Philco PMD 3410 BIX User manual

MICROWAVE OVEN
OWNER’S MANUAL
PMD 3410 BIX

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2019, Fast ČR, a. s. Revision 09/2019

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 1
CONTENTS
PART 1: SAFETY INFORMATION......................................................................................................................2
Utensils...................................................................................................................................................................................................7
Materials you can use in microwave oven ................................................................................................................................7
Materials to be avoided in microwave oven.............................................................................................................................8
PART 2: SETTING UP YOUR OVEN...................................................................................................................9
Names of Oven Parts and Accessories........................................................................................................................................ 9
Turntable Installation......................................................................................................................................................................10
Installation and connection .........................................................................................................................................................10
PART 3: INSTALLATION INSTRUCTIONS ......................................................................................................11
A. Built-in furniture ..........................................................................................................................................................................12
B. Install the oven.............................................................................................................................................................................13
PART 4: OPERATION INSTRUCTION .............................................................................................................15
1. Clock Setting .................................................................................................................................................................................15
2. Microwave Cooking....................................................................................................................................................................15
3. Grill or Combi. Cooking .............................................................................................................................................................16
4. Convection Cooking (with preheating function).............................................................................................................16
5. Convection Cooking (without preheating function)......................................................................................................17
6. Defrost By Weight........................................................................................................................................................................17
7. Defrost By Time ............................................................................................................................................................................17
8. Multi-Stage Cooking...................................................................................................................................................................17
9. Kitchen Timer ................................................................................................................................................................................17
10. Auto Menu...................................................................................................................................................................................18
11. Speedy Cooking.........................................................................................................................................................................19
12. Lock Function for Children.....................................................................................................................................................19
13. Inquiring Function....................................................................................................................................................................19
PART 5: TROUBLE SHOOTING .......................................................................................................................20
PART 6: SPECIFICATIONS ..............................................................................................................................21
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS...............22
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES.................................................................................22
This appliance has been tested in accordance with the directives in force in the European Union.
This appliance conforms to the relevant safety provisions for electrical appliances in force in the
European Union.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 2
PART 1: SAFETY INFORMATION
• THISAPPLIANCECANBEUSEDBYCHILDRENAGED
FROM8YEARSANDABOVEANDBYPERSONSWITH
REDUCEDPHYSICAL,SENSORYORMENTALCAPABILITIES
ORLACKOFEXPERIENCEANDKNOWLEDGEIFTHEY
HAVEBEENGIVENSUPERVISIONORINSTRUCTIONS
CONCERNINGUSEOFTHEAPPLIANCEINASAFEWAY
ANDIFTHEYUNDERSTANDTHEHAZARDSINVOLVED.
• CHILDRENMUSTNOTPLAYWITHTHEAPPLIANCE.
• CLEANINGANDUSERMAINTENANCECANNOTBE
PERFORMEDBYCHILDRENWITHOUTSUPERVISION.
• IFTHESUPPLYCABLEGETSDAMAGED,HAVEIT
REPLACEDBYASPECIALIZEDSERVICECENTREINORDER
TOAVOIDDANGEROUSSITUATIONS.ITISPROHIBITEDTO
USEANAPPLIANCEWITHTHESUPPLYCABLEDAMAGED.
IMPORTANT SAFETY PRECAUTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
CAUTION:
IF THE DOOR OR DOOR SEAL GET DAMAGED,
THEOVENMUSTNOTBEUSEDUNTILTHEYARE
REPAIREDBYTRAINEDPERSONNEL.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 3
CAUTION:
IT IS DANGEROUS FOR ALL PEOPLE OTHER THAN
TRAINEDPERSONNELTOPERFORMANYREPAIRS
ORMAINTENANCEINVOLVINGREMOVALOFANY
COVERSENSURINGPROTECTIONAGAINSTEMISSION
OFMICROWAVES.
CAUTION:
LIQUIDS AND OTHER FOOD SHOULD NOT BE
HEATEDUPINCLOSEDCONTAINERS,BECAUSETHEY
ARE PRONE TO EXPLOSION.
• THISAPPLIANCEISINTENDEDTOBEUSEDIN
HOUSEHOLDS AND SIMILAR PREMISES, SUCH AS
 KITCHENETTES IN SHOPS, OFFICES AND OTHER
WORKPLACES;
 AGRICULTURAL FACILITIES;
 HOTELS, MOTELS, AND OTHER ACCOMMODATION
FACILITIESWHEREAPPLIANCESAREUSEDBYGUESTS;
 BED AND BREAKFAST FACILITIES.
• THISMICROWAVEOVENISANIN-BUILTAPPLIANCE
INTENDED TO BE BUILT INTO A CABINET. MINIMUM
REQUIRED CABINET DIMENSIONS AND INSTALLATION
REQUIREMENTS ARE INCLUDED IN THIS MANUAL.
• ONLYCONTAINERSSUITABLEFORUSEINMICROWAVE
OVENSCANBEUSED.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 4
• ITISNOTALLOWEDTOUSEMETALFOODORDRINK
CONTAINERSFORCOOKINGINMICROWAVEOVENS.
• WHENHEATINGUPFOODINPAPERORPLASTIC
CONTAINERS,CHECKTHEOVENFROMTIMETOTIMETO
PREVENTIGNITION.
• MICROWAVEOVENISINTENDEDFORHEATINGUPFOOD
ANDDRINKS.DRYINGFOODORCLOTHESANDHEATING
UP HEATING PADS, SLIPPERS, WASHING SPONGES, WET
CLOTHES AND SIMILAR OBJECTS CAN LEAD TO INJURIES,
IGNITION OR FILE.
• IFTHEREISSMOKE,TURNOFFORUNPLUGTHE
APPLIANCEANDLEAVETHEDOORCLOSEDTOPREVENT
POSSIBLE FIRE FROM SPREADING.
• HEATINGUPDRINKSUSINGAMICROWAVECANCAUSE
DELAYEDBOILINGWHICHMUSTBEKEPTINMINDWHEN
HOLDING THE CONTAINER.
• BEFORECONSUMPTION,THECONTENTOFBABY
BOTTLESANDBABYFOODMUSTBESTIRREDORSHAKEN
UP AND THEIR TEMPERATURE MUST BE CHECKED TO
PREVENTBURNING.
• EGGSINSHELLSANDWHOLEHARD-BOILEDEGGSMUST
NOTBEHEATEDUPINMICROWAVEOVENSBECAUSE
THEYCANEXPLODEEVENAFTERHEATINGUPUSING
MICROWAVESHASBEENCOMPLETED.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 5
• DETAILSREGARDINGCLEANINGDOORSEAL,OPERATION
AREAS AND ADJACENT AREAS:
 -THEOVENSHOULDBECLEANEDCORRECTLYAND
POSSIBLEFOODREMAINSSHOULDBEREMOVED.
 -NOTKEEPINGTHEOVENCLEANCOULDLEADTOTHE
SURFACEFINISHDAMAGEWHICHCOULDADVERSELY
AFFECTTHEAPPLIANCE’SSERVICELIFEANDLEADTO
DANGEROUS SITUATIONS.
• DONOTUSETEMPERATUREPROBES.
• PLEASEENSURETHATTHEROTATINGTRAYDOESNOT
CHANGEITSPOSITIONWHENREMOVINGCONTAINERS
FROM THE APPLIANCE.
• THEAPPLIANCEMUSTNOTBECLEANEDUSINGSTEAM
CLEANERS.
• MINIMUMCABINETDIMENSIONSAREINCLUDEDINTHIS
MANUAL.
• IFTHECABINETISEQUIPPEDWITHDECORATIVEDOORS,
THEAPPLIANCECANONLYBEUSEDWITHTHESEDOORS
OPENED.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 6
CLEANING
BE SURE TO UNPLUG THE APPLIANCE FROM THE POWER
SUPPLY.
1. CLEANTHECAVITYOFTHEOVENAFTERUSINGWITHA
SLIGHTLYDAMPCLOTH.
2. CLEANTHEACCESSORIESINTHEUSUALWAYINSOAPY
WATER.
3. THE DOOR FRAME AND SEAL AND NEIGHBOURING
PARTSMUSTBECLEANEDCAREFULLYWITHADAMP
CLOTHWHENTHEYAREDIRTY.
4. DONOTUSEHARSHABRASIVECLEANERSORSHARP
METALSCRAPERSTOCLEANTHEOVENDOORGLASS
SINCETHEYCANSCRATCHTHESURFACE,WHICHMAY
RESULT IN SHATTERING OF THE GLASS.
5. CLEANINGTIP:FOREASIERCLEANINGOFTHECAVITY
WALLS THAT THE FOOD COOKED CAN TOUCH: PLACE
HALF A LEMON IN A BOWL, ADD 300ML 1/2 PINT
WATERANDHEATON100%MICROWAVEPOWERFOR
10MINUTES.WIPETHEOVENCLEANUSINGASOFT,DRY
CLOTH.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 7
Utensils
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry
out any service or repair operation that involves the removal of
a cover which gives protection against exposure to microwave
energy.
See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.”There
may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer‘s instructions. Do not use
cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do
not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits
to allow steam to escape.
Paper plates and cups Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for
a short-term cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 8
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled„Microwave Safe“. Some plastic containers soften, as the food
inside gets hot.„Boiling bags“ and tightly closed plastic bags should be slit,
pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture.
Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed
utensils
Metal shields the food from microwave energy. Metal trim may cause
arcing.
Metal twist ties May cause arcing and could cause a re in the oven.
Paper bags May cause a re in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature.
Wood Wood will dry out when used in the microwave oven and may split or
crack.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 9
PART 2: SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Yourovencomeswiththefollowingaccessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
G
A
CB
ED
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Grill Rack( Can not be used in microwave function and must be placed on the glass tray )

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 10
Turntable Installation
Turntable ring assembly
Turntable shaft
Glass tray
Hub (underside)
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly must always be used during cooking.
c. All food and containers of food are always placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.
Installation and connection
1. This appliance is only intended for domestic use.
2. This oven is intended for built-in use only. It is not intended for counter-top use or for use inside a
cupboard.
3. Please observe the special installation instructions.
4. The appliance can be installed in a 60cm wide wallmounted cupboard.
5. The appliance is tted with a plug and must only be connected to a properly installed earthed socket.
6. The mains voltage must correspond to the voltage specied on the rating plate.
7. The socket must be installed and connecting cable must only be replaced by a qualied electrician.
If the plug is no longer to accessible following installation, an all-pole disconnecting device must be
present on the installation side with a contact gap of at least 3mm.
8. Adapters, multi-way strips and extension leads must not be used. Overloading can result in a risk of re.
The accessible surface may be hot during operation.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 11
PART 3: INSTALLATION INSTRUCTIONS
Please Read the Manual Carefully Before Installation.
Screw
Trim-kit plastic cover
Please note
Electrical connection
The oven is tted with a plug and must only be connected to a properly installed earthed socket. In
accordance with the appropriate regulations, the socket must only be installed and the connecting cable
must only be replaced by a qualied electrician.
If the plug is no longer accessible following installation, an all-pole isolating switch must be present on the
installation side with a contact gap of at least 3 mm.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 12
A. Built-in furniture
The built-in cabinet shall not have a rear wall behind the appliance.
Minimum installation height is 85cm.
Do not cover ventilation slots and air intake points.
600
560+8
(45)
(45)
min
380
50 +3
5

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 13
B. Install the oven
1. •Donottraporkinkthepowercord.
 •Makesurethattheovenisinstalledinthecenterofthecabinet.
Trim-kit plastic cover
Screw
Installation Hole

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 14
Microwave
Grill/Conbi.
Convection
Weight Defrost
Time Defrost
Kitchen Timer
Clock
Stop/Clear
Lock

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 15
PART 4: OPERATION INSTRUCTION
This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better
for cooking.
1. Clock Setting
When the microwave oven is electried, the oven will display“0:00”, buzzer will ring once.
1) In waiting state, press“ “ once, the hour gure ash.
2) Press“ “ or“ “ to adjust the hour gures, the input time should be within 0-23.
3) Press“ “, the minute gures will ash.
4) Press“ “ or“ “ to adjust the minute gures, the input time should be within 0-59.
5) Press“ “ to nish clock setting.“:” will ash.
Note:
1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press“ ”, the oven will go back to the previous status
automatically.
2. Microwave Cooking
1) Press the“ “ key once, and“P100” will display.
2) Press“ “ repeatedly or press“ “ or“ “ to select the microwave power from 100% to 10%.“P100”,
“P80”, “P50”, “P30”, “P10” will display in order.
3) Press“” to conrm.
4) Press“ “ or“ “ to adjust the cooking time.
(The time setting should be 0:05- 95:00.)
5) Press““ to start cooking.
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0 - 1 min: 5 seconds
1 - 5 min: 10 seconds
5 - 10 min: 30 seconds
10 - 30 min: 1 minute
30 - 95 min: 5 minutes
Microwave Power Chart
Microwave
Power 100% 80% 50% 30% 10%
Display P100 P80 P50 P30 P10

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 16
3. Grill or Combi. Cooking
Press“ “ once, the screen will display“G”, and press“ ”repeatedly or press“ “ or“ “ to choose the
mode you want, and“G”, ”C-1”, ”C-2”, ”C-3”or“C-4”will display.
Press““ to conrm and press “
“ or“ “ to set cooking time from 0:05 to 95:00.
Press““ again to start cooking.
Example: If you want to use Combi.(C-1) to cook for 10 minutes, you can operate the oven as the following
steps.
1) Press“ “ once, the screen displays“G”.
2) Continue to press“ “ until the screen displays“C-1”.
3) Press““ to conrm.
4) Press“ “ or“ “ to adjust the cooking time until the oven displays“10:00”.
5) Press““ to start cooking.
Combination Power instructions:
Function Display Microwave Grill Convection
Combi.1 C-1 r r
Combi.2 C-2 r r
Combi.3 C-3 r r
Combi.4 C-4 rrr
Note: If half the grill time passes, the oven sounds twice, and this is normal. In order to have a better eect of
grilling food, you should turn the food over, close the door, and then press ” “ to continue cooking. If
no operation, the oven will continue working.
4. Air hot Cooking (with preheating function)
1) Press“ “ ,“130 °C” will display and ash. Keep pressing“ “ or press“ “ or“ “ to choose the
convection temperature (130-220 °C).
2) Press““ to conrm the temperature.
3) Press““ again to start preheating.
4) The temperature gure will ash when temperature arrives and buzzer will ring twice reminding you to
put food in, then close the door.
5) Press“ “ or“ “ to adjust the cooking time (The maximum time is 95 minutes.)
6) Press““ to start cooking.
Note:
a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
b. When the preheating time is more than 30 minutes and the temperature not arrives,buzzer will sound
twice to tell you to input the cooking time. If the time not input in 5 minutes, the oven will stop
preheating. The buzzer sound ve times and turn back to waiting states.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 17
5. Convection Cooking (without preheating function)
1) Press“ “ ,“130 °C” will display and ash. Keep pressing“ “ or press“ “ or“ “ to choose the
convection temperature (130-220 °C).
2) Press“ “ to conrm the temperature.
3) Press“ “ or“ “ to adjust the cooking time (The maximum time is 95 minutes.)
4) Press““ to start cooking.
6. Defrost By Weight
1) Press“ “ once, the screen will display“dEF1”.
2) Press“ “ or“ “ to select the food weight. The range of weight is 100-2000g.
3) Press““ key to start defrosting.
7. Defrost By Time
1) Press“ “ twice, the screen will display“dEF2”.
2) Press“ “ or“ “ to select the cooking time. The maximum time is 95 minutes.
3) Press““ key to start defrosting.
8. Multi-Stage Cooking
2 stages can be maximumly set. If one stages is defrosting, it should be put in the rst stage automatically.
The buzzer will ring once after each stage and the next stage will begin.
Example: if you want to defrost the food for 5 minutes, then to cook with 80% microwave power for 7
minutes. The steps are as following:
1) Press“ “ once, the screen display“dEF2”.
2) Press“ “ or“ “ to adjust the defrost time of 5 minutes.
3) Press“ “ once, screen will display“P100”.
4) Press“ “ or“ “ to choose microwave power till“P80”display.
5) Press“” to conrm, screen will display“P80“.
6) Press“ “ or“ “ to adjust the cooking time of 7 minutes.
7) Press“” to start cooking.
9. Kitchen Timer
1) Press“ “ once, the screen will display“00:00“ .
2) Press“ “ or“ “ to enter the correct timer.
(The maximum cooking time is 95 minutes)
3) Press“” to conrm setting, timer indicator will be lighted.
4) When the kitchen time is reached, timer indicator will go out. The buzzer will ring 5 times.
If the clock has been set (24-hour system), the screen will display the current time.
Note: The kitchen Time is dierent from 24-hour system. Kitchen Timer is a timer.

Copyright © 2019, Fast ČR, a. s. Revision 09/2019
EN - 18
10. Auto Menu
1) In waiting state, press“ “ to choose the menu from“A-1”to“A-10”.
2) Press“” to conrm the menu you choose.
3) Press“ “ or“ “ to choose the food weight.
4) Press““ to start cooking.
5) After cooking nishes, the buzzer sounds ve times.
Note:
1) Cake menu is under convection cooking with 180 °C -warm-up function, and you should preheat rst
following the auto menu operation, when the oven reaches the temperature, it will stop working and
sound to remind opening the door to put cake in, then press““ to start cooking.
2) When roast chicken is selected and 2/3 of the time has passed, it will ring twice to tell you to turn over
thefood.Youcanjustleaveitcontinue.Forbetterresult,turnthefoodover,closethedoor,andthen
press““ to continue cooking.
The menu chart:
Menu Weight Display Power
A1
AUTO REHEAT
150 g 150 g
100 %
250 g 250 g
350 g 350 g
450 g 450 g
600 g 600 g
A2
POTATO
1 (about 230 g) 1
100 %2 2
3 3
A3
MEAT
150 g 150 g
100 %
300 g 300 g
450 g 450 g
600 g 600 g
A4
VEGETABLE
150 g 150 g
100 %350 g 350 g
500 g 500 g
A5
FISH
150 g 150 g
80 %
250 g 250 g
350 g 350 g
450 g 450 g
650 g 650 g
A6
PASTA
50 g (with cold water
450 g) 50 g
80 %
100 g (with cold water
800 g) 100 g
150 g (with cold water
1200 g) 150 g
