PHC PHC17F Installation guide

Grounding:
Thismachinemustbegroundedwhileinusetoprotecttheoperatorfromelectricalshock. The
machine is equipped with an approved three-conductor cord and three-prong grounding type
plug to fit the proper grounding receptacle. The green (or green and yellow) conductor in the
cord is the grounding wire. Never connect the green (or green and yellow) wire to a live ter-
minal.
Warning:
Never operate a machine that is not properly grounded.
If it is for use on 150 to 250 volts, it has a plug like that shown in Figure D.
An adapter, Figures B & C, is available for connecting Figure Aplugs to two-plug receptacles.
The green-colored rigid ear, plug etc., must be connected to a permanent ground, such as a
properly grounded outlet box. No adapter is available for a plug as shown in Figure D.
Adapter shown in Figures B & C is not for use in Canada.
Motor:
This machine is powered by a 1 HP (model E) or 1.5 HP (model F) AC motor. Be sure your
power supply agrees with the voltage marked on nameplates. Incorrect voltage will cause the
motor to draw excessive current resulting in motor burn-out or blown fuse or circuit breaker.
Extension Cords:
Machines that have 3 wire cords requiring grounding must only be used with extension cords
that have 3-prong grounding type plugs and 3-pole receptacles. Use only three-wire exten-
sion cord.
To determine the minimum wire size required, refer to the chart below:
Chart for minimum wire size (AWG) of extension cord
Nameplate Total Extension Cord Length - Feet
Before using an extension cord, inspect it for loose or exposed wires, damaged insulation and
defective plugs.
CAUTION:
Always disconnect power cable from electrical outlet before working
on this machine.
PHC17F, PHC20F
Floor Machines
This floor
machine is a high
quality, precision
made product. All parts used in manufacturing this floor
machine have passed rigid quality control standards prior to
assembly and an “each unit” final inspection prior to packag-
ing is your assurance of proper assembly. This floor machine
is protectively packed to prevent possible damage in transit.
Should damage have occurred, please file a claim emmediat-
ly with the carrier who delivered the product to you. You must
file the freight damage claim. We, as the shipper, cannot do
this for you.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS:
CAUTION:
Service and repair should be performed only by a qualified technician.
Call 1-800-237-7582 for the location of your nearest Authorized Service Center.
OPERATION & CARE
INSTRUCTIONS
Rating -
Amps
0-10.0
10.1-13.0
13.1-15.0
25
18
16
12
50
18
16
12
75
16
14
12
100
16
14
12
125
14
14
12
150
14
12
12
175
12
12
12
200
12
12
PHC

To Assemble:
See instructions, page 3.
To Adjust Handle:
The handle adjustment is controlled by a “star latch” located at the rear of the
machine near the bottom of the handle pipe. To release, turn the knob
counter-clockwise or by applying foot pressure to the lower portion of the
knob. When a convenient handle location for machine operation has been
found, lock the handle in place by turning the star knob clockwise to tighten.
When transporting the machine or attaching brush/pad be sure the handle is
LOCKED in the upright position. NEVER TURN ON THE MACHINE WITH
HANDLE IN THE UPRIGHTLOCKED POSITION.
Brush Attachment and Removal:
Figure 1 To attach brush To remove brush
With cable unplugged,LOCKhandleinuprightpositionand tilt machine back
on the handle until the underside of the machine is fully exposed. Select the
desired brush, scrub or drive, and position the three slots of the clutch plate
over the three lugs of the gearbox. Turn the brush as shown in Fig. 1 as far
as it will go. The brush is now seated in ready-to-use position. TO
REMOVE BRUSH, disengage clutchplate slots from the gearbox by turn-
ing clockwise. DO NOT OPERATE THIS MACHINE WITHOUT
SCRUB BRUSH OR DRIVE BRUSH AND PAD IN PLACE.
NEVER POSITION RUNNING MACHINE OVER AN UNAT-
TACHED BRUSH.
To Attach a Pad:
Ifapadistobeused,apad drive (not a scrubbingbrush)mustfirstbeinstalled
asshown in the preceding paragraph. Placethe pad on the brushbristles and
push the pad firmly onto the brush. Be sure the pad is properly centered on
the brush.
To Start:
With the power cable plugged into a proper outlet, release safety latch and
squeeze the switch bar beneath the handle grips. This machine is equipped
with a mechanical safety lockout on the left handle bar to prevent accidental
startup. The lockout must be pushed forward with the operators left thumb
before the switch bar can be moved.
To Operate Safety Latch:
The operator must manually rotate the latch with the left thumb before the trig-
gercan be depressedto start brush rotation. When the trigger isreleased, the
safety latch snaps back into position. This will prevent accidental machine
startup.
CAUTION: Machine will immediately veer to one side. Be
prepared to control action.
To Operate:
This machine is designed to move from side to side. To guide right, raise the
handle slightly. The higher the handle is raised, the faster the machine will
move to the right. Conversely, to guide left, lower the handle. The more the
handle is lowered, the faster the machine will move to the left. WARNING:
DO NOT LEAVEA PLUGGED IN MACHINE UNATTENDED.
Care and Maintenance:
This machine will afford you many years of trouble free service provided it is
given proper care. Throwing, dropping, bumping across thresholds and other
misuse may result in a damaged unit and invalidate the warranty. For best
results, use a clean pad and change frequently as pad loads up. When stor-
ing your floor machine, always remove the pad and brush.
Pads can be cleaned by washing in warm water and a mild detergent, rinsing,
and hanging up to dry.
Do not lubricate this machine. Lubrication has been applied and permanent-
ly sealed at the factory.
Machine Serial Number:
To obtain qualified service, you may need the serial number of the machine
when requesting service under warranty or when ordering certain parts. The
serial number is found on the data plate located on the machine chassis, not
on the motor data plate.
Brush, Floor Machine and
Burnisher Size Determination:
The numerals contained within the machine model designation indicate the
nominal machine size. In all cases the nominal size is determined by the full
spread of the bristles of a long bristle scrub brush on a floor surface when
underthe weight of a floormachine. The spread of a short or stiff bristlebrush
will be somewhat less. The brush block diameter will always be two (2) inch-
es less than the nominal brush size, i.e., a 20” brush will have an 18” diame-
ter block. In like manner, the opening on the underside of a machine will be
about 1 to 1.5 inches smaller than the nominal machine size, i.e., a 20”
machine will have an opening of about 18.5 to 19 inches in diameter.
Warning: Connect power cord only to an electrical
supply the same as shown on the motor data plate.
Connecting to the wrong voltage supply will result in dam-
age not covered by warranty and may cause personal
injury.
NOTE: 220 volt machines are shipped without a plug on the
end of the power cord due to the many styles of 220 volt
plugs in use. Have a qualified electrician attach the proper
plug for your location to the cord end.
Warning of Potential Injury:
Moving Parts - To reduce the risk of injury, unplug before
servicing.
Fire or Explosion - Do not operate machine in the vicinity of
flammable or explosive vapors. Never use
flammable liquid to clean a floor.
ABOUT THE FLOOR MACHINE

Place the machine chassis on a
bench or floor with the handle
tee stem and the hole in the
clamp approximately in line.
Position the handle pipe above
the clamp with the decal on the
switch box facing forward.
Push the handle pipe through
clamp and over the handle tee
stem until the screw holes in the
pipe and stem are in alignment.
Insert (2) flat head screws
through the holes in the pipe
and stem with the screw heads
facing toward the front of the
machine. Assemble the (2) lock
nuts to the screws with the lock
washer facing toward the pipe.
Tighten the screws and nuts
securely with the hex wrench
provided.
Plug the motor cord into the
handle cord and push the neo-
prene sleeve over the plugs to
seal the plug joint from water
entry. Lightly coat the plug sur-
faces with dishwashing deter-
gent to allow the sleeve to slide
freely.
Ponga el chasis de la maquina
encima de un banco o en el
piso. Alineando la manija con el
centro de la abrazadera,
coloque el mango encima de la
abrazadera con la calcomania
hacia el frente.
Empuje el tuvo de el mango a
traves de la abrazadera y colo-
quelo en la manija, alineando
los huecos de los tornillos.
Introduzca (2) tornillos de
cabeza plana en los huecos del
tubo y la manija, haciendo esto
de alante hacia atras de la
maquina. Luego ensamble las
arandelas y las tuercas (aran-
dela primero y segundo la tuer-
ca).
Apriete los tornillos y tuercas
con la llave proveida con la
maquina.
Conecte el enchufe del cable
electrico del motor al del cable
electrico del mango. Luego
lubrique (con liquido detergente)
los enchufes en la superficie,
para que pueda deslizar la
cubierta que proteje los mismos
contra el agua o humedad.
handle pipe
mango
handle pipe
mango
handle tee
manija
clamp
abrazadera
clamp
abrazadera
screw
tornillo
nut
tuerca
hex wrench
llave
sleeve
cubierta
plugs
enchufes
handle tee
manija
washer
arandela
1
2
3
4
5
IMPORTANT INSTRUCTIONS!!
INSTRUCCIONES IMPORTANTES!!

TROUBLE SHOOTING GUIDE:
PROBLEM
Machine won’t start.
Machine starts but won’t reach or hold running speed
(may be accompanied by a “clicking” noise).
Machine trips building circuit breaker
Circuit breaker in machine switch box trips
(burnishers only).
Operator feels A shock or “tingle” when operating
Machine.
WARNING: This complaint usually indi-
cates an electrical defect which can
result in serious personal injury. Do not
continue to operate the machine until
corrective action has been completed.
Machine “bogs down” during operation.
POSSIBLE CAUSE
• Power cord not properly plugged
into wall outlet.
• Blown building fuse or tripped
circuit breaker.
• Tripped machine circuit breaker
(burnishers only).
• Damaged power cord or plug.
• Broken connection or wire inside
switch box.
• Failed switch or circuit breaker
(burnishers only) inside switch box.
• Failed motor capacitor.
• Motor pigtail disconnected from
handle cord set.
• Failed motor.
• Failed motor starting switch.
• Building circuit is overloaded.
•An electrical short exists within the
machine.
•Pad is loaded with dirt or floor
finish residue.
• Low electrical supply voltage.
• Undersized extension cord.
REFER TO SECTION:
”MACHINE TRIPS BUILDING CIRCUITBREAKER”
Additional burnisher related possible causes:
• Faulty breaker.
•The handle is locked (on “floating head”
models).
• Using the wring pad.
•Using excessive amount of spray buff or
restorer.
Improper or no ground in wall outlet.
• Ground prong damaged or missing on
power cord.
•Ground (green) wire loose or missing inside
switch box.
• Terminal or uninsulated wire or stray wire
strand in contact with machine frame, handle
pipe, or switch box.
• Machine underpowered for application
EXAMPLE: Using a 3/4 H.P. machine for
carpet scrubbing.
• Undersized extension cord.
• Low electrical supply voltage.
CORRECTION
• Fully engage plug with outlet receptacle.
• Replace fuse or reset circuit breaker.
• Reset circuit breaker.
•Replace with proper 3-wire cord and plug.*
• Tighten connection or replace wire.*
• Replace switch or circuit breaker.*
•Replace capacitor with one identical to the
original.*
•Connect properly and cover joint with
restraint (B525311).
• Repair or replace motor.*
• Replace both rotating and stationary
portions of switch.*
•Remove and turn off other electrical devices
on the same circuit or plug machine into a
different circuit.
• Locate and fix the short.*
• Replace and wash pad.
•Check voltage at wall outlet with an electrical
load on circuit. If less than 108 volts,
building wiring is probably inadequate. Plug
machine into a different circuit.*
•Refer to operation and care instruction for
proper cord size.
• Replace breaker.
•Unlock the handle to allow machine head to
float.
• Use buffing pads only. Never use a scrubbing
or stripping pad.
•Apply these materials very sparingly to a
floor. Excessive amounts are not necessary
and are sticky and resist pad rotation on the
floor.
•Replace plug or entire cord if damaged.*
•Replace or tighten wire.*
•Find and repair damaged or dislocated
conductor.*
• Use properly powered equipment.
•Refer to operation and care instructions for
proper cord size.
•Check voltage at wall outlet, if less than 108
volts under load, plug machine into a
different circuit.
B160719 revised 1/07 * MUST BE PERFORMED BY A QUALIFIED TECHNICIAN.
