PedalPCB Duck Box Filter Quick start guide

Copyright © 2021 - PedalPCB.com Page 1 of 5Duck Box Filter
Duck Box Filter
Revised 8/8/21
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Attack
• Decay
• Blend (Toggle switch)
CONTROLS AND FEATURES

Copyright © 2021 - PedalPCB.com Page 2 of 5
Duck Box Filter
Duck Box Filter
Parts List (Page 1 of 1)
LOCATION VALUE TYPE NOTES
R1 1K Resistor, 1/4W
R2 470K Resistor, 1/4W
R3 47K Resistor, 1/4W
R4 470K Resistor, 1/4W
R5 1M Resistor, 1/4W
R6 1K Resistor, 1/4W
R7 100K Resistor, 1/4W
R8 1K Resistor, 1/4W
R9 100K Resistor, 1/4W
R10 3M3 Resistor, 1/4W
R11 100K Resistor, 1/4W
R12 22K Resistor, 1/4W
R13 330R Resistor, 1/4W
R14 47K Resistor, 1/4W
R15 5K1 Resistor, 1/4W
R16 12K Resistor, 1/4W
R17 47K Resistor, 1/4W
R18 1M Resistor, 1/4W
R19 1M Resistor, 1/4W
R100 4K7 Resistor, 1/4W
R101 47K Resistor, 1/4W
R102 47K Resistor, 1/4W
C1 33n Film capacitor, 7.2 x 2.5mm
C2 1u Electrolytic capacitor, 5mm
C3 10n Film capacitor, 7.2 x 2.5mm
C4 10n Film capacitor, 7.2 x 2.5mm
C5 1n Film capacitor, 7.2 x 2.5mm
C6 47n Film capacitor, 7.2 x 2.5mm
C7 100p Ceramic capacitor
C8 1u Electrolytic capacitor, 5mm
C9 1u Electrolytic capacitor, 5mm
C10 2n2 Film capacitor, 7.2 x 2.5mm
C11 10u Electrolytic capacitor, 5mm
C12 47n Film capacitor, 7.2 x 2.5mm
C13 22n Film capacitor, 7.2 x 2.5mm
C100 100u Electrolytic capacitor, 5mm
C101 47u Electrolytic capacitor, 5mm
D1 DS448 Signal diode, DO-35 �Alternate part 1N4148
D100 1N5817 Schottky diode, DO-41
Q1 2N5088 BJT transistor, NPN TO-92
IC1 NJM4558 Dual op-amp, DIP8
IC2 NJM4558 Dual op-amp, DIP8
ATTACK C500K 16mm right-angle PCB mount pot
DECAY B1M 16mm right-angle PCB mount pot
SW1 SPDT Toggle switch, SPDT 2-position (ON/ON)

Copyright © 2021 - PedalPCB.com Page 3 of 5
Duck Box Filter
Duck Box Filter
Schematic Diagram

Copyright © 2021 - PedalPCB.com Page 4 of 5
Duck Box Filter
Duck Box Filter
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
T
O
G
G
L
E
S
W
I
T
C
H
L
E
D
Copyright © 2021 - PedalPCB.com Page 5 of 5
Duck Box Filter
Duck Box Filter
Drill Template
125B Enclosure
Attack
Blend
Decay
