Philips AVENT SCF900/00 User manual

www.philips.com.cn/AVENT
注册您的产品并在以下网站链接中了解详情
SCF900/00
EN User manual 3 ZH-CN 使用手册 17

3EN
Contents
1 Important 4
2 Your manual breast pump 5
Introduction 5
Overview 6
3 Use your manual breast pump 7
Clean and sterilize 7
Assemble 8
When to express milk 11
Hints to help you succeed 12
Express breast milk 12
Store your breast milk 14
Feed your baby your expressed milk 14
Choose a right teat for your baby 15
Store the manual breast pump 15
4 Troubleshooting 16

4EN
1 Important
Read this user manual carefully before you use the appliance, and save the user
manual for future reference. You can also nd this user manual at Philips website:
www.philips.com.cn/AVENT
• Before each use, check the manual breast pump. If any damage or crack is
found, stop using it immediately.
• Use the supplied components only.
• Use the manual breast pump as instructed in this user manual. Improper
usage could harm the breast.
• Never use feeding teats as dummies, paciers, or soothers.
• Keep all the components away from your baby.
• This manual breast pump is intended for personal use only for hygiene
reasons.
• Food coloring can discolor components, but it will not affect your usage.
• Make sure that the teething baby does not bite the teat too long.The
continuous and prolonged bite will damage the teat.
• For hygiene reasons, replace teats after three months of use. Use only Philips
AVENT teats and bottles together.

5EN
2 Your manual breast pump
Introduction
The silicone diaphragm of Philips Avent manual breast pump provides 100%
reliable vacuum, whilst the Let-down Massage Cushion naturally imitates your
baby’s suckling action to provide fast milk ow – silently, comfortably, and gently.
Doctors recommend that breast milk is the best nutrition for babies during the
rst year, combined with solid food after the rst six months. Your milk is specially
adapted to your baby’s needs and contains antibodies which help protect your
baby against infection and allergies.
Your manual breast pump will help you breast-feed longer.You can express and
store your milk so that – whether you are out for a few hours, taking a well
deserved rest, or back at work – your baby can still enjoy the benets of your
breast milk, even if you can not be there to give it yourself.As the pump is easy to
assemble, silent and discreet you can take it with you anywhere, allowing you to
express milk at your own convenience and maintain your milk supply.

6EN
Overview
Manual breast pump Bottle (Standard)
1Pump cover 10 Adaptor ring for wide neck bottles
2 Let-down Massage Cushion 11 Sealing disc
3Pump body 12 Bottle (120 ml)
4 Stem 13 Screw ring
5 Silicone diaphragm 14 Teat (0m+)
6 Handle 15 Dormal cap
7 Valve
8 Bottle (120 ml)
9 Stand
Tip
•Extra Philips AVENT travel pouches/ bags are sold separately.

7EN
3 Use your manual breast pump
Clean and sterilize
Before each use, clean and sterilize the pump.
• To clean:
• Disassemble all the components, wash them in warm soapy water, and
then rinse them thoroughly.
• Never use abrasive, anti-bacterial cleaning agents, chemical solvents, or
excessive concentration of detergents.
• If necessary, clean the components with a Philips AVENT cleaning brush
sold separately.
• Take care when cleaning the valve. Rub it gently between your ngers in
warm soapy water. Do not insert objects as this may cause damage. If it
gets damaged, your breast pump does not function properly.
• To sterilize:
• Sterilize all the components in a Philips AVENT electric or microwave
steam sterilizer.The pump remains sterile in the sterilizer for a minimum
of six hours, provided the lid is not removed. For details, see the
sterilizer user manual.
• Sterilize all the components in boiling water for ve minutes. Make sure
that the components do not contact the container too long, to avoid
heat deformation.
• If you use a sterilizing solution, do not leave the components in the
solution for longer than recommended.
• Do not store the components in drying/sterilizing cabinets with heating
elements. (The maximum temperature of durance is 110°C.)
After each use, disassemble all the components, clean, and sterilize them as
instructed in this user manual, to ensure hygiene.

8EN
Assemble
Note
•Make sure that you clean and sterilize the pump as instructed in this user manual.
•Make sure that you assemble the pump correctly as instructed in this user manual.
•To avoid leakage: Remove the residue around the rim before assembling. Do not overtighten.
•Wash your hands thoroughly before you take sterilized components.
1 Insert the valve into the pump body from underneath.
2 Put the bottle onto the pump body and turn it anticlockwise to x it.
Note
•Do not overtighten when assembling the bottle to the pump body.

9EN
• If you use a Philips Avent wide neck bottle, put on the adaptor ring.
3 Put the stem into the silicone diaphragm.
4 Put the silicone diaphragm onto the pump body and press the rim to ensure
a perfect seal.
Tip
•It is easier if assembled wet.

10 EN
5 Fasten the circle end of the handle on the stem and press the handle gently
until it clicks into place.
6 Insert the Let-down Massage Cushion into the pump funnel and press the
rim to ensure a perfect seal. (This is easier if assembled wet.)
7 To make the bottle stands stable, insert it into the stand.
Note
•To prevent toppling, insert the bottle into the stand after each use.

11EN
When to express milk
I f possible, wait until your milk supply and breast-feeding schedule are well established,
normally at least 2-4 weeks after birth, unless told otherwise by your doctor or breast-
feeding advisor. The exceptions are:
• If you are expressing milk for your baby to be given in hospital.
• If your breasts are engorged (painful or swollen).You can express a small amount
of milk before or between feeds to ease the pain and to help your baby latch on
more easily.
• If you have sore or cracked nipples and you may wish to express your milk until
they are healed.
• If you are separated from your baby and wish to continue to breast-feed when
you are reunited.You should express your milk regularly to stimulate your milk
supply.
Right times of the day to express your milk:
• Early in the morning when your breasts are full, just before or after your baby’s
rst feed.
• After a feed, if your baby has not emptied both breasts.
• Between feeds or in a break if you have returned to work.

12 EN
Hints to help you succeed
The pump is easy to use.Take some practice and you can get used to expressing your milk.
• Choose a time when you are not rushed and will not be interrupted.
• Having your baby or a photograph of your baby nearby can help encourage ‘let-
down’.
• Placing a warm cloth on the breasts for a few minutes before you start pumping can
encourage milk ow and soothe painful breasts.
• Warmth and relaxation can encourage milk ow. Try expressing after a bath or
shower.
• Try expressing from one breast while your baby is feeding from the other, or
continue expressing just after a feed.
• Repositioning the pump on the breast from time to time can help stimulate your milk
ducts.
Tip
•Practice with your pump to nd the best technique for you. However, if the process becomes
painful, stop and consult your breast-feeding advisor.
Express breast milk
Note
•Make sure that the Let-down Massage Cushion is clean.
•If you nd that you regularly express more than 120 ml per session, you can use a 240 ml Philips
AVENT bottle, sold separately. Do not overll the Philips AVENT bottle but keep upright, to avoid
leakage.
•If the process becomes painful or uncomfortable, stop using the pump and consult your health
professional or breast-feeding advisor.
1 Wash your hands thoroughly and make sure that your breasts are clean.
Gently squeeze a little milk from each nipple to make sure that milk ducts
are not blocked.
2 Make sure that you sterilize and correctly assemble your pump as instructed
in the "Clean and sterilize" and "Assemble" sections.

13EN
3 Express milk at the right time. For details, see the "Hints to help you succeed"
section.
4 Relax in a comfortable chair, leaning slightly forward (using cushions to
support your back). Make sure that you have a glass of water nearby.
Correction position Maximum angle Incorrect position
5 Press the funnel and the let-down massage cushion of the pump rmly against
your breast. Make sure that no air escapes – otherwise there is no suction.
6 As you gently press the handle, you will feel the suction on your breast.You
do not need to depress the handle fully to create a vacuum – only as much
as it is comfortable. Your milk will soon start owing, even though you do not
use all the suction that the pump can generate.
7 Begin by pumping 5-6 times rapidly to initiate let-down.Then, hold the
handle down for 2-3 seconds, and allow it to return to its resting place.These
2-3 second cycles imitate your baby’s natural suckling pattern and allow the
milk to ow between strokes.
8 Milk begins to ow after the rst few strokes. Do not worry if your milk
does not ow immediately. Relax and continue pumping.
Do not continue pumping for more than 5 minutes at a time if no result is
achieved.Try expressing at another time during the day.
9 In average, you need to pump for 10 minutes to express 60-120 ml. This
depends from person to person. If you notice that you can rhythmically
express more than 120ml each time, use the respective size of Philips
AVENT milk bottle for storage. Never tilt the breast pump when the milk
has reached the maximum line on the bottle. Replace with a new bottle
before re-pumping to avoid spillage.

14 EN
Store your breast milk
Caution
•Never refreeze breast milk.
•Do not add fresh breast milk to already frozen milk.
•Discard any milk that is left over at the end of a feed.
• Store expressed milk in Philips AVENT bottles tted with sealing discs and
refrigerated in the fridge or freezer immediately.
• You can store expressed breast milk in the refrigerator for up to 48 hours
(not in the door) or in the freezer for up to 3 months. Label the bottles with
the date and time of expression and use up older milk rst.
• Store only milk collected with a sterile pump to feed your baby.
Feed your baby your expressed milk
• If you store breast milk in a Philips AVENT bottle, replace the sealing disc with a
sterilized Philips AVENT teat before feeding.
• Defrost frozen breast milk overnight in the refrigerator. However, in an emergency,
you can defrost it in a jug of hot water. Once it is thawed, use within 24 hours.
• To heat breast milk:
• Stand the Philips AVENT bottle in a bowl of hot water.
• Use the Philips AVENT bottle and baby food warmer. Always check milk or food
temperature before feeding.
• Never heat breast milk in a microwave as this may destroy valuable nutrients and
antibodies. In addition, the uneven heating may cause hot spots in the liquid which
could cause burns to the throat.
• Never immerse a frozen bottle in boiling water to avoid crack or split.

15EN
Choose a right teat for your baby
小
Small
中
Medium
大
Large
Cross cut for
thicker feeds
+字孔适合
浓稠液体
Philips AVENT teats in four ow rates are designed for babies at different ages. The
replacement teats are sold separately.
The four ow rates are indicated on the teats as S (small), M (medium), L (large),
and +(cross cut for thicker feeds).
Philips AVENT standard teats are designed for the Philips AVENT standard bottles.
Choose a teat proper for your baby.The age proposed is for your reference only.
Store the manual breast pump
• Keep the small components away from children.
• Keep all the components away from the source of heat or direct sunlight.
• For hygiene maintenance, disassemble the manual breast pump and store all
the components in a dry and covered container.

16 EN
4 Troubleshooting
Problem Solution
Lack of suction • Make sure that all the components are assembled correctly
and that the valve is the right way up.
• Make sure that the diaphragm and Let-down Massage
Cushion are tted securely to the pump body and a
perfect seal is created.
No milk being
expressed
• Make sure that suction is created and the pump is correctly
assembled. Relax and try again, expression may improve
after practice. Please refer to the "Hints to help you suc-
ceed" section.
Pain in the
breast area
when expressing
• You may pump too hard.You do not need to use all the
suction that the pump can generate.Try pressing the handle
halfway and remember the 2-3 seconds pumping cycles.
• Consult your health professional/breast-feeding advisor
(see section “Hints to help you succeed”).
Milk drawn up
the Let-down
Massage Cushion
• Remove and ret the Let-down Massage Cushion. Make
sure that it is installed correctly and rmly.
• Try leaning lightly forward.
Cracking/
Discoloring
• Avoid contact antibacterial or abrasive detergents/cleaners.
• Combinations of detergents, cleaning products, sterilization
solution, softened water, and temperature uctuations may
cause the plastic to crack. If any crack is found, stop using
the pump immediately. Contact Philips AVENT consumer
care center for spare components.
• Food coloring can discolor components, but it will not
affect your usage.
• Keep all the components away from the source of heat or
direct sunlight as it can discolor components.
Components
broken or lost
• Contact Philips AVENT consumer care center for spare
components. For detailed contact information, see the back
cover of this user manual.
If you are unable to solve the problem with the provided information, contact the
Philips AVENT Consumer Care staffs. You can also consult your health professional
or breast-feeding advisor.

17
ZH-CN
目录
目录
1 重要安全说明 18
2 手动吸乳器 19
产品简介 19
功能概述 20
3 使用手动吸乳器 21
清洗与消毒 21
组装吸乳器 21
挤乳的最佳时间 24
如何成功挤乳 25
如何吸乳 25
母乳储存 27
用挤出的母乳喂食婴儿 27
选择适合宝宝的奶嘴 28
吸乳器存储 28
4 故障排除指南 29

18 ZH-CN
1 重要安全说明
使用产品之前，请仔细阅读本用户手册，并妥善保管以备日后参考。您也
可登入我们的网站查阅本产品的用户手册： www.philips.com.cn/AVENT
• 每次使用前，必须检查手动吸乳器各组件是否磨损或损坏；如有磨损
或损坏，必须立即停止使用。
• 必须使用所提供的零部件。
• 过度或不当使用吸乳器可能损伤乳房组织。
• 切勿将奶嘴用作安抚奶嘴。
• 切勿让婴幼儿将组件放入嘴中；必须将本品及组件置于婴幼儿不可触
及的地方。
• 本产品仅打算为个人使用。多人使用可能会对健康造成威胁。切勿将
本品用于本使用说明之外的其他用途。
• 食物颜色可能使组件变色，但不影响使用。
• 避免长牙期的宝宝长时间持续扯咬奶嘴，以防损坏奶嘴。
• 出于卫生考虑，建议每 3 个月更换一次奶嘴；飞利浦新安怡奶嘴与飞
利浦新安怡奶瓶配合使用。

19
ZH-CN
2 手动吸乳器
产品简介
飞利浦新安怡手动吸乳器的硅胶控制阀门结合花瓣按摩软垫一起运作，使
整体功能如同自然模拟宝宝吸母乳的动作与节奏，可安静、舒适、轻柔、
快速地挤出乳汁。
医师推荐，母乳是一岁以下婴儿最好的营养食物，宝宝出生 6 个月后，可
继续母乳喂养并逐渐添加一些辅食。您的乳汁中除含有宝宝所需要的各种
营养成分外，还含有能增强宝宝免疫力的抗体，从而保护宝宝不受感染或
过敏。
手动吸乳器有助于延长您的哺乳时间，您可以挤出乳汁并储存起来，当您
需要外出数小时、享受充分的休息或是回到工作中时，就算不能在宝宝身
边亲自哺育，您的宝宝仍然可以享用您的乳汁。手动吸乳器易于组装，使
用安全无噪音，您可以随身携带，在方便的时候挤乳，为宝宝提供乳汁。

20 ZH-CN
功能概述
手动吸乳器 标准口径奶瓶
1吸乳器封盖 10 宽口径奶瓶转换头
2花瓣按摩软垫 11 密封垫
3主体 12 奶瓶（120 毫升）
4拉杆 13 螺旋盖
5硅胶控制阀门 14 奶嘴（新生儿流量）
6手柄 15 瓶盖
7鸭嘴阀
8奶瓶（120 毫升）
9底座
提示
•为使出行时携带方便，您可选购另售的飞利浦新安怡吸乳器便携包。
