Retrofit Empty Keg Sensor
Existing Perlick single valve keg couplers can be retrofitted
to function as Smart Couplers. Simply replace the probe
with Perlick’s No. 40125 empty keg sensor. Bulk-packed.
Weight: 8 oz. each
Part No. Description
40125...................................For domestic kegs
40119...................................For imported kegs
Cleaning Adapters
Single and dual cleaning
adapters are uniquely
designed to operate
when Perlick’s keg cou-
pler is in the untapped
(handle up) position,
allowing the system to be cleaned from the faucet through
the keg coupler. Prevents solution from entering the CO2
line, eliminating beer contamination when retaping. Brass
nickel plated (Bulk Packed)
Part No. Description
43657* .................................Single/domestic kegs
43681* .................................Dual/domestic kegs
43659* .................................Series/domestic kegs
43699...................................Single/imported kegs
43702...................................Dual/imported kegs
*Note: These adapters are designed to be used with all Perlick single
valve couplers and most competitor’s couplers. Must be used with Smart
Couplers when cleaning lines from the faucet through the Smart Coupler.
Lo-Boy Coupler for Single
Valve Domestic Kegs
Uniquely constructed to tap a keg
in limited space. Just push down
and twist to tap.
Part No. Description
40030 ............................Lo-Bo
KEG COUPLERS
Perlick Smart Couplers
✓Keeps beer loss to a minimum
✓Speeds service on keg changeovers
✓Minimizes overfoaming
The patented Perlick Smart Coupler* combines an integral
Empty Keg Sensor with a quality keg coupler to eliminate
the need for wall-mounted FOB devices. It senses when a
keg is empty and shuts off the beer flow, yet leaves the line
fully charged with beer. This prevents gas from entering an
empty line causing excessive foaming when tapping a
fresh keg. Packed 25 per case. Weight: 1 lb. 8 oz. each
Part No. Description
26000F*...............................For Domestic Kegs
27500F.................................For Imported Kegs
*U.S. Patent #5,630, 441
Universal Empty Keg Sensor
Controls the amount of beer loss by closing off the beer
flow when a keg empties. Mounts directly to the keg
coupler for dual probe or imported kegs.
Part No. Description
43739...................................Universal empty
keg sensor
No. 26000F
No. 43739
No. 43657 No. 43681 No. 43659
Single Dual Series
Adapter Adapter Adapter

KEG COUPLERS
G-Series Keg Couplers for Single Valve
Domestic and Imported Kegs
Provided with non-rotating probe in stainless steel or
nickel-plated brass. Enlarged bore and wider tip opening
produces less turbulence and restriction which allows for
reduced line pressure and CO2 breakout. Nickel-plated,
forged brass body with three internally mounted
seals.Floating ball check valve equalizes line pressure.
Relief valve vents over-pressurized keg. For bent probe
design, attach #2036SS elbow to external thread on keg
couplers. Optional Locking Shield prevents accidental
untapping. Individually packed, 25 per case. Weight 24 oz.
each.
For Domestic Kegs
Part No. Descriptionr
26000G............................Probe, brass, less lock
26000GS.........................Probe, S. St., less lock
26000G1..........................Probe, brass, with lock
26000GS1.......................Probe, S. St., with lock
For Imported Kegs
Part No. Description
27500G............................Probe, brass, less lock
27500GS.........................Probe, S. St., less lock
27500G1..........................Probe, brass, with lock
27500GS1.......................Probe, S. St., with lock
Item Part No. Description
1..................40174-1 .......................Probe - brass
1..................40174-1SS ..................Probe - stainless steel
2..................40157-1*......................Probe, brass, Imported kegs
2..................40157-1SS*.................Probe, s. st., imported kegs
3..................2036SS........................Elbow for bent probe, s. st.
4..................43641-1 .......................Ball retaining spring
5..................157R2P........................Washer
6..................31080-2P.....................Ball check
7..................31089-2P.....................O-ring (3 per ass’y.)
8..................2026.............................Hex nut
9..................2068-1..........................Tailpiece
10..................23682-2P.....................Check Valve
11..................43061...........................Coupler body
12..................31479-1*......................Probe washer, imported
13..................31088-2P.....................Bottom seal washer
14..................31087-2P.....................Probe washer, domestic
15..................31084-1 .......................Retaining screw
16..................43001A ........................Yoke less lock-domestic
17..................43002A ........................Yoke with lock- domestic
18..................32474-1 .......................Wrench
*Replacement part used exclusively for Keg Couplers for Imported Kegs.
Keg Coupler Replacement Parts
3
5
4
6
1
2
7
10
89511
13
12 14 18
17
16
15
Elbow for Bent Probe
Couplers
Part No. Description
2036SS.......................................S. St. elbow coupler
Lug Straightener for Single Valve Kegs
Part No. Description
32695 .........................................Lug straightener
No. 26000G
No. 26000G1
No. 2036SS
No. 32695
Keg Coupler Replacement Parts

22
12
21
15
13
11
14
15
16
17
20
18
19
6
5
4
3
87
1
10
9
2
KEG COUPLERS
D-Series Keg Couplers for Single Valve
Domestic and Imported Kegs
Exclusive two-piece rotating probe helps prevent twisting
beer lines. Nickel-plated, forged brass body with three
internally mounted seals. Floating ball check valve equal-
izes line pressure. Relief valve vents over-pressurized
kegs. Optional Locking Shield prevents accidental untap-
ping. Converts for domestic or imported kegs by changing
probe tip. Individually packed, 25 per case. Weight 24 oz.
each.
For Domestic Kegs
Part No. Descriptionr
26000D..........................................Probe, less lock
26000D1........................................Probe, with lock
For Imported Kegs
Part No. Description
27500D..........................................Probe, less lock
27500D1........................................Probe, with lock
Item Part No. Description
1..................32499...........................Probe assembly, domestic kegs
2..................32610* .........................Probe assembly, imported kegs
3..................43641-1 .......................Ball retaining spring
4..................32461-1A.....................Probe center stem
5..................C14316........................Buna-N O-ring
6..................31080-2P.....................Ball check, Poly
7..................31079-1 .......................Tip, domestic kegs
8..................31478-1*......................Tip, Imported kegs
9..................31089-2P.....................O-ring (3 per assembly)
10..................43061...........................Coupler body
11..................31088-2P.....................Bottom seal washer
12..................31087-2P.....................Probe washer, domestic
13..................31479-1*......................Probe washer, imported
14..................23682-2P.....................Check valve
15..................157R2P........................Washer
16..................2068-1..........................Tailpiece
17..................2026.............................Nut
18..................31084-1 .......................Retaining screw
19..................43001A ........................Yoke less lock, domestic
19..................43090A*.......................Yoke less lock, imported
20..................43002A ........................Yoke with lock, domestic
20..................43091A*.......................Yoke with lock, imported
21..................2036SS........................Elbow for bent probe
22..................32474-1 .......................Wrench
*Replacement part used exclusively for Keg Couplers for Imported Kegs.
Keg Coupler Replacement Parts
Lug Straightener for Single Valve Kegs
Part No. Description
32695 .........................................Lug straightener
No. 26000D
No. 26000D1
No. 32695
Keg Coupler Replacement Parts
