PedalPCB Sliver Overdrive Quick start guide

Copyright © 2020 - PedalPCB.com Page 1 of 5Sliver Overdrive
Sliver Overdrive
Revised 1/4/21
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Volume
• Tone
• Drive
• Bass (Internal trimpot)
• Mid (Internal trimpot)
• Presence (Internal trimpot)
CONTROLS AND FEATURES

Copyright © 2020 - PedalPCB.com Page 2 of 5Sliver Overdrive
Sliver Overdrive
Parts List (Page 1 of 1)
LOCATION VALUE TYPE NOTES
R1 1M Resistor, 1/4W
R2 470K Resistor, 1/4W
R3 10K Resistor, 1/4W
R4 13K3 Resistor, 1/4W
R5 470R Resistor, 1/4W
R6 1K Resistor, 1/4W
R7 3K6 Resistor, 1/4W
R8 1K8 Resistor, 1/4W
R9 150K Resistor, 1/4W
R10 470K Resistor, 1/4W
R11 3K Resistor, 1/4W
R100 4K7 Resistor, 1/4W
R101 10K Resistor, 1/4W
R102 10K Resistor, 1/4W
R103 91R Resistor, 1/4W
C1 56n Film capacitor, 7.2 x 2.5mm
C2 100p Ceramic capacitor
C3 27n Film capacitor, 7.2 x 2.5mm
C4 10n Film capacitor, 7.2 x 2.5mm
C5 20n Film capacitor, 7.2 x 2.5mm
C6 10n Film capacitor, 7.2 x 2.5mm
C7 56n Film capacitor, 7.2 x 2.5mm
C8 56n Film capacitor, 7.2 x 2.5mm
C9 10n Film capacitor, 7.2 x 2.5mm
C10 4u7 Electrolytic capacitor, 5mm
C100 100u Electrolytic capacitor, 5mm
C101 47u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D100 1N5817 Schottky diode, DO-41
IC1 JRC4559D Dual op-amp, DIP8
VOLUME A100K 16mm right-angle PCB mount pot
TONE B100K 16mm right-angle PCB mount pot
DRIVE A1M 16mm right-angle PCB mount pot
BASS 50K Trim potentiometer 3362P-type
PRES 10K Trim potentiometer 3362P-type
MID 10K Trim potentiometer 3362P-type

Copyright © 2020 - PedalPCB.com Page 3 of 5Sliver Overdrive
Sliver Overdrive
Schematic Diagram

Copyright © 2020 - PedalPCB.com Page 4 of 5Sliver Overdrive
Sliver Overdrive
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
Copyright © 2020 - PedalPCB.com Page 5 of 5Sliver Overdrive
Sliver Overdrive
Drill Template
125B Enclosure
Tone
Volume Drive
