Philips OneBlade QP2531 User manual

QP2531, QP2530,
QP2526, QP2525,
QP2522, QP2521,
QP2520

11
12
13
3
1
4
56
7
8
9
10
2

empty page before TOC

English 6
Bahasa Indonesia 23
Bahasa Melayu 40
Português do Brasil 58
Tiếng Việt 75
ภาษาไทย 91
简体中文 106
繁體中文 124
한국어 138
ﺔﻴﺑﺮﻌﻟﺍ 154
ﯽﺳرﺎﻓ 169

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Protection cap
2 Blade
3 Blade release slide
4 On/off button
5 Battery status indicator (QP2531, QP2530 only)
6 Small plug
7 Battery charging indicator (QP2526, QP2525,
QP2522, QP2521, QP2520 only)
8 Supply unit (QP2531, QP2530: type HQ850.
QP2526, QP2525, QP2522, QP2521, QP2520:
type A00390)
9 Replacement blade (QP2531, QP2526, QP2522
only)
10 Click-on stubble comb 5mm
11 Click-on stubble comb 3mm (QP2531, QP2530,
QP2526, QP2525, QP2520 only)
12 Click-on stubble comb 2mm (QP2531, QP2530
only)
13 Click-on stubble comb 1mm
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
6English

Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit provided with the appliance. For the
type number of the original supply unit, please
see ' General description' in the manual.
- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the appliance before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- This appliance contains batteries that are non-
replaceable.
- Do not open the appliance to replace the
rechargeable battery.
7
English

Caution
- Never immerse the charging stand in water and
do not rinse it under the tap.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use water hotter than 60°C to rinse the
appliance.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This appliance is waterproof. It is suitable for
use in the bath or shower and for cleaning
under the tap. For safety reasons, the appliance
can therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Note: This appliance can only be used without
cord.
QP2531, QP2530: Charging normally takes approx.
4hours.
8English

QP2526, QP2525, QP2522, QP2521, QP2520:
Charging normally takes approx. 8hours.
A fully charged appliance has an operating time of
up to 60minutes (QP2531, QP2530) or 45minutes
(QP2526, QP2525, QP2522, QP2521, QP2520).
Charge the appliance before you use it for the first
time and when the battery charge indicator
indicates that the battery is almost empty.
Battery status indicator QP2531, QP2530:
When the battery status indicator flashes orange,
the battery is almost empty.
When the appliance is charging, the battery status
indicator light flashes green.
When the battery is fully charged, thebattery
statusindicator lights up green continuously.
Approx. 30 minutes after the battery is fully
charged or when you disconnect the appliance
from the mains, the light of the battery status
indicator switches off automatically.
Battery status indicator QP2526, QP2525, QP2522,
QP2521, QP2520:
The battery status is indicated by the performance
of the appliance. When the appliance starts
working more slowly, the battery is almost empty
and needs to be charged for optimal performance.
9
English

Charging with the supply unit
1Insert the small plug into the appliance and put
the supply unit in the wall socket.
2QP2526, QP2525, QP2522, QP2521, QP2520
only: The battery charging indicator on the
adapter lights up continuously when the
appliance is connected to the wall socket.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Using the appliance
You can use the appliance to trim, edge or shave
facial hair (beard, moustache and sideburns).
Shave for a smooth result, trim to obtain a certain
length and edge to create perfect edges and sharp
lines. This appliance is not intended for shaving,
edging or trimming hairs on lower body parts or
scalp hair. Take your time when you first start to
use the appliance. You have to acquire practice
with the appliance.
Note: This appliance can only be used without
cord.
Switching the appliance on and off
1To switch on the appliance, press the on/off
button once.
2To switch off the appliance, press the on/off
button once.
10 English

Shaving
Warning: Before you use the appliance,
always check the blade for damage or wear.
If the blade is damaged or worn, do not use
the appliance, as injury may occur. Replace
a damaged blade before you use the
appliance (see 'Replacement').
Shaving tips and tricks
- Make sure that the blade is in full contact with
the skin by placing it flat on the skin.
- For the best result, move the appliance against
the grain.
- Make long strokes while pressing lightly.
- You can use the appliance dry or wet with gel or
foam. You can even use the appliance in the
shower.
- Shaving a clean beard and face gives the best
results.
Shaving
1Switch on the appliance.
2Place the blade on the skin and move the
appliance up or against the grain in long strokes
while you press it lightly.
Note: Make sure you hold the surface of the
blade flat against your skin.
3Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
11
English

Edging
You can also use both edges of the blade to create
sharp lines and perfect edges. Hold the appliance
in such a way that the blade is perpendicular to
the skin and one of its edges touches the skin. This
allows more precise detailing of sideburns and the
area around the mouth and nose.
1To create sharp edges and lines, you can use
either edge of the blade.
2Switch on the appliance.
3Place the edge of the blade perpendicular onto
the skin.
-Make straight strokes while applying gentle
pressure.
4Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
Trimming
Trimming tips
-Always make sure that the tips of the click-
on stubble comb point in the direction in
which you move the appliance.
12 English

-Make sure that the flat part of the comb is
always in full contact with the skin to obtain
an even trimming result.
-Since hair grows in different directions, you
need to move the appliance in different
directions as well (upward, downward or
across).
-Trimming is easier when the skin and hair are
dry.
Trimming combs
The click-on stubble combs allow you to trim hair
to different lengths.
- QP2531 and QP2530 come with 4click-on
stubble combs: 5mm, 3mm, 2mm and 1mm.
- QP2526, QP2525 and QP2520 come with
3click-on stubble combs: 5mm, 3mm and
1mm.
- QP2522 and QP2521 come with 2click-on
stubble combs: 5mm and 1mm.
Start with the 5mm comb to acquire practice with
this appliance.
The indication on each comb corresponds to the
hair length in millimeters.
Trimming with comb
1Place the comb onto the blade, with the teeth
of the comb pointing upwards.
Note: Always trim in the direction of the teeth of
the comb. This will give you the best results.
2Switch on the appliance.
13
English

3Place the comb onto the skin and move the
appliance in the direction of the teeth of the
comb.
Note: For the best result, move it against the
grain.
4Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
5To remove the comb, hold it on both sides and
pull it off the blade.
Cleaning and maintenance
Clean the appliance after every use.
Caution: Never use compressed air, scouring
pads, abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
Caution: Do not tap the appliance against a
surface to remove water from it, as this may
cause damage. Replace the blade if it is
damaged.
Cleaning the appliance
1Remove the comb from the blade. Always
switch off the appliance before putting on or
taking off combs.
14 English

2If a lot of hairs have accumulated on the comb,
first blow them off.
3If a lot of hairs have accumulated on the
appliance, first blow them off.
4Switch on the appliance and rinse the blade
with lukewarm water.
Caution: Do not dry the blade with a towel or a
tissue as this may cause damage.
5Rinse the combs with lukewarm water.
6Carefully shake off excess water and let all parts
air dry completely.
Note: The blade is fragile. Handle it carefully.
Replace the blade if it is damaged.
Storage
Always attach the protection cap on the blade to
protect the blade from damage during travelling or
storage.
We advise you to let the appliance and its
attachments dry before you store them for the
next use.
15
English

1Place the protection cap onto the edge of the
blade.
2Close the protection cap.
Replacement
Usage indicator
For optimal cutting and gliding performance, we
advise you to replace the blade every 4 months,
when it no longer provides the shaving or trimming
results you expect.
The blade is equipped with a usage indicator. A
green bar will gradually appear on the blade as
you use it. When it is highly visible, it is
recommended to replace your blade for the best
OneBlade experience. Always replace the blade
with an original Philips blade.
Depending on your usage behavior, the exact
lifetime of the blade could be longer or shorter.
Similar to a manual blade, the blade becomes
blunt over time, which results in increased hair
pulling and reduced cutting performance.
Replacing the blade
1Switch off the appliance.
16 English

1
2
2Push the blade release slide upwards carefully,
and hold the blade on both sides to remove the
blade. This will prevent the blade from flying off
the handle.
3Hold the new blade on its sides and press it
onto the handle (‘click’).
Note: When you hear a click, the new blade is
placed correctly and ready for use.
Ordering accessories
To buy accessories or spare parts, visit
www.philips.com/parts-and-accessories or go to
your Philips dealer. You can also contact the
Philips Consumer Care Center in your country (see
the international warranty leaflet for contact
details).
The following parts are available:
- QP210 Blade 1-pack
- QP220 Blade 2-pack
- QP610 Replacement blade 1-pack
- QP620 Replacement blade 2-pack
Recycling
- Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an official collection point for recycling.
By doing this, you help to preserve the
environment.
17
English

- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. Please take your
product to an official collection point or a
Philips service center to have a professional
remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product.
Before you remove the battery, make sure
that the product is disconnected from the
wall socket and that the battery is
completely empty.
Take any necessary safety precautions
when you handle tools to open the product
and when you dispose of the rechargeable
battery.
1Disconnect the appliance from the mains and
let the appliance run until the motor stops.
2Remove the blade from the appliance.
3Remove the bottom of the appliance by
bending it downwards and pulling it off.
18 English

4Take out the battery compartment by
separating the bottom part from the top part.
5Separate the battery section from the bottom
part.
6Lift the battery out of the inner body with a
screwdriver. The battery is connected with
double-sided tape.
Warning: Be careful, the battery strips are
very sharp.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Warranty restrictions
The blade is not covered by the terms of the
international warranty because it is subject to
wear.
Troubleshooting
This chapter summarizes the most common
problems you could encounter with the appliance.
If you are unable to solve the problem with the
information below, visit www.philips.com/support
for a list of frequently asked questions or contact
the Consumer Care Center in your country.
19
English

Problem Possible
cause Solution
The appliance
does not charge
when it is
connected to
the mains.
The appliance
has to be
switched off
when you
charge it.
Switch off the appliance.
I cannot switch
on the
appliance when
it is connected
to the mains.
You cannot use
the appliance
when it is
charging. You
can only use the
appliance
without cord.
Disconnect the appliance from
the mains before use.
The appliance
does not work
anymore.
The
rechargeable
battery is empty.
Charge the appliance (see
'Charging'). QP2531, QP2530:
During charging, the battery
status indicator flashes.
QP2526, QP2525, QP2522,
QP2521, QP2520: During
charging, the charging indicator
on the supply unit lights up. If
the battery status indicator on
the appliance does does not
flash or if the battery charging
indicator on the supply unit
does not light up, check
whether there is a power failure
or if the wall socket is live. If
there is no power failure and
the wall socket is live but the
battery charge indicator still
does not flash or light up, take
the appliance to your dealer or
a Philips service center.
The blade is
blocked by dirt. Switch on the appliance and rinse the blade under the tap
with warm water.
20 English
