PedalPCB Curds and Whey Distortion User manual

Copyright © 2023 - PedalPCB.com Page 1 of 5Curds and Whey Distortion
Curds and Whey Distortion
Revised 8/14/23
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Level
• Mix
• Drive
• Guitar/Bass (Toggle switch)
• Contour (Toggle switch)
CONTROLS AND FEATURES

Copyright © 2023 - PedalPCB.com Page 2 of 5
Curds and Whey Distortion
Curds and Whey Distortion
Parts List (Page 1 of 1)
LOCATION VALUE TYPE NOTES
R1 1M Resistor, 1/4W
R2 2K7 Resistor, 1/4W
R3 1M Resistor, 1/4W
R4 100K Resistor, 1/4W
R5 10K Resistor, 1/4W
R6 1K Resistor, 1/4W
R7 2K Resistor, 1/4W
R8 100K Resistor, 1/4W
R9 56K Resistor, 1/4W
R10 20K Resistor, 1/4W
R11 16K Resistor, 1/4W
R12 15K Resistor, 1/4W
R13 16K Resistor, 1/4W
R14 10K Resistor, 1/4W
R15 10K Resistor, 1/4W
R16 390K Resistor, 1/4W
R17 100K Resistor, 1/4W
R100 4K7 Resistor, 1/4W * LED current limiting resistor
R101 22K Resistor, 1/4W
R102 27K Resistor, 1/4W
C1 10n Film capacitor, 7.2 x 2.5mm
C2 10p Ceramic capacitor
C3 10u Electrolytic capacitor, 5mm
C4 10u Electrolytic capacitor, 5mm
C5 47n Film capacitor, 7.2 x 2.5mm
C6 220n Film capacitor, 7.2 x 5.0mm
C7 10u Electrolytic capacitor, 5mm
C8 10p Ceramic capacitor
C9 22n Film capacitor, 7.2 x 2.5mm
C10 10u Electrolytic capacitor, 5mm
C100 10u Electrolytic capacitor, 5mm
C101 100u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D5 1N4148 Signal diode, DO-35
D6 1N4148 Signal diode, DO-35
D7 1N4148 Signal diode, DO-35
D8 1N4148 Signal diode, DO-35
D100 1N5817 Schottky diode, DO-41
IC1 TL072 Dual op-amp, DIP8
LEVEL A50K 16mm right-angle PCB mount pot
MIX B50K 16mm right-angle PCB mount pot
DRIVE C50K 16mm right-angle PCB mount pot
GTRBASS SPDT Toggle switch, SPDT 2-position (ON/ON)
CONTOUR SPDT Toggle switch, SPDT 2-position (ON/ON)

Copyright © 2022 - PedalPCB.com Page 3 of 5
Curds and Whey Distortion
Curds and Whey Distortion
Schematic Diagram

Copyright © 2023 - PedalPCB.com Page 4 of 5
Curds and Whey Distortion
Curds and Whey Distortion
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
T
O
G
G
L
E
S
W
I
T
C
H
T
O
G
G
L
E
S
W
I
T
C
H
Copyright © 2023 - PedalPCB.com Page 5 of 5
Curds and Whey Distortion
Curds and Whey Distortion
Drill Template
125B Enclosure
Level Drive
Guitar/Bass Contour
Mix
