Moxa Technologies UC-2200A Series User manual

P/N: 1802022220011
*1802022220011*
UC-2200A Series
Quick Installation Guide
Version 1.1, November 2023
Technical Support Contact Information
www.moxa.com/support

2023 Moxa Inc. All rights reserved.

- 2 -
Overview
The UC-2200A computing platform is designed for embedded data-
acquisition applications. The UC-2200A computer comes with two RS-
232/422/485 serial ports, two 10/100/1000 Mbps Ethernet ports, and a
Mini PCIe socket to support cellular modules. These versatile
communication capabilities let users efficiently adapt the UC-2200A to a
variety of complex communications solutions.
Package Checklist
Before installing the UC-2200A, verify that the package contains the
following items:
•UC-2200A Series computer
•3 round stickers for the screws to preventing tampering
•Quick installation guide (printed)
•Warranty card
IMPORTANT!
Notify your sales representative if any of the above items are
missing or damaged.
Panel Layouts
The following figures show the panel layouts of the UC-2200A:
Top Panel View

- 3 -
Bottom Panel View
Front Panel View

- 4 -
LED Indicators
LED
Status
Function
Power
Green
Power plugged in
OFF
Power is OFF
SW Ready/
Programmable
Yellow System is ON and the computer is working
normally
OFF
System is not ready.
USB/
Programmable
Green USB device is connected and working
normally
OFF
USB device is not connected
SD/
Programmable
Green
Micro SD card inserted and working
normally
OFF
Micro SD card is not detected.
Wireless Signal
Strength/
Programmable
Yellow
The number of glowing LEDs indicates the
signal strength:
2 (both Yellow): Excellent
1 (Yellow): Poor
1 (Yellow, blinking, heartbeat): Very Poor
OFF
Wireless module is not detected.
Serial Tx Green Steady ON: Serial 1/2 not working normally
Blinking: Serial 1/2 transmitting data
OFF
Serial 1/2 not used
Serial Rx
Yellow
Steady ON: Serial 1/2 working normally
Blinking: Serial 1/2 receiving data
OFF
Serial 1/2 not being used.
LAN
Green
Steady ON: A 10/100 M link has been
established
Blinking: Receiving or Transmitting data
Yellow Steady ON: A 1000 M link has been
established
Blinking: Receiving or Transmitting data
OFF
No Ethernet connection

- 5 -
Installing the UC-2200A
DIN-rail Mounting
The stainless-steel DIN-rail mounting plate comes attached to the
product’s casing (the specification for the screws is M3 x 6 mm). To
mount the UC-2200A on to a DIN rail, make sure that the stiff metal
spring is facing upwards and follow these steps.
1. Insert the top of the DIN rail into the slot
just below the upper hook of the DIN-rail
bracket.
2. Latch the unit firmly onto the DIN rail as
shown in the illustrations below:

- 6 -
Wall Mounting (optional)
The UC-2200A can be mounted using a wall-mounting kit, which needs
to be purchased separately. Follow these steps to mount the computer
on to a wall:
Step 1: Use four screws (M3 x 4
mm)
to fasten the wall-mounting
brackets on the
left panel of the
computer.
Step 2: Use another four screws
(M3 x
6 mm) to mount the
computer on a wall or a cabinet.
Connector Descriptions
Power Connector
Connect the power jack (in the package) to the UC-2200A’s DC
terminal block (located on the top panel), and then connect the power
adapter. It takes about 30 seconds for the system to boot up. Once the
system is ready, the Power LED will light up.
ATTENTION
The wiring for the input terminal block should be installed by a
skill
ed person. The wire type should be copper (Cu), wire size
should be
14 to 16 AWG, and a torque of 0.19 n-m should be
used for V+, V
-, and GND connections. The wire size of the
power input and earthing conductor should be the same.
WARNING
The product is intended to be supplied by a UL Listed Power
Unit marked "L.P.S." (or "Limited Power Source") and is rated
12
to 24 VDC, 0.9 A min., Tma = 75°C (min). If you need
further help with purchasing the power source, please contact
Moxa for further information.
WARNING
The means of power cord of adapter should be connected to a
socket-outlet with earthing connection.

- 7 -
WARNING
EXPLOSION HAZARD!
Do not disconnect equipment unless the power has been
removed or the area is known to be non-hazardous.
Grounding the UC-2200A
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI).
SG: The Shielded Ground (sometimes called
Protected Ground) contact is the
right-most
contact
of the 3
-pin power terminal block connector when
viewed from the angle shown here. Connect the SG
wire to an appropriate grounded metal surface.
Ethernet Ports
The two 10/100/1000 Mbps Ethernet ports (LAN 1 and LAN 2) come
with RJ45 connectors. The pin diagram of the ports is given below:
10/100 Mbps
1000 Mbps
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
4
–
5
–
6
Rx-
7
–
8
–
Pin
Definition
1
TRD(0)+
2
TRD(0)-
3
TRD(1)+
4
TRD(2)+
5
TRD(2)-
6
TRD(1)-
7
TRD(3)+
8
TRD(3)-
Serial Ports
The two serial ports (P1 and P2) come with terminal-block connectors.
Each port can be configured by software for the RS-232, RS-422, or
RS-485 mode. The pin assignments for the ports are given below:
Pin
RS-232
RS-422
RS-485
1
TXD
TXD+
–
2
RXD
TXD-
–
3
RTS
RXD+
D+
4
CTS
RXD-
D-
5
GND
GND
GND

- 8 -
Micro SD/SIM Card Sockets
The UC-2200A comes with a Micro SD socket for storage expansion and
a SIM card socket for cellular communication. The Micro SD card and
SIM card sockets are located on the lower part of the front panel. To
install the cards, remove the screw and the protection cover to access
the sockets and insert the Micro SD card or the SIM card into the
sockets. Make sure you insert the cards in the correct direction. Refer
to the instructions above the socket. You will hear a click when the
cards are in place. To remove the cards, push the cards in before
releasing them.
Console Port
The console port is an RS-232 port that can be connected to a 4-pin pin
header cable. You can use this port for debugging or firmware upgrade.
The console port is located on the top panel of the device and is
accessible after removing the cover of the slot.
Pin
Signal
1
TxD
2
RxD
3
NC
4
GND
USB Port
The USB 2.0 port is located at the lower part of the front panel. By
default, the USB auto-mount is disable. If enabled, the USB storage is
mounted at /media/USB_P1 /media/USB_P2.
Antenna Connectors
There are three antenna connectors on
the front panel of the UC
-
2200A. W1 and
W2 are for cellular modules.
A GPS
antenna connector is located
at the top
of the front panel. All three connectors
are of SMA type.

- 9 -
Real-time Clock
The real-time clock in the UC-2200A is powered by a lithium battery.
We strongly recommend that you do not replace the lithium battery
without the help of a Moxa support engineer. If you need to change the
battery, contact the Moxa RMA service team.
ATTENTION
There is
a risk of explosion if the battery is replaced with an
incorrect type
of battery. Replace only with the same or
equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s
instructions.
Placing a Round Sticker on a Screw
Three round stickers are included in the product package. Stick one of
them on to an external screw as indicated in the figure below to help
detect unauthorized access and tampering.
Follow these steps to place the stickers.
1. Use a cloth to clean the surface of the screws with a 75% alcohol
solution.
2. Use a tweezer to place the stickers.
3. Press the sticker down on to the screw with 15 psi (pound/square
inch) pressure for at least 15 seconds.
4. Keep the device at room temperature for 24 hours before
deploying the devices in harsh environments.
NOTE
1. Place the stickers carefully as they are thin and fragile.
2.
The ideal environment for the stickers to be stored in is
22°C (72°F) and 50% relative humidity.
3.
Keep the extra two stickers in a safe place so that only
authorized persons can access them.

- 10 -
Specifications
Input Current
Models Without Built-in LTE:
600 mA @ 12 VDC
300 mA @ 24 VDC
Models With Built-in LTE:
900 mA @ 12 VDC
450 mA @ 24 VDC
Input Voltage
12 to 24 VDC (3-pin terminal block, V+, V-, SG)
Power
Consumption
Models Without Built-in LTE:
4.5 W (w/o external USB device attached)
7.2 W (external USB device attached)
Models With Built-in LTE:
7.8 W (w/o external USB device attached)
10.5 W (external USB device attached)
Operating
Temperature
Models Without Built-in LTE:
-40 to 75°C (-40 to 167°F)
Models With Built-in LTE:
-40 to 70°C (-40 to 158°F)
Storage
Temperature
-40 to 80°C (-40 to 176°F)
Accessing the UC-2200A Using a PC
You can use a PC to access the UC-2200A by one of the following
methods:
A. Through the serial console port with the following settings:
Baudrate=115200 bps, Parity=None, Data bits=8, Stop bits
=1, Flow Control=None
ATTENTION
Remember to choose the “VT100” terminal type. Use the
console cable to connect a PC to the
UC-2200A's serial console
port
B. Using SSH over the network. Refer to the following IP addresses
and login information:
Default IP Address
Netmask
LAN 2
192.168.4.127
255.255.255.0
Login: moxa
Password: moxa

- 11 -
BSMI Certification for Taiwan
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱: 嵌入式計算機 型號（型式）: UC-2222A-T
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛
Lead
(Pb)
汞
Mercury
(Hg)
鎘
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr
+6
)
多溴聯苯
Polybrominat
ed biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
外殼 ○○○○○○
印刷電路板
及其電子組
件
－○○○○○
電纜/電線/
連接器
－○○○○○
機械部件-
金屬
－○○○○○
機械部件-
非金屬
○○○○○○
備考 1. “超出 0.1 wt %”及“超出 0.01 wt %”係指限用物質之百分比含量超出百
分比含量基準值。
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the
percentage content of the restricted substance exceeds the reference
percentage value of presence condition.
備考 2. “○”係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does
not exceed the percentage of reference value of presence.
備考 3. “－” 係指該項限用物質為排除項目。
Note 3: The “−” indicates that the restricted substance corresponds to the
exemption.

- 12 -
警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境。
警告：更換不正確之電池形式會有爆炸的風險，請依製造商說明書處理用過之電池
製造商：四零四科技股份有限公司
地址：新北市新莊區新北大道 4段3號13 樓
服務電話：[phone]
이기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은
기기로서가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다.
상호: Moxa Inc.
기자재 명칭: LTE 이동통신용 무선설비의 기기(기타)
모델명: UC-2222A-T, UC-2222A-T-AP
제조자 및제조국가 : Moxa Inc. / 대만
