Phil Jones Bass BG-100 User manual

Phil Jones Bass
PJB BASS CUB
BG-100
OWNER'S MANUAL

Thank you for purchasing the PJB BASS CUB. A great deal of dedication and
passion went into designing and building this no compromise, high performance
compact-combo amplifier. It was conceived to be a dedicated amplifier for the
“connoisseur” guitarist. Reading this manual will enable you to get the best
performance from it so that you may enjoy many years of service.
READ THIS FIRST
!Before using the BASS CUB please read ALL the instructions.
!On receipt of product, check for any signs of physical damage arising from
shipping. If any damage is visible contact your dealer.
!Keep all original packing.
!Do not use this amplifier in a way that would compromise its ventilation
system. When operating, never cover the heat sink on rear panel.
!Do not locate this amplifier near any heat source.
!This amplifier must be connected only to a power source specified in this
manual.
!For safety do not leave the amplifier plugged into a power source for long
periods of time when not in use.
!Do not let any liquid or foreign objects fall into any openings on the
amplifier.
!Never use this amplifier if it has:
1. Suffered any physical damage.
2. Been subjected to any liquids, rain or moisture.
3. Damaged cables connected to it.
If any of the above occurs, the amplifier should be examined by qualified
service personnel.
!Always operate this amplifier with the correctly rated fuse.
!Never use this amplifier without proper grounding.
!The mains plug is used as disconnect device, the disconnect device shall
remain readily operable.
! Protective earthling terminal. The apparatus should be connected to a
mains socket outlet with a protective earthing connection.
! Correct Disposal of this product. This marking indicates that this product
should not be disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health from uncontrolled
-1-

waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources.
!The apparatus shall not be exposed to dripping or splashing.
OVERVIEW OF THE BASS CUB
Sometimes all you need is an amp that can deliver true bass tones but without the
hassle of getting out a big rig amplifier. The Bass Cub is 100 watts of pure tone in
a shoebox size package and so light, it can be lifted even with a finger!
It can sit on the floor or on top of a desk. Two independent channels can accept
two instruments or one microphone. It also has a stereo input for Drum machine
or I-pod/MP3 player. Practicing can be done with the 2 internal speakers or
headphones.
The BASS CUB comes with a padded carrying bag.
With these features and great sound there is no longer an excuse you can not
practice.
AMPLIFIER FEATURES
!Dual channel switch able high impedance/high gain input OR low
impedance/low gain stage with mute function.
!One stereo input for Drum machine or I-pod/MP3 player.
!3 Band EQ.
!Balanced Line Output with ground lift.
!Tuner Out.
!Line Out.
!Sophisticated protection circuitry.
!100watt RMS Amplifier.
!Ultra low noise pre amplifier circuit.
-2-

MAXMIN
MAXMIN
INPUT LEVEL MASTER VOL
MIN MAX
CLIP
INPUT B
+18dB-18dB+18dB-18dB-18dB +18dB
+18dB-18dB
TREBLE
+18dB-18dB
MID
-18dB +18dB
BASS
INPUT
ON
OFF
LEVEL
LOW
MUTE
HIGH
LOW
MIC
HIGH
CLIP
INPUT LEVEL BASS MID TREBLE
INPUT A
POWER
MIN MAX
LIMITER
MAX 0
AUX
PUSH
HEADPHONE
12 3 4 5 678 9 10 11 12
2221
2019
18
17
16
1514
13
100-240V~ 50-60Hz
AC~INPUT
O
I
DI OUT
LINE OUT
TUNER OUT
POWER
ON OFF
REFER TO OWN ERS MANUAL
NO USER SERVICEABLE PARTS INSIDE
BEFORE OPENING
PULL MA IN PLU G
CAUTION
LIFT
GND
23 24 25 26
27 28
FRONT PANEL OVERVIEW
BACK PANEL OVERVIEW
-3-

FRONT PANEL DESCRIPTION
1. INSTRUMENT INPUT JACK CHANNEL A
This is a combo socket accepts both standard inch mono jack and XLR plug.
2. INPUT GAIN SWITCH CHANNEL A
High: Higher sensitivity, high impedance input.
Low: Lower sensitivity input setting for guitars with onboard electronics.
MIC: Switch to this when plug in a microphone.
3. CLIP INDICATOR
When the amplifier output is clipping, the LED will light up with red.
4. INPUT LEVEL SENSITIVITY CHANNEL A
5. BASS EQ CONTROL
6. MID RANGE EQ CONTROL
7. TREBLE EQ CONTROL
8. LIMITER IN/OUT SWITCH
Sends signal through limiter or bypass.
9. LIMITER INDICATOR.
This blue L.E.D (Light Emitting Diode) will light up when the signal is being
compressed. This will vary on how hard the instrument is played and how the
threshold is adjusted
10. AUX Input
Stereo input for Drum machine or I-pod/MP3 player.
11. HEADPHONE OUTPUT JACK
This jack accepts inch stereo headphone jacks.
12. POWER LED INDICATOR
With power switched on the LED light will turn bright blue.
-4-

13. INSTRUMENT INPUT JACK CHANNEL B
This is a standard inch mono jack socket.
14. CLIP/ MUTE INDICATOR
When the amplifier output is clipping, the LED will light up with red. When
muted, the LED will light up with green.
15. INPUT GAIN SWITCH CHANNEL B
High: Higher sensitivity, high impedance input.
Low: Lower sensitivity input setting for guitars with onboard electronics.
Mute: mute the input stage, when switch on, the clip LED will light up with green.
16. INPUT LEVEL SENSITIVITY CHANNEL B
17. BASS EQ CONTROL
18. MID RANGE EQ CONTROL
19. TREBLE EQ CONTROL
20. COMPRESSION ADJUSTMENT LEVEL.
This will vary the level the limiter threshold. The compression ratio is 3dB to 1.
Adjust this to suit your playing style and output power of instrument. Note that
turning this control clockwise increases the threshold level and so reduces
compression. More compression is added by turning the control counter-
clockwise, like backing off the volume control.
21. AUX INPUT VOLUME CONTROL.
Use to control the level of backing/rhythm track.
22. MASTER VOLUME CONTROL
This is the master volume control and it controls how much power you send to
your speakers as well as the line out socket on the back of the amp. When setting
up your tone or plugging in your instrument, you should keep this control at a low
level. All instruments are different when it comes to how much output is from the
pickups. Likewise for players, depending on how hard or soft you play.
-5-

BACK PANEL DESCRIPTION
23. GROUND LIFT SWITCH
This allows the grounding of balanced out socket to be disconnected. This is
useful if you are experiencing hum caused by grounding loops/problems.
24. BALANCED LINE OUT
This is an ultra-low impedance (200) balanced line out for use with recording
or PA mixing consoles. This output is not controlled by the volume control.
Changing the level on your instrument will however, vary the DI output.
25. AC INPUT SOCKET & FUSE.
Connects the amplifier to AC power supply. Always use a grounded plug and
make sure the AC cable is more than 3A rating at 250-volt AC. If you require a
longer AC power cord, we recommend the PJB heavy-duty 20 foot power cords.
These are available as an accessory. If fuse needs replacing, use a slow blow ¾
inch fuse.
26. POWER ON/OFF SWITCH
This switches the main power on and off in the amplifier. When you turn on the
power, it will have about 2 seconds delay to protect the speaker.
Do not leave the amplifier plugged into a power source for long periods of time
when not in use.
27. LINE OUT
Can be used for driving a second amplifier.
28. TUNER OUT
Connect to instrument tuner. This output can also be used as an additional
line out.
-6-

OPERATION & POSITIONING
TURN THE VOLUME DOWN on the BASS CUB before plugging in your
instrument.
Positioning the BASS CUB for Best Sound
Often, playing in different venues will cause your bass to sound different. This is
partially due to the acoustics of the hall influencing the low frequency waves that
are coming from your speaker. Bass waves are large and room dimensions heavily
influence them when the walls reflect the sound waves, causing them to collide by
adding together or canceling each other out. This causes some fundamental notes
(the ones you feel more than hear) to ring out louder than others and some notes
not to be heard at all.
Here is an indication of where fundamental bass frequencies are, showing open
string's approximate frequencies and acoustic wavelength:
F# string 24Hz 46 feet
B string 31Hz 36 feet
E string 41Hz 27 feet
A string 55Hz 20 feet
D string 73Hz 15 feet
G string 98Hz 11 feet
C string 130Hz 9 feet
This may give you some indication of the offending notes (frequencies) that may
be booming or resonating louder or quieter than others. For example if your
speakers are five feet from a wall, the open A string may sound weak. That could
be because the path length of the reflected sound off the wall from your speaker is
exactly corresponding to half a wavelength on the open A string causing at that
particular note to cancel out.
Where you position the BASS CUB will ultimately affect your low frequency
limit. For best results keep the BASS CUB on the floor. Placing it on objects off
the floor will cause it to sound thin and lack bass punch. Placing the BASS CUB
with the back close to a wall will help reinforce the lower notes. Placing it in a
room corner will further enhance the low notes.
Room size makes a large difference in how deep the bass will sound. The further
the distance to the listener the less the bass will be. This is due to the physics of
acoustics not the unit itself.
-7-

Unfortunately for bass players, low frequencies are always very difficult to
control with room acoustics. The reproduced wavelengths of the notes you are
playing often correspond to the room dimensions, in which case the reflected
sound off the walls interferes with the sound from the speaker as you get further
away from it.
Setting Up the Limiter
Although a limiter is not essential to bass amplification, it can be a useful tool in
smoothing out the character of your instrument or playing style. The BASS CUB
limiter has a preset compression ratio of 3 to 1. For each additional increase of
3dB above the set threshold, the increase in level is actually 1dB. So the dynamic
range of your instrument is reduced.
First set up the limiter by having the compression control (20) set fully clockwise.
Now switch on the limiter (8). Start playing and turn control (20) counter-
clockwise. You will see the blue light start to come on and that is the indication
that the limiter is now working. Set this control to suit your taste.
TRANSPORTING AND STORING THE BASS CUB
When transporting in a vehicle, it is recommended that you use an external case or
heavy-duty cover to prevent it being damaged by falling over or other objects
falling on it.
When Storing:
!Keep in a dry location preferably at room temperature.
!Do not store in temperatures below -20 Degrees C or above 40 Degrees C.
!Do not allow it to get wet. If this occurs, never turn it on in this condition.
!Do not leave the BASS CUB permanently connected to a power source.
-8-

SPECIFICATIONS
Speaker
Computer Optimized Vented Enclosure
Speaker Frequency Response: 60Hz~15KHz
Speaker Compliment: 2 x 5inch proprietary, extended-range drivers
Speaker Sensitivity: 91dB/W/M
Internal Speaker Impedance: 4 Ohms
Dimensions: 12 W x10.8 D x 7.8 H (inch)
Weight: 13.2 lbs
Amplifier
PJB 100watt, class A/B amplifier with digital switch mode power supply.
Signal to Noise Ratio
Better than 90 dB (EQ off, Volume on Full.)
Impedance
High Input: >4M/22pF
Low Input: >100K/22pF
Line Input: >75K
Pre Amp Line Out: < 2K
Bal. Out: <200
Levels
High Input: 10mV-2.5V
Low Input: 20mV-5V
Pre Amp Out: 1.2V
FX send: 1V
Bal. Line Out: Typical 500mV
Protection Circuits
1. AC line filter.
2. Slow-blow Fuse: 2.5A / 250V.
3. Loudspeaker Short-Circuit Protection.
4. DC Output Protection.
Included Parts
6 ft AC Power Cord
-9-

SERVICE/WARRANTY INFORMATION
The BASS CUB has a warranty period of 2 years, starting from the date of
purchase. The buyer must complete and return the enclosed warranty card
within 14 days of purchase.
This warranty covers defect in materials or workmanship that occurs in normal
use. Within warranty period PJB will repair or replace the defect unit free of labor
and parts charge. It is the buyer's responsibility to use the unit strictly according to
instructions written in this manual and amplifier manual.
This warranty is not transferable; it is provided to original owner only.
Damage/defects caused by the following conditions are not covered by this
warranty:
!Improper handling, neglect or failure to operate the unit in compliance with the
instructions given in user manual;
!Connection or operation of the speakers in any way that does not comply with
the technical or safely regulations applicable in the country where the product
is used;
!Repairs or modifications by anyone other than authorized PJB service agent;
!Damages/defects caused by force majeure or any other condition that is beyond
the control of PJB.
Should you need any warranty service, please bring the BASS CUB back to the
dealer from whom you purchased, along with your sales receipt. Depending on the
complexity of the repair work, your dealer may return the defect unit to PJB
service center for repair or replacement.
Phil Jones Bass
American Acoustic Development LLC
8559 Page Avenue St. Louis,
MO 63114 USA
Phone: [phone] Fax: [phone]
Phil Jones Bass is a division of American Acoustic Development LLC.
www.philjonesbass.com
[email protected]
www.philjonespuresound.com
-10-

Phil Jones Bass Inc.
8559 Page Ave, St. Louis,
MO 63114, USA
Phone: [phone]
Fax: [phone]
www.philjonesbass.com
[email protected]
