English
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
Please read this user manual, as it contains information about the
features of this shaver as well as some tips to make shaving easier
and more enjoyable.
General description (Fig. 1)
1 Protection cap for cleansing brush attachment
2 Click-on cleansing brush attachment
3 Attachment base
4 Comb for beard styler attachment
5 Click-on beard styler attachment
6 Click-on precision trimmer attachment
7 Click-on shaving unit
8 On/off button
9 Socket for small plug
10 Notification symbol
11 Replacement reminder
12 Travel lock symbol
13 Cleaning reminder
14 Charge symbol
15 Battery charge percentage
16 Personal comfort settings bar
17 + and - buttons for personal comfort settings
18 SmartClean system
19 Cap of SmartClean system
20 On/off button
21 Replacement symbol
22 Rinsing symbol
23 Drying symbol
24 Ready symbol
25 Charge symbol
26 Cleaning cartridge for SmartClean system
27 Supply unit
28 Small plug
6English

29 Pouch
The accessories supplied may vary for different products. The box
shows the accessories that have been supplied with your product.
Important safety information
Read this important information carefully before you use the
appliance and its accessories and save it for future reference. The
accessories supplied may vary for different products.
Danger
- Keep the supply unit dry (Fig. 2).
Warning
- To charge the battery, only use the detachable supply unit
(HQ8505) provided with the appliance.
- The supply unit contains a transformer. Do not cut off the supply
unit to replace it with another plug, as this causes a hazardous
situation.
- This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
- Always unplug the shaver before you clean it under the tap.
- Always check the appliance before you use it. Do not use the
appliance if it is damaged, as this may cause injury. Always replace
a damaged part with one of the original type.
- Do not open the appliance to replace the rechargeable battery.
Caution
- Never immerse the cleaning system or the charging stand in water
and do not rinse it under the tap (Fig. 2).
- Never use water hotter than 60°C to rinse the shaver.
- Only use this appliance for its intended purpose as shown in the
user manual.
7
English

- For hygienic reasons, the appliance should only be used by one
person.
- Never use compressed air, scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to clean the
appliance.
- If your shaver comes with a cleaning system, always use the
original Philips cleaning fluid (cartridge or bottle, depending on the
type of cleaning system).
- Always place the cleaning system on a stable, level and horizontal
surface to prevent leakage.
- If your cleaning system uses a cleaning cartridge, always make
sure the cartridge compartment is closed before you use the
cleaning system to clean or charge the shaver.
- When the cleaning system is ready for use, do not move it to
prevent leakage of cleaning fluid.
- Water may drip from the socket at the bottom of the shaver when
you rinse it. This is normal and not dangerous because all
electronics are enclosed in a sealed power unit inside the shaver.
- Do not use the supply unit in or near wall sockets that contain an
electric air freshener to prevent irreparable damage to the supply
unit.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
General
- This shaver is waterproof (Fig. 3). It is suitable for use in the bath or
shower and for cleaning under the tap. For safety reasons, the
shaver can therefore only be used without cord.
- The supply unit is suitable for mains voltages ranging from 100 to
240 volts.
- The supply unit transforms 100-240 volts to a safe low voltage of
less than 24 volts.
The display
Note: Before you use the shaver for the first time, remove the
protective foil from the display.
8English

Personal comfort settings
The appliance has a feature that allows you to personalise your
settings. You can choose between three settings depending on your
personal shaving needs (from low to high): comfort, dynamic or
efficiency (Fig. 5). When you press the - or + button, the segment of
the personal comfort settings bar that lights up shows the currently
selected setting. You can press the + or - button to select a different
setting (Fig. 5).
Charging
When the shaver is charging, the battery charge percentage and the
battery symbol flash white (Fig. 6).
The battery charge is indicated by the battery charge percentage
shown on the display.
Quick charge: When the battery symbol starts to flash quickly, the
shaver contains enough charge for one shave.
Battery fully charged
When the battery is fully charged, the battery charge percentage
lights up white continuously (Fig. 7).
Note: This appliance can only be used without cord. When you press
the on/off button during or after charging, you hear a sound to
indicate that the shaver is still connected to the wall socket.
Note: When the battery is full, the display switches off automatically
after 30 minutes.
Battery low
When the battery is almost empty, the battery charge indicator
flashes orange and the shaver beeps (Fig. 8).
Remaining battery charge
The remaining battery charge is indicated by the battery charge
percentage shown on the display.
9
English

Cleaning reminder
Clean the shaver after every shave for optimal performance. When
you switch off the appliance, the cleaning reminder flashes to remind
you to clean the appliance (Fig. 9).
Travel lock
You can lock the appliance when you are going to travel. The travel
lock prevents the appliance from being switched on by accident.
Activating the travel lock
1Press the on/off button for 3 seconds to enter the travel lock
mode (Fig. 10).
While you activate the travel lock, the travel lock symbol lights up
white continuously. When the travel lock is activated, the
appliance produces a sound and the travel lock symbol flashes
(Fig. 11).
Deactivating the travel lock
1Press the on/off button for 3 seconds.
The travel lock symbol flashes and then lights up continuously (Fig.
11). The appliance is now ready for use again.
Note: You can also deactivate the travel lock by connecting the
appliance to the wall socket.
Replacement reminder
For maximum shaving performance, we advise you to replace the
shaving heads every two years (Fig. 78).
The appliance is equipped with a replacement reminder which
reminds you to replace the shaving heads. The shaving unit symbol
lights up white continuously, the arrows flash white and the appliance
beeps to indicate that you have to replace the shaving heads (Fig. 12).
Note: After replacing the shaving heads, you can reset the
replacement reminder by pressing the on/off button for 7 seconds. If
you do not reset the replacement reminder, the shaver resets
automatically after 9 shaves.
10 English

Notification symbol
Overheating
If the appliance overheats during charging, the notification symbol
flashes orange (Fig. 13). When this happens, the shaver switches off
automatically. Charging continues once the temperature of the
appliance has decreased to the normal level.
Blocked shaving heads
If the shaving heads are blocked, the notification symbol lights up
orange continuously (Fig. 14). The replacement reminder and the
cleaning reminder flash white alternately and you hear a sound (Fig.
14). In this case, the motor cannot run because the shaving heads are
soiled or damaged.
If the shaving heads are soiled, you have to clean them. If the shaving
heads are damaged, you have to replace them.
Charging
Charge the shaver before you use it for the first time and when the
display indicates that the battery is almost empty. The battery charge
is indicated by the battery charge percentage shown on the display.
When you connect the shaver to the wall socket, you hear a sound.
Charging takes approx. 1 hour. A fully charged shaver has a shaving
time of up to 60 minutes.
Note: You cannot use the appliance while it is charging.
Charging with the supply unit
1Make sure the appliance is switched off.
2Put the small plug in the appliance and put the supply unit in the
wall socket (Fig. 15).
3After charging, remove the supply unit from the wall socket and
pull the small plug out of the appliance.
Charging in the SmartClean system (specific types
only)
1Put the small plug in the back of the SmartClean system.
11
English

2Put the supply unit in the wall socket.
3Press to open the SmartClean system cap, to be able to place the
shaver in the holder ('click') (Fig. 16).
4Hold the shaver upside down above the holder. Make sure the
front of the shaver points towards the SmartClean system holder
(Fig. 17).
5Place the shaver in the holder, tilt the shaver backwards and press
down the SmartClean system cap to connect the shaver (‘click’)
(Fig. 18).
Note: The battery symbol starts to flash to indicate that theappliance
is charging. When the battery is fully charged, the battery symbol
lights up continuously.
Using the appliance
Note: This appliance can only be used without cord.
Switching the appliance on and off
- To switch on the appliance, press the on/off button once (Fig. 19).
The display lights up for a few seconds.
- To switch off the appliance, press the on/off button once.
The display lights up for a few seconds and shows the remaining
battery charge.
Shaving
Skin adaptation period
Your first shaves may not bring you the result you expect and your
skin may even become slightly irritated. This is normal. Your skin and
beard need time to adapt to any new shaving system. To allow your
skin to adapt to this new appliance, we advise you to shave regularly
(at least 3 times a week) and exclusively with this appliance for a
period of 3 weeks.
Shaving tips
- Selectyour personal comfort settings (see ‘The display’).
- For the best results on skin comfort, pre-trim your beard if you
have not shaved for 3 days or longer.
12 English

Dry shaving
1Switch on the appliance.
2Move the shaving heads over your skin in circular movements to
catch all hairs growing in different directions (Fig. 20). Make sure
each shaving head is fully in contact with the skin. Exert gentle
pressure for a close, comfortable shave.
Note: Do not press too hard, this can cause skin irritation.
3Clean the appliance after use.
Wet shaving
For a more comfortable shave, you can also use this appliance on a
wet face with shaving foam or shaving gel.
To shave with shaving foam or shaving gel, follow the steps below:
1Apply some water to your skin (Fig. 21).
2Apply shaving foam or shaving gel to your skin (Fig. 22).
3Rinse the shaving unit under the tap to ensure that the shaving
unit glides smoothly over your skin (Fig. 23).
4Switch on the appliance.
5Move the shaving heads over your skin in circular movements to
catch all hairs growing in different directions (Fig. 20). Make sure
each shaving head is fully in contact with the skin. Exert gentle
pressure for a close, comfortable shave.
Note: Rinse the shaving unit regularly to ensure that it continues to
glide smoothly over your skin.
6Dry your face.
7Clean the appliance after use.
Note: Make sure you rinse all foam or shaving gel off the appliance.
Using click-on attachments
Note: The accessories supplied may vary for different products. The
box shows the accessories that have been supplied with your
product.
Note: Attach the click-on cleansing brush attachment on the
attachment base first, before placing it on the appliance (Fig. 24).
13
English

Removing or attaching the click-on attachments
1Make sure the appliance is switched off.
2Pull the attachment straight off the appliance (Fig. 25).
Note: Do not twist the attachment while you pull it off the
appliance.
3Insert the lug of the attachment into the slot in the top of the
appliance. Then press down the attachment to attach it to the
appliance (‘click’) (Fig. 26).
Using the trimmer attachment
You can use the precision trimmer attachment to touch up your
beard, sideburns and moustache.
1Attach the attachment to the appliance (‘click’) (Fig. 26).
2Switch on the appliance.
The display lights up for a few seconds.
3Hold the trimmer attachment perpendicular to the skin and move
the appliance downwards while you exert gentle pressure (Fig. 27).
4Clean the attachment after use (see 'Cleaning and maintenance').
Using the beard styler attachment with comb
You can use the beard styler attachment with the comb attached to
style your beard at one fixed setting, but also at different length
settings. You can also use it to pre-trim any long hairs before shaving
for a more comfortable shave.
The length settings on the beard styler attachment correspond to the
remaining hair length after cutting and range from 1 to 5mm (3/64 -
3/16in).
1Attach the attachment to the appliance ('click') (Fig. 28).
2Slide the comb straight into the guiding grooves on both sides of
the beard styler attachment (‘click’) (Fig. 29).
3Press the length selector and then push it to the left or right to
select the desired hair length setting (Fig. 30).
4Switch on the appliance.
14 English

5Move the appliance upwards while you exert gentle pressure.
Make sure the front of the comb is in full contact with the skin (Fig.
31).
6Clean the attachment after use (see 'Cleaning and maintenance').
Using the beard styler attachment without comb
You can use the beard styler attachment without the comb to contour
your beard, moustache, sideburns or neckline to a length of 0.5mm
(1/32 in).
1Pull the comb off the beard styler attachment.
Note: Grab the comb in the center to pull it off the beard styler
attachment. Do not pull at the sides of the comb (Fig. 32).
2Switch on the appliance.
3Hold the beard styler attachment perpendicular to the skin and
move the appliance downwards while you exert gentle pressure
(Fig. 33).
4Clean the attachment after use (see 'Cleaning and maintenance').
Using the cleansing brush attachment
Use the rotating cleansing brush with your daily cleansing cream. The
cleansing brush removes oil and dirt, contributing to a healthy and
oil-free skin. We advise you to use it
no more than twice a day. Start with the lowest personal comfort
setting to familiarize yourself with the attachment.
1Attach the attachment to the appliance ('click') (Fig. 34).
2Moisten the attachment with water (Fig. 35).
Note: Do not use the appliance with a dry cleansing brush
attachment, as this can irritate the skin.
3Moisten your face with water and apply a cleanser to your face
(Fig. 36).
4Place the attachment on your cheek.
5Switch on the appliance.
6Gently move the brush across your skin from the nose towards the
ear (Fig. 37). Do not push too hard onto the skin to make sure that
the treatment remains comfortable.
15
English

Do not cleanse the sensitive area around your eyes.
7After approx. 20 seconds, move the appliance to your other cheek
and start cleansing this part of your face (Fig. 38).
8After approx. 20 seconds, move the appliance to your forehead
and start cleansing this part of your face. Gently move the brush
head from left to right (Fig. 39).
Note: We advise you to not overdo the cleansing and to not
cleanse any zone longer than 20 seconds.
9After the treatment, rinse and dry your face (Fig. 40).Your face is
now ready for the next step of your daily skincare routine.
10 Clean the attachment after use (see 'Cleaning and maintenance').
Cleaning and maintenance
Note: The accessories supplied may vary for different products. The
box shows the accessories that have been supplied with your
product.
Cleaning the shaver in the SmartClean system
SmartClean system Plus has two phases: the rinsing phase and the
drying phase (Fig. 41).
Preparing the SmartClean system for use
Caution: Do not tilt the SmartClean system to prevent leakage (Fig.
42).
Note: Hold the SmartClean system while you prepare it for use.
Note: If you clean the shaver in the SmartClean system once a week,
the SmartClean cartridge lasts approximately three months.
1Put the small plug in the back of the SmartClean system.
2Put the supply unit in the wall socket.
3Press the button on the side of the SmartClean system (1) and lift
the top part of the SmartClean system (2) (Fig. 43).
4Pull the seal off the cleaning cartridge (Fig. 44).
5Place the cleaning cartridge in the SmartClean system (Fig. 45).
6While holding the SmartClean system with one hand, gently push
the top part of the SmartClean system back down (‘click’) (Fig. 46).
16 English

Using the SmartClean system
Caution: Always shake excess water off the shaver before you place
it in the SmartClean system (Fig. 47).
1Press to open the SmartClean system cap, to be able to place the
shaver in the holder ('click') (Fig. 16).
2Hold the shaver upside down above the holder. Make sure the
front of the shaver points towards the SmartClean system holder
(Fig. 17).
3Place the shaver in the holder (1), tilt the shaver backwards (2) and
press down the top cap to connect the shaver ('click') (3) (Fig. 18).
The battery symbol starts to flash, which indicates that the shaver
is charging.
4Press the on/off button on the SmartClean system to start the
cleaning program (Fig. 48).
During the rinsing phase, the rinsing symbol flashes. When the rinsing
phase is done (after approx. 10 minutes), the rinsing symbol lights up
continuously (Fig. 48).
After the rinsing phase, the drying phase starts automatically. During
this phase, the drying symbol flashes. When the drying phase is done
(after approx. 4 hours), the drying symbol lights up continuously (Fig.
49).
When the cleaning program is done, the ready symbol lights up
continuously (Fig. 50).
30 minutes after the cleaning program and charging are done, the
SmartClean system switches off automatically.
The battery symbol lights up continuously to indicate that the shaver
is fully charged (Fig. 50). Charging takes approx. 1 hour.
Note: If you press the on/off button of the SmartClean system during
the cleaning program, the program stops. In this case, the cleaning or
drying symbol goes out.
Note: If you disconnect the SmartClean system from its power supply,
the cleaning program stops.
17
English

Replacing the cartridge of the SmartClean system
Replace the cleaning cartridge when the replacement symbol flashes
orange or when you are no longer satisfied with the cleaning result. If
you clean the shaver in the SmartClean system once a week, the
SmartClean cartridge lasts approximately three months.
1While holding the SmartClean system with one hand, press the
button on the side of the SmartClean system and lift the top part
of the SmartClean system.
2Remove the cleaning cartridge from the SmartClean system and
pour out any remaining cleaning fluid (Fig. 51).
You can safely pour the cleaning fluid down the sink.
3Discard the empty cleaning cartridge.
4Unpack the new cleaning cartridge and pull off the seal (Fig. 44).
5Place the cleaning cartridge in the SmartClean system (Fig. 45).
6While holding the SmartClean system with one hand, gently push
the top part of the SmartClean system back down (‘click’) (Fig. 46).
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal performance.
Be careful with hot water. Always check if the water is not too hot,
to prevent burning your hands.
Never dry the shaving unit with a towel or tissue, as this may
damage the shaving heads.
1Switch on the shaver.
2Rinse the shaving unit under a warm tap (Fig. 23).
3Switch off the shaver. Pull the shaving head holder off the bottom
part of the shaving unit (Fig. 52).
4Rinse the hair chamber under the tap (Fig. 53).
5Rinse the shaving head holder under a warm tap (Fig. 54).
6Carefully shake off excess water and let the shaving head holder
air-dry completely.
7Attach the shaving head holder to the bottom part of the shaving
unit (‘click’) (Fig. 55).
18 English

Thorough cleaning
We advise you to clean the shaving heads thoroughly once a month
or when the appliance does not shave as well as it used to.
Note: The shaving heads are locked by a blue (Fig. 56) or an orange
(Fig. 57) retaining ring. Follow the correct instructions.
1Switch off the appliance.
2Pull the shaving head holder off the bottom part of the shaving
unit (Fig. 52).
3Rinse the hair chamber and shaving head holder under the tap.
4Turn the retaining ring anticlockwise and lift it off the shaving head
(Fig. 58).
Repeat this process for the other retaining rings. Place them aside
in a safe place.
5Remove the shaving heads from the shaving head holder (Fig. 60).
Each shaving head consists of a cutter and guard.
Note: Do not clean more than one cutter and guard at a time, since
they are all matching sets. If you accidentally put a cutter in the
wrong shaving guard, it may take several weeks before optimal
shaving performance is restored.
6Clean the cutter and guard under the tap (Fig. 61).
7Shake off excess water.
8Put the cutter back into the guard.
9Place the shaving heads in the shaving head holder (Fig. 62).
Note: Make sure the notches on both sides of the shaving heads fit
exactly onto the projections in the shaving head holder.
10 Blue retaining ring: Place the retaining ring on the shaving head
and turn it clockwise to reattach the retaining ring.
Place the arrows on the ring in line with the projections in the
shaving head holder (Fig. 63). Turn the ring clockwise until it clicks
to indicate that the ring is fixed (Fig. 64).
-Orange retaining ring: Place the retaining ring on the shaving head
and turn it clockwise to reattach the retaining ring (Fig. 65). Repeat
this process for the other retaining rings.
19
English

Hold the shaving head holder in your hand when you reinsert the
shaving heads and reattach the retaining rings (Fig. 67). Do not
place the shaving head holder on a surface when you do this, as
this may cause damage.
Each retaining ring has two recesses that fit exactly into the
projections of the shaving head holder. Turn the ring clockwise
until your hear a click to indicate that the ring is fixed (Fig. 66).
11 Attach the shaving head holder to the bottom part of the shaving
unit (‘click’) (Fig. 55).
Cleaning the click-on attachments
Never dry trimmer or beard styler attachments with a towel or tissue,
as this may damage the trimming teeth.
The accessories supplied may vary for different products. The box
shows the accessories that have been supplied with your product.
Cleaning the trimmer attachment
Clean the trimmer attachment after each use.
1Switch on the appliance with the precision trimmer attachment
attached.
2Rinse the attachment under a warm tap (Fig. 68).
3After cleaning, switch off the appliance.
4Carefully shake off excess water and let the attachment air-dry
completely.
Tip: For optimal performance, lubricate the teeth of the attachment
with a drop of sewing machine oil regularly.
Cleaning the beard styler attachment
Clean the beard styler attachment after each use.
1Pull the comb off the beard styler attachment (Fig. 69).
Note: Grab the comb in the center to pull it off the beard styler
attachment . Do not pull at the sides of the comb (Fig. 32).
2Rinse cut hairs off the cutting unit with lukewarm water (Fig. 70).
3Rinse cut hairs off the comb.
20 English
