Philco PCD8H User manual

PCD8H
Dryer
乾衣機

PCD8H_EN/170718.1151
Please read this user manual first!
Dear Customer,
Thank you for preferring a Philco product.
We hope that your product which has been
manufactured with high quality and technology
will give you the best results. We advise you
to read through this manual and the other
accompanying documentation carefully
before using your product and keep it for
future reference. If you transfer the product
to someone else, give its manual as well. Pay
attention to all details and warnings specified in
the user manual and follow the instructions given
therein.
Use this user manual for the model indicated on
the cover page.
• Read the instructions.
Explanation of symbols
Throughout this user manual the following
symbols are used:
BDANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
AWARNING!
• Warning for hazardous situations with regard
to life and property.
WARNING!
• Warning against hot surfaces.
WARNING!
• Warning against scalding hazard.
CNOTE
• Important information or useful hints about
usage.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging wastes with
the domestic waste or other wastes, discard
them to the dedicated collection points
designated by the local authorities.

3
Dryer / User Manual
1 Important instructions for
safety and environment
CNOTE
• This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
1.1 General safety
AWARNING!
The dryer can be used by children
at and above 8 years old and by
persons whose physical, sensory
or mental capabilities were not fully
developed or who lack experience
and knowledge provided that they
are supervised or trained on the
safe usage of the product and the
risks it brings out. Children should
not play with the product. Cleaning
and maintenance works should not
be performed by children unless
they are supervised by someone.
Children of less than 3 years should
be kept away unless continously
supervised.
• Adjustable feet should not be
removed. The gap between the
dryer and the floor should not be
reduced with materials such as
carpet, wood and tape. This will
cause problems with the dryer.
AWARNING!
Always have the installation and
repairing procedures carried
out by the Authorized Service.
Manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorized persons.
• Never wash the dryer by spraying
or pouring water onto it! There is
the risk of electric shock!
For the products with a steam
function:
AWARNING!
• Use only distilled water or water
condensed in the water tank of the
machine in steam programs. Do
not use mains water or additives.
When using condensed water in the
water tank, it should be filtered and
cleared of fibres.
• Do not open the door when steam
programs are running. Hot water
may be expelled.
• Before putting laundry in a steam
program, stains on it should be
removed.
• You may only put laundry that is not
dirty or stained but permeated with
unpleasant odour in steam (odour
removal) program.
• Do not use any dry cleaning sets
or additional materials in a steam
program or in any program.

4 Dryer / User Manual
1.1.1 Electrical safety
BDANGER!
• Electrical safety instructions
should be followed while electrical
connection is made during the
installation.
• The appliance must not be
supplied through an external
switching device, such as a timer,or
connected to a circuit that is
regularly switched on and off by
utility.
• Connect the dryer to a grounded
outlet protected by a fuse at the
value specified on the type label.
Have the grounding installation
performed by a qualified electrician.
Our company shall not be liable for
any damages that will arise when
the dryer is used without grounding
in accordance with the local
regulations.
• The voltage and allowed fuse
protection is stated on the type label
plate.
• The voltage specified on the type
label must be equal to your mains
voltage.
• Unplug the dryer when it is not in
use.
• Unplug the dryer from the mains
during installation, maintenance,
cleaning and repair works.
• Do not touch the plug with wet
hands! Never unplug by pulling
on the cable, always pull out by
grabbing the plug.
BDANGER!
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Power cable plug must be easily
accessible after installation.
• Damaged mains cable should be
changed notifying the Authorized
Service.
• If the dryer is faulty, it must not be
operated unless it is repaired by an
authorized service agent! There is
the risk of electric shock!
1.1.2 Product safety
DANGER!
• Superheating of the clothes inside
of the dryer can occur if you cancel
the programme or in the event of
a power failure whilst the dryer is
running, this concentration of heat
can cause self-combustion and fire
so always activate the ventilation
programme to cool down or quickly
remove all laundry from the dryer in
order to hang them up and dissipate
the heat.

5
Dryer / User Manual
DANGER!
Points to be taken into
consideration for fire hazard:
Below specified laundry or items
must not be dried in the dryer
considering fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone,
alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or
paraffin removers must be washed
in hot water with plenty of detergent
before being dried in the dryer.
For this reason especially the items
containing the above specified
stains must be washed very well,
to do this use adequate detergent
and choose a high washing
temperature.
Below specified laundry or
items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads.
Clothing cleaned with industrial
chemicals.
Items such as lighter, match,
coins, metal parts, needle etc. may
damage the drum set or may lead
to functional problems. Therefore
check all the laundry that you will
load into your dryer.
Never stop your dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to dissipate the
heat.
DANGER!
• Clothes that are washed
inadequately may ignite on their
own and even may ignite after
drying ends.
• You must provide enough ventilation
in order to prevent gases exiting
from devices operating with other
types of fuels including the naked
flame from accumulating in the
room due to the back fire effect.
AWARNING!
• Underwear that contains metal
reinforcements should not be dried
in the dryer. Dryer may be damaged
if metal reinforcements come loose
and break off during drying.
CNOTE
• Use softeners and similar products
in accordance with the instructions
of their manufacturers.
Always clean the lint filter before or
after each loading. Never operate
the dryer without the lint filter
installed.

6 Dryer / User Manual
AWARNING!
• Never attempt to repair the dryer
by yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others’ lives in
danger.
• There must not be a lockable, sliding
or hinged door that may block the
opening of the loading door in the
place where your dryer is to be
installed.
• Install your dryer at places suitable
for home use. (Bathroom, closed
balcony, garage etc.)
• Make sure that pets do not enter the
dryer. Check the inside of the dryer
before operating it.
• Do not lean on the loading door of
your dryer when it is open, otherwise
it may fall over.
• The lint must not be allowed to
accumulate around the tumble dryer
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
• Fabric softeners, or similar products.
should be used as specified by the
fabric softener instructions.
• Exhaust air must not be discharged
into a flue which is used for
exhausting fumes from appliances
burning gas or other fuels.
1.2 Mounting over a washing machine
• A fixing device should be used between
the two machines when installing the dryer
above a washing machine. The fitting
device must be installed by the authorized
service agent.
• Total weight of the washing machine and
the dryer -with full load- when they are
placed on top of each other reaches to
approx. 180 kilograms. Place the products
on a solid floor that has sufficient load
carrying capacity!
AWARNING!
• Washing machine cannot be placed on
the dryer. Pay attention to the above
warnings during the installation on your
washing machine.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm
54 cm Can be installed
60 cm Can be installed
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
45 cm 40 cm
54 cm Can be installed Cannot be
installed
60 cm Can be installed
1.3 Intended use
• Dryer has been designed for domestic use.
It is not suitable for commercial use and it
must not be applied other than of its
intended use.
•Use the dryer only for drying laundry that
are marked accordingly.
• The manufacturer waives any responsibility
arisen from incorrect usage or
transportation.

7
Dryer / User Manual
1.4 Child safety
• Packaging materials are dangerous for the
children. Keep packaging materials away
from children.
• Electrical products are dangerous for the
children. Keep children away from the
product when it is operating. Do not let
them tamper with the dryer. Use the child-
proof lock in order to prevent the children
to tamper with the dryer.
CNOTE
Child-proof lock is on the control panel.
(See Child lock)
• Keep loading door closed even when the
dryer is not in use.
1.5 Compliance with the WEEE
regulation and disposing of the waste
product
This product complies with EU
WEEE Directive (2012/19/EU). This
product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
This product has been
manufactured with high quality
parts and materials which can be reused and
are suitable for recycling. Do not dispose of the
waste product with normal domestic and other
wastes at the end of its service life. Take it to the
collection center for the recycling of electrical
and electronic equipment. Please consult your
local authorities to learn about these collection
centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with Local Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 56,8 cm
Capacity (max.) 8 kg**
Net weight (± 4 kg) 34 kg
Width
See type label***Voltage
Rated power input
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
CNOTE
• Technical specifications of the dryer are
subject to specification without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.

8 Dryer / User Manual
2 Your Dryer
2.1 Overview
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In models where the tank is placed below,
the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the tank
is placed above)
11. Power cord
2.2 Package Contents
1. Water
drain
hose *
5. Drying
basket
user
manual*
2. Filter
drawer
spare
sponge*
6. Water
Filling
Container*
3. User
Manual
7. Pure
Water*
4. Drying
basket*
8.
Fragrance
Capsules
Group*
*It can be supplied with your machine depending
on its model.

9
Dryer / User Manual
3 Installation BDANGER!
• Do not place the dryer on the power
cable.
3.2 Removing the transportation
safety assembly
AWARNING!
• Remove the
transportation
safety assembly
before using the
dryer for the first
time.
• If the door swing
side of your
appliance can
be modified, see
the reversible
door mounting
instructions.
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with the
product instead of periodically draining the water
collected in the water tank.
1
3 4
2
1-2 Pull hose at
the behind of
the dryer by
hand in order
to disconnect
it from where it
is connected.
Do not use
any tools to
remove the
hose.
3Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose of
the product in previous step.
4Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
Before the calling the nearest Authorized
Service for the installation of the dryer, ensure
that electrical installation and water drain is
appropriate referring to the user’s manual. If
they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
CNOTE
• Preparation of the dryer’s location
as well as the electrical and waste
water installations is under customer’s
responsibility.
AWARNING!
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the surface
should not be reduced by the materials
such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening of
the loading door in the place where your
dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the dryer,
make sure that its rear wall does not touch
anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside of
this range, operation of the dryer will be
adversely affected and it can get damaged.
• The rear surface of the tumble dryer shall
be placed against a wall.
•
Prior to installation, visually check if the
dryer has any defects on it. If the dryer
is damaged, do not have it installed.
Damaged products cause risks for your
safety.

10 Dryer / User Manual
CNOTE
• Water drain hose should be attached to a
height of maximum 80 cm.
• Make sure that the water drain hose
is not stepped on and it is not folded
between the drain and the machine.
• If there is an accessories pack supplied
with your product, please see the
detailed description.
3.4 Adjusting the feet
Turn the feet to left
or right until the
dryer stands level
and firmly.
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
AWARNING!
• We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.6 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer. To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this lamp is
to assist the user to place laundry in the tumble
dryer in a comfortable way. The lamps used
in this appliance have to withstand extreme
physical conditions such as vibrations and
temperatures above 50 °C

11
Dryer / User Manual
4 Preparation • Do not add wet laundry while the dryer is
in operation
• For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• Clean the filter periodically when there
is visible air collection on it or when the
symbol lights up, if there is a filter drawer
cleaning warning symbol available.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating.
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry Approximate
weights (g)* Laundry Approximate
weights (g)*
Cotton
quilt covers
(double)
1500 Blouses 150
Cotton quilt
covers (single) 1000 Cotton shirts 300
Bed sheets
(double) 500 Shirts 250
Bed sheets
(single) 350 Cotton
dresses 500
Large
tablecloths 700 Dresses 350
Small
tablecloths 250 Jeans 700
Tea napkins 100 Handkerchiefs
(10 pieces) 100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a label
stating that they are suitable for drying in a dryer
and make sure that you select the appropriate
programme.
Do not dry with
dryer
At high
temperature
At medium
temperature
At low
temperature
4.2 Laundry not suitable for drying in
the dryer
CNOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles and
button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dries earlier than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.

12 Dryer / User Manual
5 Operating the product
5.1 Control Panel
4. Drying Level Button
5. Buzzer volume/Time programs selection
button
3
4 5
2
1
Tank
full
Filter
cleaning
Child-proof
lock
Mute
Filter drawer /
Heat exchanger
cleaning
O Timer
Delay
1. Off/Program selection button
2. Start/Pause button
3. End Time button
5.2 Symbols
Select the desired program using the On/Off/
Program selection knob, the machine will turn
on.
CNOTE
•
5.3. Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
AWARNING!
• Ensure that no
laundry is jammed
to the loading
door.
Selecting a program using the On/Off/
Program selection button does not mean
that the program started. Press the
Start / Pause button to start the program.

13
Dryer / User Manual
5.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg)
Spin speed in
washing machine
(rpm)
Drying Time
(minutes)
Cottons Iron Dry
You may dry your cotton laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
81000 107
Cottons
Cupboard Dry
You may dry all your cotton laundry in this
program. (T-shirt, pants, pyjamas, baby clothes,
underwear, linen, etc.) Yo u can put your laundry in
the wardrobe without ironing.
81000 142
Cottons Extra Dry
You may dry your thick cotton laundry in this
program such as towels, bathrobe, etc. You can
put your laundry in the wardrobe without ironing.
81000 150
Synthetics Iron
Dry
You may dry your synthetic laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
4800 40
Synthetics
Cupboard Dry
You may dry all your synthetic laundry in this
program. (Shirt, T-shirt, underwear, tablecloth,
etc.) You can put your laundry in the wardrobe
without ironing.
4800 53
Daily You can dry both cotton and synthetic laundry
with this programme.41000 59
Sport You may dry your sports clothes that are
appropriate for tumble drying in this program.41000 92
Freshen up
It just provides airing for 10 minutes without any
hot air. Yo u can air the cotton and linen laundry
that are kept closed for a long time , and eliminate
the odour in them.
- - 10
Timer
Programmes
You may select from time programmes between
10 and 160 minutes to achieve the desired drying
level at low temperature. In this programme,
tumble drier’s operation lasts for the set time
independently from the dryness of laundry. This
product is available to be used with a drying
basket as option. For products that are sold
without a basket, you can obtain a basket from an
authorized service and use the drying programs
specified above. For details of use, see the drying
basket user guide.
- - -
Delicates
You may dry your delicate laundry or laundry with
hand wash symbol (silk blouses, thin underwear,
etc.) at low temperature in this program.
2600 50
Mix Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.41000 83
Baby protect Program used for baby clothing with can be dried
approval on the label.31200 70
Jeans You may dry denim pants, skirts, shirts or jackets
in this program.41200 80
Shirts It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing. 1,5 1200 40
Express 14’ Dries shirts more delicately and thus causes less
wrinkles for easy ironing.0,5 1200 14

14 Dryer / User Manual
Energy consumption values
Programmes Capacity (kg)
Spin speed in washing
machine (rpm)
Approximate amount of
remaining humidity
Energy consumption
value kWh
Cottons
cupboard dry*81000 60% 4,49
Cottons Iron dry 81000 60% 3,8
Synthetics
cupboard dry 4800 40% 1,8
* : Energy Label standard program (EN 61121:2012) All values in the table are determined according
to EN 61121:2012 standard. Consumption values may vary from the values in the chart depending
on laundry type, wringing speed, ambient conditions and voltage levels.

15
Dryer / User Manual
5.5 Auxiliary functions
Buzzer / time
Drying machine makes an audible warning when
the program is completed. If you don’t want the
machine to make an audible warning, press the
“Buzzer / Time” button. When you press the
Buzzer/Time button, a light will illuminate and no
audible warning will be made when the program
ends.
CNOTE
• You can select this function before or
after the program starts.
Buzzer/Time button is used to adjust program
duration while the Rack/Time programs are
selected.
Drying Level
Drying Level button is used for adjusting to
desired dryness level. Program duration may
change depending on the selection.
CNOTE
• You can activate this function only prior
to start of program.
End time
You can delay the end time of the program up to
24 hours with End time function.
1. Open the loading door and place the
laundry.
2. Select the drying program.
3.
4.
CNOTE
• You can add or remove laundry within
end time. Displayed time is the sum of
normal drying time and end time. End
Time LED will turn off at the end of
countdown, drying starts and drying LED
will illuminate.
Changing the end time
If you want to change the duration during the
countdown:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and repeat the End Time selection
process.
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and press the Start/Pause button.
5.6 Warning indicators
CNOTE
• Warning indicators may vary depending
on the model of your dryer.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
When the program is completed, the warning
indicator to empty the water tank turns on.
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into Pause. In this case,
empty the water tank and start the program by
pressing the Start / Pause button. Warning
indicator turns off and program resumes.
Filter drawer /Heat exchanger cleaning
When the programme is finished, the cleaning
symbol of the heat exchanger or filter drawer
may light up.
5.7 Starting the program
Press the Start/Pause button to start the
program.
Start/Pause and Drying indicators will illuminate
to indicate that program started.
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being interrupted
when the buttons are pressed during a program.
When the child lock is activated, all buttons on
the panel except the On/Off/Program selection
knob are deactivated.
Press the Drying Level and Buzzer buttons
simultaneously for 3 buttons to activate the child
lock.
The child lock has to be deactivated to be able
to start a new program after the current program
is finished or to be able to interfere with the
program. To deactivate the child lock, keep the
same buttons pressed for 3 seconds.
Press the End Time selection button and
set the delay time you wish. End Time LED
will illuminate. (When pressed and hold the
button, End Time proceeds non-stop).
Press the Start /Pause button. End Time
countdown starts. “:” Separator in the
middle of displayed delay time flashes.

16 Dryer / User Manual
CNOTE
• When the child lock is activated, the child
lock warning indicator on the screen
turns on.
• Child lock deactivates when the drying
machine is turned off and on by the On/
Off/Cancel knob.
CNOTE
• When the drying machine runs and
the child lock is active, it beeps twice
when the program selection knob is
turned. If the child lock is deactivated
without returning the program selection
knob to its previous position, program
will terminate due to the change in the
program selection knob position.
5.9 Changing the program after it is
started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running
• For instance, select Extra Dry program by
turning the On/Off/Program selection knob
to select Extra Dry instead of Iron Dry.
• Press the Start/Pause button to start the
program.
Adding and removing clothes during Pause
If you want to add or remove clothes to/from the
drying machine after the drying program starts:
• Press the Start/Pause button to put the
drying machine in Pause state. The drying
operation stops.
•Open the loading door while in Pause
state, and close the door after you remove
or add laundry.
• Press the Start/Pause button to start the
program.
CNOTE
• Adding laundry after the drying operation
starts may cause the dried laundry inside
the machine to mix with wet laundry and
leave the laundry damp at the end of
operation.
CNOTE
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases program duration and energy
consumption. So, it is recommended to
add laundry before the program starts.
• If a new program is selected by turning
the program selection knob while the
drying machine is in Pause, the running
program terminates.
WARNING!
• Do not touch the inner surface of the
drum while adding or removing clothes
during a continuing program. The drum
surface is hot.
5.10 Cancelling the program
If you want to cancel the program and terminate
the drying operation for any reason after the
drying machine starts running, turn the On/Off/
Cancel knob, the program will be cancelled.
AWARNING!
• The inside of the drying machine shall
be extremely hot when you cancel the
program during machine operation, so
run the refresh program to allow it to cool
down.
5.11 End of program
When the program ends, the Fibre Filter
Cleaning and Water Tank warning symbols
on the program observation indicator turn on.
Loading door may be opened and the dryer
machine becomes ready for another run.
Bring the On/Off/Program selection knob to On/
Off position to turn the drying machine off.
CNOTE
• If the laundry is not removed after the
program is completed, the wrinkle
prevention function activates for 2 hours
to prevent the laundry inside the machine
to get wrinkled. The program tumbles
the laundry with 10-minute intervals to
prevent them from wrinkling.

17
Dryer / User Manual
6 Maintenance and cleaning
Service life of the product extends and frequently
faced problems decrease if cleaned at regular
intervals.
AWARNING!
• Please unplug your product before
performing maintenance and cleaning
instructions. (eg control panel, body, etc.)
6.1 Lint Filter / Loading Door Inner
Surface
Lint and fiber released from the laundry to the air
during the drying cycle are collected in the Lint
Filter.
AWARNING!
• Always clean the lint filter and the inner
surfaces of the loading door after each
drying process.
CNOTE
• You can clean the lint filter housing with a
vacuum cleaner.
To clean the lint filter:
• Open the
loading door.
• Remove the
lint filter by
pulling it up
and open the
lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
A layer can build up
on the filter pores that
can cause clogging
of the filter after using
the dryer for a while.
Wash the lint filter with
warm water to remove
the layer that builds
up on the lint filter
surface. Dry the lint
filter completely before
reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
6.2 Cleaning the sensors
There are
dampness
sensors in the
dryer that detect
whether the
laundry is dry or
not.
To clean the
sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is
still hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with
vinegar and dry them.
CNOTE
• Clean metal surfaces of the sensors 4
times a year.
• Do not use metal tools when cleaning
metal surfaces of the sensors.
AWARNING!
• Never use solvents, cleaning agents or
similar substances for cleaning due to the
risk of fire and explosion!
6.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the water
that arise accumulates in the water tank. Drain
the water tank after each drying cycle.
AWARNING!
• Condensed water is not drinkable!
• Never remove the water tank when the
program is running!

18 Dryer / User Manual
If you forget to drain the water tank, the machine
will stop during the subsequent drying cycles
when the water tank is full and the Water Tank
warning symbol will flash. If this is the case, drain
the water tank and press Start / Pause button to
resume the drying cycle.
To drain the water tank:
1. Remove the water tank in the drawer or
container carefully.
2. Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
CNOTE
• If the direct water draining is used as an
option, there is no need to empty the
water tank.
6.4 For the condenser;
CNOTE
• Clean the condenser after every 30
drying cycles or once a month.
• If a drying
process has been
carried out, open
the door of the
machine and wait
until it cools down
• Unlock the 2 condenser locks after
opening the kick plate
• Pull out the condenser.
Clean the condenser
by applying
pressurized water with
a shower armature
and wait until the water
drains.
Place the condenser in
its housing. Fasten the
2 locks and make sure
that they are seated
securely.
Close the kick plate
cover.
Clean the condenser:

19
Dryer / User Manual
7 Troubleshooting
Drying operation takes too long.
Fibre filter pores might be clogged. >>> Wash the filter with warm
water.
Filter drawer might be clogged. >>> Clean the sponge and filter
cloth (if any) in the filter drawer. (for the products with a heat pump)
The condenser might be blocked. >>> Wash the condenser.(for
the products with a condenser )
The ventilation grills in front of the machine may be closed. >>>
Remove any objects in front of the ventilation grills that blocks air.
Ventilation may be inadequate because the area the machine is
installed in is too small. >>> Open the door or windows to prevent
the room temperature from rising very high.
A lime layer may have accumulated on the humidity or temperature
sensors. >>> Clean the humidity or temperature sensors.
Excessive amount of laundry might be loaded. >>> Do not load
the drying machine excessively.
Laundry might not have been wrung adequately. >>> Perform a
higher speed wringing on the washing machine.
Clothes come out damp after drying.
A program not suitable for the laundry type may have been
used.>>> Check the maintenance labels on the clothes and select
a program suitable for the clothes’ type or use time programs as
extra.
Fibre filter pores might be clogged. >>> Wash the filter with warm
water.
The condenser might be blocked. >>> Wash the condenser. (for
the products with a condenser)
Filter drawer might be clogged. >>> Clean the sponge and filter
cloth (if any) in the filter drawer.(For the products with a heat pump)
Excessive amount of laundry might be loaded. >>> Do not load
the drying machine excessively.
Laundry might not have been wrung adequately. >>> Perform a
higher speed wringing on the washing machine.
Drying machine does not turn on or program cannot be started.
Drying machine does not run after it is configured.
Power plug might be unplugged. >>> Make sure the power cord
is plugged in.
Loading door might be open. >>> Ensure that the loading door is
properly closed.
A program might not be set or Start/Pause button might not be
pressed. >>> Check that the program is set and it is not in Stand-
by position.
Child lock may be activated. >>> Turn off the child lock.
Program terminated prematurely for no reason.
Loading door might not be closed completely. >>> Ensure that the
loading door is properly closed.
There might be a power outage. >>> Press the Start/Pause
button to start the program.
Water tank may be full. >>> Empty the water tank.
Clothes have shrunk, hardened or spoiled.
A program not suitable with the laundry type might have been
used. >>> Check the maintenance labels on the clothes and
select a program suitable for the clothes.
The lighting inside the drying machine does not turn on. (For
models with a lamp)
Drying machine might not be turned on with the On/Off button or
program might not be selected for machines without an On/Off
button. >>> Make sure that the drying machine is turned on.
Lamp might be malfunctioning. >>> Contact Authorized Service to
replace the lamp.
Filter cleaning warning symbol/LED is on/flashing.
Fibre filter might not be cleaned. >>> Clean the filter.
The filter slot might be clogged with lints. >>> Clean the filter slot.
A layer of fluff might have accumulated clogging up the lint filter
pores. >>> Wash the filter with warm water.
The condenser might be blocked. >>> Wash the condenser.
Water drips from the loading door.
Fibres might have gathered on the inner sides of the loading door
and the loading door gasket. >>> Clean the inner surfaces of the
loading door and the loading door gasket surfaces.
Loading door opens by itself.
Loading door might not be closed completely. >>> Push the
loading door until the closing sound is heard.
Water tank warning symbol / led is on/flashing.
Water tank may be full. >>> Empty the water tank.
Water discharge hose might have collapsed. >>> If the product is
connected directly to the water drain check the water discharge
hose.
Steam symbol is flashing.(For the products with a steam function)
Steam tank may be empty => Fill the steam tank with distilled or
condensed water.
Steam programs do not start (For the products with a steam
function)
Steam tank may be empty, steam tank warning icon may light up
on the screen => Fill the steam tank until the steam icon goes off.
Wrinkles are not removed with wrinkle removing program. (For the
products with a steam function)
Excess amount of laundry may have been placed => Place
specified amount of laundry.
Steam application time may be selected in low level => Choose a
program with high amount of steam.
After completion of the program, the laundry may have stayed in
the machine for a long time => Take the laundry out as soon as the
program finishes, and hang it out.
Laundry odour not lessened with the odour removal program.(For
the products with an odour removal program)
Excess amount of laundry may have been placed => Place
specified amount of laundry.
Steam application time may be selected in low level => Choose a
program with high amount of steam.
AWARNING!
• If the problem persists after following the
instructions in this section, contact your vendor
or an Authorized Service. Never try to repair your
product yourself.
CNOTE
• In an event that you encounter an issue on
any part on your appliance, you can ask for a
replacement by contacting the authorized service
with the appliance model number.
• Operating the appliance with non-authentic parts
may lead the appliance to malfunction.
• Manufacturer and distributor are not liable for
malfunctions resulting from using non-authentic
parts.

請首先閱讀本用戶手冊！
親愛的顧客，
感謝您選購 Philco 產品。我們的產品具有
優質，且採用先進的技術生產，希望您能
從中獲取最佳效益。使用本產品前，建議
您仔細閱讀本手冊和附帶的其它文件，並妥
善保管，以備日後參考。如果將本產品轉讓
給他人，請一併移交本手冊。請注意用戶手
冊中載明的所有詳情和警告，並遵循其中的
指示。請將本手冊用於封面上指出的型號。
*請閱讀說明。
符號解釋
本使用者手冊中使用了以下符號：
B危險！
*觸電警告。
危險！
*火災危險警告。
A警告！
*有關生命和財產之危險情況的警告。
警告！
*高溫表面警告。
警告！
*燙傷危險警告。
C注意
*與使用有關的重要資訊或有用的提示。
本產品的包裝材料使用根據我國環
境法規可回收的材料製成。
包裝材料不得隨生活垃圾或其它垃圾一起處
置，而應送至當地機構指定的專門的回收點
進行處置。
