Pearpoint Flexitrax P550c User manual

flexitrax P550c OperationManual
Pearpoint’s advanced, crawler-based digital
video inspection system
Operation Manual
[P550c-OPMAN-ENG/04]
Rev 04
May 2019

P550c Operation Manual
www.pearpoint.com | 2
Preface
Before you begin
Please read this operation manual before using the P550c system.
The P550c system is a modular system that can be purchased as a full system package or as individual
components. Contact your Pearpoint representative to ensure you are purchasing the appropriate product for
your needs.
The contents of this manual are subject to change. Pearpoint products are under continuous development.
Pearpoint reserves the right to modify any product, including this manual, without notice and some product
changes may have taken place after publication of this manual.
For the latest information about the flexiprobe product family, including all accessories, documentation and
software updates, contact your local Pearpoint dealer or visit www.pearpoint.com.

P550c Operation Manual
www.pearpoint.com | 3
Copyright © 2019 Radiodetection Ltd. All rights reserved.
Radiodetection is a subsidiary of SPX Corporation.
Trademarks
Radiodetection, Pearpoint, flexiprobe, flexitrax, RD5100, RD7100 and flexicoiler are considered trademarks of
Radiodetection Ltd. Due to a policy of continued development, we reserve the right to alter or amend any
published specification without notice. This document may not be copied, reproduced, transmitted, modified or
used, in whole or in part, without the prior written consent of Radiodetection Ltd.
Other trademarks or registered trademarks mentioned in this document belong to their respective owners.
Disclaimer
Any third-party products (including hardware, software and services) mentioned in this manual are for
instructional purposes only and are not an endorsement by Radiodetection Ltd, Pearpoint or SPX Corporation.
Radiodetection Ltd does not accept any liability for loss of data or damage to equipment when using any third-
party products.

P550c Operation Manual
www.pearpoint.com | 4
Compliance
EU Compliance
This equipment complies with the following EU Directives:
EMC Directive: 2014/30/EU
EMF Directive: 2013/35/EU
Low Voltage Directive: 2014/35/EU
RoHS Directive: 2011/65/EU
WEEE Directive: 2012/19/EU
Industry Canada Compliance
ICES-003 Class A Notice:
This Class A digital apparatus complies with Canadian ICES-003.
Avis NMB-003, Classe A:
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada
Ingress Protection Marking
This system complies with this rating for IEC standard 60529, solid particle and liquid ingress protection:
IP55: Controller covers and connection panels open or closed.

P550c Operation Manual
www.pearpoint.com | 5
FCC 15 Compliance
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
The equipment may not cause harmful interference.
The equipment must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case you will be required to correct the interference at your own
expense.
Any modifications made to this equipment not approved by Pearpoint may void the authority granted to the user
by the FCC to operate this equipment.

P550c Operation Manual
www.pearpoint.com | 6
Warnings, Cautions and Notes
Please observe all warnings, cautions and notes in this manual before operating any Radiodetection
or Pearpoint product.
Warning! Warnings alert you to possible personal injury.
Caution: Cautions alert you to possible equipment damage.
Note: Notes contain useful information.
Warning symbols
General Warning: Refer to the manual for specific instruction or advice.
Electrical Hazard: Observe safe practices and exercise extreme caution.
Biohazard: Disinfect after use. Wear appropriate personal protective equipment (PPE).
Hot Surface: Allow to cool or use appropriate protection when handling.
Heavy object: Take additional care when lifting.

P550c Operation Manual
www.pearpoint.com | 7
Perform a risk assessment
Warning: Always carry out a risk assessment of the site to be inspected. This equipment is NOT
approved for use in areas where potentially explosive (or otherwise hazardous) gases, vapors, liquids
or solids may be present.
Pearpoint has taken care to provide the necessary information in this manual for the safe installation,
operation, maintenance and disposal of this equipment. However, you must carry out a risk
assessment before starting work as it may identify other safety issues.
Always follow standard safety precautions for working in hostile environments, including precautions
for manual handling, biological hazards and personal injury.
The P550c PSU has a number of ventilation slots around the casing that are designed to maximize air
circulation and reduce heat. There is a potential fire risk if the build-up of heat is prevented from
escaping. Under no circumstances are these ventilation slots to be covered or blocked.
Warning: Use the camera distance counter as an estimation only. Pearpoint recommends that you
use a sonde and Radiodetection cable locator to accurately locate positions of interest, especially
before starting construction works.

P550c Operation Manual
www.pearpoint.com | 8
Safety precautions
Electrical precautions
Warning: If the system connects to mains operated equipment, the external equipment must be
earthed in accordance with the manufacturer’s instructions. Failure to comply with this may cause the
system to become live and a lethal hazard.
Warning: System components must not be connected or disconnected when the power is on. Do not
touch any connectors while the system is live
Warning! Always remove the fuse when the controller is transported by air!
Always ensure that cabling is properly connected.
Always switch the system on and off using the controller power button and the on/off switch on the
Power Supply Unit (PSU). The PSU is integrated within the Powered Drum (see page 37) and
separate from the Manual Drum (see page 38).
Make sure that video and power cables are not entangled in the drum or reel. Cable ties are
recommended and will not impede system performance.
The P550c system requires a connection to a protective earth; if in doubt, consult a qualified
electrician. Electrical equipment is factory-tested for electrical safety. Routine inspection is
recommended (and may be required by law) to maintain this level of protection. If you are unsure,
contact your local safety authority for advice.

P550c Operation Manual
www.pearpoint.com | 9
Electrical precautions (continued)
The external connectors of the P550c Manual PSU unit and Powered Drum are required to be
properly sealed by the blanking caps provided or by using the correct leads to prevent water damage
to the units. Under no circumstances are these connectors to be left un-blanked.
Take care to ensure that video and power cables do not get entangled in the drum. Cable ties are
recommended and will not impede system performance. Always store the flexitrax P550c system in a
clean and dry environment.
If using a generator follow the manufacturer’s instructions on load connection and sequencing. In the
absence of these instructions the following guidelines should be used:
When starting the generator; ensure that all electrical loads, including the flexitrax P550c are switched
off before starting the generator. Allow the generator to stabilize before connecting any electrical loads
or switching on the flexitrax P550c.
When stopping the generator; ensure all electrical loads, including the flexitrax P550c are switched off
before stopping the generator.
Starting or stopping a generator whilst the flexitrax P550c system is connected and the main switch is in
the On position could lead to damage to the flexitrax P550c system or the generator.

P550c Operation Manual
www.pearpoint.com | 10
Electrical precautions (continued)
If using an invertor to power the system, a good quality full sine-wave model should be selected
Quasi-sine wave invertors are not recommended for use with this product.
Please observe your company, region and country’s Standard Code of Practice for surveying
underground utilities with CCTV equipment when using this equipment.
Biological precautions
Warning: Foul systems can be a source of serious biological hazards. Wear appropriate personal
protective equipment (PPE) when handling the P550c.
Always use heavy-duty industrial gloves when withdrawing a rod from a sewer.
Battery precautions
The controller contains a Li-Ion rechargeable battery. Only use charging equipment provided by
Pearpoint. The use of alternative chargers may cause a safety hazard and/or reduce the life of the
battery.
The battery is designed to protect itself against over-discharge, overcharge and short circuit between
charge terminals. Other batteries may not provide these safety circuits.
Warning: Exposing the controller’s Li-Ion battery to high temperatures (over 60°C or 140°F) may
activate safety systems and cause a permanent battery failure.

P550c Operation Manual
www.pearpoint.com | 11
Caution: Do not tamper with, or attempt to disassemble, the battery.
Caution: If battery failure is suspected, return the entire system to an authorized repair center for
investigation and repair. Local, national or IATA transport regulations may restrict the shipment of
faulty batteries. Check with your courier for restrictions and best practice guidelines. Talk to a
Pearpoint sales representative for authorized repair centers.
Caution: Waste Li-Ion batteries must be disposed of properly, use an approved recycling facility for
electronic waste.
Camera precautions
Warning: The camera will get hot with use. This is normal. To avoid risk of burns, do not touch the
camera when it is switched on or immediately after switching it off. Leave time for it to cool before
handling. Exercise care when handling the camera; consider using gloves.
Warning: The camera LEDs are very powerful. Do not look directly at the LEDs or point them at other
people.
Pushrod reel precautions
Warning: A coiled rod retains a large amount of energy when coiled and can cause injury if not
correctly handled. Only competent personnel should handle this product.

P550c Operation Manual
www.pearpoint.com | 12
Radiodetection and Pearpoint recommend that a risk assessment is undertaken before the rod is
handled, the bindings are cut or when using, loading, unloading, uncoiling or coiling rod.
Radiodetection and Pearpoint accept no liability for injury or damage to equipment incurred whilst
using, loading, unloading, uncoiling or coiling the rod.
Moving or transporting the system
Warning: The P550c, including its component parts are heavy. If available, use the wheels to assist
transport. Observe heavy-lifting safety practices when lifting any component of this system. For the
system weight and dimensions, see the specifications on page 262.
Warning! Never lower crawlers or other heavy equipment into manholes while personnel work in the
manhole.
Warning! Always remove the fuse when the controller is transported by air!
Disposal
Do not dispose of this product in municipal waste facilities. Please check local regulations for disposal
of electronic products, batteries and hazardous waste.
Pearpoint complies with the requirements of 2012/19/EU Waste Electrical and Electronic Equipment.

P550c Operation Manual
Contents
www.pearpoint.com | 13
Contents
Preface.................................................................2
1 Introduction .....................................................19
1.1 P550c features........................................20
1.2 Definitions...............................................21
1.3 Safety notices .........................................21
1.4 Training...................................................22
1.5 Updates and latest information................22
1.6 Pearpoint technical support.....................22
2 Quick Start ......................................................23
3 System overview .............................................25
3.1 Controller................................................25
3.2 Controller home screen .......................... 33
3.3 Controller battery.................................... 35
3.4 Cable drums........................................... 36
3.5 Pushrod reels......................................... 43

P550c Operation Manual
Contents
www.pearpoint.com | 14
4 System assembly............................................48
4.1 Crawler, Camera and accessories ..........48
4.2 Drums & External PSU............................68
4.3 Command module...................................69
4.4 Controller................................................72
4.5 Pushrod reels..........................................76
4.6 Cameras and accessories.......................78
4.7 Battery.................................................... 87
5 System setup.................................................. 93
5.1 Insert the fuse......................................... 93
5.2 Power on the controller........................... 94
5.3 Setup wizard: Set controller preferences
and company details ........................... 95
5.4 Calibrate the equipment.......................... 99
5.5 Status icons.......................................... 100
5.6 Configure the system settings............... 101

P550c Operation Manual
Contents
www.pearpoint.com | 15
5.7 Import a company logo..........................128
5.8 Set up a video title page........................129
6 Operating the system ....................................135
6.1 Before you begin...................................135
6.2 Confirming the system equipment.........136
6.3 Emergency stop....................................137
6.4 Crawler Deployment............................. 137
6.5 System stop.......................................... 149
6.6 Driving the crawlers.............................. 150
6.7 Camera control (lights, focus, pan, rotate,
zoom)................................................ 160

P550c Operation Manual
Contents
www.pearpoint.com | 16
6.8 Pushrod reels........................................165
6.9 Deploy pushrods...................................168
6.10 Zero the camera distance....................169
6.11 Streaming images to a nearby device .171
6.12 Record a video....................................174
6.13 Video tools.......................................... 181
6.14 Replay a video.................................... 188
6.15 Take a photo directly .......................... 190
6.16 Turn off the camera............................ 193
6.17 Retrieve the crawler............................ 194
7 Surveys......................................................... 195
7.1 Create a new survey............................. 195
7.2 Edit survey screen................................ 198

P550c Operation Manual
Contents
www.pearpoint.com | 17
7.3 Manage existing surveys.......................199
7.4 Export a survey.....................................204
7.5 Observations.........................................221
7.6 Reports................................................. 230
7.7 Video streaming ................................... 233
7.8 Menu shortcuts..................................... 235
7.9 Supported survey standards................. 236
8 WinCan PC connections............................... 239
8.1 Ethernet connection –no router............ 240
8.2 Ethernet connection –via router........... 247

P550c Operation Manual
Contents
www.pearpoint.com | 18
9 Status icons...................................................254
10 Maintenance and cleaning...........................255
10.1 Maintenance .......................................255
10.2 Cleaning the system............................258
10.3 Factory reset.......................................259
11 Software updates.........................................260
12 Specifications..............................................262
12.1 Controller specifications......................262
12.2 Drums and PSU..................................264
12.3 Crawlers..............................................265
12.4 Elevators.............................................266
12.5 Lighthead............................................267
12.6 Crawler cameras.................................267
12.7 Crawler wheels and spacers............... 268
12.8 Controller to drum/PSU link cables..... 269
12.9 Crawler-wheel-elevator configurations 270
12.10 Crawler configuration examples........ 272
12.11 Pushrod reel and rod specifications.. 273
12.12 Pushrod camera specifications......... 274
13 Open Source Software................................ 275
14 Index........................................................... 277
Contact us ....................................................... 284

P550c Operation Manual
1 Introduction
www.pearpoint.com | 19
1 Introduction
The P550c is an advanced pipeline video inspection
system that is ideal for a broad range of applications. It
allows operators to precisely identify and document
pipeline faults using digital video recording.
Rugged and weatherproofed, the system is designed
for use in harsh conditions. It is easy to transport and
deploy, enabling quick and successful inspections.
The P550c controller can drive any combination of
compatible pushrod reels and cameras. Its 12.1”
(307mm) screen displays the camera’s video feed,
stored videos and photos, and configuration settings.
You operate the controller using its built-in buttons and
keyboard.
If required, you can connect the controller to external
video equipment (input and output), to a headset with
microphone, and to an external keyboard.
Fig. 1.1: flexitrax P550c system with
Powered Drum and selected crawler
options

P550c Operation Manual
1 Introduction
www.pearpoint.com | 20
1.1 P550c features
The P550c inspection system offers the following features:
One-touch video recording to MP4 format.
One-touch still images captured to JPEG format.
Rotate the video feed while recording live video.
Survey data stored on high capacity (128GB) built-in solid state storage.
Rechargeable battery and external power supply options.
Integrated survey reporting.
Survey reports, videos and observation photos, can be exported to USB memory sticks, sent as
email attachments or uploaded to DropBox. MSCC3 through MSCC5 survey standards are
supported. Surveys can also be performed using the integrated WinCan option, subject to additional
licensing.
Modular system, fully compatible with any combination of flexitrax™ P550c/P350 drums, crawlers and
cameras and is also compatible with flexiprobe™ P540c/P340 rods, reels, cameras and accessories.
Note: References to P350, P354 and P356 systems and crawlers in this document also refer and apply
to P550, P554 and P556 systems and crawlers.
