Philex 27815V User manual

Installation
Before installation make sure your TV is switched
off. Select a location on the back of your TV
within comfortable reach of both a powered
USB socket and the “Antenna In” coax socket.
1. Using the sticky pads provided attach the
back of the booster housing to the location
selected on the back of the TV.
2. Connect the booster output lead to the
“Antenna In” socket on your TV, and
connect the lead from your aerial into the
booster aerial in socket.
3. Plug the booster USB lead into a powered
USB socket on the back of your TV and
switch on your TV.
Your antenna’s signal strength will now boosted by
20dB.
Please Note: Make sure the booster does not
cover any vents or connector ports on your TV.
Booster In Out Frequency Suitable
for
Max
Gain
Typ.
Noise
Power
Required
Max
Output
Typ. 5G/4G
Protection
27815V 1 1 88-694MHz
FM/DAB Radio
TV Ch 21-48
Freeview
20dB <2dB 5V USB 100dBµV >40dB
Specications
www.philex.com
1

TV Aerial
Powered
USB Port
“Antenna In”
Socket
Booster
Aerial In
Socket
Booster In Out Frequency Suitable
for
Max
Gain
Typ.
Noise
Power
Required
Max
Output
Typ. 5G/4G
Protection
27815V 1 1 88-694MHz
FM/DAB Radio
TV Ch 21-48
Freeview
20dB <2dB 5V USB 100dBµV >40dB
www.philex.com
2

Additional Advice
If there is no powered USB port available on your
TV you can use a USB mains adaptor or connect
to a USB port on a PC or other USB enabled device.
You may need to use a USB extension lead (not
supplied). Power required DC 5V𝌂100mA.
Troubleshooting
If you experience reception problems,
please see below:
No picture or sound
Is the signal reaching your TV? Please check:
- That the booster is securely connected to the
aerial and TV “Antenna In” socket
- The booster is connected to a powered
USB port
The picture or sound is breaking up
- Use a good quality wideband aerial
ideally tted outdoors
-
Use good quality coax cable - poorly screened
cable can pick up noise/interference
Powered
USB Port
Booster In Out Frequency Suitable
for
Max
Gain
Typ.
Noise
Power
Required
Max
Output
Typ. 5G/4G
Protection
27815V 1 1 88-694MHz
FM/DAB Radio
TV Ch 21-48
Freeview
20dB <2dB 5V USB 100dBµV >40dB
General Safety Precautions
• To clean rst disconnect from your TV and use
a slightly dampened soft cloth. Do not use
chemical solvents or strong detergents.
• Do not attempt to open the unit, there are no
user serviceable parts.
• If anything goes wrong, contact our technical
support or consult a qualied engineer.
www.philex.com
3

Philex reserve the right to modify their designs or
specications, Performance gures quoted are typical and
subject to normal manufacturing and service tolerances.
Standard: EN 303 354
Product Type: D Signal Distribution Amplier
Filter Class: 1 Mitigates 5G/4G interference
Suitable for digital TV signal distribution
Ch21-48 in the UK and EIRE.
Declaration of Conformity
Hereby, Philex declares that this booster/
amplier for TV broadcast reception in
domestic premises is in compliance with the
Radio Equipment Directive 2014/53/EU.
The full Declaration of Conformity is available
by contacting the following internet address:
www.philex.com/DoC
COMPLIANT
www.philex.com
4

Technical Support
If you experience problems setting up your
aerial, please visit our technical website at:
www.philex.com/products/technical-support/
to send us a message
EU Distributor:
Philex Electronic Ireland Ltd.,
Robwyn House, Corrintra,
Castleblayney, Co. Monaghan,
A75 YX76, Ireland
UK Distributor:
Philex Electronic Ltd.,
Kingsher Wharf,
London Road, Bedford,
MK42 0NX, United Kingdom.
Waste electrical and electronic
products should not be disposed
of with household waste. Please
recycle where facilities exist.
Check with your Local Authority
for recycling advice.
Made in China. © Philex Electronic Ltd 2022. vb1.2
Standard: EN 303 354
Product Type: D Signal Distribution Amplier
Filter Class: 1 Mitigates 5G/4G interference
Suitable for digital TV signal distribution
Ch21-48 in the UK and EIRE.
www.philex.com
5

www.philex.com
USB Powered
Compact
Signal Booster
27815V User Guide
Introduction
The USB Powered Compact SLx Booster ts
out of sight behind your TV and requires no
separate power supply unit as it is powered
by one of your TV’s USB ports. Sticky pads are
provided to attach it to the back of your TV.
The unit boosts VHF and UHF antenna signals
by up to 20dB.
Made in China. © Philex Electronic Ltd 2022. vb1.2
5G & 4G
lter
