PHI VILLA DOUBLE PERSON SOFA+ TEA TABLE Operation instructions

DOUBLE PERSON SOFA+ TEA TABLE
ASSEMBLE INSTRUCTION
E02GF040202701
Warranty
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
CUSTOMER SERVICE
Safety Information
PRODUCTCAUTION
This dining set was made for the explicit purpose of providing outdoor functions and isnot tobeused as a toy. Thisproduct is intended for
normal outdoor use; however, themanufacturer recommends storing and / or covering this set when any formidable/ severe weather is
product.
Children under the age of 10, near theproduct, should be supervised byacompetent adult at all times. Thisproduct isNOT intended for
commercial use and will void the warranty.
Call Our After Sales Support Hotline [phone] Monday-Friday 7am-5pm CST
Or Our Email Address: [email protected]
AlphaMarts.com
AlphaMarts.com

CHATHAM LOVESEAT WITH CUSHION
MODEL #:FSS10015LA SET2BN,FSS10015LA SET2BNE,FSS10015LA
SET2TLE
ASSEMBLY INSTRUCTIONS (CONTINUED)
WEIGHT LIMIT
500 LBS
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR LOVESEAT, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING
INCLEMENT WEATHER.
STEP 1
A. PLACELEFT ARM (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. ATTACH SEAT (D) TO LEFT ARM (A) WITH FLAT WASHER
(E) AND BOLT (G) USING ALLEN WRENCH (H). DO NOT
TIGHTEN COMPLETELY.
C. PLACE RIGHT ARM (B) UPSIDE DOWN ON A FLAT
PROTECTED SURFACE, ROTATE ASSEMBLY FROM ABOVE
STEP ON TOP OF RIGHT ARM (B) .
D. ATTACH RIGHT ARM (B) TO SEAT (D) WITH FLAT WASHER
(E) AND BOLT (G) USING ALLEN WRENCH (H). DO NOT
TIGHTEN COMPLETELY.
STEP 2
A. CONNECTBACK (C) TO RIGHT ARM (B) AND LEFT ARM (A)
WITH FLAT WASHER (E) AND BOLT (F) USING ALLEN
WRENCH (H). DO NOT TIGHTEN COMPLETELY.
B. CONNECT BACK (C) TO SEAT WITH FLAT WASHER (E) AND
BOLT (F) USING ALLEN WRENCH (H). DO NOT TIGHTEN
COMPLETELY.
C. CONNECT BACK (C) TO LEFT ARM (A) WITH FLAT WASHER
(E) AND BOLT (F) USING ALLEN WRENCH (H). DO NOT
TIGHTEN COMPLETELY.
STEP 3
A. TURNCHAIR TO UPRIGHT POSITION SO THAT IT STANDS
SQUARELY ON THE FLOOR.
B. TIGHTEN ALL BOLTS SECURELY USING ALLEN WRENCH
(H).
C. RETAIN ALLEN WRENCH (H) FOR USE TO TIGHTEN BOLTS
PERIODICALLY OR AS NEEDED.
STEP 4
PUT THE CUSHIONS ON THE SEAT ,WITH VELCRO TIE ON
THE CHAIR , THEN PUT ON THE BACK CUSHIONS.
PART LIST FIGURE QUANTITY DESCRIPTION
A
B
C
D
E
F
G
H
1PC
1PC
1PC
1PC
9+1PCS
2+1PCS
7+1PCS
1PC
LEFT ARM
RIGHT ARM
BACK
SEAT
FLAT WASHER
SHORT BOLT (M6*15)
LONG BOLT (M6*30)
ALLEN WRENCH
AlphaMarts.com
AlphaMarts.com

CHATHAM COFFEE TABLE
MODEL #:FSS10015LA SET2BN/FSS10015LA SET2BNE/FSS10015LA
SET2TLE
ASSEMBLY INSTRUCTIONS (CONTINUED)
WEIGHT LIMIT
165 LBS
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR COFFEE TABLE, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING
INCLEMENT WEATHER.
STEP 1
A
. PLACE TABLE RIM (A) UPSIDE DOWN ON A FLAT, PROTECTED
SUR
FACE.
B
. ATTACH LEGS (B) TO TABLE RIM (A) WITH FLAT WASHER (F)
AN
D BOLT (E) USING ALLEN WRENCH (G). DO NOT TIGHTEN
C
OMPLETELY.
STEP 2
A
. ATTACH LEG CONNECTOR (C) TO LEGS (B) WITH FLAT
W
ASHER (F) AND BOLT (E) USING ALLEN WRENCH (G). DO NOT
T
IGHTEN COMPLETELY.
STEP 3
A
. TURN TABLE TO UPRIGHT POSITION SO THAT IT STANDS
S
QUARELY ON THE FLOOR.
B
. TIGHTEN ALL BOLTS SECURELY USING ALLEN WRENCH (G).
STEP 4
A
. CAREFULLY PLACE TILE (D) ONTO TABLE RIM (A).
B
. RETAIN ALLEN WRENCH (G) FOR USE TO TIGHTEN BOLTS (E)
PER
IODICALLY OR AS NEEDED.
PART LIST FIGURE QUANTITY DESCRIPTION
A
B
C
D
E
F
G
1PC
4PCS
1PC
2PCS
16+1PCS
16+1PCS
1PC
TABLE RIM
LEG
LEG CONNECTOR
TILE
BOLT (M6*15)
FLAT WASHER
ALLEN WRENCH
