Philco Pmd 2012 bix User manual

MICROWAVE OVEN

USER’S MANUAL

PMD 2012 BiX

Dear customer,

thank you for buying a PHILCO brand product. So that your appliance serves you well, please read

all the instructions in this user’s manual.

EN - 1

CONTENTS

PART 1: SAFETY PRECAUTIONS..................................................................................................................... 2

PART 2: SETTING UP YOUR OVEN................................................................................................................ 13

PART 3: CONTROL PANEL............................................................................................................................. 15

PART 4: INSTALLATION AND CONNECTION ............................................................................................... 16

PART 5: OPERATION INSTRUCTION ............................................................................................................ 20

PART 6: TROUBLE SHOOTING ...................................................................................................................... 24

PART 7: SPECIFICATIONS ............................................................................................................................. 25

PART 8: DISPOSAL......................................................................................................................................... 26

EN - 2

PART 1: SAFETY PRECAUTIONS

Important safety instructions warning

to reduce the risk of ﬁre, electric shock, injury to per-

sons or exposure to excessive microwave oven energy

when using your appliance, follow basic precautions,

including the following:

1. Warning: Liquids and other foods must not be

heated in sealed containers since they are liable to

explode.

2. Warning: It is hazardous for anyone other than

a competent person to carry out any service or

repair operation that involves the removal of

a cover which gives protection against exposure to

microwave energy.

3. This appliance can be used by children aged from

8 years and above and persons with reduced

physical, sensory or mental capabilities or lack

of experience and knowledge if they have been

given supervision or instruction concerning use

of the appliance in a safe way and understand the

hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall

not be made by children unless they are older than

8 and supervised.

EN - 3

4. Keep the appliance and its cord out of reach of

children less than 8 years.

5. Only use utensils that are suitable for use in

microwave ovens.

6. The oven should be cleaned regularly and any food

deposits should be removed.

7. Read and follow the speciﬁc: “PRECAUTIONS

TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY”.

8. When heating food in plastic or paper containers,

keep an eye on the oven due to the possibility of

ignition.

9. If smoke is emitted, switch oﬀ or unplug the

appliance and keep the door closed in order to stiﬂe

any ﬂames.

10. Do not overcook food.

11. Do not use the oven cavity for storage purposes.

Do not store items, such as bread, cookies, etc.

inside the oven.

12. Remove wire twist-ties and metal handles from

paper or plastic containers/bags before placing

them in the oven.

13. Install or locate this oven only in accordance with

the installation instructions provided.

EN - 4

14. Eggs in their shell and whole hard-boiled eggs

should not be heated in microwave ovens since

they may explode, even after microwave heating

has ended.

15. This appliance is intended to be used in household

and similar applications such as:

- staﬀ kitchen areas in shops, oﬃces and other

working environments;

- by clients in hotels, motels and other residential

type environments;

- farm houses;

- bed and breakfast type environments.

16. If the supply cord is damaged, it must be replaced

by the manufacturer, its service agent or similarly

qualiﬁed persons in order to avoid a hazard.

17. Do not store or use this appliance outdoors.

18. Do not use this oven near water, in a wet basement

or near a swimming pool.

19. The temperature of accessible surfaces may be high

when the appliance is operating.The surfaces are liable

to get hot during use. Keep cord away from heated

surface, and do not cover any vents on the oven.

20. Do not let cord hang over edge of table or counter.

21. Failure to maintain the oven in a clean condition

could lead to deterioration of the surface that

EN - 5

could adversely aﬀect the life of the appliance and

possibly result in a hazardous situation.

22. The contents of feeding bottles and baby food

jars shall be stirred or shaken and the temperature

checked before consumption, in order to avoid burns.

23. Microwave heating of beverages can result in

delayed eruptive boiling, therefore care must be

taken when handling the container.

24. The appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

25. Children should be supervised to ensure that they

do not play with the appliance.

26. The appliances are not intended to be operated

by means of an external timer or separate remote-

control system.

27. Accessible parts may become hot during use.

Young children should be kept away.

28. Steam cleaner is not to be used.

29. During use the appliance becomes hot. Care should

be taken to avoid touching heating elements inside

the oven.

EN - 6

30. Only use the temperature probe recommended for

this oven. (for ovens provided with a facility to use

a temperature-sensing probe.)

31. WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to

avoid touching heating elements. Children less

than 8 years of age shall be kept away unless

continuously supervised.

32. The microwave oven must be operated with the

decorative door open. (for ovens with a decorative

door.)

33. Surface of a storage drawer can get hot.

34. The microwave oven is intended for heating food

and beverages. Drying of food or clothing and

heating of warming pads, slippers, sponges, damp

cloth and similar may lead to risk of injury, ignition

or ﬁre.

READ CAREFULLY AND KEEP FOR FUTURE

REFERENCE

EN - 7

Precautions to avoid possible exposure to excessive

microwave energy

(a) Do not attempt to operate this oven with the door

open since this canresult in harmful exposure to

microwave energy. It is important not to break or

tamper with the safety interlocks.

(b) Do not place any object between the oven front

face and the door or allow soil or cleaner residue to

accumulate on sealing surfaces.

the oven must not be operated until it has been

repaired by a competent person.

Addendum

If the apparatus is not maintained in a good state of

cleanliness, its surface could be degraded and aﬀect

the lifespan of the apparatus and lead to a dangerous

situation.

To Reduce the Risk of Injury to Persons Grounding

Installation

Danger

Electric Shock Hazard Touching some of the inter-

nal components can cause serious personal injury or

death. Do not disassemble this appliance.

EN - 8

Warning

Electric Shock Hazard Improper use of the grounding

can result in electric shock.

Do not plug into an outlet until appliance is properly

installed and grounded.

This appliance must be grounded. In the event of an

electrical short circuit, grounding reduces the risk of

electric shock by providing an escape wire for the elec-

tric current.

This appliance is equipped with a cord having a ground-

ingwirewithagroundingplug.Theplugmustbeplugged

into an outlet that is properly installed and grounded.

Consult a qualiﬁed electrician or serviceman if the

grounding instructions are not completely understood

or if doubt exists as to whether the appliance is prop-

erly grounded.

If it is necessary to use an extension cord, use only

a 3-wire extension cord.

1. A short power-supply cord is provided to reduce

the risks resulting from becoming entangled in or

tripping over a longer cord.

EN - 9

2. If a long cord set or extension cord is used:

1) The marked electrical rating of the cord set or

extension cord should be at least as great as

the electrical rating of the appliance.

2) The extension cord must be a grounding-type

3-wire cord.

3) The long cord should be arranged so that it

will not drape over the counter top or tabletop

where it can be pulled on by children or tripped

over unintentionally.

Cleaning

be sure to unplug the appliance from the power sup-

ply.

1. Clean the cavity of the oven after using with

a slightly damp cloth.

2. Clean the accessories in the usual way in soapy

water.

3. The door frame and seal and neighbouring parts

must be cleaned carefully with a damp cloth when

they are dirty.

4. Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass since they can

scratch the surface, which may result in shattering

of the glass.

EN - 10

5. CleaningTip---For easiercleaningofthecavity walls

that the food cooked can touch: Place half a lemon

in a bowl, add 300ml (1/2 pint) water and heat on

100% microwave power for 10 minutes. Wipe the

oven clean using a soft, dry cloth.

EN - 11

Utensils

Personal Injury Hazard

It is hazardous for anyone other than a compentent person to carry out any service or repair operation that

involves the removalof a cover which gives protection against exposure to microwave energy.

See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.”There

may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the

utensil in question following the procedure below.

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.

2. Cook on maximum power for 1 minute.

3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.

4. Do not exceed 1 minute cooking time.

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts

of meat or poultry to prevent overcooking. Arcing can occur if foil is

too close to oven walls.The foil should be at least 1 inch (2.5cm) away

from oven walls.

Browning dish Follow manufacturer’s instructions. The bottom of browning dish

must be at least 3/16 inch (5mm) above the turntable. Incorrect us-

age may cause the turntable to break.

Dinnerware Microwave-safe only. Follow manufacturer‘s instructions. Do not use

cracked or chipped dishes.

Glass jars Always remove lid. Use only to heat food until just warm. Most glass

jars are not heat resistant and may break.

Glassware Heat-resistant oven glassware only. Make sure there is no metallic

trim. Do not use cracked or chipped dishes.

Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make

slits to allow steam to escape.

Paper plates and cups Use for short–term cooking/warming only. Do not leave oven unat-

tended while cooking.

Paper towels Use to cover food for reheating and absorbing fat. Use with supervi-

sion for a short-term cooking only.

Parchment paper Use as a cover to prevent splattering or a wrap for steaming.

EN - 12

Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should

be labeled „Microwave Safe“. Some plastic containers soften, as the

food inside gets hot. „Boiling bags“ and tightly closed plastic bags

should be slit, pierced or vented as directed by package.

Plastic wrap Microwave-safe only. Use to cover food during cooking to retain

moisture. Do not allow plastic wrap to touch food.

Thermometers Microwave-safe only (meat and candy thermometers).

Wax paper Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray May cause arcing. Transfer food into microwave-safe dish.

Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.

Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause

arcing.

Metal twist ties May cause arcing and could cause a ﬁre in the oven.

Paper bags May cause a ﬁre in the oven.

Plastic foam Plastic foam may melt or contaminate the liquid inside when ex-

posed to high temperature.

Wood Wood will dry out when used in the microwave oven and may split

or crack.

EN - 13

PART 2: SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton and oven cavity.

Your oven comes with the following accessories:

Glass tray 1

Turntable ring assembly 1

Instruction Manual 1

A) Control panel

B) Turntable shaft

C) Turntable ring assembly

D) Glass tray

E) Observation window

F) Door assembly

G) Safety interlock system

Grill Rack (Only be used in grill

function and be placed on the glass

tray)

EN - 14

Turntable Installation

Hub (underside)

Glass tray

Turntable shaft

Turntable ring assembly

a. Never place the glass tray upside down. The glass tray should never be restricted.

b. Both glass tray and turntable ring assembly must always be used during cooking.

c. All food and containers of food are always placed on the glass tray for cooking.

d. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.

EN - 15

PART 3: CONTROL PANEL

Microwave

Grill / Combi.

Weight Defrost

Time Defrost

Kitchen Timer / Clock

+ / -

Stop / Clear

Start / + 30 sec. / Conﬁrm

Display

Door button

EN - 16

PART 4: INSTALLATION AND CONNECTION

1. This appliance is only intended for domestic use.

2. This oven is intended for built-in use only. It is not intended for counter-top use or for use inside a cupboard.

3. Please observe the special installation instructions.

4. The appliance can be installed in a 60cm wide wall-mounted cupboard (at lease 55cm deep and 85cm oﬀ

the ﬂoor).

5. The appliance is ﬁtted with a plug and must only be connected to a properly installed earthed socket.

6. The mains voltage must correspond to the voltage speciﬁed on the rating plate.

7. The socket must be installed and connecting cable must only be replaced by a qualiﬁed electrician. If the

plug is no longer to accessible following installation, an all-pole disconnecting device must be present on

the installation side with a contact gap of at lease 3mm.

8. Adapters, multi-way strips and extension leads must not be used. Overloading can result in a risk of ﬁre.

The accessible surface may be hot during operation.

Installation Instruction

The following must be noted

Electrical connection

The appliance is ﬁtted with a plug and must only be connected to a properly installed earthed socket. Only

a qualiﬁed electrician who takes the appropriate regulations into account may install the socket or replace the

connecting cable. If the plug is no longer accessible following installation, an all-pole isolating switch must be

present on the installation side with a contact gap of at least 3 mm. Contact protection must be ensured by

the installation.

Fitted units

The installation cabinet must not have a back panel behind the appliance. Minimum installation height: 850 mm.

Ventilation slots and intakes must not be covered.

Appliance in a wall-hanging unit - Fig. 1A

Appliance in a tall unit - Fig. 1B

Installing the oven - Fig. 2

Note: Do not trap or kink the mains lead.

EN - 17













PLQ



















PLQ



[

EN - 18







Table of contents

Other Philco Microwave Oven manuals

Popular Microwave Oven manuals by other brands

Modena

Modena MV Series manual

Sharp

Sharp R-450B Service manual

Pelgrim

Pelgrim MAG614RVS Instructions for use

GE JE1460WF datasheet

Flama

Flama 1888FL instruction manual

Maytag

Maytag UMV1152CA Use & care guide

Samsung

Samsung MW8598W Service manual

Samsung

Samsung MC32B7382QD/TL user manual

MASTER KITCHEN

MASTER KITCHEN MKMW FS20G D BK instruction manual

GE Monogram ZE2160SF datasheet

Pelgrim

Pelgrim MAG537RVS Instructions for use

Electrolux

Electrolux EI24MO45IB-EI27MO45TS Guía de Uso y Cuidado

GE Monogram ZEM200BF Dimensions and specifications

LG MH-602Y Service manual

mekappa

mekappa AGILE OWM14X-G6DCG instruction manual

Samsung

Samsung ME73M Owner's instructions & cooking guide

Sanyo

Sanyo EMS5595S - Microwave 0.9 Cubic Feet Instruction manual & cooking guide

Toshiba

Toshiba ML2-EC09SAIT instruction manual

Philco PMD 2012 BiX User manual

Popular Microwave Oven manuals by other brands
