Philco PD3EV User manual

Tumble Dryer
USER MANUAL
MODEL: PD3EV
Please read this operation manual throughly before using this unit.
CAUTION: RISK OF FIRE !

1
CONTENTS
SAFETY INSTRUCTIONS
■Safety Instructions…………………………………………………………...
2
INSTALLATION
■Product Description……………...…………………………………………...
6
■Installation………………………………......………………………………...
7
OPERATION
■Quick Start……………………………......………….……………………...
8
■Before Each Drying………………………………...…………………….....
9
■Control Panel………………………………………………………………...
10
■Drying Programmes Table…………………………………………………..
11
MAINTENANCE
■Cleaning And Care………………………………..………………………...
12
■Trouble Shooting……………………………………………………………...
13
■Technical Specifications…………………………………………………...
14

2
SAFETY INSTRUCTIONS
■Safety Instructions
The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the power cable is damaged, it must be replaced by the manufacturer, its service
agent or qualified persons in order to avoid hazard.
This appliance can be used by children from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance, cleaning and user maintenance shall not
be made by children without supervision.
The tumble dryer is not to be used if industrial chemicals have been used for
cleaning.
The lint trap needed to be cleaned frequently.
Lint must not to be allowed to accumulate around the tumble dryer.
Do not dry unwashed items in the tumble dryer.
Items that have been soiled with substance such as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent before being dried in the
tumble dryer.
Items such as foam rubber (latex form), shower caps, waterproof textiles, and
rubber backed articles and clothes or pillows fitted with foam rubber pads should not
be dried in the tumble dryer.
Fabric softeners, or similar products, use specified the fabric softener as specified
within instructions
The exhaust air must not be discharged into a flue which is used for exhausting
fumes from appliance burning gas or other fuels.
The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side. In such a way, opening of the tumble dryer door is
restricted.
Oil-affected items can ignite spontaneously, especially when exposed to heat
sources such as in a tumble dryer. The items become warm, causing an oxidation
reaction in the oil. Oxidation generate heat and cause fire if the heat cannd be
escaped. Piling, stacking or storing oil-affected items can made fire hazard due to
heat fail to escape.
The appliance should not be overturned during normal use or maintenance.
Remove all objects from pockets such as lighters and matches.
For appliances with ventilation openings in the base, a carpet must not obstruct the
openings.

3
Children of less than 3 years should be kept away unless continuously supervised.
Plug must be accessible after installation.
Remove all packages before using the appliance. Otherwise, serious damage and
dangerous might be happened.
Warning!
Never stop a tumble dryer before the end of the drying cycle otherwise it will
cause harm and dying due to heat still exist.
The appliance must not be connected with an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by a
utility.
■Power supply and grounding
The dryer employs alternative current with the rated voltage and
frequency. When the voltage fluctuates between 6% of rated voltage, the
dryer can work normally
A special power socket with a capacity 10A for the dryer had better be
set beside the dryer for convenience and safety. The method of
connection of the socket is as the figure below.
To be safe, please make improvements as soon as possible according to
the rules and suggestions mentioned above.
Warning!
The socket and the grounding wire must be installed by an electrician to prevent incorrect installation or
use of the socket and to guarantee the safety of use of electricity. No connection of the grounding wire
and the neutral wire, otherwise the cabinet will be charged, which is likely to cause the danger of
electric shock.

4
■Precautions
Install or store where it will not be exposed
to temperatures below freezing or exposed
to water or weather , which could cause
permanent damage and invalidate the warranty.
Keep area around the exhaust opening and
adjacent surrounding areas free from the
accumulation of lint, dust and dirt. An obstructed
port might reduce the airflow and made hazard.
Spin the laundry thoroughly in washing machine.
High spin speed can reduce the drying time and
save energy consumption。
Make sure combustible sprayer will not be
close to dryer when it is working, and once
the gas leaks, do not touch plug or
start/pause on it.
Do not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted
with combustible or explosive substances
( such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents , kerosene, etc.).
Never attempt to operate this appliance if it
is damaged, malfunctioning, partially
disassembled, or has missing or broken parts,
including a damaged cord or plug.

5
Do not allow children on or in the appliance .Close
supervision of children is necessary when the
appliance is used near children.
Please do not use the machine when your foot or
hand with water.
Do not store plastic, paper or clothing that may
burn or melt on top of the dryer during operation.
The exhaust air must not be discharged into
a flue which is used for exhausting fumes from
appliance burning gas or other fuels .
Do not dry articles containing rubber , plastic
or similar materials such as padded bras, tennis
shoes, galoshes, bath mats , rugs, bibs, baby
pants, raincoat plastic bags or pillows that may
melt or burn. Some rubber materials, when
heated, can under certain circumstances produce
fire by spontaneous combustion.
The door can be opened only after the
programme of the drying machine is completed.
Do not open the door before the programme
finished to avoid the human skin from being
scalded by hot steam or over heated drying
machine.

6
INSTALLATION
■Product Description
Note: Please see the products you purchased in kind prevail.
Accessories
Air outlet pipe
Elbow
1 Piece
1 Piece

7
■Installation
Dryer should be placed in a ventilated area with not less
than 10cm distance from the wall.
It is suggested there are no obstacles within 1.5m in front of
dryer and keep ventilated.
Once in its permanent operating position, check that the
dryer is absolutely level with the horizontal position.
If it is not, adjust the feet with a tool.
NOTE!
If dryer could not be placed horizontally (the lean angle is no more than 2°, the dryer will work
unbalanced or stop working sometimes.
Notice when installing:
Do not install the dryer in the open air or place easily damaged by rain;
Do not place the back of dryer near curtain or something in the wind;
Do not place the dryer near gas or flammable area.
Flex tube fixing:
1. Align the accessory elbow horizontally to the left or right, align the end with the slot on the exhaust port
on the back of the dryer, and push the latch into the slot firmly (Figure 1).
2. Push the end of the accessory outlet pipe with the slot into the bent pipe buckle, and turn it clockwise
into the slot (Figure 2).
3. Extend the other side straight from the window or wall hole to the outside. The telescopic tube cannot
be discounted or extended to the sewer (Figure 3, Figure 4).
Figure 1 Figure 2 Figure 3 Figure 4

8
OPERATIONS
■Quick Start
Note!
Before using, please make sure it's installed properly.
Drying
ON select program start
After Drying
Buzzer beep or "0:00"on display
Unload clean filter unplug

9
■Before Each Drying
1. Before drying, thoroughly spin the laundry in washing machine. High spin speed can reduce the drying
time and save energy consumption.
2. For uniform drying result, sort the laundry according to the fabric type and drying programme.
3. Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4. Do not over dry the clothes, because over dried clothes can easily get creases.
5. Do not dry the articles containing rubber or similar elastic materials.
6. The door can be opened only after the programme, it can prevent injury from being scalded by hot
steam or over heated drying machine.
7. Clean the lint filter and empty container after each use to avoid extension of drying time and energy
consumption.
8. Do not put clothes after dry cleaning into the dryer.
The reference weight of dry clothes (each):
Note!
Never over load.
Not for textile with dropping water. The dryer could be damaged, even fire.
Not suitable for silk or woolen textiles
Please pay attention to use the drying machine if the materials of your clothes can not be dried by it or
contain the symbols as follows:
Work clothes
(about 1120g)

10
OPERATIONS
■Control PANEL
Note!
Clean the filter cabinet and inner tube.
Clean the filter when the “Filter” light is flashing, after the dryer stop.
On/Off
After power connected in and
loading, switch the product on or off.
Start/Pause
Press the button to start or pause
the drying cycle.
Standard
Automatic drying for cotton and
linen loading with full power.
Time+
Press the button continuously to
adjusted the time of drying from
10-120 minutes .
Quick
Fast drying for the polyster, mixed-
fabric loading within 0.8kg.
Extra
To dry cotton pieces of clothing.
Drying level: extra dry.
Refresh
Refresh the laundry within 1kg.
Child Lock
This function can effectively prevent children from mis-pressing or mis-operating the dryer.
To set this function: Press “Standard” and “Quick” simultaneously for 3sec., then Child Lock
lights on.
Remaining Time
Reminder for filter cleaning.
After the program finishes, this light is on
to remind the user of cleaning the filter.

11
■Drying Programmes Table
Control Panel
Programs
Weight (max)
(kg)
Display Time
Time Adjustment
(min)
Standard
3.0
1:46
/
Extra
3.0
1:58
/
Quick
0.8
0:45
/
Time+
1.0
0:10
10-120
Refresh
1.0
0:10
10-60
Note!
Different series of products may have different combination keys for child lock.
This function is set after the machine starts to operate. Once it’s activated, no pressing
(except power On/Off key) to the dryer can work. If you want to operate the dryer, please
disable the Child Lock first.

12
MAINTENANCES
■Cleaning And Care
Filter clean
Clean the lint filter after each use.
Remove by pulling straight up.
Cleaning filter.
Use wiping cloth or your fingers.
Install filter.
If the filter is cleaned by damp
cloth or water, please install after
the sun dry.
Cleaning cabinet and inner tube
Use soft damp cloth wipe when
cleaning cabinet and inner .tube
Not to rinse by water directly.
Not to use neutral scour wipe.
Not to use gasoline and alcohol wipe.
Make sure open the front door for aeration
after cleaning the inner tube.

13
■Trouble Shooting
Trouble
Cause
Solution
Will not start
Power cut.
The power plug is not fully
plugged.
The clothes in machine are over
loaded.
The temperature fuse is cut.
Wait for switching on electricity.
Check the power socket, make sure fully
plugged.
The clothes in dryer must be after
spinning, and drying clothes cannot
exceed 3kg.
Please arrange technician restore the
temperature fuse.
External hot or
can smell hot
The lint filter is dirty.
The uptake or exhaust duct is dirty.
Make sure clean the lint filter in time.
Clean out the stem.
Clothes too dry
The clothes in machine are over
loaded.
Not to take out the clothes in time
when finish.
The clothes don’t assort properly.
The temperature is too high.
Make sure the clothes are not too full.
Take out the clothes immediately when
finish.
Observe the Laundry Labels.
Clothes shrink
Clothes excessive drying after
laundry.
Observe the Laundry Labels.
If easy to shrink, please check in
advance.
Take out the clothes when tiny damp
before too dry.
Then hang the clothes until full dry.
Hairball on
clothes
It is right for synthetic fiber and
permanent press fiber causing
hairballs. This is because the right
rub causing.
Use fabric softener lubricate fiber,
please spray settled gule on cuff and
neckline when iron clothes. Turn the
sarcenet out for reducing rub.
The sound of dryer may caused by
Heavy / wet clothes’ turning and bumping, and this will cause noise accordingly.
Air bumping: When drying, machine will generate steam which will come out from pipe and this will
cost bumping with the bottom of inner tube.
Error code
Description
Criteria
Action after fault denounced
E33
Temperature
Sensor error
Temperature Sensor
is open or short
Stop the program and go to
fault state

14
■Technical Specifications
Model
PD3EV
Dimension
(D*W*H)
520*435*640
Rated power
1250W
Rated voltage
220-240V~
Rated frequency
50Hz
Weight of product
20kg
Rated capacity
3.0kg
Ambient temperature
5ºC ~35ºC

15
Please record the following product information
Model
Serial No.
Name of the franchiser
Date of purchase
The continuous improvement of products, such as function is
changed, without prior notice, if there are any questions, please
contact customer service, Sorry for the inconvenience, and please
forgiveness.
ToolBox Customer Service Centre:
Service E-mail: [e-mail]
Please register now at: www.toolbox.hk
Website: www.gilman-group.com

乾衣機
使用說明書
型號：PD3EV
操作本機之前，請仔細閱讀本說明書。
注意：火災危險！

1
目錄
安全守則
■安全守則………………………………………………………………………………...
2
安裝
■產品介紹………………………………………………………………………………...
6
■安裝步驟………………………………………………………………………………...
7
操作
■快速操作………………………………………………………………………………...
9
■每次乾衣之前……………………………………………………………………….....
9
■控制面板………………………………………………………………………………...
10
■乾衣程序表……………………………………………………………………………..
11
維修保養
■清潔和保養……………………………………..……………………………………...
12
■疑難排解………………………………………………………………………………...
13
■技術規格………………………………………………………………………………...
14

2
安全守則
本設備不適用於肢體，感官或精神能力較弱或缺乏經驗和知識的人（包括兒童）使用，
除非由負責其安全的人員對他們使用本設備進行監督或指導。
應該督導兒童以確保他們不要玩耍本產品。
如果電源線損壞，則必須由製造商，其服務代理商或合格的技術人員更換，以免造成
危險。
如果已接受有關安全使用本設備的監督或指導，並能理解其危害，則本設備可由 8歲
及以上的兒童以及肢體，感覺或精神能力較弱或缺乏經驗和知識的人員使用。
請勿讓兒童玩耍本產品，不得在沒有監督的情況下由兒童進行清潔和用戶維護。
如果衣物已經使用工業化學品進行清潔，則不要使用此乾衣機。
必須經常清洗集棉器。
切勿使棉絨堆積在滾筒式乾衣機周圍。
請勿在滾筒式乾衣機中烘乾未洗滌的物品。
沾有食用油，丙酮，酒精，汽油，煤油，去污劑，松節油，蠟和除蠟劑等物質的物品應
在熱水中用適量的洗滌劑洗滌，然後在滾筒式乾衣機中乾燥。
泡沫橡膠（乳膠形式），浴帽，防水紡織品，橡膠背襯物品以及配有泡沫橡膠墊的衣服
或枕頭等物品不應在滾筒式乾衣機中乾燥。
應按照織物柔軟劑說明中的說明使用織物柔軟劑或類似產品。
切勿將廢氣排入用於排出設備燃燒氣體或其他燃料煙霧的煙道。
設備不得安裝在可鎖門、滑動門或鉸鏈位於乾衣機另一側的門後面以免限制乾衣機門
完全打開。
受油影響的物品會自燃，尤其是在暴露於熱源（例如滾筒式乾衣機）時。
沾有油的物品會變熱，並會引起氧化反應。氧化會產生熱量。而熱量無法散失時，則物
品可能會變得很熱而著火。堆放，堆疊或存儲受油影響的物品可防止熱量逸出，從而
引起火災。
在正常使用或維護期間，請勿將本產品翻轉。
從口袋裡取出所有物品，例如打火機和火柴。
對於在底座上有通風孔的設備，地毯一定不能阻塞通風孔。
3歲以下的兒童應遠離本設備，除非有人持續監督。
安裝後必須可插拔插頭。
使用設備之前，請先取出所有包裝。否則可能會導致嚴重損壞。

3
警告！
在乾燥程序運作結束之前，切勿停止滾筒式乾衣機，否則過多的热量會散發並
可能造成傷害和造成使用者受傷。
禁止通過外部開關設備（例如計時器）為設備供電，也不能將其連接到由公用
事業公司定期打開和關閉的電路上。
供電和接地
乾衣機採用額定電壓和頻率的交流電流，當電壓在額定電壓的 6%之間波動時，乾衣機可
以正常工作。
為了方便和安全起見，最好在乾衣機旁設定一個容量為≥
10A 的乾衣機專用電源插座，插座的連接方法如下圖所示。
為了安全起見，請根據上述規則和建議儘快進行改進。
警告！
插座和接地線必須由電工安裝，防止不正確安裝或使用插座，保證用電安全接地線
與中性線不得連接，否則會給機體充電，很可能造成觸電危險。
