Perlick HP15 Manual

48" & 72" Mounting Plate
15" & 24" Mounting Plate
Phillips
Screwdriver
Grille
B MPER, ADHESIVE POLY
LATCH STRIKE
Drill
5/32" Drill Bit
8300 W. Good Hope Rd. Milwaukee, WI 53223 Phone: [phone] Fax: [phone] perlick.com
Perlick is comitted to continuous improvement. Therefore, we reserve the right to change specifications without warning
95010 REV C
Never install if used with caster kits or
Tools Required
1/4-20 X 1/2" MACHINE SCREW
STACKING KIT INSTALLATION
#10 X 1/2" SHEET METAL SCREW
manual that came with the cabinet.
per the installation and operating
Ensure the anti-tip brackets are installed
For built-in applications only!
IMPORTANT
extended leg kits.
-1-
Parts Required
MODEL
Part Number Description HP15 HP24 &
HC24
HH24 &
HA24-18 HP48 HP72
63965 LATCH STRIKE 2 2 2 4 6
65700-2 15" Grille 1
65733-4 24" Grille 1 1 2 3
68094-15 15" Mounting Plate 1
68094-24 24" Mounting Plate 1
68094-24x18 24"x18" Mounting Plate 1
68094-48 48" Mounting Plate 1
68094-72 72" Mounting Plate 1
C31323 Bumper, Adhesive Poly 4 4 4 8 12
M00885-189 1/4-20 X 1/2" MACHINE
SCREW 4 4 4 6 6
M50050-466 #10 X 1/2" SHEET METAL
SCREW 2 2 2 5 5

8300 W. Good Hope Rd. Milwaukee, WI 53223 Phone: [phone] Fax: [phone] perlick.com
Perlick is comitted to continuous improvement. Therefore, we reserve the right to change specifications without warning
so that it can be done safely and without damage.
95010 REV C
Step 1: Drill out top row of rivets along back of the bottom cabinet
STAC ING IT INSTALLATION
using 5/32" drill bit.
-2-
These cabinets are extremely heavy. Ensure that you have
enough people on hand to help in repositioning of the unitsCAUTION:
5 rivets on 48 and 72
inch wide cabinets.
Back View
Back View
2 rivets on 24 and 15
inch wide cabinets.
Step 2: Lay upper cabinet on its back and remove leg levelers and
grille(s) from unit.
Remove 4 leg
levelers from all
sizes of upper units.
Remove 2 additional
leg levelers from
48 and 72 units.

NOTE: EXTENSION OF LEG LEVELERS
WILL INCREASE ASSEMBLY HEIGHT
68 7
8"
95010 REV C
sheet meta screws (where the rivets were dri ed out in step 1).
in step 2) by using 1/4-20 machine screws . F ange shou d be
STACKING KIT INSTALLATION
pointing away from the bottom of the unit.
Step 3: Attach mounting p ate (where the eg eve ers were removed
Step 4: P ace upper unit on top of ower unit and attach using #10
-3-
8300 W. Good Hope Rd. Milwaukee, WI 53223 Phone: [phone] Fax: [phone] perlick.com
Perlick is comitted to continuous improvement. Therefore, we reserve the right to change specifications without warning
F ange
Bottom of
cabinet

8300 W. Good Hope Rd. Milwaukee, WI 53223 Phone: [phone] Fax: [phone] perlick.com
Perlick is comitted to continuous improvement. Therefore, we reserve the right to change specifications without warning
Move stacked assembly into final position by pushing lower unit.
95010 REV C
STACKI G KIT I STALLATIO
Step 5: Attach -4- bumpers and -2- latch strikes to each new grille.
Orient tabs vertically. Attach grille assemby to upper unit.
-4-
Bumper
This edge
vertical.
Note:When using stacking kit to join -2- HH24
or HC24-18 units, a wall mount anti-tip kit
must be installe . See cabinet manual
for instructions.
