HQ9161, HQ9160

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the powerplug supplied.
◗The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
◗Do not use a damaged powerplug.
◗If the powerplug is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
C◗Make sure the powerplug does not get wet.
◗Charge and store the appliance at a
temperature between 5cC and 35cC.
C◗Never immerse the charging stand in water
nor rinse it under the tap.
◗Do not recharge the shaver in a closed pouch.
◗Always unplug the shaver before cleaning it
under the tap.
C◗The appliance complies with the
internationally approved IEC safety regulations
and can be safely cleaned under the tap.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
ENGLISH4

Charging
Make sure the appliance is switched off before
you start charging it.
Charging normally takes approx. 1 hour.
You can also shave without charging by
connecting the shaver to the mains.
Charge indications
Charging
C◗When you start charging the empty shaver,
the bottom light burns red.When the battery
contains enough power for one shave, all
lights start blinking green sequentially.
Battery fully charged
C◗When the battery has been fully charged, all
green lights are on.
A few hours after charging, all lights go out.
Remaining battery capacity
C◗The amount of power left in the battery is
indicated by the number of lights that are on.
ENGLISH 5

The remaining battery capacity is shown when
you unplug the shaver or when you switch it on
or off:
- When all lights burn green, the battery is 100%
charged.
- When the bottom light burns green, 20% of the
battery capacity is left.
Battery running low
C◗When the battery is running low, the bottom
light starts burning red.
When you switch the shaver off, this light blinks a
few times.
Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 80 minutes.
Charging the appliance
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
3Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver when the battery has been fully
charged.
ENGLISH6

Charging stand
You can also charge the appliance by placing it in
the charging stand, if provided.
Never immerse the charging stand in water nor
rinse it under the tap.
C◗Place the shaver properly in the plugged-in
charging stand.
The bottom light starts burning red.
C◗Lift the shaver from the stand without tilting
it.
Removing and inserting the clock
C1Turn the clock anticlockwise (1) ('click')
and pull it out (2).
C2Insert the clock (1) and turn it clockwise
(2) ('click').
ENGLISH 7

Setting the time
C◗Set the time by pressing the small button at
the back of the clock.
The time can only be set forward.
Replacing the battery
C1Remove the cap.Then remove the battery
by means of a miniature screwdriver.
C2Insert a new battery and put the cap back
into place.
Using the appliance
Personal Comfort Control
C◗The Personal Comfort Control system allows
you to adapt the shaver to your skin type.
- You can set the shaver to 'Normal' for a fast
and comfortable close shave.
- You can set the shaver to 'Sensitive' for a
comfortable close shave with optimal skin
comfort.
ENGLISH8

C◗The 'S' position is best suited for sensitive
skin.
C◗The 'N' position is best suited for normal
skin.
◗The in-between positions are suitable for skin
types between normal and sensitive.
Shaving
1Switch the shaver on by pressing the on/off
button once.
When you switch the shaver on or off, all lights
and symbols go on and then the remaining
battery capacity is shown for a few seconds.
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get
accustomed to the Philips system.
3Switch the shaver off by pressing the on/off
button once.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
ENGLISH 9

Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
C2Close the trimmer with your index finger.
Cleaning and maintenance
C◗The tap symbol starts blinking after every
shave to remind you that the shaver needs to
be cleaned (except when the bottom light
burns red).
Regular cleaning guarantees better shaving
performance.
◗If provided, use the washing machine to clean
the shaver. See the seperate instruction
booklet.
The normal way to clean the appliance is to rinse
the shaving unit and the hair chamber with hot
water every time you have used the shaver.
ENGLISH10

Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Every day: shaving unit and hair chamber
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly.
C4Rinse the outside of the appliance.
5Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
C6Open the shaving unit again and leave it
open to let the appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
ENGLISH 11

Every six months: shaving heads
C1Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2Clean the cutters and guards with the
brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
3Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn it clockwise.
4Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
ENGLISH12

C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Charging stand
You can clean the charging stand with a moist
cloth.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
C◗Store the appliance in the luxury pouch or
place the appliance in the stand to dry.
Replacement
C◗Replace the shaving heads as soon as the
shaving unit symbol starts blinking.
Replace damaged or worn shaving heads with
HQ9 Philips shaving heads only.
ENGLISH 13

1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Turn the lock anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
C5Put the retaining frame back into the
shaving unit (1) and turn the lock
clockwise (2).
6Close the shaving unit.
◗The shaving unit symbol will go out if you
keep the on/off button pressed for 6 seconds.
Accessories
The following accessories are available:
- HQ8000 powerplug.
- HQ9 Philips shaving heads.
ENGLISH14

- HQ110 Philips shaving head cleaner (shaving
head cleaning spray). Not available in Canada.
- HQ8010 car cord.
Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
◗The built-in rechargeable battery contains
substances that may pollute the environment.
Always remove the battery before discarding
the appliance or handing it in at an official
collection point. Dispose of the battery at an
official collection point for batteries. If you
have trouble removing the battery, you can
also take the appliance to a Philips service
centre, which will remove the battery for you
and will dispose of it in an environmentally
safe way.
Disposal of the shaver battery
Only remove the battery if it is completely empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
ENGLISH 15

3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you will find its phone number in
the worldwide guarantee leaflet). If there is no
Customer Care Centre in your country, turn to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been rinsed long enough or
the water used was not hot enough.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
ENGLISH16

◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every six months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
button is pressed.
BCause 1: the battery is empty.
◗Recharge the battery. See chapter 'Charging'.
BCause 2: the appliance is not connected to the
mains.
◗Put the powerplug in the wall socket.
C3The shaving unit has come off the shaver.
BCause: the shaving unit has not been placed
correctly.
◗If the shaving unit becomes detached from the
shaver, you can easily reattach it ('click').
ENGLISH 17

Wichtig
Lesen Sie diese Bedienungsanleitung vor dem
ersten Gebrauch des Geräts gründlich durch und
bewahren Sie sie zur späteren Einsichtnahme auf.
◗Verwenden Sie mit diesem Gerät
ausschließlich das mitgelieferte Netzteil.
◗Das Netzteil wandelt Netzspannungen von
100 bis 240Volt in eine sichere
Betriebsspannung von unter 24 Volt um.
◗Das Netzteil enthält einen Transformator.
Ersetzen Sie das Netzteil keinesfalls durch
einen anderen Stecker, da dies den Benutzer
gefährdet.
◗Benutzen Sie keinesfalls ein beschädigtes
Netzteil.
◗Ist das Netzteil defekt, darf es nur durch ein
Original-Ersatznetzteil ausgetauscht werden,
um Gefährdungen zu vermeiden.
C◗Achten Sie darauf, dass das Netzteil nicht nass
wird.
◗Laden Sie das Gerät bei Temperaturen
zwischen 5cC und 35cC. Bewahren Sie es
auch in diesem Temperaturbereich auf.
C◗Tauchen Sie die Ladestation niemals in Wasser.
Spülen Sie sie auch nicht unter fließendem
Wasser ab.
◗Nehmen Sie den Rasierer zum Laden aus der
Tasche.
◗Ziehen Sie stets das Netzteil aus der
Steckdose, bevor Sie den Rasierer unter
fließendem Wasser reinigen.
C◗Das Gerät entspricht den internationalen IEC
DEUTSCH18

Sicherheitsvorschriften und kann ohne
Bedenken unter fließendem Wasser gereinigt
werden.
Gehen Sie vorsichtig mit heißem Wasser um.
Achten Sie darauf, dass das Wasser nicht zu heiß
ist und Sie sich nicht die Hände verbrühen.
Aufladen
Das Gerät muss ausgeschaltet sein, wenn Sie mit
dem Laden beginnen.
Normalerweise ist der Akku nach ungefähr
1 Stunde voll aufgeladen.
Sie können sich auch bei leeren Akkus rasieren,
indem Sie den Rasierer an das Stromnetz
anschließen.
Ladeanzeigen
Aufladen
C◗Wenn Sie mit dem Aufladen beginnen, leuchtet
die unterste Lampe rot. Sobald der Akku
genügend Energie für eine Rasur hat, blinken
alle Lampen nacheinander grün.
DEUTSCH 19

Akku voll aufgeladen
C◗Wenn der Akku voll geladen ist, leuchten alle
Lampen grün.
Einige Stunden nach dem Laden erlöschen alle
Kontrolllampen.
Restkapazität
C◗Die Anzahl der leuchtenden Lampen zeigt die
noch im Akku verbliebene Energie an.
Die restliche Energie wird angezeigt, wenn Sie den
Stecker ziehen oder den Rasierer ein- bzw.
ausschalten.
- Wenn alle Lampen grün leuchten, ist der Akku
voll geladen.
- Wenn nur die unterste Lampe grün leuchtet, ist
eine Restkapazität von 20% vorhanden.
Die Energie geht zur Neige
C◗Wenn der Akkuladestand niedrig ist, leuchtet
die unterste Lampe rot.
Beim Ausschalten des Rasierers blinkt diese
Lampe mehrmals.
Kabellose Rasierzeit
Ein voll geladener Akku reicht für ca. 80 Minuten
kabellose Rasur.
DEUTSCH20

Laden des Geräts
C1Stecken Sie den Gerätestecker in den
Rasierer.
2Stecken Sie das Netzteil in die Steckdose.
3Ziehen Sie das Netzteil aus der Steckdose
und den Gerätestecker vom Rasierer,
sobald der Akku voll geladen ist.
Ladestation
Sie können das Gerät auch in der Ladestation
(sofern mitgeliefert) aufladen.
Tauchen Sie die Ladestation niemals in Wasser
Spülen Sie sie auch nicht unter fließendem Wasser
ab.
C◗Stellen Sie den Rasierer senkrecht in die am
Stromnetz angeschlossene Ladestation.
Die unterste Lampe leuchtet rot.
C◗Heben Sie den Rasierer aus der Ladestation,
ohne ihn zu kippen.
DEUTSCH 21

Die Uhr entnehmen und einsetzen
C1Drehen Sie die Uhr gegen den
Uhrzeigersinn (1) - Sie hören ein Klicken -
und ziehen Sie sie heraus (2).
C2Zum Einsetzen der Uhr (1) drehen Sie sie
im Uhrzeigersinn (2) - Sie hören ein
Klicken.
Die Zeit einstellen
C◗Drücken Sie auf den kleinen Knopf hinten an
der Uhr, um die Zeit einzustellen.
Die Zeit lässt sich nur vorwärts einstellen.
Die Batterie austauschen
C1Nehmen Sie die Kappe ab und entfernen
Sie dann die Batterie mit einem Mini-
Schraubendreher.
DEUTSCH22
