Digital Camera
Operating Manual
To ensure the best performance from
your camera, please read the Operatin
Manual before using the camera.
e_cover_kb386_7.fm Page 1 Monday, February 28, 2005 2:51 PM

Thank you for buying the PENTAX Digital Camera.
Please read this manual before using the camera in order to get the most
out of all the features and functions. Keep this manual safe, as it can be
a valuable tool in helping you to understand all the camera's capabilities.
Regarding copyrights
Images taken using the PENTAX Digital Camera that are for anything other than
personal enjoyment cannot be used without permission according to the rights as
specified in the Copyright Act. Please take care, as there are even cases where
limitations are placed on taking pictures even for personal enjoyment during
demonstrations, industrial enterprise or as items for display. Images taken with
the purpose of obtaining copyrights also cannot be used outside the scope of use
of the copyright as laid out in the Copyright Act, and care should be taken here
also.
To users of this camera
• There is a possibility that recorded data may be erased or that the camera may
not function correctly when used in surroundings such as installations
generating strong electromagnetic radiation or magnetic fields.
• The liquid crystal panel used in the LCD display is manufactured using
extremely high precision technology. Although the level of functioning pixels is
99.99% or better, you should be aware that 0.01% or fewer of the pixels may
not illuminate or may illuminate when they should not. However, this has no
effect on the recorded image.
Regarding trademarks
• PENTAX, Optio and smc PENTAX are trademarks of PENTAX Corporation.
• The SD logo is a trademark.
• All other brands or product names are trademarks or registered trademarks of
their respective owners.
This product supports PRINT Image Matching III.
PRINT Image Matching enabled digital still cameras, printers and software help
photographers to produce images more faithful to their intentions. Some functions
are not available on printers that are not PRINT Image Matching III compliant.
Copyright 2001 Seiko Epson Corporation. All Rights Reserved.
PRINT Image Matching is a trademark of Seiko Epson Corporation. The PRINT
Image Matching logo is a trademark of Seiko Epson Corporation.
Regarding PictBridge
PictBridge allows the user to connect the printer and digital camera directly, using
the unified standard for the direct printout of images. You can print images directly
from the camera through a few simple operations.
• There is a possibility that the illustrations and the display screen of the LCD
monitor in this manual are different from the actual product.
e_kb386.book Page 1 Monday, February 28, 2005 2:39 PM

1
Sufficient attention has been paid to the safety of this product but please
pay particular attention to the warnings indicated by the following
symbols during use.
Warning
• Do not attempt to take the camera apart or remodel the camera. High
voltages are present within the camera, and there is therefore a danger of
electric shocks if the camera is taken apart.
• If the inside of the camera should become exposed as a result of, for
example, the camera being dropped, please do not under any
circumstances touch such exposed portions, as there is a danger of
receiving an electric shock.
• Wrapping the strap of the camera around your neck is also dangerous.
Please take care that small children do not hang the strap around their
necks.
• To avoid the risk of it being swallowed by mistake, keep the SD Memory
Card out of the reach of small children. Seek medical attention immediately
if a memory card is accidentally swallowed.
• Use an AC adapter that is of the power and voltage specified for exclusive
use with this product. The use of an AC adapter other than that specified
exclusively for use with this product may cause fire or electric shocks.
• If the camera emits smoke or a strange smell, or in the event of any other
irregularity, stop using the camera immediately, remove the battery or
disconnect the AC adapter and contact your nearest PENTAX service
center. Continued use of the camera may result in fire or electric shock.
FOR SAFE USE OF YOUR CAMERA
Warning These symbols indicate that it is possible that the user
may experience serious difficulties if the warnings are
not heeded.
Caution These symbols indicate that it is possible that the user
may experience minor or middling difficulties or
physical difficulties if the warnings are not heeded.
About the Camera
e_kb386.book Page 1 Monday, February 28, 2005 2:39 PM

2
Caution
• Never try to disassemble or short the battery. Also, do not dispose of the
battery in fire, as it may explode.
• Do not charge any batteries other than rechargeable lithium-ion battery D-
LI8. The battery could explode or catch fire.
• Do not place your finger on the flash when it is discharging as there is a
risk of burns.
• Do not discharge the flash while it is touching your clothing as there is a
risk of discoloring.
• If any of the battery leakage should come in contact with your eyes, do not
rub them. Flush your eyes with clean water and get medical attention
immediately.
• If any of the battery leakage should come in contact with skin or clothes,
wash the affected areas thoroughly with water.
• Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
• Some portions of the camera heat up during use, so please take care, as
there is a risk of low temperature burns if such portions are held for long
periods of time.
• Should the LCD be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin or in your eyes or
mouth.
Warning
• Do not use the product at a voltage other than the specified voltage. Use
with a power source or voltage other than that designed can cause a fire
or electrical shock. The specified voltage is 100-240 V AC.
• Do not disassemble or modify the product. This can cause a fire or
electrical shock.
• If the generation of smoke or strange odor from the product or other
abnormality occurs, immediately discontinue using and consult a PENTAX
Service Center. Continuing to use the product can cause a fire or electrical
shock.
• If water should happen to get inside the product, consult a PENTAX
Service Center. Continuing to use the product can cause a fire or electrical
shock.
About the Battery Charging Stand and the AC Adapter
e_kb386.book Page 2 Monday, February 28, 2005 2:39 PM

3
• If lightning should be present during use of the battery charger or AC
adapter, unplug the power cord and discontinue use. Continuing to use the
product can cause damage to the equipment, fire or electrical shock.
• Wipe off the plug of the power cord if it should become covered with dust.
This can cause a fire.
Caution
• Do not place heavy objects on the AC plug cord, allow heavy objects to
drop onto it or allow the AC plug cord to become damaged due to
excessive bending. If the AC plug cord becomes damaged, consult a
PENTAX Service Center.
• Do not short or touch the output terminals of the product while it is still
plugged in.
• Remove the battery and unplug the AC plug cord when not using the
battery charging stand.
• Do not plug in the AC plug cord with wet hands. This can cause an
electrical shock.
• Do not subject the product to strong impacts or allow it to drop onto a hard
surface. This can cause a malfunction.
• To reduce the risk of hazards, use only CSA/UL Certified power supply
cord set, cord is Type SPT-2 or heavier, minimum NO.18 AWG copper,
one end with a molded-on male attachment plug cap (with a specified
NEMA configuration), and the other is provided with a molded-on female
connector body (with a specified IEC nonindustrial type configuration) or
the equivalent.
• Do not use the battery charging stand to charge batteries other than the
ones specified. This can cause overheating or malfunctions.
e_kb386.book Page 3 Monday, February 28, 2005 2:39 PM

4
• Take the international warranty card with you when you travel abroad.
Also take the Worldwide Service Network that is included in the package.
This will be useful if you experience problems abroad.
• When the camera has not been used for a long time, confirm that it is still
working properly, particularly prior to taking important pictures (such as at
a wedding or during travelling). Contents of a recording such as images
and sounds cannot be guaranteed if recording, playback or data transfer
from your camera to a computer, etc. is not possible due to a malfunction
of your camera or recording medium (SD Memory Card), etc.
• The lens on this camera is not exchangeable. The lens is not removable.
• Do not clean the product with organic solvents such as thinner, alcohol or
benzene.
• Places of high temperature and humidity should be avoided. Particular
care should be taken regarding vehicles, which can become very hot
inside.
• Storing the camera where pesticides and chemicals are handled should be
avoided. Remove from case and store in a well-ventilated place to prevent
the camera from becoming moldy during storage.
• Do not use the camera where it may come in contact with rain, water or any
other liquid, because the camera is not weather, water, or liquid resistant.
• Ensure that the camera is not subjected to substantial vibrations, shocks
or pressure. Place the camera on a cushion for protection when the
camera is subjected to the vibrations of a motorbike, car, or ship, etc.
• The temperature range in which the camera can be used is 0°C to 40°C
(32°F to 104°F).
• The liquid crystal display will become black at high temperature but will
return to normal when normal temperatures are returned to.
• The response speed of the liquid crystal display becomes slow at low
temperatures. This is due to the properties of the liquid crystal and is not
a fault.
• Periodic checks are recommended every 1 to 2 years in order to maintain
high-performance.
Care to be Taken During Handling
e_kb386.book Page 4 Monday, February 28, 2005 2:39 PM

5
• If the camera is subjected to rapid temperature changes, condensation
may form on the inside and outside of the camera.
Therefore put the camera in a bag or plastic bag, and take the camera out
when the difference in temperature has subsided.
• Avoid contact with garbage, dirt, sand, dust, water, toxic gases, salt, etc.
as this may cause damage to the camera. If rain or drops of water get onto
the camera, please wipe dry.
• Refer to “Precautions When Using an SD Memory Card” (p.23) regarding
the SD Memory Card.
• The AC plug cord supplied with the camera is for exclusive use with the
Battery charging stand D-BC25. Do not use it with any other equipment.
• Please do not press forcefully on the LCD monitor. This could cause
breakage or malfunction.
• Be careful not to sit down with the camera in your back pocket as this may
damage the exterior of the camera or the LCD monitor.
• When using a tripod with the camera, be careful not to overtighten
the screw in the tripod socket on the camera.
LED Safety Standard
This device is a digital still camera that conforms to the safety standard
(IEC60825-1) for a Class 1 LED product.
e_kb386.book Page 5 Monday, February 28, 2005 2:39 PM

6
FOR SAFE USE OF YOUR CAMERA .................................................... 1
Care to be Taken During Handling.......................................................... 4
Contents of the Operating Manual .......................................................... 9
Checking the Contents of the Package ................................................. 10
Names of Parts...................................................................................... 11
Names of Operating Parts..................................................................... 12
Getting Started 13
Attaching the Strap .................................................................................... 13
Powering the Camera ................................................................................ 14
Installing the Battery.............................................................................. 14
Removing the Battery............................................................................ 14
Charging the Battery ............................................................................. 15
Charging the Battery Abroad................................................................. 18
Using the AC Adapter (optional)............................................................ 20
Installing the SD Memory Card ................................................................. 22
Image Size and Quality ......................................................................... 24
Initial Settings (Setting the Display Language and
the Date and Time) ..................................................................................... 26
Setting the Display Language ............................................................... 26
Setting the Date and Time..................................................................... 27
Quick Start 29
Taking Still Pictures................................................................................... 29
Playing Back Still Pictures ........................................................................ 31
Playing Back an Image.......................................................................... 31
Playing Back the Previous or Next Image ............................................. 31
Rotating the Displayed Image ............................................................... 32
Common Operations 33
Turning the Camera On and Off................................................................ 33
Turning the Camera On in Playback Mode ........................................... 34
Turning the Camera On in Voice Recording Mode................................ 34
Using the Button Functions ...................................................................... 35
Capture Mode........................................................................................ 35
Playback Mode...................................................................................... 36
Voice Recording Mode .......................................................................... 38
Setting the Menus ...................................................................................... 39
How to Set the Menus ........................................................................... 39
Menu List............................................................................................... 42
Operating the Mode Palette....................................................................... 44
How to operate the Mode Palette.......................................................... 44
Taking Pictures 47
Taking Pictures .......................................................................................... 47
Changing the Mode ............................................................................... 47
Selecting the Capture Mode.................................................................. 47
Displaying Shooting Information in Capture Mode ................................ 47
Contents
e_kb386.book Page 6 Monday, February 28, 2005 2:39 PM

7
Taking Pictures by the Simplest Procedure (Green Mode) ................... 50
Setting the Functions (Program Mode).................................................. 51
Selecting the Picture Mode According to the Shooting Scene (Picture
Mode) ................................................................................................ 52
Taking Pictures of Dark Scenes
(Night Scene Mode) .......................................................................... 54
Taking Movies (Movie Mode) ................................................................ 55
Taking Panorama Pictures
(Panorama Assist Mode)................................................................... 57
Taking Pictures with Digital Filters
(Special Effect Mode) ........................................................................ 59
Using Preset Function Settings (User Mode) ........................................ 62
Using the Self-Timer.............................................................................. 63
Using the Remote Control Unit (optional).............................................. 64
Continuous Shooting
(Continuous Shooting Mode)............................................................. 66
Using the Zoom to Change the Subject Size ........................................ 67
Taking Time-lapse Movies..................................................................... 69
Setting the Shooting Functions................................................................ 71
Selecting the Focus Mode..................................................................... 71
Selecting the Flash Mode...................................................................... 74
Selecting the Recorded Pixels .............................................................. 75
Selecting the Quality Level.................................................................... 77
Adjusting the White Balance ................................................................. 79
Changing the Focusing Area................................................................. 81
Setting the Light Metering Range to Determine the Exposure .............. 82
Setting the Sensitivity ............................................................................ 84
Setting the Exposure (EV Compensation)............................................. 85
Setting the Auxiliary AF Light ................................................................ 86
Setting the Instant Review Time............................................................ 87
Setting the Color Mode (Color Mode).................................................... 88
Registering Frequently Used Functions
(Fn Setting)........................................................................................ 89
Setting the QUICK Button ..................................................................... 91
Setting the Image Sharpness ................................................................ 92
Setting the Color Saturation .................................................................. 93
Setting the Image Contrast.................................................................... 94
Saving the Settings.................................................................................... 95
Saving the Menu Items (Memory) ......................................................... 95
Registering Functions in User Mode ..................................................... 96
Returning the Shooting Functions to the Default Settings .................... 98
Recording and Playback 99
Recording Sound (Voice Recording Mode) ............................................. 99
Playing Back Sound................................................................................. 100
Adding a Voice Memo.............................................................................. 101
Recording a voice memo..................................................................... 101
Playing Back a Voice Memo................................................................ 102
Playback/Deleting/Editing 103
Playing Back Images ............................................................................... 103
Playing Back Still Pictures................................................................... 103
e_kb386.book Page 7 Monday, February 28, 2005 2:39 PM

8
Zoom Display ...................................................................................... 103
Playing Back Movies ........................................................................... 105
Displaying Shooting Information in Playback Mode ............................ 107
Nine-Image Display ............................................................................. 108
Slideshow ............................................................................................ 109
Deleting Images, Movies and Sounds.................................................... 110
Deleting a Single Image, Movie or Sound ........................................... 110
Deleting All Images ............................................................................. 112
Protecting Images, Movies and Sounds from Deletion (Protect)......... 113
Viewing Images on a TV .......................................................................... 115
Playing Back an Image Using the Remote Control Unit (optional)...... 116
Setting the Printing Service (DPOF)....................................................... 117
Printing Single Images ........................................................................ 117
Printing All Images .............................................................................. 119
Direct Printing Using PictBridge............................................................. 120
Connecting the Camera to the Printer................................................. 120
Printing Single Images ........................................................................ 121
Printing All Images .............................................................................. 122
Printing Using the DPOF Settings ....................................................... 123
Disconnecting the Camera from the Printer ........................................ 123
Editing Images.......................................................................................... 124
Changing the Image Size and Quality................................................. 124
Trimming Images................................................................................. 126
Editing Pictures with Color Filters........................................................ 128
Editing Pictures with Brightness Filter ................................................. 129
Editing Movies ..................................................................................... 131
Copying Files............................................................................................ 134
Settings 136
Camera Settings....................................................................................... 136
Setting Up the Start-up Screen ........................................................... 136
Formatting an SD Memory Card or the Built-in Memory ..................... 138
Changing the Sound Settings.............................................................. 139
Changing the Date and Time .............................................................. 141
Setting the World Time........................................................................ 143
Changing the Display Language ......................................................... 145
Changing the USB Connection Mode ................................................. 146
Changing the Video Output Format..................................................... 146
Adjusting the Brightness of the LCD Monitor....................................... 147
Sleep Timeout ..................................................................................... 148
Setting Auto Power Off........................................................................ 149
Setting the Guide Display.................................................................... 150
Resetting to Default Settings............................................................... 151
Appendix 152
List of City................................................................................................. 152
Optional Accessories .............................................................................. 153
Messages .................................................................................................. 154
Troubleshooting....................................................................................... 156
Main Specifications.................................................................................. 158
WARRANTY POLICY................................................................................ 161
Index.......................................................................................................... 165
e_kb386.book Page 8 Monday, February 28, 2005 2:39 PM

9
This operating manual contains the following chapters.
1 Getting Started –––––––––––––––––––––––––––––––––––––––––
This chapter explains what you need to do after purchasing the camera before you start
taking pictures. Be sure to read it and follow the instructions.
2 Quick Start ––––––––––––––––––––––––––––––––––––––––––––
This chapter explains the simplest way to take pictures and play back images. Use it if
you want to start taking pictures straightaway.
3 Common Operations ––––––––––––––––––––––––––––––––––––
This chapter explains common operations such as the functions of the buttons and how
to use the menus. For more details, refer to the respective “Taking Pictures”,
“Recording and Playback”, “Playback/Deleting/Editing” and “Settings” chapters.
4 Taking Pictures ––––––––––––––––––––––––––––––––––––––––
This chapter explains the various way of capturing images and how to set the relevant
functions, including how to use the Capture Mode screen to select the capture mode
best suited to the situation.
5 Recording and Playback –––––––––––––––––––––––––––––––––
This chapter explains how to record sound only or add a voice memo to an image, and
how to play back voice memos.
6 Playback/Deleting/Editing ––––––––––––––––––––––––––––––––
This chapter explains how to play back images on the camera or on a TV, how to
delete, resize and trim images, and how to print images directly to the printer.
7 Settings –––––––––––––––––––––––––––––––––––––––––––––––
This chapter explains how to set the camera-related functions.
8 Appendix––––––––––––––––––––––––––––––––––––––––––––––
This tells you about the messages displayed on the LCD monitor and what to do in the
event of trouble.
The meanings of the symbols used in this operating manual are explained below.
Contents of the Operating Manual
1indicates the reference page number for an explanation of the
related operation.
indicates information that is useful to know.
indicates precautions to be taken when operating the camera.
1
3
2
4
5
6
7
8
e_kb386.book Page 9 Monday, February 28, 2005 2:39 PM

10
Items marked with an asterisk () are also available as optional accessories.
For other optional accessories, refer to “Optional Accessories” (p.153).
Type of AC plug cord
D-CO2A Australia/D-CO2E Europe/D-CO2H Hong Kong, United Kingdom/
D-CO2J Japan/D-CO2K Korea/D-CO2U North America, Canada
Checking the Contents of the Package
Camera
Optio S5n
Strap
O-ST20 ()
Software (CD-ROM)
S-SW29
AV cable
I-AVC7 ()
USB cable
I-USB17 ()
Rechargeable
lithium-ion battery
D-LI8 ()
Battery charging stand
D-BC25 ()
AC plug cord Operating Manual
(this manual)
Digital Camera
Operating Manual
To ensure the best performance from
your camera, please read the Operatin
Manual before using the camera.
e_kb386.book Page 10 Monday, February 28, 2005 2:39 PM

11
Front
Back
Names of Parts
Power indicator
Power switch
Flash
Self-timer lamp/
Auxiliary AF light
Remote control receiver
USB/AV terminal
Lens
Strap lug
DC input terminal
Terminal covers
Shutter release button
Microphone
Battery/card cover
Focus status lamp (green)
LCD monitor
Tripod socket
Flash status lamp (red)
Battery charging stand terminal
Speaker
e_kb386.book Page 11 Monday, February 28, 2005 2:39 PM

12
Guide Indications
A guide to available button operations appears on the LCD monitor
during operation.
The buttons are indicated as shown below.
Names of Operating Parts
Four-way controller (2)2Zoom button
Four-way controller (3)3for digital zoom y
Four-way controller (4)4for trimming
Four-way controller (5)5QUICK/ibutton
MENU button for operating as the
QUICK button
Shutter release button for deleting an
OK button
Zoom button
OK/Display button
MENU button
Four-way controller
Power switch
QPlayback button
QUICK/ibutton
MODE button
MENU
SHUTTER
OK
e_kb386.book Page 12 Monday, February 28, 2005 2:39 PM

13
1
Getting Started
Getting Started
Attaching the Strap
Pass the narrow end of the strap through the strap lug and pass the other end
through the loop.
e_kb386.book Page 13 Monday, February 28, 2005 2:39 PM

14
1
Getting Started
Powering the Camera
Install the battery provided with the camera.
1Open the battery/card cover.
Slide the battery/card cover in the direction indicated by the arrow and flip
the cover open .
2 Insert the battery with the 2 symbol facing toward the LCD
monitor while using the side of the battery to press the battery
lock lever in the direction indicated by the arrow.
3Close the battery/card cover.
1Release the battery by using your finger to press the battery
lock lever in the same direction as when you inserted the
battery.
Pull the battery out.
Installing the Battery
Removing the Battery
If you intend to use the camera continuously for a long period, use of the
AC adapter D-AC8 (optional) is recommended. (1p.21)
• Insert the battery correctly. If the battery is incorrectly oriented, it may
cause a malfunction.
• Do not remove the battery when the camera is turned on.
• If you do not intend to use the camera for a long time, remove the battery.
• If the camera is left without the battery for a long time, the date will be
reset.
Battery lock
lever
Battery/card cover
Battery
3
2
1
1
2
1
2
e_kb386.book Page 14 Monday, February 28, 2005 2:39 PM

15
Getting Started
1
Use the battery charging stand D-BC25 supplied with the camera to charge the
battery before using the camera for the first time or when the [Battery depleted]
message appears. You can charge the battery without removing it from the
camera.
1Connect the AC plug cord to the battery charging stand
D-BC25.
2Plug the AC plug cord into the power outlet.
3Turn the camera off.
4Place the camera in the battery charging stand.
Position the camera so that the lens rests in the depression in the case. The
CAMERA charging indicator on the stand lights red while the battery is being
charged and goes out when charging is completed.
5Remove the camera from the battery charging stand when
charging is completed.
Charging the Battery
Charging the Battery in the Camera
To power outlet
Battery charging stand D-BC25
AC plug cord
1
2
CAMERA charging indicator
4
e_kb386.book Page 15 Monday, February 28, 2005 2:39 PM

16
Getting Started
1
You can remove the battery from the camera and charge it.
3Place the battery in the battery charging stand so that the
PENTAX name is visible.
The BATTERY charging indicator on the stand lights red while the battery is
being charged and goes out when charging is completed.
4Remove the battery from the battery charging stand when
charging is completed.
Charging the Battery by Itself
• You can put the camera and the battery together on the battery charging
stand to charge the battery inside the camera and a spare battery.
• The time required for full charge is about 100 minutes.
The appropriate ambient temperature range for charging the battery is
0°C – 40°C (32°F to 104°F).
• The charging time may vary depending on the ambient temperature and
charging conditions.
• When the battery reaches the end of its service life, the time that the
camera can be operated becomes shorter even when the battery is fully
charged. In this event, replace the battery.
• You can also remove the battery from the camera and charge it using the
optional battery charger D-BC8.
3
BATTERY charging
indicator
e_kb386.book Page 16 Monday, February 28, 2005 2:39 PM

17
Getting Started
1
• Approximate Operating Time (when the D-LI8 battery is fully charged)
Number of recordable images: Approx. 155 (at 23°C with the LCD monitor
on and the flash used for 50% of shots)
Playback time: Approx. 130 min.
Movie recording time: Approx. 65 min.
Sound recording time: Approx. 300 min.
• The number of recordable images are based on CIPA standard measurement
and may vary depending on capture mode and shooting conditions.
• Battery Level Indicator
You can check the battery level by the symbol on the LCD monitor.
• Always charge the battery before using the camera for the first time or
when the battery has not been used for a long time.
• Do not use the battery charging stand D-BC25 to charge batteries other
than D-LI8 rechargeable lithium-ion batteries, as the charging stand may
overheat or be damaged as a result.
• If the battery is inserted correctly but the charging indicator blinks, the
battery may be faulty. Replace with a new battery.
• In general, battery performance temporarily deteriorates as the
temperature decreases. When using the camera in a cold environment,
keep it warm by putting it in your pocket or inside your coat. Battery
performance that has deteriorated due to low temperature will be restored
when the battery is returned to room temperature.
• Be sure to take a spare battery with you when traveling abroad or to a
cold region, or if you intend to take a lot of pictures.
(lit green) : Adequate power remains.
p
(lit green) : Battery is running low.
p
(lit yellow) : Battery is running very low.
p
(lit red) : Battery is exhausted.
p
[Battery depleted] : The camera will turn off after the message appears.
e_kb386.book Page 17 Monday, February 28, 2005 2:39 PM

18
Getting Started
1
• Recycling Batteries
The battery charging stand supplied with the camera is designed to switch
automatically to the voltage (100-240V) and frequency (50Hz, 60Hz) of the
electricity supply in the country or region where used.
However, electrical socket shapes differ depending on the country or region.
Before traveling abroad, you are advised to check the socket shape in your
destination (see “Main Socket Types in the Major Countries and Regions of the
World” (p.20)) and take an appropriately shaped off-the-shelf adapter plug with
you. (Electrical socket shapes may vary depending on the region of the country.
Check the socket shape used in the region.)
The socket shape does not affect the charging method.
This symbol indicates that the battery is recyclable. Cover the
terminals with insulating tape and take the battery to a store
displaying this symbol.
Charging the Battery Abroad
• Use of an off-the-shelf transformer may lead to defective operation.
• Unplug the adapter plug from the power outlet when the battery charging
stand is not in use.
Type A B BF C S
Shape Adapter
plug
—
Adapter plug
e_kb386.book Page 18 Monday, February 28, 2005 2:39 PM
