Pentium P3 PowerStation User manual

CTC Parker Automation A3-06229-100
Pentium Third Serial Port Installation
Introduction
This document explains how to add a third serial port to P3, P4, or P5
PowerStations that have a Pentium CPU card. It includes instructions for
opening the PowerStation, reconfiguring the System Support card, estab-
lishing communication for COM2 on the CPU card, reinstalling the
System Support card, installing the third COM port, closing the PowerSta-
tion, enabling COM3 during startup, reconfiguring the PowerStation’s
touchscreen, and having Windows®detect the new serial port.
Warning You must observe normal precautions against electrostatic
discharge to prevent damage to the PowerStation.
Electrostatic Discharge Precautions
Modern integrated electronic devices, especially CPUs and memory chips,
areextremelysensitivetoelectrostaticdischarges(ESD)andfields.Before
you disassemble the PowerStation, be sure to follow these simple precau-
tions to protect you and the PowerStation from harm resulting from ESD.
1. To avoid electric shock, always disconnect power from the PowerSta-
tion before you remove the back cover. Do not touch any components
of the CPU card or other cards while the PowerStation is on.
2. Disconnect power before making any hardware configuration chang-
es. The sudden rush of power as you connect a jumper or install a card
may damage sensitive electronic components.
3. Only handle internal components in an ESD-safe location, using ap-
propriate grounding methods.
4. Always ground yourself to remove any static charge before you touch
the CPU card.
5. Be particularly careful not to touch the chip connectors.
6. Keep any card in its anti-static packaging when it is not installed in the
PowerStation and place it on a static dissipative mat when you are
working on it.
7. Wear a grounding wrist strap for continuous protection.

Pentium Third Serial Port Installation
2
CTCParkerAutomation
Before You Start
Be sure you have the following tools:
• Keyboard (If you have a P3 or P4 PowerStation, you will also
need a Y cable.)
• Flat-head and Phillips screwdrivers
• Needlenose pliers
8. Third COM Port Upgrade Kit (including the serial tang cable
assembly pictured below)
Open the PowerStation
In order to add a third serial port to the PowerStation, you must
open the unit.
Warning For safety reasons, the PowerStation should be opened
only by qualified service personnel.
To open the PowerStation, complete the following steps:
1. Turn off the PowerStation.
2. Disconnect the unit from the power source.
3. Remove the PowerStation from its enclosure (if previously in-
stalled).
Consult your PowerStation User Guide if you need help with
this removal.

Pentium Third Serial Port Installation
CTC Parker Automation
3
4. Remove the back cover from the unit by removing the screws
that secure the cover.
5. Remove the Compact Flash (CF) card if applicable.
Important Always make sure power to the PowerStation is turned off
when removing the CF card.
Reconfigure the System Support Card
The first step in adding a third serial port to the PowerStation is to
reconfigure the System Support card. The following sections
explain how to do this, including instructions for disconnecting
cables from the System Support card, and removing and reconfig-
uring the card.
Disconnect the Cables
Before you can remove and reconfigure the System Support card,
you must first disconnect some cablesthat are attached to the card.
Use the illustration below to find the cables and other components
mentioned in the following steps.
Video cable
Touchscreen
cable (P5)
Backlight
cable (P6)
Serial cable
Wide ribbon
cable

Pentium Third Serial Port Installation
4
CTCParkerAutomation
To disconnect the cables, complete the following steps:
1. Press out the locking ears to disconnect the video and wide
ribbon cables.
The video cable connects at the top left corner of the card. The
wideribboncableconnectsvery closetothe othervideocable.
2. Lift thelocking ears to disconnect the serialcable from the top
center of the System Support card.
3. Disconnect the backlightcable (P6)by depressing thelatch on
top of the connection and sliding the connector out.
4. Disconnect the touchscreen cable (P5) by depressing the latch
on top of the connection and sliding the connector out.
Remove the System Support Card
Once you have disconnected the cables from the System Support
card, you can remove the card. Use the illustration below to find
the components mentioned in the following steps.
To remove the System Support card, complete the following
steps:
1. Remove the tang screw from the System Support card tang.
Tang screw System Support card

Pentium Third Serial Port Installation
CTC Parker Automation
5
2. Carefully pull out the System Support card and lay it to the
side.
Important Be careful to observe ESD guidelines when handling the
System Support card.
Reconfigure the System Support Card
After you have removed the System Support card from the Power-
Station, you are ready to reconfigure the card.
To reconfigure the System Support card, complete the follow-
ing steps:
1. On the System Support card, findthe IRQ jumpers JP7and the
jumpers JP8, JP9, and JP11, as shown below.
IRQs JP7
JP11 JP9
JP8

Pentium Third Serial Port Installation
6
CTCParkerAutomation
2. Move the COM jumper at IRQ 3 to IRQ 11 and the TOUCH
jumper at IRQ 11 to IRQ 9, as shown below.
3. Change jumper JP8 according to the RS setting you need.
IRQs JP7
(default)
3457910111215
COM
zzzzzzzzz
zzzzzzzzz
TOUCH
zzzzzzzzz
IRQs JP7
(
new
)
3457910111215
COM
zzzzzzzzz
zzzzzzzzz
TOUCH
zzzzzzzzz
JP8
(
RS232
)
3457910
232
zzzzzz
422
zzzzzz
485
zzzzzz
JP8
(
RS422
)
3457910
232
zzzzzz
422
zzzzzz
485
zzzzzz
JP8
(
RS485
)
3457910
232
zzzzzz
422
zzzzzz
485
zzzzzz
232
422/485
422/485

Pentium Third Serial Port Installation
CTC Parker Automation
7
4. Change jumper JP9-A from Off To On, and jumper JP9-B
from On To Off.
Making these changes sets the System Support card to COM3.
5. Change jumper JP11-B from Off to On.
Making this change sets the touchscreen to COM4.
Establish Communication for COM2 on the
CPU Card
The next step in adding a third serial port to the PowerStation is to
establish communication for COM2 on the CPU card. To do this,
you may need to change a jumper setting (if you need to change
the interface to RS422 or RS485 communication). Then you will
connect the 9-pin COM2 cable to the CPU card.
Default New
(A-Off)
2F8h (A-On) 3E8h
AB AB
zzzz
z z z z
 
Default New
(B-On)
2E8h
AB AB
zz z z
z z z z


Pentium Third Serial Port Installation
8
CTCParkerAutomation
Change Jumper Settings (if required)
Perform this step only if you need to change the interface to
RS422 or RS485 communication.
Important You do not need to remove the CPU card from the back-
plane to complete this step.
To change jumper settings, complete the following steps:
1. Gentlylaytheunit facedowntoenableeasy accesstothe CPU
card.
2. Use the needlenose pliers to set jumper JP1.
Use the following cut-away diagrams to determine the exact
locations and settings for this jumper.
RS232 Configuration (Default)

Pentium Third Serial Port Installation
CTC Parker Automation
9
RS422 Configuration
RS485 Configuration

Pentium Third Serial Port Installation
10
CTCParkerAutomation
Connect the 9-pin COM2 Cable to the CPU
Connectthe 9-pin ribbon cable, attached to the ventedtang, to one
of the COM2 connectors on the CPU depending on the communi-
cationprotocoldesiredforCOM2.ConnecttheCOM2cableto the
connector closest tothe exterior tangfor RS-232communications.
For RS-422 or RS-485 communications, connect the COM2 cable
to the connector farthest from the tang. Refer to the illustration
below for clarification.
Important Be sure that pin 1 is closest to the riser card, toward the
bottom of the PowerStation, or the connection will not
function properly.
RS-232
connector
RS-422/485
connector
JP1 set to RS-232
Red stripe
indicates pin 1

Pentium Third Serial Port Installation
CTC Parker Automation
11
Reinstall the System Support Card
After you have reconfigured the System Support card and estab-
lished communication for COM2 on the CPU card, reinstall the
System Support card in the PowerStation.
To reinstall the System Support card, complete the following
steps:
1. Slide the System Support card back into its slot in the Power-
Station.
2. Reconnectthe touchscreen and backlight cables to the System
Support card, as shown in the illustration below.
3. Reconnect the video cable and wide ribbon cable to the Sys-
tem Support card, as shown in the illustration below.
4. Attach the card to the PowerStation with the tang screw.
Video cable
Touchscreen
cable (P5)
Backlight
cable (P6)
Serial cable
Wide ribbon
cable

Pentium Third Serial Port Installation
12
CTCParkerAutomation
Install the Third COM Port (COM3)
After you have reinstalled the reconfigured System Support card,
you are ready to install the third COM port (COM3) on your
PowerStation.
To install the third COM port, complete the following steps:
1. Insert the new serial tang (from the Third COM Port Upgrade
Kit) into the next available slot, as shown in the illustration be-
low.
Note You may need to remove a blank cover if an insertion slot
is not available for the new serial tang.
2. Attach the 9-pin ribbon cable from the new serial tang to the
System Support card, as shown in the preceding illustration.
Close the PowerStation
After you have established COM2 on the CPU card and installed
the reconfigured System Support card and the third COM port,
close the PowerStation.
In order to close the PowerStation, complete the following
steps:
1. If you have a CF card, insert it into the PowerStation’s flash
card slot.
Important Make sure that the PowerStation is turned off when you
insert the CF card.
New serial tang
9-pin ribbon
cable
System Support
card

Pentium Third Serial Port Installation
CTC Parker Automation
13
2. Replace the back cover on the PowerStation and fasten the
screws that you removed in step 4 of Open the PowerStation
on page 3.
3. Reconnect the PowerStation to the power source.
Enable COM2 During System Startup
Before the PowerStation can use the new COM2 port, you must
enable the port.
ToenableCOM2 during startup,completethefollowingsteps:
1. Turn the PowerStation on.
2. While the system is starting up, press the Delete key during
the memory test to enter the CMOS setup utility.
3. From the CMOS setup utility main menu, select ‘PNP/PCI
Configuration’; then press Enter.
4. Press the arrow down key to highlight ‘IRQ9 assigned to’.
5. Press the Page Up key to select ‘Legacy ISA’.
6. Perform steps 4 and 5 for IRQ11.
7. Press Esc to save and return to the main menu.
8. From the CMOS setup utility main menu, select ‘Integrated
Peripherals’; then press Enter.
9. Press the arrow up orarrow down key to highlight‘Serial Port
2’.
10. Press the Page Up key to select ‘2F8/IRQ3’.
11. Press Esc to save and return to the main menu.
12. Highlight ‘Save & Exit Setup’; then press Enter.
13. Press Y at the ‘Save to CMOS and Exit’ prompt; then press
Enter.

Pentium Third Serial Port Installation
14
CTCParkerAutomation
Reconfigure the Touchscreen
The final step in adding a third serial port to your PowerStation is
to reconfigure then calibrate the touchscreen. You must do this
because the COM port for the touchscreen has now changed from
COM3 to COM4. You can calibrate the touchscreen in MS-DOS
mode by running the touchscreen configuration utility from the
MachineShop Shell. If you are running Windows on your Power-
Station, you can reconfigure the touchscreen by running the
UPDD program in Windows. If you use both MS-DOS and
Windows operating systems, you must reconfigure the touch-
screen in both DOS and Windows. Instructions for both proce-
dures follow.
Reconfiguring the Touchscreen under
MS-DOS
To reconfigure the touchscreen, complete the following steps:
1. Reboot the PowerStation, and when “Starting MS-DOS...”ap-
pears, press the F5 key on your keyboard.
2. At the DOS prompt, type edit AUTOEXEC.BAT.
3. In the AUTOEXEC.BAT file, change the Address and/or IRQ
setting, and save the file.
Note The following segment of the AUTOEXEC.BAT file
shows the new values for IRQ and Address.
4. Reboot the PowerStation.
Important You must restart your system for the changes to take effect.
The third serial port to your PowerStation has been successfully
installed. You can now use this port to communicate with external
devices.
PROMPT $p$g
SET TEMP=C:\DOS
SET TOUCH_ADDR=2E8
SET TOUCH_IRQ=9
PATH C:\;C:\DOS;C:\CTC

Pentium Third Serial Port Installation
CTC Parker Automation
15
Reconfiguring the Touchscreen under Win-
dows
If you run Microsoft Windows 95, 98, or NT on your PowerSta-
tion, you must configure the touchscreen under Windows.
To reconfigure the touchscreen under Windows, complete the
following steps:
1. On the Windows taskbar, click Start; then click Programs,
then click UPDD, and then select Settings.
The Pointer Device Properties dialog will appear.
2. Select the Hardware tab.
3. In the Port drop down box, select COM4.
4. Click the Apply button.
Several messages will appear as the system captures the
properAddressandIRQassignedtoCOM4. Iftheinstructions
ask that you reboot the PowerStation, do so.
The Hardware page should appear, as shown below, for a
properly configured system using COM4. If your system does
not display as shown you must select the Advanced button to
change the parameters.
5. Exit the Pointer Device Properties dialog.

Pentium Third Serial Port Installation
16
CTCParkerAutomation
6. Restart the PowerStation.
Important You must restart the PowerStation for the changes to
take effect.
Recalibrating the Touchscreen
After reconfiguring the touchscreen, you must also recalibrate it.
You can calibrate the touchscreen in MS-DOS mode from the
MachineShop Shell or under Windows 95, 98, or NT. If you use
both DOS and Windows operating systems, you must recalibrate
the touchscreen in both DOS and Windows. Instructions for both
procedures follow.
Recalibrating the Touchscreen under
MS-DOS
The MachineShop Shell comes with a calibration utility that you
can use to calibrate the touchscreen in MS-DOS mode. The cali-
bration utility requires a keyboard and involves calibrating the
touchscreen for text and for graphics.
To calibrate the touchscreen, complete the following steps:
1. On the MachineShop Shell main menu, press the Settings but-
ton.
The Settings submenu will appear as shown below.

Pentium Third Serial Port Installation
CTC Parker Automation
17
2. On the Settings submenu, press the PWRSTA button.
The PowerStation Settings menu will appear, as shown below.
3. On the PowerStation Settings submenu, press the Calibrate
Touchscreen button.
You will be prompted that a keyboard is needed to calibrate
the touchscreen. Then you will be asked if you want to
continue.
4. If necessary, install a keyboard on thePowerStation. See your
PowerStation User Manual for information about connecting
a keyboard to the PowerStation.
5. When you have attached a keyboard to the PowerStation,
press the Yes button to continue the calibration.
6. Pressanykey onthekeyboardwhenyouareready tobeginthe
calibration program.
7. Type H for Hard calibrate.
8. When the next screen appears, follow the instructions on the
screen by touching each square as it appears until you hear a
beep.
9. When you have finished, press any key.
10. Press X or Esc to exit the calibration utility.
Important After calibrating the touchscreen, enter Interact inProgram
Mode. Verify that the cursor appears on the screen where
you touch. If it does not, recalibrate the touchscreen. The
calibration must be accurate to avoid activating a button
unintentionally during Run Mode.

Pentium Third Serial Port Installation
18
CTCParkerAutomation
Recalibrating the Touchscreen under
Windows
To recalibrate the touchscreen under Windows 95, 98, or NT,
complete the following steps:
1. On the Windows taskbar, click the Start button; then click Pro-
grams, then click UPDD, then Calibrate.
An arrowappearsin the upper left corner. Placeyour finger on
the target in the upper left corner. As the target moves from
corner to corner, place your finger on the target. Calibration is
finished when you are returned to the desktop.
