Phase Linear Phase Linear BT1613 User manual

BT1613
BT1613
PS/AS
AUX IN
iPod Ready AM/FM/CD/MP3/
WMA Receiver with Bluetooth
Technology
Receptor iPod AM/FM/CD/MP3/
WMA con Tecnología Bluetooth
Récepteur prêt d'iPod AM/FM/CD/
MP3/WMA avec la technologie de
Bluetooth
Owner's Manual/Manual del Usario/Manual de L'Utilisateur
SERIES

BT1613
ii

BT1613
1
INTRODUCTION
Contents
Operating Instructions............................... 2
Tuner Operation ........................................ 6
CD Player Operation................................. 8
MP3/WMA File Requirements................. 10
MP3/WMA Operation .............................. 12
Using a USB Device or SD Card............. 14
iPod Operation ........................................ 16
Bluetooth Operation ................................ 18
Remote Control....................................... 21
Care and Maintenance............................ 22
Troubleshooting....................................... 23
Specifications .......................................... 24
Toll-Free Installation Assistance
If you require assistance, contact Technical
Support at 1-800-323-4815 from 9:00 a.m. to
6:00 p.m. EST Monday through Friday (U.S.A.
and Canada only).
Para obtener instrucciones en Español, diríjase a la página 25. Pour des instructions en Francais, référez-vous à la page 51.

BT1613
2
OPERATING INSTRUCTIONS
Power
Press the power button (1) or any other
button on the face of the receiver to turn the
unit on when the ignition switch is on. Press the
power button again to turn the receiver off. If
the radio was left on when the ignition was last
turned off, the receiver will turn on automatically
when the ignition switch is again turned on. If
the receiver was off when the ignition was last
turned off, the receiver must be turned on
manually when restarting the vehicle.
Source
Press the SRC button (2) to select a different
mode of operation as indicated on the display
panel. Available sources include Tuner, CD,
SD, USB, BT AUDIO, iPod and Auxiliary Input.
During CD player operation, pressing SRC will
change to the tuner source without ejecting the
disc. To access the Auxiliary Input source,
press the SRC button until "AUX" is indicated in
the display.
Volume
To increase the volume, turn the AUDIO
CONTROL (3) clockwise. To decrease the
volume, rotate the AUDIO CONTROL counter
clockwise. When volume is adjusted, the
volume level is shown on the display panel as a
number ranging from “00” (lowest) to “46”
(highest).
BT1613
19
10
8
5
16 27
6
43
2
14
25
13
17
19 22
20
21
23 24
18
15
11 12
7
LIFT
PS/AS

BT1613
3
Select
Press the AUDIO
CONTROL button (4)
to step through the
menu of audio
functions: volume
(VOL), bass (BAS),
treble (TRB), balance
(BAL), fader (FAD),
and volume (VOL). When adjusting audio
functions, the unit will automatically exit select
mode and return to the normal display after five
seconds or when another function is activated.
Bass
Press the AUDIO CONTROL button (4) twice
until “BAS” appears in the display. Within five
seconds, turn the AUDIO CONTROL (3)
clockwise or counter clockwise to adjust the
bass from “-6” to “+6”. “0” represents a flat
response. The bass level is shown on the
display for five seconds or until another function
is activated.
Treble
Press the AUDIO CONTROL button (4) three
times until “TRB” appears in the display. Within
five seconds, turn the AUDIO CONTROL (3)
clockwise or counter clockwise to adjust Treble
from “-6” to “+6”. “0” represents a flat response.
The treble level is shown on the display for five
seconds or until another function is activated.
Balance
Press the AUDIO CONTROL button (4) four
times until “BAL” appears in the display. Within
five seconds, turn the AUDIO CONTROL (3)
clockwise (or counter clockwise) to adjust
Balance between the right and left speakers
from “BAL R12” (full right) to “BAL L12” (full
left). “BAL C00” represents an equal balance
level between the right and left speakers. The
balance position is shown on the display for five
seconds or until another function is activated.
Fader
Press the AUDIO CONTROL (4) five times until
“FAD” appears in the display. Within five
seconds, turn the AUDIO CONTROL (3)
clockwise or counter clockwise to adjust
balance between the front and rear speakers
from “FAD R12” (full rear) to “FAD F12” (full
front). “FAD C00” represents an equal balance
level between the front and rear speakers. The
fader position is shown on the display for five
seconds or until another function is activated.
System Menu
Press and hold the DISP button (9) to
view the system “MENU”. Press the DISP
button repeatedly or use the >>| (14) or |<< (13)
button to access the following MENU options.
PAIR HF/AD
This feature is used to pair your mobile phone
to the unit’s Bluetooth system. To initiate the
pairing process select “Pairing HF” and then
press the AUDIO CONTROL button.
RE-CON/DIS-CON
Use this feature to reconnect or disconnect a
paired mobile phone manually. Turn the AUDIO
CONTROL (4) to select “RE-CON” to reconnect
or “DIS-CON” to disconnect and then press the
AUDIO CONTROL button (4) to perform the
operation.
BT VOL (00-42)
Use this feature to set the default voice volume
for all incoming calls. Use the AUDIO
CONTROL to adjust the voice volume from “00”
to “42”.
Clock (CLK)
Turn the AUDIO CONTROL left to adjust the
hours and right to adjust the minutes.
AREA
Turn the AUDIO CONTROL to select the
appropriate frequency spacing for your area:
USA, LAT (Latin America), EUR (Europe), or
RUS (Russia).
DISTANT/LOCAL
This feature is used to designate the strength of
the signals at which the radio will stop during
automatic tuning. “Distant” is the default setting,
VOL
VOL
BAS
TRB
BAL
FAD
PU
S
H
S
E
E
L
C
T
B
B
S
L
E
T
AA
AD
F
R
PU
S
H
S
E
E
L
C
T
B
B
S
L
E
T
AA
AD
F
R
PU
S
H
S
E
E
L
C
T
B
B
S
L
E
T
AA
AD
F
R
PU
S
H
S
E
E
L
C
T
B
B
S
L
E
T
AA
AD
F
R

BT1613
4
allowing the radio to stop at a broader range of
signals. To set the unit to select only strong
local stations during automatic tuning, turn the
AUDIO CONTROL to choose “Local”.
P-VOL (00-46)
Use the “VOL PGM” option to select the default
volume the radio will assume when first turned
on. To program a specific start-up volume level,
turn the AUDIO CONTROL to select the
desired level.
NOTE: If the P-Vol is set higher than the
volume selected when the unit is turned off,
the unit will resume the lower volume when
turned back on - not the P-Vol.
BEEP ON/OFF
The beep tone feature allows the selection of
an audible beep tone to be heard each time a
button is pressed on the face of the radio. Turn
the AUDIO CONTROL to select from the
following Beep Tone options:
• BEEP ON: Beep is heard any time a
button is pressed (function activated).
• BEEP OFF: Beep is not heard.
iX-BASS
Press the iXBASS button (15) to activate the
iXBASS feature. When listening to music at low
volume levels, this feature will boost the bass
and treble ranges to compensate for the
characteristics of human hearing. Press
iXBASS again to deactivate this feature.
Subwoofer
Press the SUB-W button (18) to activate the
Subwoofer function. Press again to turn the
Subwoofer function off.
NOTE: The Subwoofer feature only works
when an external amplifier and subwoofer
are connected via the Sub line out
connection on the back of the unit.
Audio Mute (MUTE)
Press the MUTE button (6) to mute the audio
volume. “MUTE” flashes on the display. Restore
volume to the previous setting by pressing the
mute button again, adjusting the AUDIO
CONTROL.
Liquid Crystal Display (LCD)
The liquid crystal display (LCD) panel (8)
displays the frequency, time and activated
functions of the unit.
NOTE: After being subjected to cold
temperatures, LCD panels may take longer
to respond and visibility of the numbers on
the LCD may decrease slightly. The LCD
display will return to normal when the
temperature increases to a normal range.
Display (DISP)
When the unit is on, the LCD automatically
shows the display for the current source of
operation.
When the unit is on, press the DISP button (9)
to display the time of day. After five seconds,
the display reverts to the current source.
Auxiliary Input
Lift the cover on the right side of the radio to
reveal the AUX IN connector (16). Use the
included 3.5mm media cable to connect a
portable media device for playback through the
vehicle sound system.
Front Panel Release
The front panel REL (release) button (10)
releases the mechanism that holds the front
panel to the chassis.
Detaching the Front Panel
To detach the front panel, first press the REL
button (10) to release the left side of the panel.
Next, grasp the released side and pull the panel
off the chassis. After removing the front panel,

BT1613
5
store it in the supplied carrying case to protect it
from dirt and damage.
Re-attaching the Front Panel
To re-attach the front panel, make sure the
electrical terminals on the back of the panel are
free of dust and dirt, as debris could cause
intermittent operation or other malfunctions.
Position the right side of the panel in place so
that it is correctly engaged, and then lightly
press the left side of the panel until the panel
locks into place.
Reset Button
The reset button (26) is located on the front of
the chassis and can only be accessed with the
front panel removed. The reset circuitry
protects the microprocessor circuitry. Since
resetting the unit will erase the time and preset
memories, it should only be activated upon
initial installation after all wiring is complete, or
if there is a malfunction of any of the switches
on the unit. In these circumstances, pressing
the reset button will clear the system and return
the unit to normal operation.
2
1
REMOVE FRONT PANEL
RESET
26

BT1613
6
TUNER OPERATION
AM/FM Band Selector (BAND)
Press the BAND button (5) during radio play to
switch between three FM bands and two AM
bands. “F1”, “F2”, “F3” or “AM”, “AM2” will
appear in the display to indicate the band
currently selected.
Tuning
Automatic Tuning
Press the >>| button (14) to tune upward in
frequency and the |<< button (13) to tune
downward in frequency. The unit will
automatically stop at the next strong station. If
the Local mode is active, the radio will seek the
next strong local station when either button is
pressed.
Manual Tuning
Press the >>| (14) or |<< (13) button for more
than two seconds to select manual tuning
mode. “MANUAL” will appear in the display.
Press the Up or Down Tuning buttons to move
radio frequency up or down two digits at a time.
Press and hold the Up or Down Tuning buttons
to quickly advance to a certain frequency.
Release when the desired frequency is
reached. If tuning is not adjusted within five
seconds of entering manual tuning mode, the
radio will revert to automatic tuning and “AUTO”
will appear in the display.
Preset Stations
Up to six stations on each band can be stored
as presets and can then be instantly recalled by
pressing the associated preset button on the
front panel (19-24) or remote control. To store a
station, turn the radio on and select the desired
band and station. Press and hold the desired
preset button (numbered one through six on the
face of the radio or remote control) for more
BT1613
19
10
8
5
16 27
6
43
2
14
25
13
17
19 22
20
21
23 24
18
15
11 12
7
LIFT
PS/AS

BT1613
7
than two seconds. When stored, the preset
number will appear in the display. The station is
now stored and can be recalled at any time by
pressing the corresponding preset button.
Repeat for the remaining five presets on the
current band and for all presets on the other
three bands.
Preset Scan/Automatically Store
(PS/AS)
Automatically Store
Select six strong stations and store them for
the current band using the Automatic Store
feature. To enable this feature, press and hold
the PS/AS button (17) for more than two
seconds. The radio will automatically scan each
band and enter strong stations into the preset
memory positions. After entering the stations
into memory, the unit will automatically stop at
each station for five seconds so each can be
heard. When using the Automatically Store
feature, the new stations replace any stations
already stored in preset memory.
Preset Scan
Press the PS/AS button (17) to scan the six
preset stations in the AM band or all FM bands.
The unit will stop at each station for five
seconds before continuing to the next preset
station, and the preset number will flash on the
display during the preset scan. Press PS/AS
again to stop scanning and listen to the current
station.

BT1613
8
CD PLAYER OPERATION
Insert CD
With the label surface facing up, gently insert
the disc into the CD slot (11) until the soft-
loading mechanism engages and pulls the disc
in. Disc play begins. The track number and
elapsed time appear in the display.
Track Select
Track select features are used to quickly
access the beginning of a particular track when
a disc is in play. Press the >>| button (14) to
move forward or the |<< button (13) to move
backward on the disc to locate the desired
track. Track numbers will appear in the display
as they are accessed.
Press and hold the >>| or |<< button to fast
forward or fast reverse through a disc. During
either function, the elapsed time will appear on
the display. Release the button to resume CD
play.
Play/Pause
Press the play/pause button (19) to suspend
disc play. “PAUSE” will appear in the display.
Press the play/pause button again to resume
disc play. The “PAUSE” indication will
disappear from the display, and play will
resume from the pausing point.
Disc Intro Scan (INT)
During disc play, press the 2INT button (20) to
play the first 10 seconds of each track on the
disc. “INT” will appear in the display. When the
desired track is reached, press 2 INT again to
end the scan function and play the selected
track. “INT” will disappear from the display. The
scan function will also be canceled when
activating the repeat or shuffle functions.
BT1613
19
10
8
5
16 27
6
43
2
14
25
13
17
19 22
20
21
23 24
18
15
11 12
7
LIFT
PS/AS
NOTE: The unit is designed for play of
standard 5” (12 cm.) compact discs only. Do
not attempt to use 3” (8 cm.) CD singles in
this unit, either with or without an adaptor,
as damage to the player and/or the disc may
occur. Such damage will not be covered by
the warranty on this product.

BT1613
9
Disc Repeat (RPT)
Press the 3 RPT button (21) during disc play to
continuously repeat the selected track. “RPT”
will appear in the display. Press 3 RPT again to
stop repeating.“RPT” will disappear from the
display, and regular play will resume. The
repeat function will also be canceled when
activating the scan or shuffle functions.
Disc Shuffle (RDM)
Press the 4 RDM button (22) during disc play to
play all tracks on a CD in random, shuffled
order. “RDM” will appear in the display. Press 4
RDM again to stop random play. “RDM” will
disappear from the display and regular play will
resume. The shuffle function will also be
canceled when activating the scan or repeat
functions.
Disc Eject
Press the eject button (12) to stop CD play and
eject the disc. The unit will change to tuner or
AUX operation, depending on which mode was
in operation prior to disc play. If the disc is not
removed from the unit within 15 seconds, the
disc will be reloaded to prevent accidental
damage. Disc play can be resumed by pressing
SRC (2) to choose the CD player function.
CD Player Error Codes
If a problem should develop while operating the
CD player, “Disc Error” or “Error 1” may appear
on the display panel. If “Disc Error” appears, try
ejecting and reloading the disc into the player.
While the disc is out of the unit, make sure it is
clean and undamaged, and then load it
correctly. “Error 1” can indicate a number of
problems with the unit, including a mechanical
error or an error in the microprocessor control
of the player. Pressing the reset button (26)
may help, but will erase the time and preset
memory. If the suggested measures do not
solve the problem, contact an approved
warranty station near you for further assistance.

BT1613
10
MP3/WMA FILE REQUIREMENTS
MP3 and WMA (Windows Media Audio) music
files are digital audio files that are compressed
to allow more files on a single CD. This unit can
play MP3/WMA directly from files contained on
a CD-R/RW, USB device or SD card using the
buttons on the receiver (or remote control) as
described below. Many types of software are
available for converting audio files into MP3/
WMA formats. Phase Linear recommends Nero
or Roxio Easy CD Creator. Depending on the
media type and recording method, some CD-R/
RWs may be incompatible with this unit. The
unit supports playback of MP3/WMA and CDDA
(CDA), Mixed-Mode CDs and CD-Extra
(including multi-session discs), but discs on
which the session has not been closed will
not play.
Notes on MP3/WMA Play
This unit can play MP3 (MPEG1, 2, 2.5 Audio
Layer 3). However, the MP3 recording media
and accepted formats are limited. When writing
MP3/WMA, pay attention to the following
restrictions.
Acceptable Media
The MP3/WMA recording media acceptable to
this unit are CD-ROM, CD-R and CD-RW.
When using CD-RW, use full format rather than
quick format to prevent malfunction.
Acceptable Disc Formats
The following formats are available for the
media used in this unit. The maximum number
of characters used for file name including the
delimiter (".") and three-character extension are
indicated in parentheses.
• ISO 9660 Level 1 (11 characters)
• ISO 9660 Level 2 (31 characters)
• Joliet (31 characters)
• Romeo (31 characters)
Up to 200 characters can be displayed in the
long file name format. For a list of available
characters, see the instruction manual of the
writing software and the section “Entering File
and Folder Names” below. The media
reproducible on this unit has the following
limitations:
• Maximum number of nested folders: 8
• Maximum number of files per disc: 999
• Maximum number of folders per disc: 255
MP3/WMA written in formats other than those
listed above will not play successfully and their
file names or folder names will not be displayed
properly.
MP3/WMA Encoder and CD
Writer Settings
Use the following settings when compressing
audio data in MP3 data with the MP3 encoder.
• Transfer bit rate: 32 - 320 kbps
• Sampling frequency: 32, 44.1, 48kHz
(WMA) and 16, 22.05, 24, 32, 44.1, 48kHz
(MP3)
When using a CD writer to record MP3/WMA up
to the maximum disc capacity, disable
additional writing. To record an empty disc up to
the maximum capacity at once, select the “disc
at once” option.

BT1613
11
Entering ID3 Tag
This unit supports ID3 tag versions 1.0 and 1.1.
For the character codes, refer to the table
below.
Entering File and Folder Names
Names using the code list characters are the
only file names and folder names that can be
entered and displayed. Other characters will not
display correctly. The unit recognizes and plays
only files with the MP3/WMA extension.
NOTE: A file name entered with characters
not on the code list may not play correctly.
Writing Files into a Disc
When a disc containing MP3/WMA data is
loaded, the unit checks all data. If the disc
contains many folders or non-MP3/WMA files,
MP3/WMA play will be delayed, it may take
time for the unit to move to the next file, and
searches may not be performed smoothly.
Loading such a disc may produce loud noise
and cause damage to the speakers.
NOTE: Do not attempt to play a disc
containing a non-MP3/WMA file with the
MP3/WMA extension or a disc containing
non MP3/WMA files.
Electronic Shock Protection
• 10 seconds for CDDA (CDA)
• 60 seconds for MP3/WMA recorded at
44.1kHz, 128kbps
Bit Rates
The unit supports bit rates from 32 - 320 kbps.
File Playing Order
When selected for play, files and folders (Folder
Search, File Search or Folder Select) are
accessed in the order they were written by the
CD writer. As a result, the order in which they
are expected to be played may not match the
order in which they are actually played.
You may be able to set the order in which MP3/
WMA are to be played by writing them onto a
disc such as a CD-R with their file names
beginning with play sequence numbers such as
"01" to "99".
For example, a disc with the following folder/file
hierarchy is subject to Folder Search, File
Search or Folder Select as shown below.

BT1613
12
MP3/WMA OPERATION
Pause
Press the 1 >/|| button (19) to suspend disc
play. Press the play/pause button again to
resume play.
Track Select
Press the >>| (14) or |<< (13) button for less
than one second to advance to the next track
on the disc, or press and hold to fast forward or
fast reverse through the disc. Disc play starts
when the button is released.
Navigating Folders
Press the 5\/ and 6/\ buttons (23, 24) to select
the next or previous folder/directory.
Intro Scan (INT)
During disc play, press the 2 INT button (20) to
play the first 10 seconds of each track on the
disc. When the desired track is reached, press
2INT again to end the scan and play the
selected track.
Repeat (RPT)
Press the 3 RPT button (21) to repeatedly play
the current file. Press 3RPT again to resume
normal playback.
Random (RDM)
Press the 4 RDM button (22) to randomly play
all files on the disc. Press 4RDM again to
resume normal playback.
BT1613
19
10
8
5
16 27
6
43
2
14
25
13
17
19 22
20
21
23 24
18
15
11 12
7
LIFT
PS/AS

BT1613
13
MP3/WMA File or Folder Search
The unit offers two methods of searching for
files or folders:
Direct File Number Search
Press the BAND button (5). The LCD will
display "Number". Turn the AUDIO CONTROL
to select the desired track number, then press
the AUDIO CONTROL to confirm and play the
selected file.
Navigation Search
Press the BAND button (5) twice. The LCD will
display "File". Turn the AUDIO CONTROL to
navigate through all folders and sub-folders on
the disc. The folder names will be displayed on
the LCD. Press the AUDIO CONTROL to
access the sub-folders or files. Turn the AUDIO
CONTROL to navigate, then press the select
knob to confirm and begin file play. During
navigation search, turn the AUDIO CONTROL
counter-clockwise to return to the previous
folder level.
Display Information
Press the DISP button (9) to display the clock
or available ID3 information, as follows: song
title, directory name, artist name, etc.

BT1613
14
USING A USB DEVICE OR SD CARD
Loading a USB Device
USB devices can be played through the USB
connector on the front panel. To access files on
a USB device, insert the USB device as
indicated below:
After inserting an USB device containing MP3
or WMA files, “USB HOST” appears on the
display and the unit will automatically scan the
card for music files and begin playback.
To eject the USB device, press the SRC button
(2) to select a different source. Pull the USB
device straight out and return the cover to the
closed position.
Loading an SD Card
To insert an SD card, you must first remove the
front panel to reveal the SD card slot (see
“Front Panel Release” on page 4). Insert your
SD Card as illustrated below and then reinstall
the front panel.
After inserting an SD card containing MP3 or
WMA files, “SD/MMC” appears on the display
and the unit will automatically scan the card for
music files and begin playback.
To eject the SD card, remove the front panel
and then press in on the SD card to release it.
Pull the SD card straight out and replace the
front panel.
Navigating Files
Please refer to “MP3/WMA Operation” on
page 12 for information regarding directory
navigation and file searching.
Copying Music
Your BT1613 is equipped with a Copy feature
that allows you to copy an MP3 or WMA file to
an SD/MMC card or USB device. To copy
music, perform the following steps:
1. Insert a disc and select the track you
would like to copy.
2. Press the COPY button (25) to activate the
Copy feature.
3. Turn the AUDIO CONTROL (3) to select
the USB or CARD (SD/MMC) source.
4. Press the AUDIO CONTROL button (4) to
begin copying.
• The unit will begin copying the
current file, starting at the beginning
of the track. The LCD will display
“>>> ##”. Copying will stop at the
end of the file.
• The recorded information is stored in
a folder named “MY_MP3” or
“MY_WMA” on the destination
source.
• Copying will stop and the unit will
display “Memory Full” if the selected
storage device is full.
To stop copying before the file is complete,
press the COPY button. The LCD will display
“STOP” and the incomplete track will be deleted
from the destination folder.
RESET

BT1613
15
NOTE: Never remove a USB device during
recording or music transfer. This may
damage the device or cause the system to
lock up. Do not switch modes or turn the
radio power or ignition off while recording.
Erasing Copied Files
You can erase copied files from a USB device
or SD/MMC card while the file is playing, or
after selecting the file in Number Search or
Navigation Search mode. To erase a file,
perform the following steps:
1. Press and hold the BAND button (5) to
activate the Erase function. The LCD will
display “ERASE 010”.
2. Press the AUDIO CONTROL button (4) to
select Erase mode.
3. Turn the AUDIO CONTROL (3) and select
“Y” to erase (or select “N” to cancel the
erase function).
4. Press the AUDIO CONTROL button to
confirm. The file will stop playback (if
playing) and will be erased. When
finished, the system will display
“ERASE OK”.
File Management
Music recorded or transferred using the
BT1613 will be stored in the default folders
listed below:
• MY_MP3: Transferred MP3 files.
• MY_WMA: Transferred WMA files.
Recorded/transferred music is stored in the
corresponding folder and given the following
naming convention: “XX0001.MP3”, where XX
is the name of the source (i.e. SD0001.MP3).

BT1613
16
iPod OPERATION
Accessing iPod Mode
This unit is equipped with an iPod ready
function that will allow you to control and charge
your iPod (if compatible) using the front panel
control buttons.
The unit will automatically switch to iPod mode
when an iPod is plugged into the iPod cable.
To return to the iPod menu from any other
source menu, press the SRC button (2) on the
front panel or remote control until “iPod”
appears on the display.
NOTE: The BT1613 will not select video files
regardless of whether or not a video file was
the last file playing when the iPod was
plugged into the radio. Only music files are
supported.
Turning the iPod On/Off
The iPod power turns on automatically when
the iPod is connected to 30-pin iPod cable, as
long as the automobile ignition is turned on.
You can turn the iPod off by disconnecting it
from the cable or by turning the ignition off.
When the ignition is turned off, the iPod will
pause and then enter sleep mode after 2
minutes. The iPod cannot be turned on/off from
the iPod itself while connected.
NOTE: The iPod will continuously recharge
when connected to unit, as long as the
vehicle ignition is turned on.
Viewing Playback Information
Press the PS/AS button (17) to display iPod
playback information in the following order:
• Song Title
•Artist
•AlbumName
•ElapsedTime
Play/Pause
Press the 1 >/|| button (19) to suspend or
resume play.
Track Selection
Select a Track
Press the >>| (14) or |<< (13) button for less
than 1 second to advance to the next song in
the current folder.
Fast Forward / Fast Reverse
Press and hold the >>| (14) or |<< (13) button
button for more than 1 second to fast forward or
fast reverse. Playback begins when the button
is released.
Repeat (RPT)
Press the 3 RPT button (21) during disc play to
continuously repeat the selected song. Press
3RPT again to stop the repeat function.
Press and hold the 3 RPT button (21) for more
than 3 seconds to continuously repeat the
entire album/folder. Press and hold 3 RPT
again to stop the repeat function.
iPod
photo iPod iPod mini iPod nano
HEAD UNIT
8 Din iPod Ready Cable
iPod Cable

BT1613
17
Shuffle (RDM)
Press the 4 RDM (22) button to randomly play
all files in the current folder/album. Press
4 RDM again to resume normal play. Press and
hold 4 RDM for more than three seconds during
iPod playback to randomly play the songs in all
folders. Press 4 RDM again for more than three
seconds to resume normal play.
Searching Mode
During iPod playback mode, press the BAND
button (5) to enter iPod Searching Mode. Press
the BAND button repeatedly to access search
modes in the following order:
• Playlist
•Artist
• Album
• Song
•Genre
After selecting the desired search mode, press
the AUDIO CONTROL button (4) within 10
seconds to confirm the search mode. Rotate
the rotary encoder knob to navigate through the
Album, Artist or Songs contained on your iPod.
Press the AUDIO CONTROL to play the
selected song. During the searching mode,
press PS/AS to quickly return to the top level of
the Album, Playlist, Genre, etc.

BT1613
18
BLUETOOTH OPERATION
Before attempting to use the Bluetooth
functions on the BT1613, please make sure
your mobile phone supports Bluetooth functions
(Headset or Handsfree profiles or both). Adhere
to the following guidelines for successful
operation.
• Before using Bluetooth functions, you
must pair your mobile phone to the
BT1613 head unit. (See “Pairing the
Bluetooth system with your Mobile Phone
and Head Unit” on page 18.) To ensure the
best reception for pairing and re-
connection, please make sure the phone
battery is fully charged before you begin.
• Try to perform pairing within a few minutes
of the phone being turned on.
• Once the unit has been paired with the
phone, “BT60A” will be displayed on the
mobile phone.
• To achieve the best performance, always
keep the mobile phone within 3 meters of
the head unit.
• Always keep a clear path between the
mobile phone and the head unit. Never
place a metal object or any other obstacle
between the mobile phone and the head
unit.
• Some mobile phones (like Sony Ericsson)
may have a "Power Saving Mode" option.
PLEASE DO NOT use the Power saving
Mode with the BT1613.
• Before accepting or making a call, make
sure your mobile phone's “Bluetooth
function” is turned on.
• To ensure the best conversation quality/
performance, stay within one meter of the
head unit when talking.
• To “disconnect” the mobile phone from the
head unit, turn the Bluetooth connectivity
off on the mobile phone or use the DIS-
CON (disconnect) feature under the
System Menu (see “RE-CON/DIS-CON”
on page 3).
• While talking in Telephone mode, it is
recommended that you set the main
volume level below “30”. A higher volume
setting may create an unwanted echo in
the vehicle that can feed back into the
microphone.
• If you have difficulty pairing or the
Bluetooth operation is not functioning
properly, you can try a “soft reset” by
removing the front panel (see “Front Panel
Release” on page 4) and waiting 1 minute.
If after reattaching the panel, operation
has not resumed normally, you can
perform a complete system Reset (see
“Reset Button” on page 5).
Pairing the Bluetooth system
with your Mobile Phone and
Head Unit
1. Press and hold the DISP button (9) to
access the MENU. “PAIR HF” is the first
option on the menu.
2. Press the AUDIO CONTROL button (4) to
initiate the pairing process. Keep the
mobile phone within 2 meters of the unit
during pairing.
3. Refer to the instructions that came with
your mobile phone to activate the
Bluetooth function and search for devices.
4. Select “BT60A” from the pairing list on the
mobile phone.
5. Enter “1234” as the password.
• If pairing is successful, the display
will show your device name.
• If pairing fails, “PAIR FAIL” is flashed
on the display for 3 seconds, and
then the unit will revert to the
previous operation automatically. If
pairing fails, repeat the above steps.
NOTE: During Pairing, only the Power,
Volume +/-, B (Clear) and Mute keys are
functional. Other keys are disabled during
pairing mode.
