Peltec 600 Series User manual

315-655-8476 nwww.peltectimers.com
619
05/30/14
600 Series
WARNING: Do not bring the hot and neutral to 3 and 5
without a load. This will cause a catastrophic failure to the
timer. This is not covered by warranty.
NOTE: The voltage to the load does not need to be the
same as the voltage to power the timer.
12Volt DC
WALL ADAPTER
OUTDOOR
LIGHTING
Neutral
Hot
120VAC120VAC50/60Hz
619-1 TIMER
–
+
1 2 3 4 5
PELTEC 6191 Wired into circuit
DAILY/WEEKLY
DIGITAL TIMER
n User-programmable 24-hour, 7-day digital timer
n 15 different program periods built in: Full week, 7 individual days and
7 multiple-day combinations
n Set automatic On/Off cycles; use manual override when needed
n Real-time 24/7 accuracy to the minute
n 12-hour am/pm clock format
n Set up to 8 On/Off cycles per day
n On board LED power indicator
n LCD display shows ON and OFF status
n Memory backup with onboard battery
n 20 Amp resistive switching capability, maximum
n Choice of 6 voltages: 120VAC, 230VAC, 24VAC/VDC, 12VAC/VDC
n Clear protective cover included
n UL and CE approvals, RoHS compliant
BUTTON FUNCTIONS
FEATURES
SPECIFICATIONS
Dimensions ................ in inches 2/H x 2/W x 1/D
in mm 60H x 60W x 37D
Supply voltage ranges .... 100–130VAC, 200–250VAC,
24VAC/VDC, 12VAC/VDC
Operating accuracy ....... ±1 second/day at 20°C
Operating temperature ... -10°C to +55°C
Standards ................. UL, CE, RoHS, CUR E166259
619-1 100 –130VAC
619-2 200–250VAC
619-3 24VAC/VDC
619-4 12VAC/VDC
619-BRKT Mounting bracket
619 TIMER OPTIONS
Press ℗RESET button to reset timer before using.
CLOCK: Press/hold to set current time with Day, Hour, Min buttons.
Press to commence program execution after setting.
TIMER: Press to enter program mode, and to review up to 8 total
programmed on/off cycles.
DAY: In Clock mode, sets the current day of the week.
In Timer mode, selects the built-in program period desired.
HOUR: Sets the hour.
MIN: Sets the minutes.
MANUAL: Press to select ON/AUTO/OFF mode indicator.
RESET: Press to Cancel all settings. Recessed button next to ℗ .
Depress with pencil or ballpoint pen.
ON: Red LED indicator is lit when the internal relay is energized,
closing the Common (3) to NO (5) terminal.
TYPICAL WIRING EXAMPLE

2747 Route 20 East, Cazenovia, NY 13035
315-655-8476 nwww.peltectimers.com 05/30/14
Peltec619 DAILY/WEEKLY DIGITAL TIMER
INSTALLING AND PROGRAMMING THE TIMER
1 MO TU WE TH FR SA SU
2 MO
3 TU
4 WE
5 TH
6 FR
7 SA
8 SU
9 MO TU WE TH FR
10 SA SU
11 MO TU WE TH FR SA
12 MO TU WE
13 TH FR SA
14 MO WE FR
15 TU TH SA
PROGRAM PERIODS
Relay Terminals 3, 4, 5
power the device
controlled by the timer
Timer Terminals
1 and 2
power the timer
Output to the timed device
goes through the contacts of the
output relay, rated to a maximum of
16A resistive (8A inductive) at 250VAC,
20A resistive at 125VAC
and 16A resistive at 30VDC
RESET BUTTON To clear all settings, push in the the Reset Button
with a small pointed object. Reset button is above Min button and to
the right of ℗. Pressing buttons advance forward only.
SET THE CLOCK Press and hold the Clock button. Press the Day
button until correct day is displayed. Press the Hour button until
correct hour is displayed. AM or PM is visible in the upper left. Press
the Min button until correct minute is displayed. Release the Clock
button. Clock is set.
SET THE TIMER Plan ahead and use care when setting. To change
any or all On/Off times, timer must be reset first. "Correcting" just one
setting is not possible.
Review the list of built-in Program Periods. Select the appropriate
combination of days with common On-Off times. The timer can be set
for more than one Program Period but all On-Off times will be the
same for days within that program. Do not set conflicting times.
Examples: Acceptable combination 9) MoTuWeThFr and 10) SaSu
Unacceptable combination 9) MoTuWeThFr and 14) MoWeFr
If choosing multiple Program Periods, up to 8 total On/Off settings
are possible. If choosing a single Program Period up to 8 total On/Off
settings per day are possible.
SELECT THE PROGRAM PERIOD and SET ON-OFF TIMES
Press Timer button. 1ON appears in the window. Next press Day to
reach the desired Program Period. To select the first desired On time,
Press Hour, then Min.
To select the first desired Off time, press Timer. 1OFF appears in the
window. Next press Day to select the same Program Period.
Press Hour, then Min, to select the first Off time.
Set up to 8 On-Off cycles by repeating the process for each On time
and each Off time. Be sure to set Off time before choosing a different
Program Period.
COMPLETE AND CHECK TIMER SETTINGS
Finally, press Clock to return to current time. Check that the Indicator
line under the current time is above AUTO; if not press the Manual
button until Auto is indicated. To confirm programmed settings, press
Timer repeatedly to sequentially review all On-Off settings showing
On times, Off times and Program Periods.
OVERRIDE FUNCTIONS Two override functions are available,
effective only when timer is running in AUTO mode.
"Anti-Burglar" Random Override Example: When away, turn house
lights or radio on and off in an unpredictable pattern.
Press and hold the Day button, then press the Min button. ℗ appears
in lower left corner, indicating the timer is now in Random mode,
overriding the Program settings and turning output to On every
10 to 120 minutes. To resume set programming, press and hold the
Day button, then press the Min button. ℗ no longer shows and
programming returns.
Maintenance or Emergency Override In Auto mode, when timer is
executing Program settings, two temporary override conditions can
be employed.
1Change output status from On to Off by pressing Manual button to
move Indicator from Auto to Off. Press Manual again to return to Auto
mode. Output remains Off until timer reaches next On setpoint.
2Change output status from Off to On by pressing Manual button to
move Indicator from Auto to On. Press Manual again to return to Auto
mode. Output remains On until timer reaches next Off setpoint.
BATTERY REPLACEMENT The timer includes a standard CR2032
lithium button battery which keeps the time correct. Replace after 2
or 3 years, using a coin to remove the battery cover.
