PedalPCB Stringer Overdrive Quick start guide

Copyright © 2021 - PedalPCB.com Page 1 of 5Stringer Overdrive
Stringer Overdrive
Revised 8/7/21
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Volume
• Filter
• Gain
CONTROLS AND FEATURES

Copyright © 2021 - PedalPCB.com Page 2 of 5
Stringer Overdrive
Stringer Overdrive
Parts List (Page 1 of 1)
LOCATION VALUE TYPE NOTES
R1 2M2 Resistor, 1/4W
R2 1K Resistor, 1/4W
R3 470K Resistor, 1/4W
R4 10K Resistor, 1/4W
R5 10K Resistor, 1/4W
R6 47K Resistor, 1/4W
R7 220R Resistor, 1/4W
R8 3K9 Resistor, 1/4W
R9 1K Resistor, 1/4W
R10 1K Resistor, 1/4W
R11 1K Resistor, 1/4W
R12 470K Resistor, 1/4W
R13 10K Resistor, 1/4W
R14 100R Resistor, 1/4W
R15 10K Resistor, 1/4W
R16 10K Resistor, 1/4W
R17 10K Resistor, 1/4W
R18 4K7 Resistor, 1/4W
R19 10K Resistor, 1/4W
R20 2M2 Resistor, 1/4W
R21 4K7 Resistor, 1/4W
C1 22n Film capacitor, 7.2 x 2.5mm
C2 10u Electrolytic capacitor, 5mm
C3 51p Ceramic capacitor
C4 47n Film capacitor, 7.2 x 2.5mm
C5 220n Film capacitor, 7.2 x 5.0mm
C6 220n Film capacitor, 7.2 x 5.0mm
C7 1u Electrolytic capacitor, 5mm
C8 100n Film capacitor, 7.2 x 2.5mm
C9 10u Electrolytic capacitor, 5mm
C10 47u Electrolytic capacitor, 5mm
C11 47u Electrolytic capacitor, 5mm
C12 100n Film capacitor, 7.2 x 2.5mm
C13 47u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D4 1N5817 Schottky diode, DO-41
Q1 J201 JFET transistor, N-channel
Q2 2N3904 BJT transistor, NPN TO-92
Q3 2N3904 BJT transistor, NPN TO-92
IC1 JRC4558 Dual op-amp, DIP8
VOLUME B100K 16mm right-angle PCB mount pot
FILTER W20K 16mm right-angle PCB mount pot
GAIN A500K 16mm right-angle PCB mount pot

Copyright © 2021 - PedalPCB.com Page 3 of 5
Stringer Overdrive
Stringer Overdrive
Schematic Diagram

Copyright © 2021 - PedalPCB.com Page 4 of 5
Stringer Overdrive
Stringer Overdrive
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
Copyright © 2021 - PedalPCB.com Page 5 of 5
Stringer Overdrive
Stringer Overdrive
Drill Template
125B Enclosure
Volume
Filter
Gain
