Perfect Aire NP8000 User manual

CONTENTS
SAFETY PRECAUTIONS ..................................................................................... 2
IDENTIFICATION OF PARTS................................................................................3
AIR CONDITIONER FEATURES.......................................................................... 5
OPERATING INSTRUCTIONS .............................................................................6
INSTALLATION INSTRUCTIONS ........................................................................ 8
CARE AND MAINTENANCE ...............................................................................13
TROUBLESHOOTING TIPS ............................................................................... 14
This manual provides the information needed for proper use and maintenance of this air
conditioner. Basic preventative care can help extend the life of this unit. The “Troubleshooting
Tips” section in this manual contains a chart with solutions to the most common problems.
Referring to this section may save time and prevent the need for a service call in the event of
a problem.
!CAUTION
● Contact an authorized service technician for repair or maintenance of this unit.
● Contact an installer for installation of this unit if necessary.
● The air conditioner is not intended for use by young children without supervision.
Young children should be supervised to ensure that they do not play with the air conditioner.
● Disabled persons may require assistance with set up.
● If the power cord is to be replaced, replacement work should be performed by authorized
personnel only.
● Installation and repair work must be performed in accordance with the national wiring
standards by authorized personnel only.
● Do not operate your air conditioner in a wet room such as a bathroom or laundry room.
NOTE: All the illustrations in this manual are for explanation purposes only. Unit purchased
may be slightly different.
The design and specifications are subject to change without prior notice for product
improvement. Contact customer service for details.
1
NOTE: The rating data indicated on the energy label is based on the testing condition of installing the
un-extended air exhaust duct without flat mouth, round mouth, and wall exhaust adaptors.
(The duct and the adaptors are listed in the accessories chart of this Instruction Manual.)

The air conditioner must be operated within the temperature range indicated below:
SAFETY PRECAUTIONS
MODE ROOM TEMPERATURE
COOL 62°F (17°C) – 95°F (35°C)
DRY 55°F (13°C) – 95°F (35°C)
2
Your air conditioner should be used in such a way
that it is protected from moisture (i.e. condensation,
splashed water, etc.). Do not place your air
conditioner where it can fall or be pulled into water
or any other liquid. If the unit does ever fall into
water, unplug immediately.
Always transport your air conditioner in a vertical
position and stand on a stable, level surface
during use.
Turn off the product when not in use.
Always contact a qualified person to carry out repairs.
If the supply cord is damaged it must be replaced by
an authorized service technician.
Keep an air path of at least 11.8 in (30 cm) all around
the unit from walls, furniture and curtains.
If the air conditioner is knocked over during use, turn
off the unit and unplug from the main power supply
immediately.
Do not operate your air conditioner in a wet room such as a
bathroom or laundry room.
Do not touch the unit with wet or damp hands or when
barefoot.
Do not press the buttons on the control panel with anything
other than your fingers.
Do not remove any fixed covers. Never use this appliance
if it is not working properly or if it has been dropped
or damaged.
Never use the plug to start and stop the unit. (Always use
the switch on the control panel to power the unit on and off.)
Do not cover or obstruct the inlet or outlet grilles.
Do not use hazardous chemicals to clean or come into
contact with the unit. Do not use the unit in the presence of
flammable substances or vapor such as alcohol,
insecticides, petrol, etc.
Do not allow children to operate the unit unsupervised.
Do not use this product for functions other than those
described in this instruction manual.
●Use the unit in the recommended room size.
●Locate the unit where furniture cannot obstruct the air flow.
●Keep blinds/curtains closed during the sunniest part of the day.
●Keep the filters clean.
●Keep doors and windows closed to keep cool air in and warm air out.
Energy Saving Tips
!
Always do this Never do this
Operation of Current Device
1. Plug in the air conditioner.
2. The power supply cord will have TWO buttons on the plug head. Press the TEST
button. The RESET button will click as it pops out.
3. Press the RESET button; again you will notice a click as the button engages.
4. The power supply cord is now supplying electricity to the unit.
(On some products this is also indicated by a light on the plug head.)
NOTES: Do not use this device to turn the unit on or off.
Always make sure the RESET button is pushed in for correct operation.
If power supply cord is damaged, it cannot be repaired. Please call customer service to assist with replacement.
TEST
RESET
Plug in &
press RESET
NOTE: Some plugs have buttons on the top.
The power supply cord contains a current device that senses damage to the power
cord. To test your power supply cord do the following:
The power supply must be replaced if it fails to reset when either the TEST button is pushed or it cannot be reset.

3
NOTE:
All of the illustrations in this manual are for explanation purposes only. Your air conditioner may be slightly different.
IDENTIFICATION OF PARTS
• Exhaust hose 1 Set
• Flat mouth adaptor
• Window slider kit with bolt
• Vent joint
• Foam Seal 1 Piece
• Wall exhaust adaptor A* 1 Set
• Round mouth adaptor B*
• Expansion Plugs & Wooden Screws*
(*Not included. Set sold separately.)
• Remote Control and Battery 1 Set
• Drain hose 1 Piece
Vent
Joint
Exhaust
Hose
Flat Mouth
Adaptor
Bolt Window
Slider Kit

IDENTIFICATION OF PARTS (CONTINUED)
NAMES OF PARTS
Front
Operation Panel
Horizontal Louver Control Lever
(adjust manually)
Carrying Handle
(both sides)
Remote signal receptor
Panel
1.
2.
3.
4.
5.
Fig.1
Fig. 2
Rear
Upper Air Filter
(Behind the grille)
Air Outlet
Wheel
Air intake
Drain Outlet
Air intake
Lower Air Filter
(Behind the grille)
Bottom tray drain outlet
6.
7.
8.
9.
10.
11.
12.
13.
8
9
10
11
12
6
7
13
4
13
2
5
4

AIR CONDITIONER FEATURES
Before you begin, thoroughly familiarize yourself with the control panel and remote control and all its
functions, then follow the symbol for the functions you desire.
The unit can be controlled by the unit control panel alone or with the remote control.
ELECTRONIC CONTROL OPERATING INSTRUCTIONS
Fig. 3
NOTE: This manual does not include Remote Control Operations; see the Remote Control
Instructions packed with the unit for details.
OPERATION PANEL OF THE AIR CONDITIONER
5
4
ON
OFF
MODE select button
Selects the appropriate operating mode. Each
time you press the button, a mode is selected
in a sequence that goes from AUTO, COOL,
DRY, and FAN.The mode indicator light
illuminates under the different mode setting.
SLEEP button
Used to initiate the SLEEP operation.
UP ()and DOWN () buttons
Used to adjust (increase/decrease) temperature
settings (2°F/1°C increments) in a range of 62°F
(17°C) to 88°F (30°C) or the TIMER setting in a
range of 0-24 hrs.
NOTE: The control is capable of displaying
temperature in degrees Fahrenheit or
degrees Celsius. To convert from one to the
other, press and hold the Up and Down
buttons at the same time for 3 seconds.
POWER button
Power switch on/off.
TIMER button
Used to initiate the AUTO ON start time and
AUTO OFF stop time program, in conjuction
with the & buttons.
FAN button
Control the fan speed. Press to select the fan
speed in three steps - LOW, HIGH and AUTO.
The fan speed indicator light illuminates under
different fan settings except AUTO speed.
When AUTO fan speed is selected, all of the
fan indicator lights turn dark.
LED Display
Shows the set temperature in "OC" or "OF" and
the Auto-timer settings. While on DRY and FAN
modes, it shows the room temperature.
(Details about error codes that may appear
on the display can be found on the next page.)
7
1
2
33
6
5

OPERATING INSTRUCTIONS
- Press the "MODE" button until the "COOL"
indicator light comes on.
- Press the ADJUST buttons " ∧ " or " ∨ " to
select your desired room temperature. The
temperature can be set within a range of
62OF-88OF/17OC-30OC.
- Press the "FAN" button to choose the
fan speed.
- Press the "MODE" button until the "DRY"
indicator light comes on.
- Under this mode, you cannot select a fan speed
or adjust the temperature.
- Keep windows and doors closed for the best
dehumidifying effect.
- Remove exhaust hose. (See page 11.)
COOL operation
DRY operation
- Press the "MODE" button until the "FAN" indicator
light comes on.
- Press the "FAN" button to choose the fan speed.
The temperature cannot be adjusted.
- Remove exhaust hose. (See page 11.)
FAN operation
TIMER operation
If setting the timer when the unit is on:
First press the TIMER button; the TIMER OFF
indicator light illuminates. It indicates the Auto Stop
program is initiated. Press the TIMER button again;
the TIMER ON indicator light illuminates. It
indicates the Auto Start program is initiated.
If setting the timer when the unit is off:
First press the TIMER button; the TIMER ON
indicator light illuminates. It indicates the Auto Start
program is initiated. Press the TIMER button again;
the TIMER OFF indicator light illuminates. It
indicates the Auto Stop program is initiated.
- Press or hold the UP or DOWN button to change
the Auto time by 0.5 hour increments, up to 10
hours, then at 1 hour increments up to 24 hours.
The control will count down the time remaining
until start.
- The selected time will register in 5 seconds and
the system will automatically revert back to
displaying the previous temperature setting.
- Turning the unit ON or OFF at any time or
adjusting the timer setting to 0.0 will cancel the
Auto Start/Stop timed program.
- When the malfunction (E1 or E2) occurs, the Auto
Start/Stop timed program will also be cancelled.
E1- Room temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call customer service.
E2- Evaporator temperature sensor error-
Unplug the unit and plug it back in.
If error repeats, call customer service.
E4- Display panel communication error-
Unplug the unit and plug it back in.
If error repeats, call customer service.
P1- Bottom tray is full - Connect the
drain hose and drain the collected
water away. If error repeats, call
customer service.
Error and protection codes:
AUTO operation
- When you set the air conditioner in AUTO mode,
it will automatically select cooling or fan only
operation depending on the temperature you have
selected and the room temperature.
- The air conditioner will control room temperature
automatically around the temperature point you
have set.
- Under AUTO mode, you cannot select the
fan speed.
NOTE: When more than one error occurs,
the priority of the code display order is:
E4--E2--E1--P1.
SLEEP operation
In this mode the selected temperature will
increase by 2OF/1OC 30 minutes after the mode
is selected.The temperature will then increase
by another 2OF/1OC after an additional 30
minutes. This new temperature will be
maintained for 7 hours before it returns to the
originally selected temperature. This ends the
Sleep mode and the unit will continue to operate
as originally programmed.
NOTE: This feature is not available under FAN or
DRY mode.
6

OPERATING INSTRUCTIONS (CONTINUED)
OTHER FEATURES
After the unit has stopped, operation cannot be
restarted in the first 3 minutes. This is to protect
the unit. Operation will automatically start after
3 minutes.
Wait 3 minutes before resuming operation.
Air flow direction adjustment
Fig. 4
If the unit breaks off unexpectedly due to the power
being cut, it will restart with the previous function
setting automatically when the power is restored.
Auto-Restart
7
- The louver can be set to the desired position
manually. (See Fig. 4.)
- Do not place heavy objects or other loads onto
the louver. Doing so will damage the unit.
- Keep the louver fully opened during operation.
Adjust
manually

INSTALLATION INSTRUCTIONS
Fig. 5
Horizontal
window
Vertical
window
Window Slider Kit
Minimum:2.22 ft (67.5 cm)
Maximum:4.04 ft (123 cm)
Fig. 6
Fig. 7
Window Slider Kit
Minimum:2.22 ft (67.5 cm)
Maximum:4.04 ft (123 cm)
7
7
8
11.8 in
11.8 in
Fig. 7a
Extension
piece
NOTE: If the window opening is less than 2.22 ft,
cut the extension piece (see Fig. 7a) shorter so the
kit properly fits in the window opening. Only cut if
absolutely necessary. Never cut the hole in the
window slider kit.

INSTALLATION INSTRUCTIONS (CONTINUED)
Window sill
Window sill
Fig. 8
See Fig. 8.
See Fig. 10.
See Fig. 11.
sill. See Fig. 9.
Fig. 9
26.5” - 48”
Fig. 10
Fig. 11
9
