Philco PHSI 2213 Manual

Instruction manual
Návod k obsluze
Návod na obsluhu
Instrukcja obsługi
Használati útmutató
PHSI 2213

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the
instructions in this user's manual.

1Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
CONTENTS
PART 1: IMPORTANT SAFETY INSTRUCTIONS...................................................................................................................2
PART 2: KNOW YOUR IRON.....................................................................................................................................................3
PART 3: BEFORE FIRST USE ...................................................................................................................................................4
PART 4: HOW TO CLEAN AND STORE .................................................................................................................................7

2Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
PART 1: IMPORTANT SAFETY INSTRUCTIONS
• This appliance may be used by children 8 years of age and
older and by persons with physical or mental impairments
or by inexperienced persons if they are properly
supervised or have been informed about how to use of the
product in asafe manner and understand the potential
dangers. Cleaning and maintenance performed by the
user must not be performed by children unless they are
older than 8 years of age and under supervision. Keep
this appliance and the power cord out of reach of children
younger than 8years of age.
• Children must not play with the appliance.
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should always be followed:
1. Make sure the power used corresponds with the one indicated on the rating label.
2. Use the iron only for needed use as descried in the instruction manual.
3. Close supervision is necessary when any appliance is used near children. Do not leave iron unattended
while connected or on an ironing board. Burns can occur from touching hot metal parts, hot water or steam.
4. Keep the iron out of reach of children.
5. The iron should never be left unattended while it is connected to the mains supply.
6. Unplug the iron from the mains electrical supply before:
7. Cleaning
8. Filling with water or emptying the water tank
9. Immediately after use
10. Never operate the iron with damaged power cord or plug, or after it has fallen or been damaged in any
way. To avoid the risk of electric shock, do not disassemble the iron, take it to a qualified serviceman for
examination and repair.
11. Do not let cord touch hot surfaces.
12. To protect against a risk of electric hazards, do not immerse the iron in water or any other liquid.
13. The iron must be used and rested on a stable surface.
14. When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
15. The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.

3Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
PART 2: KNOW YOUR IRON
11. 1. 2. 3. 4. 5. 6.
7.
8.
10.
9.
1. Waterfilling inlet
2. Steam control turning knob
3. Burst of steam button
4. Spray Button
5. Temperature contron buttons
6. LED display lights
7. Power cord protector
8. Water tank
9. Soleplate
10. Self-cleaning button
11. Spray Nozzle

4Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
PART 3: BEFORE FIRST USE
It is normal for small amount of smoke to be produced the first time, this will quickly disappear.
When using the steam function for the first time, do not direct the steam towards the laundry, as there could
be debris from the steam vents.
FILLING WITH WATER
We recommend the use of distilled water.
Make sure that both the Steam Control turning Knob is in “off”
Hold the iron upright so that the water-filling inlet is in a horizontal position.
Fill with water through Water Filling Inlet until the water reach the “MAX” mark indicated on the side of the iron,
and never fill above this mark.
LED DISPLAY PANEL
Displays the fabric setting and the temperatures indicators
SETTING TEMPERATURE
Follow the ironing instructions on the garment label. If there is no instruction but you do know the kind of fabric,
please consult the following table.
NOTE:
If the fabric consists of various kinds of fabrics, always select the temperature required by the most delicate
fabrics.
Fabric Temperature control Temperature requirement
Synthetic Low temperature
Silk, wool  Medium temperature
Cotton, linen  MAX High temperature
Ironing without steam
If you intend to dry-iron fabrics there is no need to fill the water tank ,However,if water is already in the water
tank, you don’t need to empty it
1. Set the steam control to the off position
2. Plug your iron in to the mains supply socket and switch the socket on ,The STANDBY and and lights will
illuminate.
3. Press the +/- buttons to select the temperature setting appropriate to the fabric type being ironed. For
example, if you select the  setting .The STANDBY and  lights will illuminate and the  light
will flash as your iron heats up .when the  light stops flashing .your iron is at the correct temperature
and ready to use .
4. During use, the  light will flash periodically as your iron maintains the selected temperature

5Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
Steam ironing
If you do not allow your iron to reach the selected temperature, water may drip from the soleplate during steam
ironing .
It is recommended that for harder to iron fabrics such as cotton and linen, steam should be used when ironing.
When ironing cotton and linen ,always select the highest temperature ,steam should never be used on delicate
fabrics like nylons, acrylics and synthetics .
1. Filled your iron with water
2. Plug your iron into the mains supply and switch on
3. Use the +/- buttons to select the  or MAX setting ,The hotter your iron ,The more steams is generated
4. When the  or MAX light stops flashing ,your irons is at the correct temperature and ready to use,
During use, the  or MAX light will flash periodically as your iron maintains the selected temperature
5. Adjust the steam control lever to select the desired steam output
6. Move the steam control lever to the high steam setting to increase the amount of steam ,or towards
the off (0) setting to decrease the amount of steam ,
7. The steam can be shut off at any time by setting the steam control to the off (0) postion
Spraying
The spray function will only operate when there is water in the water tank
1. The water spray can be used to help iron heavy fabrics or difficult areas(collars, pockects, sleeves, creases,
etc ).It can also be uses when ironing delicate fabrics which can not be steam ironed.
2. Simply press the button as required to produce as spray of water .if the spray is being used for the first time
,or if the iron has been standing for some time ,you may need to press the spray button a few times before
it works correctly
Burst of steam
Your iron must be set to either  or MAX ,Wait several seconds between each press of the steam button
.press the shot of steam button whenever you have a stubbom crease that needs extra steam ,Steam will burst
from the holes in the soleplate of your iron into the fabric.
Vertical steam ironing
Never iron garments when they are being worn
Your iron can be used for vertical steam ironing curtains ,dresses on the hangers etc.
1. Fill your iron with water
2. Plug your iron into the mains supply and switch on
3. Use the +/- buttons to select the  or MAX setting ,The hotter your iron ,The more steams is generated
4. When the  or MAX light stops flashing ,your irons is at the correct temperature and ready to use,
During use, the  or MAX light will flash periodically as your iron maintains the selected temperature
5. Hold your iron 15cm(6 inches) from the fabric
6. Press the shot of steam button ,The steam will penetrate the fabric removing the creases. To apply more
steam press the shot of steam button again ,wait several seconds between each press of the button

6Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
ANTI-CALC SYSTEM
A special filter inside the water tank softens the water and prevents scale build-up in the soleplate. The filter is
permanent and does not need replacing.
Note: Use tap water only. Distilled and demineralized water makes the anti-calc system ineffective by altering
its physicochemical characteristics.
ANTI-DRIPPING SYSTEM
This iron is equipped with drip stop function: the iron automatically stops steaming when the temperature is too
low to prevent water from dripping out of the soleplate.
With the anti-dripping system, you can perfectly iron even the most delicate fabrics.
Safety auto shut-off function
ALWAYS disconnect your iron from the mains supply socket after use, NEVER leave the iron unattended with
the auto shut-off function in operation
Your iron will shut off if it has not been used for 15 minutes when resting on its heel ,or 30 seconds with the
soleplate face down ,The STANDBY light will flash indicating that your iron is now in auto-shut off mode.
To restart your iron, either press the +/- buttons or mover your iron gently. The iron will revert back to its
previous setting .

7Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
PART 4: HOW TO CLEAN AND STORE
After using, lift the iron with the filling hole downwards to empty the remaining water from the Water tank.
Insert the plug into the socket, and set the Temperature Control Dial to “MAX” for 1-2 minutes to evaporate the
remaining water, and then unplug the iron and let it cool down before storing it.
ATTENTION:
When the plug connecting with the power socket, the user is not allowed to leave.
When the power cord is damaged, contact your dealers or an authorized service center for repair.
In case of any repairs, replacement of cord or plug, or adjustment, please consult a qualified technician, or take
appliance to an authorized service facility.
NOTE:
1. This appliance is not intended for use by persons (including children) with reduced physical. Sensory
or mental capabilities ,or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the appliance
3. The iron must not be left unattended while it is connected to the supply mains
4. The plug must ne removed from the socket-outlet before the water reservoir is filled with water
5. The filling aperture must not be opened during use ,
6. The iron must be use and rested on a stable surface
7. When placing the iron on its stand, ensure that the surface on which the stand is placed is stable
8. The iron is not be used if it has been dropped .if there are visible signs of demage or it is leaking

8Revison 03/2017Copyright © 2017, Fast ČR, a. s.
EN
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or electronic products must
not be added to ordinary municipal waste. For proper disposal, renewal and recycling hand over these
products to determined collection points. Or as an alternative in some European Union states or other
European countries you may return your products to the local retailer when buying an equivalent new
product. Correct disposal of this product helps save valuable natural resources and prevents damage
to the environment caused by improper waste disposal. Ask your local authorities or collection facility
for more details. In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier for the
necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this product, request the
necessary information about the correct disposal method from the local council or from your retailer.
This appliance complies with EU rules and regulations regarding electromagnetic and electrical safety.
Changes in the text, design and technical specifications may be made without prior notice and we reserve the
right to make such changes.

is aregistered trademark used under license from
Electrolux International Company, U.S.A.
