IPC CT15 User manual

CT15 - CT15R - CT30 - CT45 - CT46 -
CT15 ECS - Lavamatic 360 -
Lavamatic 460 - Lavamatic 15 -
Lavamatic 30 - Lavamatic 45
(IT) MANUALE ISTRUZIONI PER L’USO / (EN) OPERATOR’S MANUAL /
(FR) MANUEL D’INSTRUCTIONS / (DE) BEDIENUNGSANLEITUNG /
(ES) MANUAL DE INSTRUCCIONES / (NO) BRUKERHÅNDBOK /
(NL) GEBRUIKERSHANDLEIDING / (PT) MANUAL DE UTILIZAÇÃO /
(SE) INSTRUKTIONSBOK / (RU) РУКОВОДСТВО ОПЕРАТОРА /
(BG) РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ / (CN) 操作手册 /
Consultare attentamente questo manuale prima di procedere a qualsiasi intervento sulla macchina
Read this manual carefully before carrying out any work on the machine
Lire attentivement ce manuel avant toute intervention sur la machine
Vorliegendes Handbuch vor jedem Eingri󰀨 an der Maschine aufmerksam durchlesen
Consulte detenidamente este manual antes de llevar a cabo cualquier trabajo en la máquina
Konsulter denne håndboken nøye før du går i gang med noen som helst type inngrep på maskinen
Raadpleeg deze handleiding aandachtig alvorens met enige werkzaamheid aan de machine te beginnen
Consulte atentamente este manual antes de efectuar qualquer intervenção na máquina
Läs noggrant igenom denna handbok innan du utför något som helst ingrepp på maskinen
Прочетете внимателно това ръководство, преди да започнете работа с машината
Внимательно ознакомьтесь с данной инструкцией до проведения любой работы с машиной
操作机器之前请认真阅读本手册
(SL) PRIROČNIK Z NAVODILI ZA UPORABO / (SK) NÁVOD NA POUŽITIE /
(PL) PODRĘCZNIK OPERATORA / (HU) HASZNÁLATI ÚTMUTATÓ /
(HR) PRIRUČNIK ZA KORIŠTENJE / (RO) MANUAL DE UTILIZARE /
(CZ) NÁVOD PRO OBSLUHU / (TR) KULLANIM KILAVUZU
Pozorno preberite to navodilo za uporabo, preden se lotite kakršnega koli poseganja v stroj
Tento návod si pozorne prečítajte pred každým zásahom na stroji.
Przed rozpoczęciem pracy z urządzeniem należy uważnie przeczytać niniejszy podręcznik
A géppel történő munkavégzést megelőzően gyelmesen olvassa el ezt az útmutatót
Pažljivo pročitajte ovaj priručnik prije izvođenja bilo kakvih radnji na uređaju.
Citiți cu atenție acest manual înainte de a efectua orice operațiuni asupra mașinii
Před jakoukoli manipulací se strojem si nejdříve pozorně přečtěte tento návod.
Makine ile herhangi bir işlem yapmadan önce bu kılavuzu dikkatle okuyun

GB
ENGLISH
(Translation of original
instructions)
2

CT15 TECHNICAL SPECIFICATIONS ...................................................................5
CT30 TECHNICAL SPECIFICATIONS ...................................................................7
CT45 TECHNICAL SPECIFICATIONS ...................................................................9
CT46 TECHNICAL SPECIFICATIONS ..................................................................11
MACHINE DIMENSIONS.......................................................................................13
SAFETY SYMBOLS...............................................................................................15
Battery charger.....................................................................................................16
Figure.....................................................................................................................17
GENERAL INFORMATION....................................................................................24
Scope of the manual .....................................................................................................................24
Identifying the machine .................................................................................................................24
Documentation provided with the machine ...................................................................................24
TECHNICAL INFORMATION.................................................................................25
General description ....................................................................................................................... 25
Legend ..........................................................................................................................................25
Danger zones ................................................................................................................................25
Accessories ...................................................................................................................................25
SAFETY INFORMATION .......................................................................................25
Safety regulations ......................................................................................................................... 25
HANDLING AND INSTALLATION.........................................................................27
Lifting and transporting the packaged machine ............................................................................ 27
Checks on delivery ........................................................................................................................28
Unpacking .....................................................................................................................................28
Electrical connections and earth (cable models)........................................................................... 28
Power supply batteries (battery models) .......................................................................................28
Batteries: preparation ....................................................................................................................28
Batteries: installation and connection............................................................................................ 29
Batteries: removal .........................................................................................................................29
Battery charger (battery models)................................................................................................... 29
Choosing a battery charger (machines without ON-BOARD battery charger) .............................. 29
Preparing the battery charger ....................................................................................................... 30
Lifting and transporting the machine ............................................................................................. 30
PRACTICAL GUIDE FOR THE OPERATOR.........................................................30
Controls - Description.................................................................................................................... 30
Mounting and adjusting the squeegee ..........................................................................................31
To move the machine, proceed as follows: ................................................................................... 32
Mounting and changing the brush/drive disks ............................................................................... 32
Detergents - Instructions ............................................................................................................... 32
Preparing the machine for work .................................................................................................... 33
Working ......................................................................................................................................... 33
At the end of work: ........................................................................................................................ 34
Some useful tips to get the most from your scrubber drier .......................................................... 34
Carpet accessory .......................................................................................................................... 34
Combi accessory........................................................................................................................... 35
Draining the dirty water ................................................................................................................. 35
Draining the clean water ............................................................................................................... 35
PERIODS OF INACTIVITY ....................................................................................35
BATTERY MAINTENANCE AND CHARGING ......................................................36
MAINTENANCE INSTRUCTIONS.........................................................................36
Maintenance - General rules ......................................................................................................... 36
Routine maintenance .................................................................................................................... 36
Squeegee blades: replacing ......................................................................................................... 37
Fuses: replacement (battery models) (Fig. L) ............................................................................... 37
Fuses: replacement (cable models) (g. M) .................................................................................. 37
Routine maintenance .................................................................................................................... 37
Six monthly operations .................................................................................................................. 38
TROUBLESHOOTING ..........................................................................................38

How to resolve possible problems ................................................................................................ 38
Error codes displayed, battery version .......................................................................................... 40

GB
CT15 TECHNICAL SPECIFICATIONS
CT15 B35
CT15 B35 ECS
CT15 C35
CT15 B35 R CT15 C35 R
Cleaning width mm 355 360 360
Squeegee width mm 450 430 430
Cleaning capacity per hour m2/h 1300 1300 1300
Number of brushes n° 1
Brush diameter mm 355 100
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 140 600 140 1120 820
Brush motor power W 200 450 250 250 370
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 200 400 550 400
Solution tank L 15
Dirty water tank L 16,5
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 95 95 52,5 74,5 69,5
Transported weight Kg 36 36 15 36 15
Number of batteries n° 2 2 /2/
Battery voltage V 12 12 /12 /
Individual battery capacity Ah (5h) 29 /29 /
Power system voltage V 115 - 240 115 - 240 115 115 - 240 115
220 220
Machine dimensions mm
X=790
Z=1180
Z1=690
Y=468
X=750
Z=1180
Z1=690
Y=435
X=750
Z=1180
Z1=690
Y=435
Battery compartment dimensions
(length, width, height) mm 205x265x205 /205x265x 205 /
Packed size (length, width, height) mm 800x450x640 900x610x960
Sound pressure (EN 60704) LpA
(dBA) ≤70 ≤70 ≤70 72 74
Measurement uncertainty K
(dBA) 2,5 2,5 2,5 2,5 2,5
5

GB
Vibration level (hand) (IEC 60335-2-72) ahv
m/sec2≤2,5 ≤2,5 ≤2,5 ≤2,5 ≤2,5
Measurement uncertainty, k m/sec20,5 0,5 0,5 0,8 0,8
Vibration level (body) HBV
m/sec2/////
Measurement uncertainty, k m/sec2/////
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 /100 - 240 /
Hz 50 - 60 /50 - 60 /
Power supply frequency Hz / / 50 - 60 /50 - 60
Power supply V 24 24 115 - 240 24 115
110 - 240
Rated power W 750 650 650 800 770
Rated current A 31 27 6,6 - 2,8 33 6,7
3,3
Gross weight: maximum allowable weight with the machine fully loaded and ready for use. The
gross weight of the vehicle includes, when applicable, full clean water tanks, empty dirty water tanks
(half full in the case of recycling systems), empty dust bags, the hopper lled to its rated capacity,
the largest recommended batteries and all accessories such as cables, hoses, detergent, mops
and brushes.
Transported weight: the weight of the machine including the batteries, but excluding optionals (for
example, the operator’s cabin, FOPS, second and third side brushes and front brush attachment),
fresh water (in the case of scrubbers or combined machines) and the weight of a standard operator
(75 kg)
Data subject to variation without warning.
6

GB
CT30 TECHNICAL SPECIFICATIONS
CT30 B45 CT30 C45
Cleaning width mm 455
Squeegee width mm 545
Cleaning capacity per hour m2/h 1670
Number of brushes n° 1
Brush diameter mm 455
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 140 140
Brush motor power W 350 400
Drive motor power W /
Maximum speed Km/h /
Suction motor power W 550 400
Solution tank L 28
Dirty water tank L 30
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 126 81
Transported weight Kg 76 28
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 100-240 115
220
Machine dimensions mm
X=850
Z=1220
Z1=745
Y=568
Battery compartment dimensions
(length, width, height) mm 240x330x220 /
Packed size (length, width, height) mm 900x610x960
Sound pressure (EN 60704) LpA
(dBA) ≤70 72
Measurement uncertainty K
(dBA) 2,5 2,5
7

GB
Vibration level (hand) (IEC 60335-2-72) ahv
m/sec2≤2,5 ≤2,5
Measurement uncertainty, k m/sec20,5 0,5
Vibration level (body) HBV
m/sec2/ /
Measurement uncertainty, k m/sec2/ /
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 /
Hz 50 - 60 /
Power supply frequency Hz /50 - 60
Power supply V 24 115 - 240
Rated power W 900 940
Rated current A 37,5 7 - 4,4
Gross weight: maximum allowable weight with the machine fully loaded and ready for use. The
gross weight of the vehicle includes, when applicable, full clean water tanks, empty dirty water tanks
(half full in the case of recycling systems), empty dust bags, the hopper lled to its rated capacity,
the largest recommended batteries and all accessories such as cables, hoses, detergent, mops
and brushes.
Transported weight: the weight of the machine including the batteries, but excluding optionals (for
example, the operator’s cabin, FOPS, second and third side brushes and front brush attachment),
fresh water (in the case of scrubbers or combined machines) and the weight of a standard operator
(75 kg)
Data subject to variation without warning.
8

GB
CT45 TECHNICAL SPECIFICATIONS
CT45 B50
CT45 BT50
CT45 C50
Cleaning width mm 500
Squeegee width mm 730
Cleaning capacity per hour m2/h 1750
Number of brushes n° 1
Brush diameter mm 500
Maximum brush pressure g/cm2/
Brush rotation speed g/1° 160 140
Brush motor power W 400 450
Drive motor power W 180
Maximum speed Km/h 3,5
Suction motor power W 550 400
Solution tank L 40
Dirty water tank L 45
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 140 145 105
Transported weight Kg 88 88 40
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 100-240 115
220
Machine dimensions mm
X=980
Z=1290
Z1=806
Y=715
Battery compartment dimensions
(length, width, height) mm 265x335x255 /
Packed size (length, width, height) mm
Sound pressure (EN 60704) LpA
(dBA) 72 72 72
Measurement uncertainty K
(dBA) 2,5 2,5 2,5
Vibration level (hand) (IEC 60335-2-72) ahv
m/sec2≤2,5 ≤2,5 ≤2,5
9

GB
Measurement uncertainty, k m/sec20,6 0,6 0,4
Vibration level (body) HBV
m/sec2///
Measurement uncertainty, k m/sec2///
Maximum water and detergent
temperature °C 4 - 55
Battery charger
V 100 - 240 /
Hz 50 - 60 /
Power supply frequency Hz / / 50 - 60
Power supply V 24 24 115 - 240
Rated power W 950 1130 980
Rated current A 39,5 47 7 - 4,4
Gross weight: maximum allowable weight with the machine fully loaded and ready for use. The
gross weight of the vehicle includes, when applicable, full clean water tanks, empty dirty water tanks
(half full in the case of recycling systems), empty dust bags, the hopper lled to its rated capacity,
the largest recommended batteries and all accessories such as cables, hoses, detergent, mops
and brushes.
Transported weight: the weight of the machine including the batteries, but excluding optionals (for
example, the operator’s cabin, FOPS, second and third side brushes and front brush attachment),
fresh water (in the case of scrubbers or combined machines) and the weight of a standard operator
(75 kg)
Data subject to variation without warning.
10
