message, begin
ning with the 3rd byte (Unit address) and extending
through the body of the message, ending with the
last byte before the checksum. The total of the bytes
is then ANDed with 255 so that the checksum is trun
cated to a single byte
n03 1ETX
End of transmission character #03
6 Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
3.2.1 Attenuator
This group of remote messages allow the user to monitor and control the channel attenuator of the TLTR3100
unit. In order for the unit to accept changes made via the remote control it must be placed in remote mode.
Table 3.2: Attenuator instruction list
To unit From unit Description
20 Attenuator status request
21 Attenuator status response
22 Attenuator change request
TLTR3100 Peak Communications Ltd. 7

Installation and Operating Handbook
3.2.1.1 Instruction 20 (Attenuator status request)
Table 3.3: Attenuator status request message format (instruction 20)
Message
byte no. Set value / example Length (bytes) Description
102 1 STX
271 Number of bytes
332 1 Unit address
420 1 Instruction number
5'L' 1 Test loop translator
6?1 Checksum
703 1 ETX
8 Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
3.2.1.2 Instruction 21 (Attenuator status response)
Table 3.4: Attenuator status response message format (instruction 21)
Message
byte no. Set value / example Length (bytes) Description
102 1 STX
213 1 Number of bytes
332 1 Unit address
421 1 Instruction number
5'L' 1 Test loop translator
6'+11500 =
11.500dB' 6Attenuation in 0.001dB steps
Attenuator only capable of 0.125dB steps
12 ?1 Checksum
13 03 1 ETX
TLTR3100 Peak Communications Ltd. 9

Installation and Operating Handbook
3.2.1.3 Instruction 22 (Attenuator change request)
Table 3.5: Attenuator change request message format (instruction 22)
Message
byte no. Set value / example Length (bytes) Description
102 1 STX
213 1 Number of bytes
332 1 Unit address
422 1 Instruction number
5'L' 1 Test loop translator
6'+11500 =
11.500dB' 6Attenuation in 0.001dB steps
Attenuator only capable of 0.125dB steps
12 ?1 Checksum
13 03 1 ETX
10 Peak Communications Ltd. TLTR3100

Installation and Operating Handbook
3.2.2 Unit
This group of remote messages allow the user to monitor the unit/main status part of the TLTR3100 unit.
Table 3.6: Unit instruction list
To unit From unit Description
40 Unit status request
41 Unit status response
TLTR3100 Peak Communications Ltd. 11

Installation and Operating Handbook
3.2.2.1 Instruction 40 (Unit status request)
Table 3.7: Unit status request message format (instruction 40)
Message
byte no. Set value / example Length (bytes) Description
102 1 STX
261 Number of bytes
332 1 Unit address
440 1 Instruction number
5?1 Checksum
603 1 ETX
12 Peak Communications Ltd. TLTR3100
