Philips 6000 Series User manual

Электробритвы Philips HQ6900/16 Серия 6000:
Инструкция пользователя

HQ6940, HQ6900

2

3
A
B
C
D
E
F
G
H
1

4


 6
 16
 27
 38
 48
 58
 69
 80
 90
 100
 110
 120
 131
 141
 151
 161

6

Congratulations on your purchase and welcome
to Philips! To fully benet from the support that
Philips offers, register your product at www.philips.
com/welcome.
The Super Lift & Cut system ensures a close and
easy shave every day. For the best result, move the
shaving heads over your skin in both straight and
circular movements.
Replace the shaving heads every two years for
optimal shaving results.

 Protection cap
 Shaving unit
 Shaver on/off slide
 Mains plug
 Appliance plug
 Cleaning brush
 Trimmer (HQ6940 only)
 Trimmer slide (HQ6940 only)

Read this user manual carefully before you use the
appliance and save it for future reference.

- Keep the shaver and the mains cord dry.

- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.


- Children should be supervised to ensure that they
do not play with the appliance.
- Do not use the shaver or the mains cord if it is
damaged.
- If the mains cord is damaged, always have it
replaced with one of the original type in order to
avoid a hazard.

- Always put the protection cap on the shaver
to protect the shaving heads when you are
travelling.
- Only use the mains cord supplied.
- Store the appliance at a temperature between
5°C and 35°C.
- This appliance is not washable. Never immerse
the appliance in water, nor rinse it under the tap.
- Noise level: Lc = 64 dB(A)

This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.

The appliance is equipped with an automatic voltage
selector and is suitable for mains voltages from 100
to 240 volts.
 7



1 Put the appliance plug in the shaver.
2 Put the mains plug in the wall socket.
3 Push the on/off slide upwards to switch on the
shaver.
4 Move the shaving heads over your skin. Make
both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed
to the Philips shaving system.
5 Push the on/off slide downwards to switch off
the shaver.
6 Put the protection cap on the shaver every
time you have used it, to prevent damage.

You can use the trimmer to trim your sideburns and
moustache.
1 Push the slide upwards to open the trimmer.
The trimmer can be activated while the motor is
running.

Regular cleaning guarantees better shaving
performance.
8

This appliance is not washable. Never immerse the
appliance in water, nor rinse it under the tap.
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to
clean the appliance.
- For easy and optimal cleaning, Philips Shaving
Head Cleaning Spray (type no. HQ110) is
available. Ask your Philips dealer for information.
Note: Philips Shaving Head Cleaning Spray may not be
available in all countries. Contact the Customer Care
Centre in your country about the availability of this
accessory.
You can also clean the shaver in the following way:

1 Switch off the shaver. Remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the top of the appliance rst. Use the
cleaning brush supplied.
3 Press the release button (1) and remove the
shaving unit (2).
4 Clean the inside of the shaving unit and the
hair chamber with the cleaning brush.
2
1
 9

5 Put the shaving unit back onto the shaver.

1 Switch off the shaver. Remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button (1) and remove the
shaving unit (2).
3 Turn the wheel anticlockwise (1) and remove
the retaining frame (2).
4 Remove the cutters and guards and clean them
with the cleaning brush supplied.
Note: Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may take
several weeks before optimal shaving performance is
restored.
5 Clean the cutter with the short-bristled side of
the cleaning brush.
Brush carefully in the direction of the arrow.
2
1
1
2
10

6 Brush the guard.
7 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit, push it down (1) and turn the
wheel clockwise (2).
8 Put the shaving unit back onto the shaver.

For extra thorough cleaning, put the shaving heads
in a degreasing liquid (e.g. alcohol) every six months.
To remove the shaving heads, follow steps 1 to 4
described above. After cleaning, lubricate the central
point on the inside of the guards with a drop of
sewing machine oil to prevent wear of the shaving
heads.

Clean the trimmer every time you have used it.
1 Switch off the shaver. Remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the cleaning brush
supplied.
Tip: Lubricate the trimmer teeth with a drop of sewing
machine oil every six months.
1
2
 11


1 Put the protection cap on the shaver to
prevent damage.

Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ55
Philips Shaving Heads only.
1 Switch off the shaver. Remove the mains plug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button (1) and remove the
shaving unit (2).
3 Turn the wheel anticlockwise (1) and remove
the retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit.
2
1
1
2
12

5 Put the retaining frame back into the shaving
unit, push it down (1) and turn the wheel
clockwise (2).
6 Put the shaving unit back onto the shaver.

The following accessories are available:
- HQ55 Philips Shaving Heads.
- HQ110 Philips Shaving Head Cleaning Spray (not
available in China).

- Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.

If you need service or information or if you have a
problem, please visit the Philips website at
www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone
number in the worldwide guarantee leaet). If there
is no Consumer Care Centre in your country, go to
your local Philips dealer.

The shaving heads (cutters and guards) are not
covered by the terms of the international guarantee
because they are subject to wear.
1
2
 13


This chapter summarises the most common
problems you could encounter with the appliance. If
you are unable to solve the problem with the
information below, contact the Consumer Care
Centre in your country.
Problem Cause Solution
Reduced
shaving
performance.
The shaving heads
are dirty. You have
not cleaned the
shaver well enough
or you have not
cleaned it for a
long time.
Clean the shaver thoroughly
before you continue shaving.
See chapter ‘Cleaning and
maintenance’.
Long hairs
obstruct the
shaving heads.
Clean the cutters and guards
with the cleaning brush
supplied. See chapter ‘Cleaning
and maintenance’, section
‘Every two months: shaving
heads’.
The shaving heads
are damaged or
worn.
Replace the shaving heads
every 2 years for optimal
shaving results. See chapter
‘Replacement’.
The shaver
does not work
when I push
the on/off
slide upwards.
The shaver is not
connected to the
mains.
Put the mains plug in the wall
socket.
14

Problem Cause Solution
Skin irritation. Your skin needs
time to get used
to the Philips
shaving system.
Skin irritation during the rst 2-
3 weeks of use is normal. After
this period, the skin irritation
usually disappears.
 15

16

Поздравления за вашата покупка и добре дошли
във Philips! За да се възползвате изцяло от
предлаганата от Philips поддръжка, регистрирайте
продукта си на адрес www.philips.com/welcome.
Системата Super Lift & Cut гарантира ежедневно
гладко и удобно бръснене. За постигане на
най-добър резултат движете бръснещите глави
по кожата си с едновременно праволинейни и
кръгови движения.
Сменяйте бръснещите глави на всеки две години,
за да постигнете оптимални резултати при
бръснене.

 Предпазна капачка
 Бръснещ блок
 Плъзгач за вкл./изкл. на самобръсначката
 Мрежов щепсел
 Жак на уреда
 Четка за почистване
 Приставка за подстригване (само за HQ6940)
 Плъзгач на приставката за подстригване
(само за HQ6940)

Преди да използвате уреда, прочетете
внимателно това ръководство за експлоатация и
го запазете за справка в бъдеще.



- Пазете самобръсначката и захранващия кабел
сухи.

- Този уред не е предназначен за ползване
от хора с намалени физически усещания
или умствени недостатъци или без опит и
познания, включително деца, ако са оставени
без наблюдение и не са инструктирани от
страна на отговарящо за тяхната безопасност
лице относно начина на използване на уреда.
- Наглеждайте децата, за да не си играят с уреда.
- Не използвайте самобръсначката или
захранващия кабел, ако са повредени.
- Ако захранващият кабел е повреден, с
оглед предотвратяване на опасност винаги
заменяйте повредения захранващ кабел само с
оригинален такъв.

- За да предпазите бръснещите глави при
пътуване, винаги поставяйте предпазната
капачка на самобръсначката.
- Използвайте само доставения с комплекта
захранващ кабел.
- Съхранявайте уреда при температура между
5°C и 35°C.
- Този уред не може да се мие. Никога не
потапяйте уреда във вода и не го изплаквайте
под чешмата.
- Ниво на шума: Lc = 64 dB(A)

Този уред Philips е в съответствие с всички
стандарти по отношение на електромагнитните
излъчвания (EMF). Ако се употребява правилно и
 17

съобразно напътствията в Ръководството, уредът
е безопасен за използване според наличните
досега научни факти.

Уредът е съоръжен с автоматичен селектор на
напрежение и е подходящ за напрежения на
мрежата в диапазона от 100 до 240 волта.


1 Включете щекера на уреда в гнездото му.
2 Включете щепсела на захранващия кабел в
контакта.
3 Преместете плъзгача за вкл./изкл. нагоре, за
да включите самобръсначката.
4 Движете бръснещите глави по кожата си.
Правете едновременно праволинейни и
кръгови движения.
Най-добри резултати се получават при бръснене
на суха кожа.
На кожата ви може би ще са необходими 2 или 3
седмици, за да свикне със системата за бръснене
Philips.
5 Преместете плъзгача за вкл./изкл. надолу, за
да изключите самобръсначката.
6 За да избегнете повреди, поставяйте
обратно предпазната капачка след всяка
употреба на самобръсначката.
18


Можете да ползвате машинката за подстригване,
за да подстрижете бакенбардите и мустаците.
1 Избутайте плъзгача нагоре, за да отворите
машинката за подстригване.
Ножчето може да бъде задействано, докато
електромоторът работи.

Редовното почистване гарантира по-ефикасно
бръснене.
Този уред не може да се мие. Никога не
потапяйте уреда във вода и не го изплаквайте
под чешмата.
Никога не използвайте за почистване на уреда
фибро гъби, абразивни почистващи препарати
или агресивни течности, като бензин или
ацетон.
- За лесно и оптимално почистване се предлага
спрей Philips Shaving Head Cleaning Spray (тип
№ HQ110). За информация се обърнете към
търговец на уреди Philips.
Забележка: Спреят за почистване Philips Shaving
Head Cleaning Spray може да не се предлага
във всички страни. Свържете се с Центъра за
обслужване на клиенти във вашата страна,
за да се осведомите дали се продава тази
принадлежност.
Можете да почиствате самобръсначката и по
следния начин:
 19
