Philips DVDR3432V/12 User manual

Quick Start Guide
2006 © Koninklijke Philips N.V.
All rights reserved.
12 NC 3139 245 22172
Need help?
User Manual
See the user manual that came with your
Philips recorder.
Online
go to www.philips.com/support.
3Enjoy
Start recording
A
Record to DVD or VCR
APress DVD to record to a recordable DVD.
Or, press VCR to record to a VHS tape.
BLoad in a blank recordable DVD to the disc tray or a
VHS tape to the tape deck.
CPress SOURCE repeatedly to select the source to
record from (eg, TUNER, CAM1, DV, EXT1 or EXT2).
zTo record a TV programme, use P+/-on the
remote control to select a programme channel.
DPress REC MODE repeatedly to select a desired
recording mode (refer to the Record Mode table).
EPress REC to start recording.
Note To set the recording time, press
repeatedly to extend the recording time in 30-minute
increments. The recording will stop automatically at
the designated end time.
zIf record from an external device, press PLAY on
the device to start playback.
FTo stop the recording, press STOP .
B
Dubbing (DVD îVCR)
APress DVD to dub from DVD to VCR.
Or, press VCR to dub from VCR to DVD.
BGet ready the appropriate disc and VHS tape in the
recorder.
CPress DIRECT DUBBING .
OK
SP
Rec. Mode
OK Cancel
01H54M
Remaining Time
DSelect the desired recording mode, then move to
OK
in the menu and press on the remote
control to start dubbing.
ETo stop the dubbing, press STOP .
DVD Recorder /VCR DVDR3430V
DVDR3432V
Connect
Set up
Enjoy
1
2
3
What’s in the box?
PREV NEXT
DVD Recorder / VCR Remote Control
and 2 batteries
RF Coaxial Cable
User
Manual
Start playback
A
From a disc
APress DVD on the remote control.
BPress OPEN/CLOSE , load a disc and close
the disc tray.
CPress PLAY/PAUSE to start playback.
DTo stop playback, press STOP .
B
From a VHS tape
APress VCR on the remote control.
BInsert a pre-record VHS tape into the tape deck.
Press REW to rewind the tape if necessary to the
beginning of the recording.
CPress PLAY/PAUSE to start playback.
DTo stop playback, press STOP .
REC MODE
VCR DVD
PLAY/PAUSE
SOURCE

1Connect 2Set up
DSetup and install TV channels.
Highlight and press right X.
Select { Channel Search } and press to start
automatic TV channel search.
Setu
p
Menu - Channel Setu
p
E
d
i
t
Sor
t
Channel Searc
h
Sort Channels
Searc
h
Note This process may take several minutes. Once
complete, the total number of channels found and
stored appears on the TV.
ESet the date and time.
Highlight and press right X.
Select { Date (dd/mm/yy) } or { Time (hh/mm/ss) }
and press . Use the numeric keypad 0-9 to
input the date/time, then press to confirm.
Setu
p
Menu - Cloc
k
01
/
01
/
0
6
00
:
05
:
08
A
u
t
o
Date (dd / mm /
yy)
Time
(
hh : mm : ss
)
Date-Time Settin
g
Note The settings will be updated according to the
broadcast channel information of preset Programme
Number 1.
FPress SETUP to exit.
Basic Connection
Before Connecting
Select one of the following basic connections ( Aor B) according to the type of connecting devices you have.
If your TV is currently connected to a VCR, you have to unplug all the connections from your VCR and TV.
Your new Philips Recorder replaces the VCR for your recording needs.
Option A
Use this connection if you are connecting the antenna
cable directly from the antenna wall socket or from a
Cable Box without a Scart output socket.
AUnplug the antenna cable that is currently connected
to your TV and plug in the antenna cable to the
ANTENNA socket on this recorder.
BUse the supplied RF coaxial cable to connect the
TV socket on this recorder to the Antenna In
socket on the TV.
CUse a scart cable (not supplied) to connect the
EXT1 TO TV-I/O socket on this recorder to the
Scart input socket on your TV.
DPlug in the power cable from the recorder to an AC
power outlet.
~
MAINS
TOTV - I/O
EXT1
AUX- I/O
EXT2S-VIDEO
(Y/C)
AUDIO
AUDIO
COMPONENT
VIDEO
R
L
PR
PB
Y
AUDIO/ VIDEO OUT AUDIO / VIDEO OUT 1
VIDEO
(CVBS)
COAXIAL
DIGITALAUDIO OUT
ANTENNA
TV
SCART IN
From an off-
air antenna
wall socket or
cable box
Television ( rear)
Note See the accompanying user manual for other possible connections (e.g. Composite Video, S-VIDEO).
Option B
Use this connection if your current antenna cable is
connecting through a Cable Box with Scart output
socket.
AKeep the existing antenna connection from the Cable
box to your TV.
BUse a scart cable (not supplied) to connect the
EXT1 TO TV-I/O socket on this recorder to the
Scart input socket on your TV.
CUse another scart cable to connect the
EXT2 AUX-I/O socket on this recorder to the
Scart output socket on the Cable Box.
DPlug in the power cable from the recorder to an AC
power outlet.
~
MAINS
TOTV - I/O
EXT1
AUX- I/O
EXT2S-VIDEO
(Y/C)
AUDIO
AUDIO
COMPONENT
VIDEO
R
L
P
R
P
B
Y
AUDIO/ VIDEO OUT AUDIO / VIDEO OUT 1
VIDEO
(CVBS)
COAXIAL
DIGITALAUDIO OUT
ANTENNA
TV
SCART IN
Philips Recorder (rear)
From an off-air
antenna wall socket
Television ( rear)
Philips Recorder
(rear)
Cable Box (rear)
A
Finding the viewing channel
APress STANDBY-ON on the recorder.
BTurn on the TV and other connected devices (e.g.
Cable Box, Satellite Receiver).
CIf your TV does not switch to the correct viewing
channel, press the Channel Down button (or AV,
SELECT, °button) on the TV’s remote control
repeatedly until you see the blue DVD background
screen. This is the correct viewing channel for the
recorder.
B
Start basic setup
Use the recorder’s remote control and follow the on-
screen instructions to complete the installation.
APress SETUP on the remote control.
Countr
y
Screen Save
r
Reset Menu Settin
g
s
Setu
p
Menu - Genera
l
German
y
En
g
lis
h
On
OK
Note Use up Sand down Tkeys to toggle
through the options. Select an item by pressing
right X. To conrm a setting, press .
BSelect the country of your residence.
Highlight and press right X.
Select { Country } and press to confirm your
selection.
CSelect the recorder’s menu display language.
Remain in mode, select { On Screen Display
Language } and press right X.
Select the desired language option and press to
conrm your selection.
