PedalPCB Super Stevie Overdrive Quick start guide

Copyright © 2020 - PedalPCB.com Page 1 of 5Super Stevie Overdrive
Super Stevie Overdrive
Revised 5/18/20
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site are for identication purposes only.
Use of these names, logos, and brands does not imply endorsement.
• Volume adjusts the overall output volume
• Gain sets the amount of signal gain / drive
• Treble controls the amount of Treble
• Bass controls the amount of Bass
CONTROLS AND FEATURES

Copyright © 2020 - PedalPCB.com Page 2 of 5Super Stevie Overdrive
Super Stevie Overdrive
Parts List
LOCATION VALUE TYPE NOTES
R1 1M Resistor, 1/4W
R2 1M Resistor, 1/4W
R3 3K3 Resistor, 1/4W
R4 3K3 Resistor, 1/4W
R5 1K5 Resistor, 1/4W
R6 3K3 Resistor, 1/4W Omit for High Gain version
R7 3K3 Resistor, 1/4W
R100 100R Resistor, 1/4W
R101 10K Resistor, 1/4W
R102 8K2 Resistor, 1/4W
R103 4K7 Resistor, 1/4W
C1 33n Film capacitor, 7.2 x 2.5mm
C2 47n Film capacitor, 7.2 x 2.5mm
C3 1u Film capacitor, 7.2 x 5mm
C4 47p Ceramic capacitor
C5 47n Film capacitor, 7.2 x 2.5mm
C6 150p Ceramic capacitor
C7 1u Film capacitor, 7.2 x 5mm
C100 100n Film capacitor, 7.2 x 2.5mm
C101 47u Electrolytic capacitor, 5mm
C102 100n Film capacitor, 7.2 x 2.5mm
C103 47u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D100 1N4148 Signal diode, DO-35
IC1 NE5532 Dual op-amp, DIP8
VOLUME B10K 16mm right-angle PCB mount pot
DRIVE B500K 16mm right-angle PCB mount pot B1M for High Gain version
TREBLE B10K 16mm right-angle PCB mount pot B5K for Flat EQ version
BASS B50K 16mm right-angle PCB mount pot

Copyright © 2020 - PedalPCB.com Page 3 of 5Super Stevie Overdrive
Super Stevie Overdrive
Schematic Diagram

Copyright © 2020 - PedalPCB.com Page 4 of 5Super Stevie Overdrive
Super Stevie Overdrive
Wiring Diagram

Copyright © 2020 - PedalPCB.com Page 5 of 5Super Stevie Overdrive
Super Stevie Overdrive
Drill Template
125B enclosure
F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
