Philips Semiconductors Product data
NE/SA/SE5534/5534ASingle low noise operational amplifier
2001 Aug 03 3
ABSOLUTE MAXIMUM RATINGS
SYMBOL PARAMETER RATING UNIT
VSSupply voltage ±22 V
VIN Input voltage ±V supply V
VDIFF Differential input voltage1±0.5 V
Tamb Operating temperature range
NE 0 to +70 °C
SA –40 to +85 °C
SE –55 to +125 °C
Tstg Storage temperature range –65 to +150 °C
TjJunction temperature 150 °C
PDPower dissipation at 25 °C2
SO8 package 750 mW
DIP8 package 1150 mW
Output short-circuit duration3Indefinite
Tsld Lead soldering temperature (10 sec max) 230 °C
NOTES:
1. Diodes protect the inputs against over voltage. Therefore, unless current-limiting resistors are used, large currents will flow if the differential
input voltage exceeds 0.6 V. Maximum current should be limited to ±10 mA.
2. For operation at elevated temperature, derate packages based on the following junction-to-ambient thermal resistance:
8-pin plastic DIP 105 °C/W
8-pin plastic SO 160 °C/W
3. Output may be shorted to ground at VS= ±15 V, Tamb = 25 °C. Temperature and/or supply voltages must be limited to ensure dissipation
rating is not exceeded.
DC ELECTRICAL CHARACTERISTICS
Tamb = 25 °C; VS= ±15 V, unless otherwise specified. 1, 2, 3
NE/SA5534/5534A SE5534/5534A
Min Typ Max Min Typ Max
VOS 0.5 4 0.5 2 mV
Offset voltage Over temperature 5 3 mV
∆VOS/∆T 5 5 µV/°C
IOS 20 300 10 200 nA
Offset current Over temperature 400 500 nA
∆IOS/∆T 200 200 pA/°C
IB500 1500 400 800 nA
Input current Over temperature 2000 1500 nA
∆IB/∆T 5 5 nA/°C
ICC Supply current 4 8 4 6.5 mA
per op amp Over temperature 10 9 mA
VCM Common mode input range ±12 ±13 ±12 ±13 V
CMRR Common mode rejection ratio 70 100 80 100 dB
PSRR Power supply rejection ratio 10 100 10 50 µV/V
-
RL≥600 Ω, VO= ±10 V 25 100 50 100 V/mV
Over temperature 15 25 V/mV
VOUT Output swing RL≥600 Ω±12 ±13 ±12 ±13 V
Over temperature ±10 ±12 ±10 ±12 V
RL≥600 Ω; VS= ±18 V ±15 ±16 ±15 ±16 V
RL≥2 kΩ±13 ±13.5 ±13 ±13.5 V
Over temperature ±12 ±12.5 ±12 ±12.5 V
RIN Input resistance 30 100 50 100 kΩ
ISC Output short circuit current 38 38 mA
NOTES:
1. For NE5534/5534A, TMIN = 0 °C, TMAX = 70 °C
2. For SA5534/5534A, TMIN = –40 °C, TMAX = +85 °C
3. For SE5534/5534A, TMIN = –55 °C, TMAX = +125 °C
