Philips CD1802B/90 User manual

CD180
Register your product and get support at
www.philips.com/welcome
EN User manual

2
Delete a record 16
Delete all records 16
Direct access memory 16
7 Call log 17
View the call records 17
Save a call record to the phonebook 17
Delete a call record 17
Delete all call records 17
Return a call 17
8 Redial list 18
View the redial records 18
Redial a call 18
Save a call record to the phonebook 18
Delete a redial record 18
Delete all redial records 18
9 Phone settings 19
Sound settings 19
Name the handset 19
Set the date and time 19
Set the display language 19
10 Services 20
Auto conference 20
Network type 20
Select the recall duration 20
Dial mode 20
Register the handsets 21
Unregister the handsets 21
Restore default settings 21
11 Default settings 22
12 Technical data 23
13 Frequently asked questions 24
14 Notice 25
Declaration of conformity 25
Use GAP standard compliance 25
Compliance with EMF 25
Contents
1 Important safety instructions 4
2 Your CD180 5
What is in the box 5
Overview of the phone 6
Overview of the base station 7
Display icons 7
3 Get started 8
Connect the base station 8
Install the handset 8
Congure your phone (country dependent)
9
Charge the handset 9
Check the battery level 10
What is standby mode? 10
Check the signal strength 10
Switch your handset On/Off 10
4 Calls 11
Make a call 11
End a call 12
Answer a call 12
Adjust the earpiece volume 12
Mute the microphone 12
Make a second call 12
Answer a second call 12
Toggle between two calls 12
Make a conference call with the external
callers 13
5 Text and numbers 14
Enter text and numbers 14
6 Phonebook 15
View the phonebook 15
Search a record 15
Call from the phonebook 15
Access the phonebook during a call 15
Add a record 15
Edit a record 16
EN

3
Disposal of your old product and batteries
25
English
EN

4
Caution
Use only the power adapter listed in the user•
instructions.
Use only the batteries listed in the user
•
instructions.
Do not allow the charging contacts or the
•
battery to come into contact with metal
objects.
Do not open the handset, base station or
•
charger as you could be exposed to high
voltages.
Do not allow the product to come into
•
contact with liquids.
Risk of explosion if battery is replaced by an
•
incorrect type.
Dispose of used batteries according to the
•
instructions.
Always use the cables provided with the
•
product.
For pluggable equipment, the socket-outlet
•
shall be installed near the equipment and shall
be easily accessible.
This equipment is not designed to make
•
emergency calls when the power fails. An
alternative has to be made available to allow
emergency calls.
Do not expose the phone to excessive heat
•
caused by heating equipment or direct sunlight.
Do not drop your phone or allow objects to
•
fall on your phone.
Do not use any cleaning agents containing
•
alcohol, ammonia, benzene, or abrasives as
these may harm the set.
Do not use the product in places where there
•
are explosive hazards.
Do not let small metal objects come into
•
contact with the product. This can deteriorate
audio quality and damage the product.
Active mobile phones in the vicinity may cause
•
interference.
Metallic objects may be retained if placed near
•
or on the handset receiver.
About operating and storage temperatures
Operate in a place where temperature is
•
always between 0°C to +35°C (32°F to
95°F).
Store in a place where temperature is
•
always between -20°C and +45°C (-4° F
to 113° F).
Battery life may be shortened in low
•
temperature conditions.
1 Important safety
instructions
Power requirements
This product requires an electrical supply
•
of 100-240 volts AC. In case of power
failure, the communication can be lost.
The voltage on the network is classied
•
as TNV-3 (Telecommunication Network
Voltages), as dened in the standard EN
60950.
Warning
The Electrical network is classied as •
hazardous. The only way to power down the
charger is to unplug the power supply from
the electrical outlet. Ensure that the electrical
outlet is always easily accessible.
To avoid damage or malfunction
EN

5
Line cord*
Guarantee
Quick start guide
Note
* In some countries, you have to connect the•
line adapter to the line cord, then plug the line
cord to the telephone socket.
2 Your CD180
Congratulations on your purchase and welcome
to Philips!
To fully benet from the support that Philips
offers, register your product at www.philips.
com/welcome.
What is in the box
Base station
Handset
Charger
Power adapter
English
EN

6
1Earpiece
2REDIAL/C - Delete text or
digits.
- Cancel operation.
- Enter the redial list.
3- Scroll up on the
menu.
- Increase the
earpiece volume.
- Enter the
phonebook.
4- End the call.
- Exit the menu/
operation.
- Press and hold to
turn the handset
on/off.
5#- Make a predial call.
- Press and hold to
enter a pause.
6- Mute/unmute the
microphone.
7Microphone
8R- Recall key
(This function is
network dependent.)
9*- Set the dial mode
(pulse mode or
temporary tone
mode).
10 - Make and receive
calls.
11 - Scroll down on the
menu.
- Decrease the
earpiece volume.
- Enter the call log.
12 MENU/OK - Access the main
menu.
- Conrm the
selection.
- Enter the options
menu.
13 Battery door
Overview of the phone
EN

7
Icon Descriptions
When the handset is off the base
station/charger, the bars indicate
the battery level (full, medium
and low).
When the handset is on the base
station/charger, the bars keep
scrolling until charging completes.
The empty battery icon ashes
and you hear an alert tone.
The battery is low and needs
recharging.
It displays the link status between
the handset and base station. The
more bars are shown, the better
the connection is.
It indicates a received call in the
call log.
It indicates an outgoing call in the
redial list.
It ashes when there is a new
missed call.
It is steadily on when browsing
the missed calls in call log.
It ashes when receiving an
incoming call.
It remains steadily on when you
hang up the phone.
The ringer is off.
It ashes when there is a new
voice message.
It remains steadily on when
the voice messages are already
viewed in the call log.
It is off when there is no voice
message.
/ It displays when you scroll up/
down a list/increase and decrease
the volume.
There is more digits on the right.
Overview of the base station
1 - Find handsets.
- Press and hold to register
additional handsets.
Display icons
In standby mode, the icons shown on the main
screen tell you what features are available on
your handset.
English
EN

8
the power socket on the wall.•
Install the handset
Caution
Risk of explosion! Keep batteries away from•
heat, sunshine or re. Never discard batteries
in re.
Use only the supplied batteries.
•
Risk of decreased battery life! Never mix•
different brands or types of batteries.
Warning
Check the battery polarity when inserting in•
the battery compartment. Incorrect polarity
may damage the product.
The batteries are pre-installed in the handset.
Pull the battery tape off from the battery door
before charging.
3 Get started
Caution
Ensure you have read the safety instructions in•
the “Important” section before you connect
and install your handset.
Connect the base station
Warning
Risk of product damage! Ensure that the•
power supply voltage corresponds to the
voltage printed on the back or the underside
of the phone.
Use only the supplied power adapter to charge
•
the batteries.
Note
If you subscribe to the digital subscriber line•
(DSL) high speed internet service through
your telephone line, ensure you install a DSL
lter between the telephone line cord and
the power socket.. The lter prevents noise
and caller ID problems caused by the DSL
interference. For more information on the DSL
lters, contact your DSL service provider.
The type plate is located on the bottom of the
•
base station.
1Connect each end of the power adapter
to:
the DC input jack at the bottom of
•
the base station;
the power socket on the wall.
•
2Connect each end of the line cord to:
the telephone socket at the bottom•
of the base station;
the telephone socket on the wall.
•
3Connect each end of the power adapter
to (for multi handset version only):
the DC input jack at the bottom of
•
the extra handset charger.
EN

9
2Select [PHONE SETUP] > [DATE/
TIME], then press MENU/OK to conrm.
3Select the setting. Select [DD/MM]
or [MM/DD] as the date display and
[12 HOURS] or [24 HOURS] as the
time display. Then press MENU/OK to
conrm.
The setting is saved.
»
Note
The date and time format setting is country•
dependent.
Charge the handset
Place the handset on the base station to charge
the handset.When the handset is placed
correctly on the base station, your hear a
docking sound.
The handset starts charging.
»
Note
Charge the batteries for 8 hours before rst •
use.
If the handset becomes warm when the
•
batteries are being charged, it is normal.
Your phone is now ready to use.
Congure your phone
(country dependent)
1 When using your phone for the rst time,
you see a welcome message.
2Press MENU/OK.
Set the country/language
Select your country/language if prompted,
then press MENU/OK to conrm.
The country/language setting is saved.
»
Note
The country/language setting option is•
country dependent. If no welcome message
is displayed, it means the country/language
setting is preset for your country. Then you
can set the date and time.
Set the date and time
Tip
To set the date and time later, press•REDIAL/
Cto skip this setting.
1Press MENU/OK.
2Select [PHONE SETUP] > [DATE/
TIME], then press MENU/OK to conrm.
3Press the numeric buttons to enter the
date, then press MENU/OK to conrm.
The time setting menu is displayed on
»
the handset.
4Press the numeric buttons to enter the
time.
If the time is in 12-hour format, press
•
/ to select [AM] or [PM].
5Press MENU/OK to conrm.
Set the date and time format
1Press MENU/OK.
English
EN

10
Check the signal strength
It displays the link status between
the handset and base station. The
more bars are shown, the better
the connection is.
Ensure the handset is linked to the base
•
station before you make or receive calls
and carry out the phone functions and
features.
If you hear warning tones when you are
•
on the phone, the handset is almost out
of battery or the handset is out of range.
Charge the battery or move the handset
nearer to the base station.
Switch your handset On/Off
Press and hold• to switch off the
handset. The handset’s screen turns off.
Note
When the handset is switched off, no call can•
be received.
Press and hold• to switch on the
handset. It takes a few seconds for the
handset to power up.
Check the battery level
The battery icon displays the current battery
level.
When the handset is off the base
station/charger, the bars indicate
the battery level (full, medium
and low).
When the handset is on the base
station/charger, the bars ash
until charging completes.
The empty battery icon ashes.
The battery is low and needs
recharging.
The handset turns off if the batteries are empty.
If you are on the phone, you hear warning
tones when the batteries are almost empty.The
call gets disconnected after the warning.
What is standby mode?
Your phone is in standby mode when it is idle.
The standby screen displays the handset name
and number/date and time, signal icon, and
battery icon.
EN

11
The redial list is displayed and the most»
recent number is highlighted.
2Press .
The most recent number is then dialed»
out.
Call from the redial list
You can make a call from the redial list.
Tip
For more information, see “Redial a call” in the•
Redial list section.
Call from the phonebook
You can make a call from the phonebook list.
Tip
For more information, see “Call from the•
phonebook” in the Phonebook section.
Call from the call log
You can return a call from the received or
missed call log.
Tip
For more information, see “Return a call” in•
the Call log section.
Note
The call timer displays the talk time of your•
current call.
Note
If you hear warning tones, the handset is•
almost out of battery or the handset is out
of range. Charge the battery or move the
handset nearer to the base station.
4 Calls
Note
When the power fails, the phone cannot•
access emergency services.
Tip
Check the signal strength before you make•
a call or when you are in a call. For more
information, see “Check the signal strength” in
the Get started section.
Make a call
You can make a call in these ways:
Quick call
•
Dial before you call•
Redial the most recent number•
Call from the redial list.•
Call from the phonebook list•
Call from the call log•
Quick call
1Press .
2Dial the phone number.
The number is dialed out.»
The duration of your current call is
»
displayed.
Dial before you call
1Dial the phone number
To erase a digit, press• REDIAL/C.
To enter a pause, press and hold
• #.
2Press to dial out the call.
Redial the most recent number
1Press REDIAL/C.
English
EN

12
The caller cannot hear you, but you»
can still hear his voice.
2Press again to unmute the microphone.
You can now communicate with the»
caller.
Make a second call
Note
This service is network dependent.•
1Press Rduring a call.
The rst call is put on hold.
»
2Dial the second number.
The number displayed on the screen is»
dialed out.
Answer a second call
Note
This is a country dependent setting.•
When there is a periodical beep to notify you
of an incoming call, you can answer the call in
these ways:
1Press R and to answer the call.
The rst call is put on hold, and you »
are now connected to the second call.
2Press Rand to end the current call
and answer the rst call.
Toggle between two calls
1Press R and .
The current call is put on hold, and you»
are now connected to the other call.
End a call
You can end a call in these ways:
Press
• ; or
Place the handset to the base station•
or charging cradle.
Answer a call
When the phone rings, press .
Warning
When the handset rings, keep the handset•
away from your ear to avoid ear damage.
Note
The caller ID service is available if you have•
registered to the caller ID service with your
service provider.
Tip
When there is a missed call, the handset•
displays a notication message.
Turn off the ringer for all incoming
calls
When the phone rings, press .
Adjust the earpiece volume
Press / to adjust the volume during a call.
The earpiece volume is adjusted and»
the phone is back to the call screen.
Mute the microphone
1Press during a call.
The handset displays»[MUTE ON].
EN

13
Make a conference call with
the external callers
Note
This service is network dependent. Check with•
the service provider for additional charges.
When you are connected to two calls, press R,
then .
The two calls are combined and a»
conference call is established.
English
EN

14
Key Characters (for Greek)
0 space 0
1 - 1
2A B 2 Γ
3Δ E Z 3
4H Θ | 4
5K Λ M 5
6N Ξ O 6
7Π P Σ 7
8T Y Φ 8
9X Ψ Ω 9
5 Text and
numbers
You can enter text and numbers for handset
name, phonebook records, and other menu
items.
Enter text and numbers
1Press once or several times on the
alphanumeric key to enter the selected
character.
2Press REDIAL/C to delete the character.
Press / to move the cursor left and
right.
key Characters (for English/
Latin/Norwegian/
Danish/Polish)
0 space 0 Ø
1 - 1
2 A B C 2 Æ
3 D E F 3
4 G H I 4
5J K L 5 Ł
6 M N O 6
7 P Q R S 7
8 T U V 8
9W X Y Z 9
** ? / \ ( )
# # ‘ , - &
EN

15
2Press the alphanumerical key that
corresponds to the character.
The rst record that starts with this
»
character is displayed.
Call from the phonebook
1Press or press MENU/OK >
[PHONEBOOK] > [VIEW] to access the
phonebook list.
2Select a contact in the phonebook list.
3Press to make the call.
Access the phonebook during
a call
1Press MENU/OK, select
[PHONEBOOK] then press MENU/OK
again to conrm.
2Select the contact, then press MENU/OK
to conrm.
The number can be viewed.
»
Add a record
Note
If your phonebook memory is full, the handset•
displays a notication message. Delete some
records to add new ones.
1Press MENU/OK.
2Select [PHONEBOOK] > [ADD NEW],
then press MENU/OK to conrm.
3Enter the name, then press MENU/OK to
conrm.
4Enter the number, then press MENU/OK
to conrm
Your new record is saved.
»
6 Phonebook
This phone has a phonebook that stores up to
50 records.You can access the phonebook from
the handset. Each record can have a name up
to 12 characters long and a number up to 24
digits long.
View the phonebook
Note
You can view the phonebook on one handset•
only each time.
1Press or press MENU/OK >
[PHONEBOOK] > [VIEW] to access the
phonebook list.
2Select a contact and view the available
information.
Search a record
You can search the phonebook records in these
ways:
Scroll the contacts list.
•
Enter the rst character of the contact.•
Scroll the contact list
1Press or press MENU/OK >
[PHONEBOOK] > [VIEW] to access the
phonebook list.
2Press and to scroll through the
phonebook list.
Enter the rst character of a contact
1Press or press MENU/OK >
[PHONEBOOK] > [VIEW] to access the
phonebook list.
English
EN

16
Delete all records
1Press MENU/OK.
2Select [PHONEBOOK] > [DELETE
ALL], press MENU/OK to conrm.
The handset displays a conrmation
»
request.
3Press MENU/OK to conrm.
All records (except the 2 direct access
»
memory records) are deleted.
Direct access memory
You have 2 direct access memories (Keys
1 and 2). To dial the saved phone number
automatically, press and hold on the keys in
standby mode.
Depending on your country, Keys 1 and 2 are
preset to [1_VOICEMAIL] (voice mail number)
and [2_INFO SVC] (information service
number) of your network operator respectively.
Tip
Press and hold•#to insert a pause.
Note
The phonebook only saves new number entry.•
Tip
For more information on how to edit the•
numbers and name, see the section on Text
and numbers.
Edit a record
1Press MENU/OK.
2Select [PHONEBOOK] > [EDIT], then
press MENU/OK to conrm.
3Select a contact, then press MENU/OK
to conrm.
4Edit the name, then press MENU/OK to
conrm.
5Edit the number, then press MENU/OK
to conrm.
The record is saved.
»
Delete a record
1Press MENU/OK.
2Select [PHONEBOOK] > [DELETE],
then press MENU/OK to conrm.
3Select a contact, then press MENU/OK
to conrm.
The handset displays a conrmation
»
request.
4Press MENU/OK to conrm.
The record is deleted.
»
EN

17
5Enter and edit the number, then press
MENU/OK to conrm.
The record is saved.
»
Delete a call record
1Press .
The incoming call log is displayed.»
2Select a record, then press MENU/OK to
conrm.
3Select [DELETE], then press MENU/OK
to conrm
The handset displays a conrmation
»
requests.
4Press MENU/OK to conrm.
The record is deleted.
»
Delete all call records
1Press .
The incoming call log is displayed.»
2Press MENU/OK to enter the options
menu.
3Select [DELETE ALL], then press MENU/
OK to conrm
The handset displays a conrmation
»
requests.
4Press MENU/OK to conrm.
All records are deleted.
»
Return a call
1Press .
2Select a record on the list.
3Press to make the call.
7 Call log
The call log stores the call history of all missed
or received calls.The incoming call history
includes the name and number of the caller,
call time and date.This feature is available if you
have registered to the caller ID service with
your service provider.
Your phone can store up to 20 call records.The
call log icon on the handset ashes to remind
you of any unanswered calls. If the caller allows
the display of his identity, you can view his
name or number.The call records are displayed
in chronological order with the most recent
received call at the top of the list.
Note
Ensure the number in the call list is valid before•
you can call back directly from the call list.
View the call records
1Press .
The incoming call log is displayed.»
2Select a record, then press MENU/OK
and select [VIEW] for more available
information.
Save a call record to the
phonebook
1Press .
The incoming call log is displayed.»
2Select a record, then press MENU/OK to
conrm.
3Select [SAVE NUMBER], then press
MENU/OK to conrm.
4Enter and edit the name, then press
MENU/OK to conrm.
English
EN

18
2Select a record, then press MENU/OK to
conrm.
3Select [DELETE], then press MENU/OK
to conrm.
The handset displays a conrmation
»
request.
4Press MENU/OK to conrm.
The record is deleted.
»
Delete all redial records
1Press REDIAL/C to enter the list of dialed
calls.
2Select a record, then press MENU/OK to
conrm.
3Select [DELETE ALL], then press MENU/
OK to conrm.
The handset displays a conrmation
»
request.
4Press MENU/OK to conrm.
The record is deleted.
»
8 Redial list
The redial list stores the call history of dialed
calls. It includes the names and/or numbers you
have called.This phone can store up to 10 redial
records.
View the redial records
Press REDIAL/C.
Redial a call
1Press REDIAL/C.
2Select a record, then press .
The number is dialed out.»
Save a call record to the
phonebook
1Press REDIAL/C to enter the list of dialed
calls.
2Select a record, then press MENU/OK to
conrm.
3Select [SAVE NUMBER], then press
MENU/OK to conrm.
4Enter and edit the name, then press
MENU/OK to conrm.
5Enter and edit the number, then press
MENU/OK to conrm.
The record is saved.
»
Delete a redial record
1Press REDIAL/C to enter the list of dialed
calls.
EN

19
Name the handset
The name of the handset can be up to 10
characters. It is displayed on the handset screen
in standby mode.
1Press MENU/OK.
2Select [PHONE SETUP] > [PHONE
NAME], then press MENU/OK to
conrm.
3Enter or edit the name. To erase a
character, press REDIAL/C.
4Press MENU/OK to conrm.
The setting is saved.
»
Set the date and time
For more information, see “Set the date and
time” and “Set the date and time format”“ in
the Get started section.
Set the display language
Note
This feature only applies to models with•
multiple-language support.
Languages available for selection vary with
•
different countries.
1Press MENU/OK.
2Select [PHONE SETUP] >
[LANGUAGE], then press MENU/OK to
conrm.
3Select a language, then press MENU/OK
to conrm.
The setting is saved.
»
9 Phone settings
You can customize the settings to make it your
own phone.
Sound settings
Set the handset’s ringtone volume
You can select among 5 ringtone volume
levels or [OFF].
1Press MENU/OK.
2Select [PHONE SETUP] >[SOUNDS] >
[RING VOLUME], then press MENU/OK
to conrm.
3Select a volume level, then press MENU/
OK to conrm.
The setting is saved.
»
Set the handset’s ringtone
You can select from 5 ringtones.
1Press MENU/OK.
2Select [PHONE SETUP] > [SOUNDS] >
[RING TONES], then press MENU/OK
to conrm.
3Select a ringtone, then press MENU/OK
to conrm.
The setting is saved.
»
Set the key tone
Key tone is the sound made when you press a
key on the handset.
1Press MENU/OK.
2Select [PHONE SETUP] > [SOUNDS] >
[KEY TONE], then press MENU/OK to
conrm.
3Select [ON]/[OFF], then press MENU/
OK to conrm.
The setting is saved.
»
English
EN

20
Select the recall duration
Ensure that the recall time is set correctly
before you can answer a second call. In normal
case, the phone is already preset for the recall
duration.You can select among 3 options:
[SHORT], [MEDIUM] and [LONG].The
number of available options varies with different
countries. For details, consult your service
provider.
1Press MENU/OK.
2Select [SERVICES] > [RECALL TIME],
then press MENU/OK to conrm.
3Select an option, then press MENU/OK
to conrm.
The setting is saved.
»
Dial mode
Note
This feature only applies to models that•
support both tone and pulse dial.
Dial mode is the telephone signal used in your
country. The phone supports tone (DTMF) and
pulse (rotary) dial. Consult the service provider
for detailed information.
Set the dial mode
1Press MENU/OK.
2Select [SERVICES] > [DIAL MODE],
then press MENU/OK to conrm.
3Select a dial mode, then press MENU/OK
to conrm.
The setting is saved.
»
Note
If your phone is in pulse dial mode, press•*
during a call for temporary tone mode. Digits
entered for this call are then sent out as tone
signals.
10 Services
The phone supports a number of features that
help you handle and manage the calls.
Auto conference
To join an external call with another handset,
press .
Activate/Deactivate auto conference
1Press MENU/OK.
2Select [SERVICES] > [CONFERENCE],
then press MENU/OK to conrm.
3Select [AUTO]/[OFF], then press
MENU/OK to conrm.
The setting is saved.
»
Network type
Note
This feature only applies to models with•
network type support.
1Press MENU/OK.
2Select [SERVICES] > [NETWORK
TYPE], then press MENU/OK.
3Select a network type, then press MENU/
OK.
The setting is saved.
»
EN
