PedalPCB Pathogen Distortion Quick start guide

Copyright © 2021 - PedalPCB.com Page 1 of 6Pathogen Distortion
Pathogen Distortion
Revised 8/8/21
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Bass
• Mid
• Treble
• Volume
• Gain
• Voice (Toggle Switch)
CONTROLS AND FEATURES

Copyright © 2021 - PedalPCB.com Page 2 of 6
Pathogen Distortion
Pathogen Distortion
Parts List (Page 1 of 2)
LOCATION VALUE TYPE NOTES
R1 1M Resistor, 1/4W
R2 1K Resistor, 1/4W
R3 470K Resistor, 1/4W
R4 10K Resistor, 1/4W
R5 1K Resistor, 1/4W
R6 6K8 Resistor, 1/4W
R7 10K Resistor, 1/4W
R8 470K Resistor, 1/4W
R9 1K Resistor, 1/4W
R10 47K Resistor, 1/4W
R11 100K Resistor, 1/4W
R12 1K Resistor, 1/4W
R13 10K Resistor, 1/4W
R14 4K7 Resistor, 1/4W
R15 470K Resistor, 1/4W
R16 1K Resistor, 1/4W
R17 470K Resistor, 1/4W
R18 47K Resistor, 1/4W
R19 47K Resistor, 1/4W
R20 33K Resistor, 1/4W
R21 33K Resistor, 1/4W
R22 680K Resistor, 1/4W
R23 10K Resistor, 1/4W
R100 4K7 Resistor, 1/4W
R101 10R Resistor, 1/4W
R102 10K Resistor, 1/4W
R103 10K Resistor, 1/4W
R104 10K Resistor, 1/4W
R105 10K Resistor, 1/4W
R106 10K Resistor, 1/4W
R107 10K Resistor, 1/4W
R108 10K Resistor, 1/4W
R109 10K Resistor, 1/4W
R110 10K Resistor, 1/4W
R111 10K Resistor, 1/4W
R112 10K Resistor, 1/4W
R113 10K Resistor, 1/4W
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D5 1N4148 Signal diode, DO-35
D100 1N5817 Schottky diode, DO-41
IC1 JRC4580 Dual op-amp, DIP8
IC2 JRC4580 Dual op-amp, DIP8
IC3 JRC4580 Dual op-amp, DIP8

Copyright © 2021 - PedalPCB.com Page 3 of 6
Pathogen Distortion
Pathogen Distortion
Parts List (Page 2 of 2)
LOCATION VALUE TYPE NOTES
C1 220p Ceramic capacitor
C2 220n Film capacitor, 7.2 x 5.0mm
C3 220n Film capacitor, 7.2 x 5.0mm
C4 33n Film capacitor, 7.2 x 2.5mm
C5 560p Ceramic capacitor
C6 1u Film capacitor, 7.2 x 5.0mm
C7 220p Ceramic capacitor
C8 220n Film capacitor, 7.2 x 5.0mm
C9 1u Film capacitor, 7.2 x 5.0mm
C10 220p Ceramic capacitor
C11 1u Film capacitor, 7.2 x 2.5mm
C12 4n7 Film capacitor, 7.2 x 2.5mm
C13 47n Film capacitor, 7.2 x 2.5mm
C14 100n Film capacitor, 7.2 x 2.5mm
C15 47n Film capacitor, 7.2 x 2.5mm
C16 1u Film capacitor, 7.2 x 5.0mm
C17 47n Film capacitor, 7.2 x 2.5mm
C18 470p Ceramic capacitor
C19 1u Film capacitor, 7.2 x 5.0mm
C20 100n Film capacitor, 7.2 x 2.5mm
C21 330p Ceramic capacitor
C22 47n Film capacitor, 7.2 x 2.5mm
C23 330p Ceramic capacitor
C24 1u Film capacitor, 7.2 x 5.0mm
C25 4n7 Film capacitor, 7.2 x 2.5mm
C100 100u Electrolytic capacitor, 5mm
C101 100u Electrolytic capacitor, 5mm
C102 100n Film capacitor, 7.2 x 2.5mm
C103 100n Film capacitor, 7.2 x 2.5mm
C104 100n Film capacitor, 7.2 x 2.5mm
C105 100u Electrolytic capacitor, 5mm
C106 100u Electrolytic capacitor, 5mm
C107 100u Electrolytic capacitor, 5mm
C108 100u Electrolytic capacitor, 5mm
C109 100u Electrolytic capacitor, 5mm
C110 100u Electrolytic capacitor, 5mm
BASS B100K 16mm right-angle PCB mount pot
MID A100K 16mm right-angle PCB mount pot
TREBLE A50K 16mm right-angle PCB mount pot
VOLUME A100K 16mm right-angle PCB mount pot
GAIN A100K 16mm right-angle PCB mount pot
SW1 SPDT Toggle switch, SPDT 2-position (ON/ON)

Copyright © 2021 - PedalPCB.com Page 4 of 6
Pathogen Distortion
Pathogen Distortion
Schematic Diagram

Copyright © 2021 - PedalPCB.com Page 5 of 6
Pathogen Distortion
Pathogen Distortion
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
T
O
G
G
L
E
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
Copyright © 2021 - PedalPCB.com Page 6 of 6
Pathogen Distortion
Pathogen Distortion
Drill Template
125B Enclosure
Bass
Voice
Mid Treble
Volume Gain
