Philips ID9370 User manual

ID9370_IFU_EN_US.book Page 6 Tuesday, February 13, 2007 12:48 PM

7
EN
3 Safety information
8ImportantInformation
8Foryoursafety
8NeedHelp?
9 Configure your ID9370
9 Install battery
10 Language
10 Registration
11 What’s in the box?
12 Your ID9370
12 Overview of the handset
14 Install
15 Call
17 Personal Settings
22 Advanced Settings
23 Games
25 Troubleshooting
27 Information
29 Index
Contents
ID9370_IFU_EN_US.book Page 7 Tuesday, February 13, 2007 12:48 PM

8
EN Important Information
For your safety
This equipment is not designed to make emergency calls in the event of a power failure.
Alternative arrangements should be made for access to emergency calls.
To avoid damage or malfunction:
- Do not allow the product to come into contact with liquid.
- Do not open it as you could be exposed to high voltages.
- Never use any battery type other than the one supplied.
- Do not hold the handset too close to your ear when the phone is ringing or when
activating the loudspeaker as it may damage your hearing.
- Do not expose the phone to excessive heat caused by heating equipment or direct
sunlight.
- Do not drop your phone or allow objects to fall on your phone.
- Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as these
may harm the set.
- Active mobile phones in the vicinity may cause interference.
About operating and storage temperatures:
- Operate in a place where temperature is always between 0 and 35º C (32 to 95º F).
- Store in a place where temperature is always between -20 and 45º C (-4 to 113º F).
- Battery life may be shortened in low temperature conditions.
Need Help?
For more information on troubleshooting:
Troubleshooting: page 25
Please refer to the following website for more information on Philips web support:
Online Support
www.philips.com/support
ID9370_IFU_EN_US.book Page 8 Tuesday, February 13, 2007 12:48 PM

9
EN
Configure your ID9370
Install battery
Your ID9370 is supplied with 2 rechargeable batteries allowing approximately up to 12 hours of
talk-time and up to 150 hours stand-by time. Before using the handset, the batteries have to be
installed and fully charged.
1. Use the coin or screwdriver to unlock the battery cover.
2. Place the batteries as indicated and replace the cover.
3. Lock the battery cover.
screw
charger contact plate
Bottom View
Unlock
anticlockwise
charger contact plate
screw
Lock
clockwise
Bottom View
Please use a coin or screwdriver that is the right shape and size for the screw that is used.
Otherwise you may damage the screw when tightening it.
ID9370_IFU_EN_US.book Page 9 Tuesday, February 13, 2007 12:48 PM

10
EN Configure your ID9370
Language
Your ID9370 can support different display languages.
To change the language
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Lan-
guage and press mSELECT.
2. Scroll : to your desired language and press mSELECT to confirm.
A validation tone is emitted and the screen returns to previous menu.
Registration
The procedures described below are the procedures that you will find in your ID9370 handset.
The procedures may vary according to the handset you want to register. In this case, please
refer to the manufacturer of the additional handset.
Additional handsets must be registered to the base unit before you can use them. Up to 6
handsets can be registered to one base station.
Register your ID937
After charging it for a few minutes, the word WELCOME appears on a blue screen. Next, the
idle screen appears. Follow these steps to register your handset:
1. In idle mode, the message “Press Base page key for 3 secs. Press and hold m” will be
prompted on the screen. Follow the screen instructions to start registration.
2. Enter PIN will be displayed on your screen. Enter the default Master PIN number - 0000.
3. Press mOK to confirm your registration.
The Master PIN is required before you can register or unregister handsets. The default
PIN is 0000.
All the handset keys (except the mkey) are deactivated until the above registration
process is completed.
ID9370_IFU_EN_US.book Page 10 Tuesday, February 13, 2007 12:48 PM

11
EN
What’s in the box?
The following accessories are included:
Power supply for
base station
User Guide Warranty card
Handset 2 AAA rechargeable
NiMH batteries
Splitter
ID9370_IFU_EN_US.book Page 11 Tuesday, February 13, 2007 12:48 PM

12
EN Your ID9370
Overview of the handset
LCD Screen
Talk key
Keypad lock key /
Format key
Up/Down Navigation
keys
Earpiece
Right Soft
key
Hang-up key
Alphanumeric keypad
Case key / Pause
key /
Intercom key
Loudspeaker key
Event LED
(top of the handset)
Left Soft key
Microphone
ID9370_IFU_EN_US.book Page 12 Tuesday, February 13, 2007 12:48 PM

13
EN
Your ID9370
Handset keys
Press To
mEnter the main menu from stand-by mode.
Select the function displayed on the handset screen directly above it.
Activate mute function during a call.
Switch on the backlight.
>Go to redial list from stand-by mode.
Select the function displayed on the handset screen directly above it.
Initiate a second call, consult phonebook, call transfer or activate/deactivate
HD Sound mode during a call.
Switch on the backlight.
rAnswer an incoming external or internal call.
Insert R for operator services when on the line.
eHang up a call.
Return to stand-by mode.
Long press in stand-by mode to switch off the handset, short press to switch
on the handset again.
uAccess call log from stand-by mode.
Scroll up a menu list or go to the previous phonebook or call log record.
Increase earpiece volume during a call.
Go to the previous character in editing mode.
dAccess phonebook from stand-by mode.
Scroll down a menu list or go to the next phonebook or call log record.
Decrease earpiece volume during a call.
Go to the next character in editing mode.
cInitiate an internal call in idle mode.
Short press to initiate an internal call during a call or switch call between an
internal and external call.
Long press to initiate a conference call with an external call and another
internal call.
vAnswer an incoming call in handsfree mode.
Activate and deactivate the loudspeaker* during a call.
#Dial # in stand-by mode.
Long press to mute the ringer in stand-by mode.
Long press to insert a pause in dialling mode.
Long press to switch between upper and lower case in editing mode.
FDial * in stand-by mode.
Long press to activate and deactivate keypad lock.
Change the display format when viewing a 7-, 10- or 11-digit call log record
(with numbers starting with the digit 1).
*WARNING Handsfree activation can suddenly increase the volume in the earpiece to a
very high level. Make sure the handset is not too close to your ear.
ID9370_IFU_EN_US.book Page 13 Tuesday, February 13, 2007 12:48 PM

14
EN Install
Install battery
See page 9.
Charge battery
1. Place the handset on the charging cradle of the base station. A beep tone is emitted if the
handset is placed correctly.
2. A charging animation on the handset indicates that the battery is charging.
3. Leave it there until the batteries are fully charged (at least 24 hours).
4. The handset is fully charged when the charging animation stops and is displayed.
Low battery warning
The battery level is shown at the top left of the handset screen. When the battery level
becomes low, an empty battery icon is displayed on the screen.
If the battery level becomes exceedingly low, the phone automatically switches off and any
function in progress will not be saved.
Out of range warning
The indoor and outdoor range of the phone is up to 50 metres and 300 metres respectively.
When the handset moves beyond operation range, the antenna icon will blink.
Philips 1
08-08
MENU
06:00pm
REDIAL
The handset must be charged for at least 24 hours before using it for the first time.
ID9370_IFU_EN_US.book Page 14 Tuesday, February 13, 2007 12:48 PM

15
EN
Call
Intercom
This feature is only available when there are at least 2 registered handsets. It allows you to make
free internal calls, transfer external calls from one handset to another and use the conference
option.
Intercom another handset
To be able to use intercommunication feature, you must have at least 2 handsets registered to
your base station (see page 10 "Registration").
1. Press ckey in stand-by mode.
2. Intercom is established immediately if there are only 2 registered handsets. If there are
more than 2 registered handsets, the handset numbers which are available for intercom
will be displayed. Scroll : to All Handsets and press mSELECT to call all the handsets
or scroll to the specific handset you want to call and press mSELECT.
Transfer an external call to another handset
1. During the call, make a long press on ckey to put the external call on hold (the caller
can no longer hear you).
2. Intercom is established immediately if there are only 2 registered handsets. If there are more
than 2 registered handsets, the handset numbers which are available for intercom will be
displayed. Scroll : to All Handsets and press mSELECT to call all the handsets or
scroll to the specific handset you want to call and press mSELECT. The called handset
rings.
3. Press rkey on the called handset to answer the internal call, where both internal call-
ers can talk.
4. Press ekey on the first handset to transfer the external call to the called handset.
Switch between an internal and external call
1. Press ckey once to switch between an internal call and external call.
If the handset does not belong to ID9370 range, this function may not be available.
If there is no answer from the called handset, press ckey to resume the external call.
ID9370_IFU_EN_US.book Page 15 Tuesday, February 13, 2007 12:48 PM

16
EN Call
Three-party conference call
The conference call feature allows one external call to be shared with two handsets (in inter-
com). The three parties can share the conversation and no network subscription is required.
1. Press and hold cto put the external call on hold and start the intercom procedure (the
caller can no longer hear you).
2. Long press cto display the handset numbers which are available for intercom. Scroll :
to All Handsets and press mSELECT to call all the handsets or scroll to the specific
handset you want to call and press mSELECT.
The called handset rings.
3. Press rkey on the called handset to answer the internal call, where both internal call-
ers can talk.
4. Press and hold c for 2 seconds on the first handset to start the three-party conference,
whereby Conference is displayed on the screen.
TIP If Conference mode is activated, a three-party conference call is automatically
established if the second handset takes the line when there is already an external call
in progress.
ID9370_IFU_EN_US.book Page 16 Tuesday, February 13, 2007 12:48 PM

17
EN
Personal Settings
Handset Tones
Ring Volume
There are 5 ringer volume options (Silence, Low, Medium, High and Progressive). The default
level is Medium.
To set ring volume
1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT
to enter Handset Tones and press mSELECT again to enter Ring Volume.
2. Scroll : to your desired volume level and press mSELECT to confirm.
A validation tone is emitted and the screen returns to previous menu.
Ring Melody
There are 16 ring melodies available on your handset.
To set Ring Melody
1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT
to enter Handset Tones, scroll : to Ring Melody and press mSELECT.
2. Scroll : to your desired melody to play the melody.
3. Press mSELECT to set the ring melody.
A validation tone is emitted and the screen returns to previous menu.
Personal Set
Handset Tones
Wallpaper
Contrast
Handset Name
Language
Babysit Mode
Backlight Time
Theme Colour
When Silence is activated, the icon is displayed on the screen.
WARNING When the handset rings during an incoming call, please do not hold the
handset too close to your ear as the volume of the ringing tone may damage your hearing.
ID9370_IFU_EN_US.book Page 17 Tuesday, February 13, 2007 12:48 PM

18
EN Personal Settings
Group Melody
To benefit from this feature, you must subscribe to the Caller Line ldentification service.
This menu enables you to select and set the melodies to be played when there is an external
incoming call from a contact whose name is stored in your phonebook and is part of a group.
You can associate 1 ring melody to each group.
There are three phonebook groups (Group A, B, C) available for you to organise your contacts.
Each group can be assigned a unique melody.
To set Group Melody
1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT
to enter Handset Tones, scroll : to Group Melody and press mSELECT.
2. Scroll : to the group for which you wish to set melody and press mSELECT.
3. Scroll : to the desired melody to play the melody.
4. Press mSELECT to set the group melody.
A validation tone is emitted and the screen returns to previous menu.
Key Beep
A single beep is emitted when a key is pressed. You can enable or disable the key beep. By
default, the key beep is On.
To set key beep On/Off
1. Press mMENU, scroll : to Personal Set and press mSELECT, press mSELECT
to enter Handset Tones, scroll : to Key Beep and press mSELECT.
2. Scroll : to On or Off and press mSELECT to confirm.
A validation tone is emitted and the screen returns to previous menu.
ID9370_IFU_EN_US.book Page 18 Tuesday, February 13, 2007 12:48 PM

19
EN
Personal Settings
Wallpaper
This feature allows you to select the wallpaper to be displayed in stand-by mode. There are 6
wallpapers
pre-installed on your handset. The 6th wallpaper is a blank wallpaper.
To set wallpaper
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Wallpa-
per and press mSELECT.
2. Scroll :to your desired wallpaper and press mSELECT to confirm.
A validation tone is emitted and the screen returns to previous menu.
Contrast level
There are 3 contrast level options (Level 1, Level 2 or Level 3). The default contrast level is
Level 2.
To set contrast level
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Con-
trast and press mSELECT.
2. Scroll : to your desired contrast level (Level 1, Level 2 or Level 3) and press mSE-
LECT to confirm.
A validation tone is emitted and the screen returns to previous menu.
Handset Name
You can name the handset and display the handset name in stand-by mode. The default handset
name of your handset is PHILIPS.
ID9370_IFU_EN_US.book Page 19 Tuesday, February 13, 2007 12:48 PM

20
EN Personal Settings
To rename the handset
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Handset
Name and press mSELECT.
2. Edit the handset name and press mOK to confirm.
A validation tone is emitted and the screen returns to previous menu.
Language
See page 10.
Babysit mode
You must have at least 2 handsets registered to your base station to be able to use this feature
(see page 10 "Registration").
This feature allows you to monitor, e.g. the baby’s room. Place the handset in the room to be
monitored. If the sound level around the microphone of the handset exceeds a certain thresh-
old, the handset can automatically call another handset registered on the same base station.
To use the Babysit feature you need to activate it (e.g. on handset 1) and enter the number of
the handset to be called (e.g. handset 2) in the event that there are noises in the monitored
room. Place the handset which is in Babysit mode (e.g. handset 1) in the room to be monitored.
If this handset detects a sound level greater than a certain threshold, it will automatically initiate
an internal call to the selected handset (e.g. handset 2).
To activate Babysit mode
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Babysit
mode and press mSELECT.
2. Scroll through the list of handsets available and press mSELECT to select the handset to
be called.
Maximum length of the handset name is 14 characters and the default handset name
is PHILIPS.
In Babysit mode, all keys are deactivated except for mMENU key. Babysit mode is
displayed on the screen when this function is activated and the handset cannot per-
form any normal operation (making an outgoing call, receiving an incoming call, inter-
com another handset, paging, etc.)
You can still perform all normal operations (making an outgoing call, receiving an
incoming call, intercom another handset, paging, etc.) on the selected handset.
ID9370_IFU_EN_US.book Page 20 Tuesday, February 13, 2007 12:48 PM

21
EN
Personal Settings
To deactivate Babysit mode
1. Press mMENU, select Off and press mSELECT.
Backlight time
To set Backlight time
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Back-
light Time and press mSELECT.
2. Select 20s, 40s and 60s and press mSELECT to confirm.
A validation tone is emitted.
Theme Colour
To set theme colour
1. Press mMENU, scroll : to Personal Set and press mSELECT, scroll : to Theme
Colour and press mSELECT.
2. Scroll :to Theme Colour 1, Theme Colour 2 or Theme Colour 3 and press mSE-
LECT to confirm.
A validation tone is emitted.
Backlight is activated when there is an incoming call, new message, etc. The default
backlight time is 20s.
ID9370_IFU_EN_US.book Page 21 Tuesday, February 13, 2007 12:48 PM

22
EN Advanced Settings
Registration
See page 10.
Unregistration
To unregister a handset
1. Press mMENU, scroll :to Advanced Set and press mSELECT, scroll : to Unreg-
istration and press mSELECT.
2. Enter the Master PIN when prompted and press mOK to confirm.
3. Select in the list of handsets displayed, the handset that you wish to unregister.
A validation tone is emitted to indicate successful unregistration and the screen shows
Unregistered.
Advanced Set
Registration
Unregistration
If no action is taken on the handset within 15 seconds, the unregistration procedure
will be aborted and the handset returns to stand-by mode.
ID9370_IFU_EN_US.book Page 22 Tuesday, February 13, 2007 12:48 PM

23
EN
Games
Memory
The objective of this game is to find and match different pairs of graphics in the shortest possible
time using your memory. To win, you have to complete matching all 8 pairs of graphics in a 4x4
matrix.
To start the game
1. Press m MENU , scroll : to Games and press m SELECT , press m SELECT to enter
Memory game.
2. An instruction screen is displayed.
3. Press mSELECT to start the game.
4. To exit from the game, press >.
Puzzle
This is a picture game where you have to move around small pieces of jumbled up pictures and
put them together in order to form a complete picture.
To start the game
1. Press m MENU , scroll : to Games and press m SELECT , scroll : to Puzzle and
press
m SELECT .
2. An instruction screen is displayed.
3. Press mSELECT to start the game.
4. To exit from the game, press >.
Games
Memory
Puzzle
Tetris
Press 2/ 4/ 6/ 8keys to move up / left / right / down respectively.
Press 5to select.
Press 2/ 4/ 6/ 8keys to move up / move left / move right / move
down respectively.
ID9370_IFU_EN_US.book Page 23 Tuesday, February 13, 2007 12:48 PM

24
EN Games
Tetris
You can rotate each shaped block as they fall such that they fit neatly into horizontal blocks. The
more blocks you can gather within the same level, the more you will score.
To start the game
1. Press mMENU, scroll : to Games and press mSELECT, scroll : to Tetris and
press mSELECT.
2. An instruction screen is displayed.
3. Press mSELECT to start the game.
4. To exit from the game, press >.
Press 2/ 4/ 6/ 8keys to rotate / move left / move right / move down
respectively.
ID9370_IFU_EN_US.book Page 24 Tuesday, February 13, 2007 12:48 PM

25
EN
Troubleshooting
Troubleshooting of the phone
Please refer to the following website for more information on Philips web support:
www.philips.com/support
Problem Causes Solution
The icon is not
blinking when the handset
is placed on the base
• Bad battery contact
• Dirty contact
• Battery is full
• Move the handset
slightly
• Clean the battery con-
tact with a cloth moist-
ened with alcohol
• No need to charge
No dialling tone • No power
• Batteries are empty
• You are too far from
the base station
• Wrong line cable
• Line adaptor (when
needed) is not con-
nected to the line cord
• Check the connec-
tions. Reset the phone:
unplug and plug back in
the mains
• Charge the batteries for
at least 24 hours
• Move closer to the
base station
• Use the line cable pro-
vided
• Connect the line adap-
tor (when needed) to
the line cord
Poor audio quality • You are too far from
the base station
• The base station is too
close to electrical
appliances, reinforced
concrete walls or metal
doorframes
• Move closer to the
base station
• Move the base station
at least one metre away
from any electrical
appliances
The icon is blinking • Handset is not regis-
tered to the base sta-
tion
• You are too far from
the base station
• Register the handset to
the base station
• Move closer to the
base station
ID9370_IFU_EN_US.book Page 25 Tuesday, February 13, 2007 12:48 PM
