Pelgrim GVW305XL User manual

Instructions for use
Dishwasher
Bedienungsanleitung
Geschirrspüler
GVW305XL

EN User instruction EN 3 - EN 30
DE Bedienungsanleitung DE 3 - DE 30
Pictograms used - Verwendete Piktogramme
Important information - Wichtige Informationen
Tip - Tipp

Contact a registered installer to fit your appliance
(see “Installation instructions”). Do not connect the
appliance to the electrical mains until the installation is
complete.
This appliance is intended to be used in household and
similar applications such as:
▷staff kitchen areas in shops, offices and other working
environments;
▷farmhouses;
▷by clients in hotels, motels and other residential type
environments;
▷bed and breakfast type environments.
For EN60335-1:
• This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be done by children without
supervision.
SAFETY INSTRUCTIONS

For IEC60335-1:
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• Packaging material could be dangerous for children!
• This appliance is for indoor household use only.
• To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
• Please unplug before cleaning and performing
maintenance on the appliance.
• Use a soft cloth moistened with mild soap, and then
use a dry cloth to wipe it again.
Earthing Instructions
• This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is equipped
with an earthing conductor plug.
• The plug must be plugged into an appropriate outlet
that is installed and earthed in a ccordance with all local
codes and ordinances.
• Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
SAFETY INSTRUCTIONS

• Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
• Do not modify the plug provided with the appliance, if it
does not fit the outlet.
• Have a proper outlet installed by a qualified electrician.
• Do not abuse, sit on, or stand on the door or dish rack
of the dishwasher.
• Do not operate your dishwasher unless all enclosure
panels are properly in place.
• Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
• Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
▷Locate sharp items so that they are not likely to
damage the door seal;
▷Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points facing
down or placed in a horizontal position.
• Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep children
away from the dishwasher when the door is open.
SAFETY INSTRUCTIONS

• Check that the detergent powder is empty after
completion of the wash cycle.
• Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent.
• For unmarked plastic items not so marked, check the
manufacturer's recommendations.
• Use only detergent and rinse agents recommended for
use in an automatic dishwasher.
• Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
• The door should not be left open, since this could
increase the risk of tripping.
• If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
• During installation, the power supply must not be
excessively or dangerously bent or flattened.
• Do not tamper with controls.
• The appliance needs to be connected to the main water
valve using new hose sets. Old sets should not be
reused.
• To save energy, the appliance will go to standby mode
automatically when there is no operation during some
time.
• When the appliance is not in use keep the door closed.
You might trip over an open door.
SAFETY INSTRUCTIONS

EN 3
Your dishwasher
Introduction 4
Using your dishwasher
Description 5
Quick start 5
Control panel 6
Water softener 8
Adding salt 9
Preparing and loading dishes 10
Function of the rinse aid and dishwasher detergent 12
Filling the rinse aid reservoir 13
Filling the detergent dispenser 14
Programming your dishwasher
Wash cycle table 15
Saving energy 16
Starting a wash cycle 16
Changing the program mid-cycle 16
Forget to add a dish? 17
Auto open 17
Maintenance
Filtering system 18
Cleaning the spray arms 19
Caring for the dishwasher 20
Cleaning the door 21
Errors
What should I do, if... 22
Technical data sheet 26
Loading the baskets according to EN60436 27
Tips for using the cutlery rack 29
Your dishwasher and the environment
Disposal 30
CONTENTS

EN 4
Introduction
You have chosen to purchase a Pelgrim dishwasher.
Optimum user comfort and easy operation were paramount during the development of this
product.
This manual describes how you can get the most out of your dishwasher. It provides you with
information on how to operate the appliance, as well as background information about how it
works. You will furthermore also find maintenance tips.
The safety instructions that are relevant during the installation are included in the installation
guide. This is intended for the installation technician.
Read this manual before using the appliance. Keep this manual somewhere safe so that
subsequent users can also benefit from the information contained within.
You can find the most recent version of the instructions for use on our website.
YOUR DISHWASHER

EN 5
USING YOUR DISHWASHER
Description
Features and appearance of baskets and cutlery baskets may vary, depending on your
model.
1. Salt container
2. Detergent dispenser
3. Rinse aid reservoir
4. Lower spray arm
5. Filtering system
6. Top nozzle
7. Cutlery rack
8. Upper spray arm
9. Cup rack
10. Upper basket
11. Lower basket
Quick start
Please read the corresponding content in this manual for more details about the operation.
Inside Outside
1. Setting the water softener/loading the salt.
2. Removing larges residues on the cutlery/dishes. Avoid pre-rinsing.
3. Loading the baskets.
4. Filling the dispenser and the rinse aid reservoir.
5. Selecting a program and running the dishwasher.
6
15
4
2 3 11
10
89
7

EN 6
USING YOUR DISHWASHER
Control panel
1 2 3 4
5 6 78
72
72
1 On/Off
1 2 3 4
5 6 78
72
72
Press this button to turn on your dishwasher, the screen lights up.
7 Start
1 2 3 4
5 6 78
72
72
• Press this button to start after selecting a programme (and
possibly a function).
• Press and hold this button for 3 seconds to cancel the current
programme and function.
2 Programs
Auto
1 2 3 4
5 6 78
72
72
An auto sensing wash for lightly, normally or heavily soiled
crockery, with or without dried-on food. A sensor detects how dirty
the water in the machine is and automatically adjusts the program
temperature and duration.
Intensive
1 2 3 4
5 6 78
72
72
For heavily soiled items, include pots and pans, with dried on food.
ECO
1 2 3 4
5 6 78
72
72
This is the standard program suitable for normally soiled loads,
such as pots, plates, glasses and lightly soiled pans. It is the
most efficient program in terms of its combined energy and water
consumption for normaly soiled loads.
Glass
1 2 3 4
5 6 78
72
72
For lightly soiled crockery and glass.
90 min
1 2 3 4
5 6 78
72
72
For normally soiled loads that need a quick wash.
Rapid
1 2 3 4
5 6 78
72
72
A shorter wash for lightly soiled loads that do not need drying.
