Philips HQ7142 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ7142
08/02
PRODUCT INFORMATION
General:
- Mains/rechargeable operation
- World-wide automatic voltage selection
- Electronic on/off switch
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100 - 240 Volt / 50 - 60 Hz
- Motor voltage : 1,2 Volt
- Shaving heads : HQ8 - 4222 036 05820
- SAP coding : HQ7142
DISASSEMBLY- AND RE-ASSEMBLY ADVICE
Disassembly:
- Remove shaving unit, to prevent damaging during
repairing.
- Remove the 2 screws (A) out of the hairchamber.
- Remove the hairchamber from the body.
- Remove the 2 screws (B) on the backside of the shaver.
- Remove the cover.
- Remove the side grips.
- Remove the housing by bending the hooks with a
screwdriver.
- Take out the basic body.
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Car cord : 4222 036 08920
- Pouch : 4222 036 14160
HQ7142
EXPLODED VIEW & PARTS LIST
3
7
B
11
10
12
1
2
4
5
8
9
6A
Pos Service code Description
1
2
3
4
4222 036 14050
4222 036 12610
4222 036 04080
4222 036 04090
4222 036 04000
4222 036 04040
4222 036 08930
4222 036 06800
4222 036 05820
Protection cap Cheetah
Bracket-assy
Power plug EUR
Power plug GBR
Power plug KOR
Power plug PRC
Power plug JAP
Power plug Can/Tw/Ven
Shaving heads
Pos Service code Description
5
6
7
8
9
10
11
12
4222 036 12990
4222 036 12640
4222 036 14100
4222 036 12570
4222 036 15300
4222 036 02770
4222 036 12220
4222 036 15310
4222 036 11480
Holder-assy
Hairchamber
Basic body
Grip left & right
Housing-assy
Brush
Trimmer assy
Back shell assy
Screw
