Introduction
The shaver comes with two different kinds of
NIVEA FOR MEN cartridges: Extra Fresh Shaving
Gel for a fresh sensation during and after shaving
and Moisturising Shaving Lotion for sensitive skin.
This gives you the opportunity to try them out and
discover which one suits your skin type best.
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Only use the powerplug and the charging stand
supplied.
The powerplug transforms 100-240 volts to a safe
low voltage of less than 24 volts.
The powerplug contains a transformer. Do not cut
off the powerplug to replace it with another plug,
as this causes a hazardous situation.
Do not use a damaged powerplug or charging
stand.
If the powerplug or charging stand is damaged,
always have it replaced with one of the original
type in order to avoid a hazard.
Charge, store and use the appliance at a
temperature between 5°C and 35°C.
Make sure the powerplug does not get wet.
Never immerse the charging stand in water nor
rinse it under the tap.
-
-
-
-
-
-
-
-
-
-
ENGLISH

Do not leave the shaver in the plugged-in charging
stand for more than 24 hours.
The appliance is watertight and can be cleaned
under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
used in the bath or shower.
Check if the gel and lotion supplied with the
appliance contain ingredients (see back of
cartridge) to which you are allergic before you
start using the appliance. Do not use the gel
and/or lotion if you are allergic to one or more
ingredients.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.
Charging
Charging takes approx. 8 hours.
Do not leave the shaver in the plugged-in charging
stand for more than 24 hours.
Charge indications
Battery running low
When the battery is running low, the charging
light burns red during shaving.When you switch
off the shaver, the charging light ashes red for a
few seconds.
-
-
-
-
,
ENGLISH 5

When you start charging the shaver while the
battery is running low, the charging light ashes
red for max. 24 minutes.
During charging
During charging the charging light burns green.
Charging the appliance
Charge the shaver before using it for the rst time
and when the shaver indicates that the battery is
running low.
1 Insert the small plug into the charging stand
and put the powerplug in the wall socket.
2 Place the shaver in the charging stand.
The shaver automatically switches off when it is
placed in the charging stand.
3 Remove the powerplug from the wall socket
and pull the small plug out of the charging
stand when the battery has been fully charged.
You can then leave the appliance in the
charging stand.
Cordless shaving time
A fully charged shaver has a cordless shaving time of
up to 45 minutes.
Cartridges
Cartridges with NIVEA FOR MEN shaving gel/lotion
are available in boxes containing ve cartridges and
one small plastic pump.
The NIVEA FOR MEN shaving gel/lotion in the
cartridges will keep for 32 months when stored at
temperatures between 0 cC and +40 cC.
Only use Philips NIVEA FOR MEN Cool Skin
(HQ170 and HQ171) cartridges.
,
,
ENGLISH6

One Philips NIVEA FOR MEN Cool Skin cartridge
contains enough gel/lotion for approx. 10 shaves.
For hygienic reasons, we advise you to insert a
new pump when you start using a new set of ve
cartridges.
Do not throw the pump away when you replace
an empty cartridge. You will need it for all ve
cartridges.
Remove the shaving gel/lotion cartridge from the
appliance when you are not going to use the shaver
for more than one week.
When you have run out of shaving gel/lotion
cartridges and you do not know where to buy them,
contact the Customer Care Centre in your country
(see ‘Guarantee & service’).
Inserting cartridges
1 When you start using a new set of cartridges,
take the pump out of its bag and push it into
a cartridge until it locks into position with a
click.
2 Press the release button (1) and open the
cover of the cartridge compartment (2).
3 Slide the cartridge with the pump into the
shaver. It only ts properly if the white side of
the pump is pointing upwards.
4 Close the cover (you will hear a click).
5 Press the yellow pump button a few times
until the NIVEA FOR MEN shaving gel/lotion
appears.The shaver is now ready for use.
2
1
2
1
ENGLISH 7

Replacing cartridges
Do not throw the pump away when you replace
an empty cartridge.You will need it for the other
cartridges.
1 Press the release button and open the cover of
the cartridge compartment.
2 Remove the empty cartridge and pull out the
pump.
3 Push the pump into a new cartridge until it
locks into position with a click.
4 Slide the cartridge with the pump into the
shaver. It only ts properly if the white side of
the pump is pointing upwards. Close the cover.
Storing cartridges
You can conveniently store the other cartridges
by attaching them to the wall holder supplied.
The holder has suction caps which allow you to
attach it to the wall easily. In this way you always
have the cartridges close at hand, which is very
convenient, especially when you shave in the
shower.
The wall holder is only suitable for storing
cartridges. Never hang or place the shaver on the
wall holder. If you do, the shaver may fall!
,
2
1
2
1
ENGLISH8

Using the appliance
Shaving
Switching on the shaver
1 Press the on/off button once to switch on the
shaver.
2 Press the yellow pump button to apply NIVEA
FOR MEN shaving gel/lotion to your skin.
3 Move the shaving heads over your skin, making
both straight and circular movements.
4 While shaving, press the pump button
frequently to apply more NIVEA FOR MEN
shaving gel/lotion so that the shaver keeps
gliding smoothly over your face.
Do not press the shaver too hard against your skin
while shaving. If you prefer, you can wet your face
before shaving.
For the best shaving results, shaving gel/lotion
should be pumped up frequently.
The shaver will not perform optimally when
used without shaving gel/lotion.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
Switching off the shaver
1 Press the on/off button once to switch off the
shaver.
2 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
Rinse the shaver after each shave. Remove the
cartridge if you are not going to use the appliance
for more than one week.
,
,
,
ENGLISH 9

3 Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
Attaching the trimmer
1 Switch off the shaver.
Clean the shaver before you attach the trimmer (see
chapter ‘Cleaning and maintenance’).
2 Press the release button (1) and pull the
shaving unit off the shaver (2).
3 Tilt the trimmer slightly backwards.
4 Fit the trimmer onto the shaver (you will hear
a click).The trimmer is now ready for use.
5 Activate the trimmer by pressing the on/off
button once.
Removing the trimmer
1 Switch off the shaver.
2 Remove the trimmer by pressing the release
button again and pulling the trimmer off the
shaver.
3 Put the shaving unit back onto the shaver.
2
1
2
1
ENGLISH10

Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
To maintain optimal shaving performance and to
keep the shaver clean, you have to thoroughly rinse
the shaving unit and hair chamber with hot water
after every shave.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Cleaning
Shaving unit: Quick Clean after every shave
1 Make sure the appliance is switched on.
2 Keep the shaving unit closed.
3 Rinse the shaving unit and the hair chamber
under a hot tap by letting the water run
through the openings below the shaving unit
for at least 30 seconds.
4 Shake off excess water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
Shaving unit and hair chamber: every week
We advise you to clean the appliance thoroughly
at least once a week to maintain optimal shaving
performance.
You can also follow this procedure when the shaving
heads have to be cleaned.
1 Switch off the shaver.
ENGLISH 11

2 Press the release button to open the shaving
unit.
3 Rinse the inside of the shaving unit.
4 Rinse the outside of the shaving unit.
5 Rinse the hair chamber.
6 Make sure the inside of the shaving unit and
the hair chamber have been cleaned properly.
7 Close the shaving unit and shake off excess
water.
8 Open the shaving unit again and leave it open
to let the appliance dry completely.
Charging stand
1 Unplug the charging stand.
2 Clean the charging stand with a moist cloth.
22
ENGLISH12

Trimmer
1 Clean the outside of the trimmer with the
brush supplied after every use.
The trimmer can also be cleaned by rinsing it
under the tap.
2 If the trimmer is used frequently, lubricate the
trimmer teeth with a drop of sewing machine
oil every six months.
Storage
Charging stand
The shaver can be stored in the charging stand,
even when it is wet.
Always unplug the charging stand before storing
the wet or dry shaver in it.
Pouch
The shaver can be stored in the pouch supplied.
There is also room for two NIVEA FOR MEN
Cool Skin cartridges.The pouch will provide
extra protection during travel.
Hanging cord
The shaver can also be stored by hanging it from
the hanging cord supplied. Storing the shaver
by means of the hanging cord ensures optimal
drying conditions.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ177 Philips Cool Skin shaving heads only.
,
,
,
ENGLISH 13

Replacing the shaving heads
1 Switch off the shaver.
2 Press the release button to open the shaving
unit.
3 Turn the wheel anticlockwise (1) and remove
the retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit.
5 Put the retaining frame back into the shaving
unit, press the wheel (1) and turn it clockwise
(2).
Accessories
The following accessories are available:
HQ8500/8000 powerplug.
HQ177 Philips Cool Skin shaving heads.
HQ170 NIVEA FOR MEN Cool Skin Moisturising
Shaving Lotion.
HQ171 NIVEA FOR MEN Cool Skin Extra Fresh
Shaving Gel.
-
-
-
-
1
2
1
2
1
2
1
2
ENGLISH14

Environment
Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.
The built-in rechargeable shaver battery contains
substances that may pollute the environment.
Always remove the battery before you discard
and hand in the shaver at an ofcial collection
point. Dispose of the battery at an ofcial collection
point for batteries. If you have trouble removing
the battery, you can also take the shaver to a
Philips service centre.The staff of this centre will
remove the battery for you and will dispose of it
in an environmentally safe way.
Disposal of the battery
Only remove the battery if it is completely empty.
1 Let the shaver run until it stops, undo the
screws and open the shaver.
2 Remove the battery.
Do not put the shaver back into the charging stand
after the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Customer
Care Centre in your country, go to your local Philips
dealer or contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
-
-
ENGLISH 15

Troubleshooting
1 The shaving heads do not move smoothly over
the skin.
Cause: not enough shaving gel/lotion has been
applied.
Press the pump button a few times until sufcient
NIVEA FOR MEN shaving gel/lotion has been
released to allow the shaving heads to move
smoothly over your face again.
2 Reduced shaving performance
Cause 1: the shaving heads are dirty.
The shaver has not been cleaned immediately after
use and/or has not been rinsed long enough and/or
the water used to rinse the shaver was not hot
enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: long hairs are obstructing the shaving
heads.
Press the release button to open the shaving unit.
Turn the wheel anticlockwise (1) and remove the
retaining frame (2).
Clean the cutters and guards.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
Remove the hairs with the brush supplied.
Put the shaving heads back into the shaving unit. Put
the retaining frame back into the shaving unit and
turn the lock clockwise.
To prevent long hairs from obstructing the shaving
heads, remove the shaving heads once a month and
clean them with the brush supplied.
-
-
-
ENGLISH16

Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
3 The shaver does not work when the on/off
button is pressed.
Cause 1: the battery is empty.
Recharge the battery. See chapter ‘Charging’.
Cause 2: dried-up shaving gel/lotion is blocking the
shaving heads.
Clean the shaving heads thoroughly. See chapter
‘Cleaning and maintenance’.
Cause 3: the shaving heads are damaged.
Replace the shaving heads. See chapter
‘Replacement’.
4 The cover of the cartridge compartment
cannot be closed
Cause 1: the cartridge has not been inserted
correctly.
Insert the cartridge correctly. It only ts properly
into the shaver if the white side of the pump is
pointing upwards.
Cause 2: the cartridge has not been pushed far
enough into the shaver.
Press the cartridge until it is properly seated.
5 The NIVEA FOR MEN shaving gel/lotion has
changed colour or has turned watery.
Cause: the NIVEA FOR MEN shaving gel/lotion
has not been stored at the right temperature.
Insert a new cartridge.
6 Skin irritation occurs
Cause 1: your skin has not yet become
accustomed to this shaving system.
Allow 2-3 weeks for your skin to get accustomed to
this shaving system.
-
-
-
-
-
-
-
-
ENGLISH 17

Cause 2: the shaving gel/lotion irritates your skin.
Try the other type of NIVEA FOR MEN cartridge.
Wet your face before shaving with the shaving
gel/lotion.
If the irritation does not disappear within 24 hours,
we advise you to stop using the shaving gel/lotion.
-
ENGLISH18

19
Einführung
Der Rasierer wird mit zwei Sorten NIVEA FOR
MEN-Kartuschen geliefert: Extra Fresh-Frischegel
für ein erfrischendes Gefühl während und nach
der Rasur sowie eine Feuchtigkeit spendende
Rasieremulsion für empndliche Haut. Sie können
beide Sorten ausprobieren und ermitteln, welche
sich für Ihren Hauttyp am besten eignet.
Wichtig
Lesen Sie diese Bedienungsanleitung vor dem
Gebrauch des Geräts aufmerksam durch und
bewahren Sie sie für eine spätereVerwendung auf.
Dieses Gerät ist für Benutzer (einschl. Kinder)
mit eingeschränkten physischen, sensorischen
oder psychischen Fähigkeiten bzw. ohne jegliche
Erfahrung oderVorwissen nur dann geeignet, wenn
eine angemessene Aufsicht oder ausführliche
Anleitung zur Benutzung des Geräts durch eine
verantwortliche Person sichergestellt ist.
Achten Sie darauf, dass Kinder nicht mit dem
Gerät spielen.
Verwenden Sie zum Auaden des Geräts nur
das mitgelieferte Netzteil und die mitgelieferte
Ladestation.
Das Netzteil wandelt Netzspannungen von 100
bis 240Volt in eine sichere Betriebsspannung von
unter 24Volt um.
Das Netzteil enthält einenTransformator. Ersetzen
Sie das Netzteil keinesfalls durch einen anderen
Stecker, da dies den Benutzer gefährden kann.
Benutzen Sie keinesfalls ein beschädigtes Netzteil
oder eine beschädigte Ladestation.
Wenn das Netzteil oder die Ladestation defekt
oder beschädigt ist, darf es/sie nur von einem
-
-
-
-
-
-
-
DEUTSCH

Philips Service-Center oder einer von Philips
autorisierten Werkstatt durch ein Original-
Ersatzteil ausgetauscht werden, um Gefährdungen
zu vermeiden.
Laden und benutzen Sie das Gerät bei
Temperaturen zwischen 5°C und 35°C. Bewahren
Sie es auch in diesemTemperaturbereich auf.
Achten Sie darauf, dass das Netzteil nicht nass wird.
Tauchen Sie die Ladestation niemals in Wasser.
Spülen Sie sie auch nicht unter ießendem Wasser
ab.
Lassen Sie den Rasierer nicht länger als 24 Sunden
in der am Netz angeschlossenen Ladestation.
Der Rasierer ist wasserdicht und kann unter
ießendem Wasser gereinigt werden.
Gehen Sie vorsichtig mit heißem Wasser um. Achten
Sie darauf, dass das Wasser nicht zu heiß ist und Sie
sich nicht die Hände verbrühen.
Das Gerät erfüllt die internationalen IEC-
Sicherheitsvorschriften und kann ohne Bedenken
unter der Dusche oder in der Badewanne benutzt
werden.
Prüfen Sie vor dem Gebrauch des Geräts, ob
das Gel bzw. die Emulsion Inhaltsstoffe enthält,
gegen die Sie allergisch sind (siehe Rückseite
der Kartusche).Verwenden Sie das Gel bzw. die
Emulsion nicht, wenn Sie auf eine oder mehrere
Substanzen allergisch reagieren.
Elektromagnetische Felder (EMF; Electro
Magnetic Fields)
Dieses Philips Gerät erfüllt sämtliche Normen
bezüglich elektromagnetischer Felder (EMF). Nach
aktuellen wissenschaftlichen Erkenntnissen ist das
Gerät sicher im Gebrauch, sofern es ordnungsgemäß
und entsprechend den Anweisungen in dieser
Bedienungsanleitung gehandhabt wird.
-
-
-
-
-
-
-
DEUTSCH20

Laden
Das Laden dauert ca. 8 Stunden.
Lassen Sie den Rasierer nicht länger als 24 Sunden
in der am Netz angeschlossenen Ladestation.
Ladeanzeigen
Akku fast leer
Wenn der Akku fast leer ist, leuchtet die
Ladekontrollanzeige während der Rasur rot auf.
Wenn Sie den Rasierer ausschalten, blinkt die
rote Ladekontrollanzeige einige Sekunden lang.
Wenn Sie den Rasierer bei niedrigem
Akkuladestand auaden, blinkt die rote
Ladekontrollanzeige maximal 24 Minuten lang.
Während des Auadens
Während des Auadens leuchtet die
Ladekontrollanzeige grün.
Das Gerät laden
Laden Sie das Gerät vor dem ersten Gebrauch
auf. Laden Sie es auch, wenn der Rasierer einen
niedrigen Akkustand anzeigt.
1 Stecken Sie den kleinen Stecker in die
Ladestation und das Netzteil in die Steckdose.
2 Setzen Sie den Rasierer in die Ladestation.
Der Rasierer schaltet sich automatisch aus, wenn Sie
ihn in die Ladestation stellen.
3 Ziehen Sie das Netzteil aus der Steckdose und
den kleinen Stecker vom Rasierer, sobald der
Akku vollständig geladen ist. Sie müssen den
Rasierer nicht aus der Ladestation nehmen.
,
,
,
DEUTSCH 21

Kabellose Rasierzeit
Mit einem vollständig geladenen Rasierer können Sie
sich bis zu 45 Minuten kabellos rasieren.
Kartuschen
Die Kartuschen mit NIVEA FOR MEN Frischegel
bzw. Rasieremulsion werden in Packungen mit je
5 Kartuschen und einer kleinen Kunststoffpumpe
geliefert.
NIVEA FOR MEN Kartuschen mit Frischegel bzw.
Rasieremulsion sind 32 Monate haltbar, wenn sie
beiTemperaturen zwischen 0 cC und +40 cC
aufbewahrt werden.
Verwenden Sie ausschließlich Philips NIVEA FOR
MEN Cool Skin Kartuschen (HQ170 bzw. HQ171).
Eine Philips NIVEA FOR MEN Cool Skin Kartusche
enthält genügend Gel bzw. Emulsion für ca. 10
Rasuren.
Verwenden Sie beim Öffnen einer neuen Packung
mit 5 Kartuschen aus hygienischen Gründen die
neue Pumpe.
Werfen Sie die Pumpe nicht weg, wenn Sie eine
neue Kartusche einsetzen. Sie benötigen die Pumpe
für alle fünf Kartuschen aus derselben Packung.
Falls Sie den Rasierer länger als eine Woche
nicht verwenden, sollten Sie die Gel- bzw.
Emulsionskartusche aus dem Gerät nehmen.
Sind Ihnen die Kartuschen mit Frischegel bzw.
Rasieremulsion ausgegangen und Sie wissen nicht,
wo sie erhältlich sind, wenden Sie sich bitte an
das Philips Service-Center in Ihrem Land (siehe
“Garantie und Kundendienst”).
DEUTSCH22
