Phcbi MPR-715F Series User manual

MPR-715FSeries
Please read the operating instructions carefully before using this product, and keep the operating
instructions for future use.
See page 46 for all model numbers.
Operating Instructions
Pharmaceutical Refrigerator

2
Table of contents
Introduction ················································································P.3
Precautions for safe operation ·······················································P.4
Symbols for warning and caution ····································· P.4
Warning and caution for handling the unit ·························· P.5
Environmental conditions·······························································P.8
Precautions and action for temperature rise ·····································P.9
Precautions for temperature rise ····································· P.9
Action for chamber temperature rise ································P. 10
Check of enclosures···································································· P.11
Refrigerator components ·····························································P.12
Main body····································································P.12
Control panel ······························································P.14
Installation location ····································································P.16
Installation ···············································································P.17
Start-up procedure ······································································P.18
Handling of storage items ····························································· P.19
Initial setting, setting range and function code ··································P.19
During/after power failure······························································P.20
Setting of chamber temperature ····················································P.21
Lock of chamber temperature setting ············································· P.22
Stop of freezer operation ····························································· P.23
Procedure to stop the freezer operation ······························P. 23
Procedure to resume the freezer operation ························P.24
Defrost ·····················································································P.25
Defrost in refrigerator······················································P.2 5
Defrost in freezer ···························································P.2 5
Setting of alarm temperature ························································P.26
Setting of high temperature alarm (refrigerator) ····················P.2 6
Setting of low temperature alarm (refrigerator) ·····················P. 27
Setting of high temperature alarm (freezer)··························P.2 8
Setting of low temperature alarm (freezer)···························P.2 9
Setting of buzzer suspended period ··············································· P.30
Troubleshooting··········································································P.31
Action for alarm ··········································································P.33
Action for alarm with error code ···················································· P.34
Action for maintenance code ························································P.34
Safety functions·········································································· P.35
Routine maintenance ·································································P.36
Guideline for maintenance ·············································P.3 6
Stop of operation at maintenance ····································P.3 6
Cleaning exterior, interior and accessories ··························P. 37
Checking power supply cord ···········································P.3 7
Checking temperature recorder (option) ····························P. 37
Replacement of wear-out parts ····················································· P.38
Replacing the battery for power failure alarm ·····················P. 38
Replacing the fan motor for cooling circuit ·························P.3 8
Important aspects when disposing of unit ········································ P.39
Refrigerant···································································P.3 9
Temperature recorder (option) ·······················································P.44
Battery mounting box (option)························································P.44
Specifications ··········································································· P.45
Structural specifications ·················································P.4 5
Functional specifications ················································P.4 6
Performance specifications ············································P.46
Safety check sheet (for copy) ·······················································P.47

3
INTRODUCTION
Read the operating instructions carefully before using the appliance and follow the instructions for safe
operation.
Handling of Operating Instructions
PHC Corporation never guarantees any safety if the appliance is used for any objects other than
intended use or used by any procedures other than those mentioned in the operating instructions.
Keep the operating instructions in an adequate place to refer to it as necessary.
Contact our sales representative or agent if any page of the operating instructions is lost or page
order is incorrect.
Contact our sales representative or agent if any point in the operating instructions is unclear or if
there are any inaccuracies.
The operating instructions is only for the pharmaceutical refrigerator MPR-715F made by PHC Corporation.
The contents are subject to change without notice.
No part of the operating instructions may be reproduced in any form without the expressed written permission
of PHC Corporation.
Proposal for safe storage of freezer contents
This pharmaceutical refrigerator can store the medical or biological material in the low temperature
environment. We can offer some precautions below to protect the valuable material against
accidental temperature rise. Contact our sales representative or agent for the details or installation.
▪Temperature recorder (Option)
▪Battery mounting box (Option)
▪Remote alarm system (Marketed product)
<Intended Use>
This equipment is designed for storage of pharmaceuticals, samples and reagents.

4
PRECAUTIONS FOR SAFE OPERATION
It is imperative that the user complies with the operating instructions as it
contains important safety advice.
Items and procedures are described so that you can use this unit correctly and safely. If the
precautions advised are followed, this will prevent possible injury to the user and any other person.
Symbols for warning and caution
The warning and caution regarding to the safety is indicated with the following indications and symbols
in this manual and on the product. Always check and follow the indications.
Degree and indication of risk/damage
Precautions are illustrated in the following way. Never fail to follow the instructions since both
precautions are important item regarding to the safety.
WARNING Failure to observe WARNING signs could result in a hazard to
personnel possibly resulting in serious injury or death.
CAUTION Failure to observe CAUTION signs could result in injury to
personnel and damage to the unit and associated property.
Symbol shows;
This symbol means caution.
This symbol means an action is prohibited.
This symbol means an instruction must be followed.
Warning for electric shock (label on the product)
This mark is labeled on the cover in which the electrical components of
high voltage are enclosed to prevent the electric shock. Never remove
the cover.
Warning for caution (label on the product)
This symbol indicates that caution is required. Refer to product
documentation for details.
Caution for hot surface (label on the product)
This mark is labeled on the surface of which around surface becomes hot.
Take care of the burn injury.

5
Warning and caution for handling the unit
WARNING - Installation ▪Use ▪Stop -
Do not use the unit outdoors.
Current leakage or electric shock may result if the unit is exposed to rain water.
Only qualified engineers or service personnel should install the unit.
The installation by unqualified personnel may cause electric shock or fire.
Install the unit on a sturdy floor and take an adequate precaution to prevent the
unit from turning over.
If the floor is not strong enough or the installation site is not adequate, this may result in
injury from the unit falling or tipping over.
Never install the unit in a humid place or a place where it is likely to be splashed
by water.
Deterioration of the insulation may result which could cause current leakage or electric
shock.
Never install the unit in a flammable or volatile location.
This may cause explosion or fire.
Never install the unit where acid or corrosive gases are present.
The current leakage or electric shock may result due to corrosion.
Always ground (earth) the unit to prevent electric shock.
If the power supply outlet is not grounded, it will be necessary to install a ground
by qualified engineers.
No earth may cause electric shock.
Never ground the unit through a gas pipe, water main, telephone line or lightning
rod.
Inadequate grounding may cause electric shock in the case of an incomplete circuit.
Connect the unit to a power source as indicated on the rating label attached to
the unit.
Use of any other voltage or frequency other than that on the rating label may cause fire
or electric shock.
Never store volatile or flammable substances in this unit if the container cannot
be sealed.
These may cause explosion or fire.
Do not insert metal objects such as a pin or a wire into any vent, gap or any
outlet on the unit.
This may cause electric shock or injury by accidental contact with moving parts.
Use this unit in safe area when treating the poison, harmful or radiate articles.
Improper use may cause bad effect on your health or environment.
Turn off the power switch and disconnect the power supply to the unit prior to
any maintenance of the unit.
Failure to follow this may cause electric shock or injury.
Do not touch any electrical parts (such as power supply plug) or operate
switches with a wet hand.
This may cause electric shock.

6
PRECAUTIONS FOR SAFE OPERATION
Ensure you do not inhale or consume medication or aerosols from around the
unit at the time of maintenance.
These may be harmful to your health.
Never splash water directly onto the unit.
Never put containers with liquid on the unit.
Water or liquid may cause electric shock or short circuit.
Never bind, process, or step on the power supply cord, or never damage or
break the power supply plug.
Do not use the power supply cord if there is something wrong with it.
A broken power supply cord or plug may cause fire or electric shock.
Never disassemble, repair, or modify the unit or optional components yourself.
Any such work carried out by an unauthorized person may result in fire, or electric
shock or injury due to a malfunction.
Disconnect the power supply plug if there is something wrong with the unit.
Continued abnormal operation may cause electric shock or fire.
When removing the power supply plug from the power supply outlet, grip the
power supply plug, not the cord.
Pulling the cord may result in electric shock or fire by short circuit.
Disconnect the power supply plug when the unit is not used for long periods.
Keeping the connection may cause electric shock, current leakage, or fire due to the
deterioration of insulation.
If the unit is to be stored unused in an unsupervised area for an extended period,
ensure that children do not have access and that doors cannot be closed
completely.
Removing doors prevents accidents such as suffocation.
The disposal of the unit should be accomplished by appropriate personnel.
Leaving the unit in an unsupervised area may cause accidents.
Do not put the packing plastic bag within reach of children.
Leaving the packing plastic bag may cause accidents such as suffocation.
Do not position this unit and the other unit so that it is difficult to operate the
disconnection of the power supply plug. Failure to disconnect the power supply
plug may cause fire if there is something wrong with the unit.

7
CAUTION - Power supply, re-start, moving, service call -
This unit must be plugged into a dedicated circuit protected by branch circuit
breaker.
Use a dedicated power source as indicated on the rating label attached to the
unit.
A multiple-tap may cause fire resulting from abnormal heating.
Connect the power supply plug to the power source firmly after removing the
dust on the plug.
A dusty plug or improper insertion may cause a heat or ignition.
Never store corrosive substances such as acids or alkalis in the unit except in a
sealed container.
These may be detrimental to health and may cause corrosion of internal
components, cooling circuit or electrical components.
Check the setting when starting up of operation after power failure or turning off
of power switch.
The stored items may be damaged due to the change of setting.
When moving the unit, contact our sales representative or agent.
The moving by a user may cause damage or injury resulting from tipping over of the
unit.
Prepare a safety check sheet when you request any repair or maintenance for
the safety of service personnel.
Copy the “Safety check sheet” and hand it to service personnel after filling the sheet.

8
ENVIRONMENTAL CONDITIONS
This equipment is designed to be safe at least under the following conditions (based on the IEC
61010-1):
Indoor use;
Altitude up to 2000 m;
Temperature 5 oC to 40 oC
Maximum relative humidity 80 % for temperature up to 31 oC decreasing linearly to 50 % relative
humidity at 40 oC;
Mains supply voltage fluctuations up to ±10 % of the nominal voltage;
Transient overvoltages up to the levels of overvoltage category II;
Temporary overvoltages occurring on the mains supply;
Applicable pollution degree of the intended environment (pollution degree 2 in most cases).

9
PRECAUTIONS AND ACTION FOR TEMP. RISE
Precautions for temperature rise
As a preventive measure, take the following steps to protect the valuable storage items in the chamber
in case the unit should stop operating as a result of unforeseen events (such as a power failure) and its
chamber temperature should rise.
<Important> PHC Corporation guarantees this product under certain warranty conditions.
However, please note that PHC Corporation shall not be responsible for any loss or
damage to the contents of the product.
Dividing the storage items up between a multiple number of freezers
As a preventive measure, divide up valuable storage items and store them in a multiple number of freezers in
case an unforeseen event should occur.
Conducting periodic maintenance and inspection in accordance with a maintenance system (contract
required)
For details on the maintenance system, contact our sales representative or agent.
Installing a battery mounting box (optional component) and preparing to take action to deal with
emergencies
Install a battery mounting box, and also make preparations to deal with emergencies should the product stop
operating as a result of an unforeseen event.
Replacing the battery for power failure alarm (Replacement frequency: Every three years [the F1 and
the chamber temperature display will appear alternately on the temperature display]) [page 38]
The alarm functions will not work when the battery charge is depleted. Contact our sales representative or
agent to replace the battery.
The replacement of the battery for power failure alarm is a paid service.
Installing a remote alarm system (When the product is installed in an unmanned location)
Connect a remote alarm device (sold on the market) to the remote alarm terminals of the product, and install a
remote alarm system to alert the administrator in charge. Contact our sales representative or agent to install the
system.
Replacing the fan motor for cooling circuit (Replacement frequency: Every six years [the F2 and the
chamber temperature display will appear alternately on the temperature display]) [page 38]
When the fan motor for cooling circuit deteriorates, the cooling capability is reduced and the chamber
temperature may rise. Contact our sales representative or agent to replace the fan motor for cooling circuit.
The replacement of the fan motor for cooling circuit is a paid service.

10
PRECAUTIONS AND ACTION FOR TEMP. RISE
Action for chamber temperature rise
When the high-temperature alarm or power failure alarm (when the battery mounting box battery is
installed) has been activated (in which case, the alarm indicator blinks and the buzzer sounds) as a
result of an unforeseen event, take the action described below without delay to protect the storage
item.
Checking the causes and taking the necessary action
<Important> Check the cause of the temperature rise and take action without delay to deal with
the cause. (“Action for alarm” [page 33])
 If the alarm fails to stop or the chamber temperature fails to drop even after one hour, a machine
malfunction may have occurred. Contact our sales representative or agent without delay.
 Transfer the storage items to another refrigerator and freezer.
Action when the product has stopped due to a power failure
If a power failure is responsible for the rise in temperature, check the recovery time from the power failure,
and take the appropriate action in accordance with the expected recovery time.
<Action to take when the power failure is of short duration (several minutes to up to one hour)>
 Do not open the doors as this will cause the chamber temperature to rise.
 Reduce the ambient temperature to 25 °C or below.
<Action to take when the power outage is of long duration (one hour or more)>
 Transfer the storage items to another refrigerator and freezer.
 Provide a back-up power source if no other refrigerator and freezer are available.
