Philips HQ560/16 User manual

ENGLISH 4
BAHASA MELAYU 15
INDONESIA 26
TI”NG VI◊T 37
 47
56
66
76
HQ560

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the powerplug supplied.
◗The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
◗Do not use a damaged powerplug.
◗If the powerplug is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
C◗Make sure the powerplug does not get wet.
◗Charge, store and use the appliance at a
temperature between 5cC and 35cC.
◗Do not recharge the shaver in a closed pouch.
C◗The appliance complies with the
internationally approved IEC safety regulations
and can be safely cleaned under the tap.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
◗Always unplug the shaver before cleaning it
under the tap.
ENGLISH4

Charging
Make sure the appliance is switched off before
you start charging it.
When you charge the shaver for the first time or
after a long period of disuse, let it charge
continuously for 12 hours. Charging normally
takes approx. 8 hours.
Do not leave the appliance connected to the
mains for more than 24 hours.
Charge indications
Charging
C◗As soon as you start charging the empty
shaver, the green pilot light goes on.
Charging the appliance
Charge the appliance when the motor stops or
starts running slower.
Do not recharge the shaver in a closed pouch.
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
ENGLISH 5

3Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver when the battery has been fully
charged.
Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 30 minutes.
Using the appliance
Shaving
1Switch the shaver on by pressing the on/off
button once.
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3Switch the shaver off by pressing the on/off
button once.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
ENGLISH6

Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
chamber with hot water every time you have
used the shaver.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
C◗For extra thorough cleaning, the Philips Action
Clean (shaving head cleaner, type HQ100) is
available.Ask your Philips dealer for
information.
BThe Philips Action Clean may not be available in
all countries. Contact the Customer Care Centre in
your country about the availability of this
accessory.
ENGLISH 7

You can also clean the shaver in the following
way:
Every day: shaving unit and hair chamber
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
4Rinse the outside of the appliance.
5Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
C6Open the shaving unit again and leave it
open to let the appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
ENGLISH8

Every six months: shaving heads
C1Open the shaving unit, turn the wheel
anticlockwise (1) and remove the retaining
frame (2).
C2Clean the cutters and guards with the
brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
3Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit, press the wheel (1) and turn it
clockwise (2).
4Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
ENGLISH 9
1
2

C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
◗The powerplug and the shaver can be stored
in the pouch supplied.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ53 Philips shaving heads only.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
ENGLISH10
OIL
1
2

C4Remove the shaving heads and place new
ones in the shaving unit.
C5Put the retaining frame back into the
shaving unit, press the wheel (1) and turn it
clockwise (2).
6Close the shaving unit.
Accessories
The following accessories are available:
- HQ8000 powerplug.
- HQ53 Philips shaving heads.
- HQ100 Philips Action Clean (shaving head
cleaner).
- HQ101 Philips Action Clean refill (shaving head
cleaning liquid).
- HQ110 Philips shaving head cleaner (shaving
head cleaning spray).
Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
The built-in rechargeable battery contains
substances that may pollute the environment.
ENGLISH 11
2
1

Always remove the battery before discarding the
appliance or handing it in at an official collection
point. Dispose of the battery at an official
collection point for batteries. If you have trouble
removing the battery, you can also take the
appliance to a Philips service centre, which will
remove the battery for you and will dispose of it
in an environmentally safe way.
Disposal of the battery
Only remove the battery if it is completely empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Guarantee & service
If you need information or if you have a
problem, please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
ENGLISH12

your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been rinsed long enough or
the water used was not hot enough.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every six months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
button is pressed
BCause: the battery is empty.
ENGLISH 13

◗Recharge the battery. See chapter 'Charging'.
3The shaving unit has come off the shaver.
BCause: the shaving unit has not been placed
correctly.
◗If the shaving unit becomes detached from the
shaver, check whether the hinge spring is still
properly attached, i.e. has not come loose and
does not show any cracks or damage. If the
hinge spring is still properly attached, the
shaving unit can be easily put back on the
shaver again. However, if the hinge spring has
come loose, is cracked or damaged, please
contact your Philips dealer or the nearest
Philips service centre to avoid damage to your
shaver.
ENGLISH14

Penting
Baca arahan penggunaan ini dengan teliti sebelum
menggunakan perkakas dan simpan untuk rujukan
di masa depan.
◗Hanya gunakan plag kuasa yang dibekalkan.
◗Plag kuasa mengubah 100-240 volt kepada
voltan rendah dan selamat tidak melebihi 24
volt.
◗Plag kuasa mengandungi sebuah transformer.
Jangan potong plag kuasa untuk
menggantikannya dengan plag yang lain kerana
ini akan menimbulkan situasi berbahaya.
◗Jangan gunakan plag kuasa yang rosak.
◗Jika plag kuasa rosak, sentiasa gantikan dengan
jenis tulen bagi mengelakkan bahaya.
C◗Pastikan plag kuasa tidak kena basah.
◗Cas, simpan dan gunakan perkakas pada suhu
antara 5cC dan 35cC.
◗Jangan mengecas semula pencukur di dalam
pau tertutup.
C◗Perkakas mematuhi peraturan keselamatan
antarabangsa IEC yang diluluskan dan boleh
dibersihkan dengan selamat di bawah pili air.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak begitu panas, untuk mengelakkan
tangan anda daripada kelecuran.
◗Sentiasa cabut plag daripada pencukur
sebelum membersihkannya di bawah pili air.
BAHASA MELAYU 15

Mengecas
Pastikan perkakas dimatikan sebelum dicas.
Apabila anda mengecas pencukur bagi kali
pertama setelah lama tidak digunakan, biarkan ia
dicas berterusan selama 4 jam. Pengecasan
biasanya mengambil masa selama lebih kurang 1
jam.
Jangan biarkan perkakas dipasang pada sesalur
kuasa selama lebih daripada 24 jam.
Arahan cas
Mengecas
C◗Sebaik sahaja anda mula mengecas pencukur
yang kosong, lampu panduan hijau akan
menyala.
Mengecas perkakas
Cas perkakas apabila motor berhenti atau menjadi
semakin lambat.
Jangan mengecas semula pencukur di dalam pau
tertutup.
C1Pasangkan plag perkakas pada alat
pencukur.
2Pasangkan plag kuasa ke soket dinding.
BAHASA MELAYU16

3Cabut plag kuasa dari soket dan cabut plag
alat dari pencukur apabila bateri telah dicas
penuh.
Masa pencukuran tanpa kord
Pencukur yang dicas penuh ada masa pencukuran
tanpa kord sehingga kira-kira 30 minit.
Menggunakan perkakas
Pencukuran
1Hidupkan alat pencukur dengan menekan
butang hidup/mati sekali.
C2Gerakkan kepala pencukur denagn gerakan
lurus dan membulat di atas permukaan
kulit dengan pantas.
Hasil pencukuran yang terbaik akan terhasil jika
muka anda kering.
Kulit anda mungkin memerlukan 2 atau 3 minggu
untuk membiasakan diri dengan sistem Philips.
3Matikan pencukur dengan menekan butang
hidup/mati sekali.
C4Pasang semula penutup pelindung pada
pencukur setelah setiap penggunaan untuk
mengelakkan kerosakan.
BAHASA MELAYU 17

Perapian
Untuk merapikan jambang dan kumis kemas.
C1Buka perapi dengan menolak selak ke atas.
Perapi dapat dihidupkan semasa motor berjalan.
Pembersihan dan penyenggaraan
Membersih alat pencukur dengan kerapkali
menjamin prestasi pencukuran terbaik.
Cara paling senang dan bersih untuk mencuci
perkakas adalah dengan membilas dengan air
panas unit mencukur dan ruang menyimpan
rambut setiap kali setelah anda menggunakan alat
pencukur tersebut.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak begitu panas, untuk mengelakkan
tangan anda daripada kelecuran.
C◗Untuk pembersihan yang lebih menyeluruh,
pembersih Tindakan Bersih Philips (pembersih
kepala pencukur, jenis HQ100) tersedia.
Bertanya kepada dengan penjual Philips anda
untuk dapatkan maklumat.
BPembersih Tindakan Bersih Philips mungkin tidak
terdapat di semua negara. Hubungi Pusat
Khidmat Pelanggan di negeri anda untuk
mengetahui tentang ketersediaan aksesori ini.
BAHASA MELAYU18

Anda juga boleh membersihkan pencukur dengan
cara yang berikut:
Setiap hari: unit pencukur dan ruang rambut
1Matikan alat pencukur, cabut plag kuasa
dari soket dinding dan cabut plag perkakas
dari pencukur.
C2Tekan butang pelepas untuk membuka unit
pencukur.
C3Bersihkan unit pencukur dan ruang rambut
dengan membilasnya di bawah paip air
panas untuk beberapa waktu
4Bilaskan bahagian luar perkakas.
5Tutup unit pencukur dan keluarkan air
lebihan dengan menggoncangkannya.
Jangan keringkan unit pencukur dengan tuala atau
tisu, kerana ini akan merosakkan kepala alat
pencukur.
C6Buka unit pencukur sekali lagi dan biarkan
ia terbuka supaya perkakas kering
sepenuhnya.
Anda juga boleh membersihkan ruang rambut
tanpa air dengan menggunakan berus yang
dibekalkan.
BAHASA MELAYU 19

Setiap enam bulan: kepala pencukur
C1Buka unit pencukur, putarkan roda
melawan arah jam (1) dan tanggalkan
rangka penahan (2).
C2Bersihkan pemotong dan adangan dengan
berus yang dibekalkan
Jangan bersihkan lebih dari satu pemotong dan
adangan pada sesuatu masa, kerana setiap set
adalah berpadanan. Jika anda tercampur adukkan
set pemotong dan adangan dengan tidak sengaja,
ia mungkin mengambil masa sehingga beberapa
minggu sebelum mutu pencukuran terbaik dapat
dicapai semula.
3Letakkan semula kepala pencukur ke dalam
unit pencukur. Letakkan semula rangka
penahan ke dalam unit pencukur, tekan
roda (1) dan pusingkannya ikut arah jam(2).
4Tutup alat pencukur.
Perapi
Bersihkan perapi setiap kali anda
menggunakannya.
1Matikan alat pencukur, cabut plag kuasa
dari soket dinding dan cabut plag perkakas
dari pencukur.
BAHASA MELAYU20
1
2

C2Bersihkan perapi dengan berus yang
dibekalkan.
C3Lincirkan gigi perapi setiap enam bulan
dengan setitik minyak mesin jahit.
Penyimpanan
C◗Pasangkan kembali penutup perlindungan pada
alat pencukur untuk mengelakkan kerosakan.
◗Plag kuasa dan pencukur boleh disimpan di
dalam beg kecil yang disediakan.
Penggantian
Gantikan kepala pencukur setiap dua tahun sekali
untuk mendapatkan hasil pencukuran yang
optimum.
Gantikan kepala pencukur yang rosak atau haus
dengan Philips HQ53 kepala pencukur sahaja.
1Matikan alat pencukur, cabut plag kuasa
dari soket dinding dan cabut plag perkakas
dari pencukur.
BAHASA MELAYU 21
OIL

C2Tekan butang pelepas untuk membuka unit
pencukur.
C3Putar roda melawan arah jam (1) dan
tanggalkan rangka penahan (2).
C4Keluarkan kepala pencukur dan gantikan
dengan yang baru pada unit pencukur.
C5Kembalikan rangka penahan ke dalam unit
pencukur, tekan roda (1) dan putarkan ke
arah jam (2).
6Tutup alat pencukur.
Aksesori
Aksesori berikut boleh didapati:
- Plag kuasa HQ8000.
- Kepala pencukur Philips HQ53.
- Pembersih Tindakan Bersih Philips HQ100
(pembersih kepala pencukur).
- Isian semula pembersih Tindakan Bersih Philips
HQ101 (cecair pembersih kepala pencukur).
BAHASA MELAYU22
1
2
2
1
