Phil & Teds Peanut User manual

english
ATTENTION!READINGALL
THESEINSTRUCTIONSWILL
GREATLYREDUCETHECHANCE
OFTOYSBEINGTHROWN!
(blokes: don’t say you weren’t told )
PG parental guidance required
NB baby not included

peanut
peanutinstructions
Use only for children weighing no more than
9kg/19.8lbs
Follow these simple steps and you’ll be ready
for some home & away sleep assurance in
no time!
bits & bobs
Red numbers below refer to peanut parts
indicated on the inside back flap of this guide.
1. Head end leg
2. Foot end leg
3. Handles (x2)
4. Aluminium frame and fabric wall
5. Fabric wall cord
6. Plastic base
7. Plastic base brackets (x4)
8. Harness fixing points
9. Mattress
10. Cover
11. Vibe latch hooks
12. Vibe latch lever
13. Classic/Sport/Dash/Hammerhead frame
grips
IMPORTANT – READ
THE INSTRUCTIONS
CAREFULLY BEFORE
USE AND KEEP THEM
FOR FUTURE REFERENCE.
14. Classic/Sport/Dash/Hammerhead locking
arms (left & right hand)
15. Nutshell
16. Head end
17. Foot end
safe & sound
We’ve attained the following safety standards:
• EN 1466:2004
• EN1888:2005
• ASNZS 2088:2000
• ASTM F833-07a
• ASTM F2194-07a
getting to grips
Letters in red refer to line drawings on the inside
front cover.
a Carefully remove the peanut and its
component parts from the packaging.
Remove the cover and mattress from the
aluminium frame and fabric wall and check
the plastic base is correctly positioned;
making sure the curved edges face upwards.
b Standing side-on to your peanut rotate both
legs downwards towards the centre of the
peanut, as shown. Push the plastic base
down into the fabric wall.
c Turn the peanut upside down on a flat surface
keeping hold of the plastic base as you turn
it over. Locate the plastic base brackets, two
at each end of the base. Note that there are
2

english
also raised bumps between each set of
brackets – these will help keep the legs in
place once they are hooked into the
brackets.
d To hook the legs into the plastic base
brackets; hold the plastic base with one
hand and the head end leg with the other.
Lift the base upwards and hook the leg
under the two small plastic brackets on
the base. Ensure they are fully engaged in
each bracket before moving on. Repeat
for the legs at the foot end.
The legs are made from spring steel, giving
them tension, so you’ll have to use a bit of
muscle power to hook them under the
second set of brackets!
e Next, locate the four exposed sections of
the cord loop that runs around the bottom
of the fabric side wall. Pull the cord sections
from opposite sides into the middle of the
plastic base and hook them together.
Repeat for the second set of cord loops,
making sure they are securely fastened to
each other before moving on.
f Turn the peanut over and place the
mattress inside, so the sponge-like fabric
is facing upwards.
g The peanut’s cover zips on and off as
required. When you’re ready to carry the
peanut the handles will slide up the legs to
provide more handle length.
3
final check points!
Before placing your precious bundle into the
peanut, ensure:
•The legs are fully engaged under the
brackets on the plastic base (see step ‘d’)
•The cord loops are hooked together
securely.
attaching the nutshell
hPick up your nutshell and open it out with
the elastic edge at the bottom, as shown.
i Locate the two holes on the top of the
peanut frame (on both sides of your peanut)
and slot the ends of the nutshell rods fully
into the holes, making sure the hood is
facing the right way (so it covers the head
end of your peanut!).
j Ease the elastic bottom of the hood around
the aluminium frame.
harness fixing points
If you want to secure your little one in the
peanut, there are two fixing points located
either side of the base, under the mattress
(see no. 8 in the parts diagram). This will
allow you to fasten a harness to the peanut.
attaching the peanut
to the vibe buggy
NOTE: Do not use the peanut fitted to the buggy
in combination with a child in the main buggy
seat and/or double kit.

peanut
4
removing the peanut from the
vibe buggy
Make sure the vibe buggy brake is engaged.
n Extend the peanut handles to their full
length. Stand side-on to the peanut and hold
it by its handles with one hand.
o Reach over the peanut to the side furthest
away from you and release the latch hooks
from the vibe frame by rotating the peanut
latch lever upwards and lifting the latch
hooks backwards and upwards. Take the
weight of the peanut with the handles in
one hand, to prevent the far latch from
re-engaging.
p With your free hand: release the second
latch, as before, and lift the peanut away
from the vibe frame.
attaching the peanut to the
classic/sport/dash or
hammerhead buggy
NOTE: Do not use the peanut fitted to the buggy
in combination with a child in the main buggy
seat and/or double kit.
Make sure the buggy brake is engaged and the
seat is in the lie-flat position. Do not remove the
fabric seat from your buggy
q Remove the pull bar from the buggy and
replace with the locking arms (left and right
hand). Make sure they are fully secured
Make sure the vibe buggy brake is engaged,
the seat is in the lie-flat position and the pull bar
is removed.
k Stand side-on to your vibe buggy and extend
the peanut handles to their full length.
Hold the peanut by its handles with one
hand and position it over the frame of
the vibe. NOTE: The head end of the peanut
should point towards the vibe front wheel.
With your free hand, guide the peanut latch
hooks, located on either side of the peanut
frame, over the upper pull bar slots on the
vibe frame.
Press down on the latch hook closest to
you, listening for the sound of the hooks
locking in place. Look to make sure the
latch housing is sitting flush on the vibe
frame and the peanut latch lever has
returned to the downward position.
l Still holding the peanut handles with one
hand: reach over to the second latch,
furthest away from you, and press down
on the peanut latch hooks until you hear
them lock into place.
Check both latches are fully engaged by
gently tugging on the handles and making
sure the peanut doesn’t come free from
the frame.
m Slide the handles down the legs to sit
neatly out of the way and you’re good to
go!

5
english
removing the peanut from the
classic/sport/dash or
hammerhead buggy
Make sure the buggy brake is engaged.
u Stand side-on to your buggy, reach over the
peanut to the side furthest away from you
and release the head end leg by unclipping
it from the locking arm. Taking the weight of
the peanut with the handles, release the
side closest to you and lift the peanut up and
away from the buggy frame, tilting the foot
end slightly to release the frame grips.
pack down!
v To pack your peanut down for safe
keeping, remove the nutshell from peanut’s
main frame. Turn the peanut upside down,
unhook the fabric side wall cord and
release the legs from the plastic base;
unhooking them from the small plastic
brackets at the head and the foot end of
the base.
w Rotate both legs downwards towards the
outside edges of the peanut. The base,
frame and fabric side wall will now flatten
down to a smaller size, ready to be
re-assembled next time around.
and the nib springs are engaged.
r Next, stand side-on to your buggy and extend
the peanut handles to their full length. Position
the peanut above the buggy frame; holding the
peanut handles in one hand and the head end
of the aluminium frame in the other.
NOTE: The head end of the peanut should
point towards the buggy front wheel.
Lower the peanut downwards and forwards
towards the buggy seat tilting the foot end
downwards slightly, this will capture the buggy
frame between the grips on either side of the
peanut. Check to make sure the peanut is
secure within the buggy frame on both sides.
s Push both handles down the legs and pull
forward slightly. Next, reach down and secure
the locking arm to the front end leg by
‘clipping’ it onto the wire, as shown. Reach
over the peanut and repeat for the side furthest
away from you. NOTE: there are two separate
‘clipping slots’, the furthest away is for the dash
& hammerhead models, the other for the
classic & sport models.
Check that both sides of the peanut are fully
secure by gently tugging on the handles and
making sure the peanut doesn’t come free
from the frame.
t Slide the handles down the legs to sit neatly
out of the way and you’re good to go!
