INSTALLATION INSTRUCTIONS
MASTERTEMP®& MAX-E-THERM®HEATER
DIRECT AIR INTAKE DUCT WITH 3-INCH PVC PIPE KIT
MASTERTEMP® HEATER [KIT P/N 461031)
MASTERTEMP® 125 HEATER [KIT P/N 474845)
MAX-E-THERM® HEATER [KIT P/N 475002)
READ AND FOLLOW ALL INSTRUCTIONS - SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
• Adapter -1, Vent Cap-1, 3" PVC pipe-1 (attached to adapter from manufacturing), 3" PVC Union-1
• #8 Self-Tapping Screws (qty.5), Installation instructions.
Direct Air Intake Duct with 3-inch PVC Pipe (Indoor Installation)
For indoor heater installations where combustion air supply might be insufficient, the MasterTemp®
and Max-E-Therm®heaters are certified for a direct air intake duct using 3-inch PVC pipe. If outside
air is drawn through 3” PVC duct directly into the heater, PVC pipe can be installed in accordance
with the following requirements:
The air intake opening MUST be installed at least 1 ft. above the roof line or normal snow levels for
free air flow. The Category I or III exhaust vent termination cap must have at least 3 ft. minimum
vertical clearance from air intake duct.
See diagram on next page.
Air Intake Kit Contents
P/N 474441.C

2
NOTE
Each 90-degree elbow reduces the maximum horizontal PVC air intake duct run by 12 feet and each
45-degree elbow in the PVC air intake duct run reduces the maximum run by 6 feet. See the Table 1 for the
maximum lengths using 90-degree elbows.
WARNING!
DO NOT USE PVC PIPE FOR FLUE
EXHAUST VENT. FLUE EXHAUST
VENT TEMPERATURES CAN BE IN
EXCESS OF 400° F. FLUE EXHAUST
VENT MUST BE CATEGORY I or
CATEGORY III METAL VENT.
Combustion 3 in. PVC Pipe
Inlet Air Intake Duct Requirements
Combustion Air Intake 3 in. Pipe
(Vertical or Horizontal)
No. of 90° Elbows Maximum Length in Feet (M)
0 70 ft. (21.3 M)
1 58 ft. (17.7 M)
2 46 ft. (14.0 M)
3 34 ft. (10.4 M)
4 22 ft. ( 6.7 M)
Table 1.
Direct Air Intake Duct with 3-inch PVC Pipe (Indoor Installation)
(MasterTemp®Heater shown)

3
5. Attach and secure the adapter with pvc pipe to the air
orifice with three self-tapping screws provided (Fig. 5).
6. Install and secure air orifice back on the blower with
two top and bottom screws (Fig. 6).
7. Install and secure side panel with the PVC pipe
protruding through the side panel (Fig. 7).
8. Install and secure half of 3" PVC union on the pipe
with plastic pipe cement (Fig. 8).
9. Place and secure screened vent cap on the top of the
last vent pipe section with two screws provided.
1. Remove right side panel from the heater (Fig. 1).
2. Loose air orifice top and bottom screws on the blower
(Fig. 2 and Fig. 3).
4. Remove air orifice from the blower (Fig. 4).
When installing this kit, basic safety precautions should always be followed. Read and follow all instructions.
• Powered socket/nut driver
• 1/4” nut driver bit
• 5/16" socket and nut driver
• 3/8" nut driver
INSTALLING THE PVC INTAKE VENT KIT ON THE MASTERTEMP®HEATER
To install the PVC Intake Kit on the MaterTemp® Heater:
Required installation tools:
FIG. 1
FIG. 2
FIG. 3
FIG. 4
FIG. 5
FIG. 6
FIG. 7
FIG. 8
MasterTemp®125 Heater
MasterTemp®125 Heater
MasterTemp®125 Heater

4
5. Attach and secure the adapter with pvc pipe to the air
orifice with three self-tapping screws provided (Fig. 5).
6. Install and secure air orifice back on the blower with
two top and bottom screws (Fig 5.).
7. Reinstall the upper jacket halves with the PVC pipe
protruding through the side of the jacket (Fig. 6)
8. Install and secure half of 3" PVC union on the pipe
with plastic pipe cement (Fig. 7).
9. Place and secure screened vent cap on the top of the
last vent pipe section with two screws provided.
1. Remove the 4 bolts from the heater jackets. Remove the
upper jackets halves from the heater (Fig. 1).
2. Loose air orifice top and bottom screws on the blower
(Fig. 2 and Fig. 3).
4. Remove air orifice from the blower (Fig. 4).
When installing this kit, basic safety precautions should always be followed. Read and follow all instructions.
• Powered socket/nut driver
• 1/4” nut driver bit
• 5/16" socket and nut driver
• 3/8" nut driver
INSTALLING THE PVC INTAKE VENT KIT ON THE MAX-E-THERM®HEATER
To install the PVC Intake Kit on the Max-E-Therm® Heater:
Required installation tools:
FIG. 1
FIG. 2
FIG. 3
FIG. 4
FIG. 7
FIG. 6
FIG. 5
Blower PVC pipe
SELF-TAPPING SCREWS
