PedalPCB Mouton Fuzz Quick start guide

Copyright © 2020 - PedalPCB.com Page 1 of 6Mouton Fuzz
Mouton Fuzz
Revised 8/12/20
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site are for identication purposes only.
Use of these names, logos, and brands does not imply endorsement.
• Tone
• Bloom
• Level
• Fuzz
• Mid (Toggle Switch)
• Thick (Toggle Switch)
CONTROLS AND FEATURES

Copyright © 2020 - PedalPCB.com Page 2 of 6Mouton Fuzz
Mouton Fuzz
Parts List (Page 1 of 2)
LOCATION VALUE TYPE NOTES
R1 1M Resistor, 1/4W
R2 1M Resistor, 1/4W
R3 10K Resistor, 1/4W
R4 10K Resistor, 1/4W
R5 1M Resistor, 1/4W
R6 100K Resistor, 1/4W
R7 1M Resistor, 1/4W
R8 220K Resistor, 1/4W
R9 62K Resistor, 1/4W
R10 100K Resistor, 1/4W
R11 100K Resistor, 1/4W
R12 1K2 Resistor, 1/4W
R13 3K3 Resistor, 1/4W
R14 2K4 Resistor, 1/4W
R15 220K Resistor, 1/4W
R16 6K8 Resistor, 1/4W
R17 1K8 Resistor, 1/4W
R18 330R Resistor, 1/4W
R19 3K3 Resistor, 1/4W
R100 22K Resistor, 1/4W
R101 22K Resistor, 1/4W
R102 4K7 Resistor, 1/4W
C1 220p Ceramic capacitor
C2 33n Film capacitor, 7.2 x 2.5mm
C3 1u Electrolytic capacitor, 5mm
C4 10n Film capacitor, 7.2 x 2.5mm
C5 10n Film capacitor, 7.2 x 2.5mm
C6 100n Film capacitor, 7.2 x 2.5mm
C7 220p Ceramic capacitor
C8 100n Film capacitor, 7.2 x 2.5mm
C9 100n Film capacitor, 7.2 x 2.5mm
C10 100n Film capacitor, 7.2 x 2.5mm
C11 15n Film capacitor, 7.2 x 2.5mm
C12 100n Film capacitor, 7.2 x 2.5mm
C13 10n Film capacitor, 7.2 x 2.5mm
C14 2u2 Electrolytic capacitor, 5mm
C100 100u Electrolytic capacitor, 5mm
C101 47u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D100 1N5817 Schottky diode, DO-41

Copyright © 2020 - PedalPCB.com Page 3 of 6Mouton Fuzz
Mouton Fuzz
Parts List (Page 2 of 2)
LOCATION VALUE TYPE NOTES
IC1 NE5532 Dual op-amp, DIP8
IC2 NE5532 Dual op-amp, DIP8
Q1 J201 N-Channel JFET
Q2 2N4401 BJT transistor, NPN TO-92
Q3 2N4401 BJT transistor, NPN TO-92
TONE C10K 16mm right-angle PCB mount pot
BLOOM B100K 16mm right-angle PCB mount pot
LEVEL A10K 16mm right-angle PCB mount pot
FUZZ A10K 16mm right-angle PCB mount pot
MID ON/OFF/ON SPDT toggle switch
THICK ON/ON SPDT toggle switch

Copyright © 2020 - PedalPCB.com Page 4 of 6Mouton Fuzz
Mouton Fuzz
Schematic Diagram

Copyright © 2020 - PedalPCB.com Page 5 of 6Mouton Fuzz
Mouton Fuzz
Wiring Diagram

Copyright © 2020 - PedalPCB.com Page 6 of 6Mouton Fuzz
Mouton Fuzz
Drill Template
125B enclosure
