PedalPCB Canis Distortion User manual

Copyright © 2023 - PedalPCB.com Page 1 of 5Canis Distortion
Canis Distortion
Revised 12/14/23
All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site
are for identication purposes only. Use of these names, logos, and brands does not imply endorsement.
• Volume
• Drive
• Tone
• Presence (Trim pot)
• Bass (Trim pot)
CONTROLS AND FEATURES

Copyright © 2023 - PedalPCB.com Page 2 of 5
Canis Distortion
Canis Distortion
Parts List (Page 1 of 1)
LOCATION VALUE TYPE NOTES
R1 220R Resistor, 1/4W
R2 1M Resistor, 1/4W
R3 470K Resistor, 1/4W
R4 2K2 Resistor, 1/4W
R5 10K Resistor, 1/4W
R6 3K Resistor, 1/4W
R7 4K7 Resistor, 1/4W
R8 470K Resistor, 1/4W
R9 3K Resistor, 1/4W
R10 10K Resistor, 1/4W
R11 33K Resistor, 1/4W
R100 10K Resistor, 1/4W
R101 10K Resistor, 1/4W
CLR 4K7 Resistor, 1/4W * LED current limiting resistor
C1 82n Film capacitor, 7.2 x 2.5mm
C2 22n Film capacitor, 7.2 x 2.5mm
C3 100n Film capacitor, 7.2 x 2.5mm
C4 100p Ceramic capacitor
C5 10u Electrolytic capacitor, 5mm
C6 2n2 Film capacitor, 7.2 x 2.5mm
C7 22n Film capacitor, 7.2 x 2.5mm
C8 10n Film capacitor, 7.2 x 2.5mm
C9 82n Film capacitor, 7.2 x 2.5mm
C10 4u7 Electrolytic capacitor, 5mm
C100 100u Electrolytic capacitor, 5mm
C101 100n Film capacitor, 7.2 x 2.5mm
C102 47u Electrolytic capacitor, 5mm
D1 1N4148 Signal diode, DO-35
D2 1N4148 Signal diode, DO-35
D3 1N4148 Signal diode, DO-35
D4 1N4148 Signal diode, DO-35
D100 1N5817 Schottky diode, DO-41
IC1 TL072 Dual op-amp, DIP8
BASS 50K Trimmer potentiometer, 3362P type
PRES 5K Trimmer potentiometer, 3362P type
VOLUME A50K 16mm right-angle PCB mount pot
TONE B50K 16mm right-angle PCB mount pot
DRIVE A1M 16mm right-angle PCB mount pot

Copyright © 2022 - PedalPCB.com Page 3 of 5
Canis Distortion
Canis Distortion
Schematic Diagram

Copyright © 2023 - PedalPCB.com Page 4 of 5
Canis Distortion
Canis Distortion
Wiring Diagram

F
O
O
T
S
W
I
T
C
H
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
P
O
T
E
N
T
I
O
M
E
T
E
R
L
E
D
D
C
J
A
C
K
I
N
P
U
T
J
A
C
K
O
U
T
P
U
T
J
A
C
K
Copyright © 2023 - PedalPCB.com Page 5 of 5
Canis Distortion
Canis Distortion
Drill Template
125B Enclosure
Volume Drive
Tone
