Pepperl+Fuchs VOC M-F256-B12-V1D-CR0 Series User manual

Industrial Event Camera
VOC*M-F256-B12-V1D-CR0*
Manual

With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published
by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elek-
troindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause:
"Expanded reservation of proprietorship"
Worldwide
Pepperl+Fuchs Group
Lilienthalstr. 200
68307 Mannheim
Germany
Phone: [phone] - 0
E-mail: [e-mail]
North American Headquarters
Pepperl+Fuchs Inc.
1600 Enterprise Parkway
Twinsburg, Ohio 44087
USA
Phone: [phone]
E-mail: [e-mail]
Asia Headquarters
Pepperl+Fuchs Pte. Ltd.
P+F Building
18 Ayer Rajah Crescent
Singapore 139942
Phone: [phone]
E-mail: [email protected].com
https://www.pepperl-fuchs.com

Industrial Event Camera
Contents
2023-06
3
1 Introduction................................................................................................................ 5
1.1 Content of this Document............................................................................. 5
1.2 Target Group, Personnel ............................................................................... 5
1.3 Symbols Used ................................................................................................ 6
2 Product Specifications.............................................................................................. 7
2.1 Use and Application ...................................................................................... 7
2.2 Dimensions................................................................................................... 10
2.3 Field of view size.......................................................................................... 11
2.4 Display Elements .........................................................................................14
2.5 Electrical Connection .................................................................................. 14
2.6 Camera Optics .............................................................................................15
2.7 The Heater ....................................................................................................15
2.8 MicroSD card................................................................................................ 15
2.9 Digital Input Trigger Signal .........................................................................15
2.10 Accessories.................................................................................................. 16
3 Installation................................................................................................................17
3.1 Storage and Disposal.................................................................................. 17
3.2 Preparation................................................................................................... 17
3.3 Mounting the Camera ..................................................................................17
3.4 Connecting the Camera ..............................................................................18
3.5 System Requirements ................................................................................. 21
4 Functions.................................................................................................................. 22
4.1 Streaming ..................................................................................................... 22
4.2 Recording ..................................................................................................... 22
4.3 Access Protection........................................................................................ 24
5 Web Interface ........................................................................................................... 25
5.1 Opening the User Interface in the Web Browser ...................................... 25
5.2 Camera Management Tool ..........................................................................25

Industrial Event Camera
Contents
2023-06
4
5.3 User interface ...............................................................................................25
5.3.1 Events............................................................................................................................... 27
5.3.2 Settings............................................................................................................................. 27
5.3.3 Expert Settings ................................................................................................................. 33
5.3.4 System.............................................................................................................................. 36
5.3.5 Update .............................................................................................................................. 36
5.3.6 REST API Interface ........................................................................................................... 37
6 Maintenance and Repair .........................................................................................39
6.1 Servicing.......................................................................................................39
6.2 Repair ............................................................................................................39
7 Troubleshooting .......................................................................................................40
7.1 What to Do in the Case of a Fault ...............................................................40

Industrial Event Camera
Introduction
2023-06
5
1 Introduction
1.1 Content of this Document
This document contains information required to use the product in the relevant phases of the
product life cycle. This may include information on the following:
•Product identification
•Delivery, transport, and storage
•Mounting and installation
•Commissioning and operation
•Maintenance and repair
•Troubleshooting
•Dismounting
•Disposal
The documentation comprises the following parts:
•This document
•Datasheet
In addition, the documentation may comprise the following parts, if applicable:
•EU-type examination certificate
•EU declaration of conformity
•Attestation of conformity
•Certificates
•Control drawings
•Instruction manual
•Functional safety manual
•Other documents
1.2 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and dismount-
ing lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation, com-
missioning, operation, maintenance, and dismounting of the product. The personnel must have
read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
Note
For full information on the product, refer to the further documentation on the Internet at
www.pepperl-fuchs.com.
Note
For specific device information such as the year of construction, scan the QR code
on the device. As an alternative, enter the serial number in the serial number search
at www.pepperl-fuchs.com.

2023-06
6
Industrial Event Camera
Introduction
1.3 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Warning Messages
You will find warning messages, whenever dangers may arise from your actions. It is mandatory
that you observe these warning messages for your personal safety and in order to avoid prop-
erty damage.
Depending on the risk level, the warning messages are displayed in descending order as fol-
lows:
Informative Symbols
Action
1. This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note
This symbol brings important information to your attention.

Industrial Event Camera
Product Specifications
2023-06
7
2 Product Specifications
2.1 Use and Application
This manual applies to the industrial event camera (hereinafter referred to as camera). The
camera is supplied with 24 V DC and features a network interface (10BaseT/100Base-TX) and
trigger input. The camera is used for the continuous monitoring of machinery and systems in
industrial applications.
Recording can be triggered directly from the PLC via the network interface. The recording func-
tion supports a pre-run buffer of up to 15 minutes to optimally capture events. The rugged
design and the integrated heater to prevent condensation mean that the camera can be used
under harsh operating conditions. The camera is automated and integrated via a web interface.
Design of the Sensor
Figure 2.1 Overview
1Fixed-focus camera
2MicroSD card behind the cover
3LED power
4LED status
5Ethernet port
6Pressure-compensation element
7Power supply and digital input connection
8Mounting bracket with 4 x M6 female threads
9Thread ¼" - 20 UNC for mounting standard photo stands
12
3
4
5
7
9
6
8

2023-06
8
Industrial Event Camera
Product Specifications
Special Product Features
Video Recording Function with Pre-Run and Post-Run Buffer
•In addition to the video recording function, the recording function supports pre-run buffers
to capture actions that occur before the trigger event. The user can see what happened
60 seconds before and after an event. With the expert settings, the recording time can be
extended up to 15 minutes. This can be useful for applications whereby unexpected
events and operations must be stored for fault analysis or documentation purposes.
Integrated Web-Based, Password-Protected User Interface
•The camera has a web interface for easy commissioning and diagnostic purposes. The
camera can be configured via a standard web browser.
Integrated Heater
•Since the camera can be used at ambient temperatures as low as -30 °C, a heater that
can be adjusted via software is integrated to minimize the formation of condensation
around the camera lens .
Static and Dynamic Text Overlays in the Video
•Static: camera name, time, date in live view, and recording.
•Dynamic: The User Datagram Protocol (UDP) interface enables user-defined overlay
information to be added to the video sequence, e.g., for certain error messages. This sim-
plifies fault analysis.
REST API
•REST API allows an individual user interface to be programmed and for the camera to be
integrated directly into IT systems. The REST API can read out information and issue
commands (e.g., a trigger signal).
Real-Time Streaming Protocol (RTSP)
•The camera supports the RTSP standard protocol for video streaming, so audio-visual
data can be transferred across the network. This allows the camera live view to be dis-
played on standard HMI displays using RTSP.
Application Examples
Accessories for Safety Devices
The camera is an accessory for safety devices to quickly identify the cause of a safety-related
fault.
Figure 2.2 Safety light grid

Industrial Event Camera
Product Specifications
2023-06
9
High-Bay Warehouses
The camera will record a video leading up to and after the event if the storage process has
failed.
Figure 2.3 Automated storage and retrieval systems
Production Machines
The camera sends a live view to a screen to monitor the status of a machine or a hard-to-reach
area.
Figure 2.4 Wind turbine

2023-06
10
Industrial Event Camera
Product Specifications
2.2 Dimensions
The camera housing has the following dimensions.
Figure 2.5 Housing dimensions
The camera has a powder-coated aluminum housing and a glass front panel. The mounting
bracket is securely attached to the housing and cannot be removed.
114
126
82
84.6
38.3
32.5 32
34.6
5
25
25
40
40
1/4-20 UNC
M6 (4x)
