Philips HQ7890CC User manual

HQ7890CC

1 2 3 4
56 7 8
9 10 11 12
13 14 15 16
17 18 19 20

HQ7890CC
ENGLISH 6
 18
 32
 43
 55
 67
 79
 92
 104
 116
 129
 142
 155
 167
 179
 192

6
Introduction
Congratulations on your purchase and welcome to Philips!To fully benefit
from the support that Philips offers, register your product at
www.philips.com/welcome.
Important
Read this user manual carefully before you use the shaver and the Jet
Clean system. Save the user manual for future reference.
Danger
- Make sure the adapter does not get wet (Fig. 1).
Warning
- Be careful with hot water. Always check if the water is not too hot,
to prevent your hands from getting burnt.
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
- The shaver and the Jet Clean system are not intended for use by
persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliances by a person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the shaver and the Jet Clean system.
Caution
- Do not use the shaver or the Jet Clean system if it is damaged.
- Do not immerse the shaver in water (Fig. 2).
- This shaver is not suitable for shaving in the shower.
- Charge, use and store the shaver at a temperature between 5°C
and 35°C.
- Water may leak from the socket at the bottom of the shaver when
you rinse it.This is normal and not dangerous because all electronics
are enclosed in a sealed power unit inside the shaver (Fig. 3).
- Always put the protection cap on the shaver to protect the shaving
heads when you are travelling.
ENGLISH

- The shaver, the Jet Clean system and the other accessories are not
dishwasher-proof.
- Only use the adapter supplied.
- If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
- Only use the Jet Clean systemwith the original HQ200 cleaning fluid.
- Do not immerse the Jet Clean system in water nor rinse it under the
tap. (Fig. 4)
- Use and store the Jet Clean system at a temperature between
5°C and 35°C.
- Always place the Jet Clean system on a stable, level and horizontal
surface to prevent leakage.
- Always place the Jet Clean system on a fluid-resistant surface.
- When the Jet Clean system is ready for use, do not move it to
prevent leakage of cleaning fluid.
- The Jet Clean system thoroughly cleans but does not disinfect your
shaver, therefore do not share the shaver with others.
Compliance with standards
- The shaver complies with the internationally approved IEC safety
regulations and can be safely cleaned under the tap (Fig. 5).
- The shaver and the Jet Clean system comply with all standards
regarding electromagnetic fields (EMF). If handled properly and
according to the instructions in this user manual, the appliances are
safe to use based on scientific evidence available today.
General
- The adapter transforms 100-240 volts to a safe low voltage of less
than 24 volts.
- Noise level: Lc = 60 dB [A]
ENGLISH 7

Charging
Make sure the shaver is switched off before you charge it.
Charging takes approx. 1 hour.
You can also shave without charging by connecting the shaver to the mains.
A fully charged shaver has a cordless shaving time of up to 55 minutes.
1 Charge the shaver when the bottom light flashes orange.
Charge indications
Charging
- When you start charging the empty shaver, the bottom light flashes
orange.When the battery contains enough power for one shave, the
middle charging light starts flashing green (Fig. 6).
Battery fully charged
- When the battery is fully charged, the top charging light lights up
green continuously.
Battery low
- When the battery is almost empty i.e. when there are only 5 or less
shaving minutes left, the bottom charging light starts to flash orange.
When you switch off the shaver, this light still flashes orange a few times.
Charging with the adapter
1 Put the appliance plug in the shaver (Fig. 7).
2 Put the adapter in the wall socket.
3 Remove the adapter from the wall socket and pull the appliance
plug out of the shaver when the battery is fully charged.
Charging in the Jet Clean system
1 Place the shaver in the holder and completely push down the lever
to lock the shaver into place (Fig. 8).
,The charging light on the Jet Clean system flashes to indicate that
the shaver is charging.
,When the charging light lights up continuously (after approx. 1
hour), the shaver is fully charged (Fig. 9).
ENGLISH8

2 Move the lever upwards until it does not go any further (1) and
remove the shaver from the Jet Clean system(2). (Fig. 10)
,The charging light goes out.


1 Press the on/off button once to switch on the shaver.
2 Move the shaving heads over your skin in circular
movements (Fig. 11).
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get accustomed to the Philips
shaving system.
Note: Do not make straight movements.
3 Press the on/off button once to switch off the shaver.
4 Clean the shaver (see chapter ‘Cleaning and maintenance’).
5 Put the protection cap on the shaver every time you have used it,
to prevent damage (Fig. 12).

You can use the trimmer to groom your sideburns and moustache.
1 Push the slide downwards to open the trimmer (Fig. 13).
Note:You can activate the trimmer while the motor is running.
2 Close the trimmer (‘click’) (Fig. 14).
Cleaning and maintenance
The best and most hygienic way to clean the shaver is in the Jet Clean
system.You can also clean the shaver by rinsing it under the tap or with
the brush supplied.
Regular cleaning guarantees better shaving performance.
Note:Water may leak from the socket at the bottom of the shaver when you
rinse it.This is normal and not dangerous.
ENGLISH 9


Preparing the Jet Clean system for use
Fill the cleaning chamber before first use and when the cleaning light
flashes to indicate that the fluid level is too low.When the fluid level
drops below the minimum level, the cleaning light flashes with intervals
and the holder returns to its starting position.
If you use the Jet Clean system to clean the shaver every day, refill the
cleaning chamber approx. every 15 days.
1 Simultaneously press the release buttons on both sides of the
cleaning chamber (1) and lift the Jet Clean system off the cleaning
chamber (2) (Fig. 15).
The cleaning chamber remains behind.
2 Unscrew the dosing cap from the bottle with HQ200 Cleaning
Fluid and remove the airtight seal.
3 Fill the cleaning chamber with cleaning fluid up to the MAX
indication (Fig. 16).
4 Place the Jet Clean system back onto the cleaning chamber (Fig. 17).
Make sure the release buttons snap back into place.
5 Put the appliance plug in the Jet Clean system and put the adapter
in the wall socket (Fig. 18).
,The holder automatically moves to the highest position.
The Jet Clean system is now ready for use.

1 Place the shaver in the holder and completely push down the lever
to lock the shaver into place.
,The charging light on the Jet Clean system flashes to indicate that
the shaver is being charged.
2 Press the start button to start the cleaning program. (Fig. 19)
The cleaning light starts flashing and the shaver is automatically lowered
into the cleaning fluid.
,During the cleaning program, which takes approx. 1 hour, the
cleaning light flashes continuously.
ENGLISH10

,During the first phase of the cleaning program, the shaver automatically
switches on and off several times and is put in different positions.
,During the second phase of the cleaning program, the shaver is
placed in the drying position. It stays in this position until the end
of the program.The cleaning light lights up continuously.
,After the cleaning program, the shaver automatically returns to its
starting position and starts charging.The charging light on the
Jet Clean system flashes.
Note: If you press the start button or open the lever during cleaning, the
cleaning program is aborted and reset. In this case, the cleaning light stops
ashing and the holder returns to its starting position.
Note: If the adapter is removed from the wall socket during cleaning, the
cleaning program is aborted.The holder remains in its current position.
When the adapter is put back into the wall socket, the holder moves to
the highest position.
Note: If the uid volume in the cleaning chamber drops below the minimum
level during the cleaning program, the program is aborted.The cleaning
light ashes with intervals and the holder returns to its starting position.
Cleaning the Jet Clean system
The cleaning chamber is not dishwasher-proof.
Clean the cleaning chamber every two weeks.
1 Simultaneously press the buttons on both sides of the Jet Clean
system (1) and lift the Jet Clean system off the cleaning chamber
(2). (Fig. 20)
The cleaning chamber remains behind.
2 Pour any remaining cleaning fluid out of the cleaning
chamber. (Fig. 21)
You can simply pour the cleaning fluid down the sink.
3 Rinse the cleaning chamber under the tap (Fig. 22).
4 Place the Jet Clean system back onto the cleaning chamber (Fig. 23).
Make sure the release buttons snap back into place.
5 Clean the Jet Clean system with a moist cloth.
ENGLISH 11


Be careful with hot water.Always check if the water is not too hot, to
prevent your hands from getting burnt.
1 Switch off the shaver, remove the adapter from the wall socket and
pull the appliance plug out of the shaver.
2 Press the release button to open the shaving unit (Fig. 24).
3 Rinse the hair chamber and the inside of the shaving unit under a
hot tap for some time (Fig. 25).
4 Rinse the outside of the shaving unit under a hot tap for some
time (Fig. 26).
5 Close the shaving unit and shake off excess water.
Never dry the shaving unit with a towel or tissue, as this may damage
the shaving heads.
6 Open the shaving unit again and leave it open to let the shaver dry
completely (Fig. 27).
You can also clean the hair chamber without water with the brush supplied.
Extra-thorough cleaning method
1 Switch off the shaver, remove the adapter from the wall socket and
pull the appliance plug out of the shaver.
2 Open the shaving unit, turn the lock anticlockwise (1) and remove
the retaining frame (2) (Fig. 28).
3 Clean the cutters and guards with the brush supplied (Fig. 29).
Note: Do not clean more than one cutter and guard at a time, since they are
all matching sets. If you accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving performance is restored.
4 Put the shaving heads back into the shaving unit. Put the retaining
frame back into the shaving unit and turn the lock
clockwise (Fig. 30).
5 Close the shaving unit.
ENGLISH12

Cleaning the trimmer
Clean the trimmer every time you have used it.
1 Switch off the shaver, remove the adapter from the wall socket and
pull the appliance plug out of the shaver.
2 Clean the trimmer with the brush supplied (Fig. 31).
3 Lubricate the trimmer teeth with a drop of sewing machine oil
every six months (Fig. 32).
Storage
There are two ways to store the shaver:
- put the protection cap on the shaver to prevent damage (Fig. 12).
- store the shaver in the Jet Clean system (Fig. 33).
Replacement
For optimal shaving performance, we advise you to replace the shaving
heads every 2 years.
Replace damaged or worn shaving heads with HQ8 Philips Shaving Heads
only.
Note: Do not mix up the cutters and the guards to guarantee optimal
shaving performance.
1 Switch off the shaver, remove the adapter from the wall socket and
pull the appliance plug out of the shaver.
2 Press the release button to open the shaving unit.
3 Turn the lock anticlockwise (1) and remove the retaining
frame (2) (Fig. 28).
4 Remove the shaving heads and place new ones in the shaving unit.
Put the retaining frame back into the shaving unit and turn the lock
clockwise (Fig. 34).
ENGLISH 13

Make sure that the projections of the shaving heads fit exactly into the
recesses.
5 Close the shaving unit.

The following accessories are available:
- HQ8 Philips Shaving Heads.
- HQ110 Philips Shaving Head Cleaning Spray.
- HQ8010 Car Cord.
- HQ200 Philips Cleaning Fluid.

- Do not throw away the shaver and the Jet Clean system with the
normal household waste at the end of their life, but hand them in at
an official collection point for recycling. By doing this, you help to
preserve the environment (Fig. 35).
- The built-in rechargeable shaver battery contains substances that may
pollute the environment.Always remove the battery before you
discard and hand in the shaver at an official collection point. Dispose
of the battery at an official collection point for batteries. If you have
trouble removing the battery, you can also take the shaver to a Philips
service centre.The staff of this centre will remove the battery for you
and will dispose of it in an environmentally safe way (Fig. 36).

Only remove the battery if it is completely empty.
1 Remove the adapter from the wall socket and pull the appliance
plug out of the shaver.
2 Let the shaver run until it stops and undo the two screws in the
back of the shaver (Fig. 37).
3 Undo the two screws in the hair chamber (Fig. 38).
4 Undo the three screws in the power unit (Fig. 39).
ENGLISH14

5 Bend the 4 hooks aside (1) to take out the power unit (2) (Fig. 40).
Be careful, the hooks are very sharp.
6 Remove the power unit cover with a screwdriver (Fig. 41).
7 Remove the rechargeable battery.
Be careful, the battery strips are very sharp.
Do not connect the shaver to the mains again after you have
removed the battery.

If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you find its phone number in the worldwide
guarantee leaflet). If there is no Consumer Care Centre in your country,
go to your local Philips dealer.
Guarantee restrictions
The shaving heads (cutters and guards) are not covered by the terms of
the international guarantee because they are subject to wear.

Problem Solution
The shaver
does not shave
as well as it
used to.
The Jet Clean system may not have cleaned the
shaver properly because the cleaning fluid in the
cleaning chamber is soiled or the cleaning fluid level
is too low. Clean the shaver thoroughly before you
continue shaving. If necessary, clean and refill the
cleaning chamber (see chapter ‘Cleaning and
maintenance’).
The shaving heads may be damaged or worn.
Replace the shaving heads (see chapter
‘Replacement’).
ENGLISH 15

Problem Solution
Long hairs may obstruct the shaving heads. Clean the
cutters and guards with the brush supplied (see
chapter ‘Cleaning and maintenance’).
The shaver
does not work
when I press
the on/off
button.
The battery may be empty. Recharge the battery
(see chapter ‘Charging’) or connect the shaver to the
mains.
The shaver may not be connected to the mains. Put
the appliance plug in the shaver and put the adapter
in the wall socket.
The shaving unit
has come off
the shaver.
The shaving unit was not placed correctly. Put the
shaving unit back onto the shaver by inserting the
hinge into the slot in the rim of the hair chamber.
Then push the shaving unit home until it locks into
place (‘click’).
The shaver is
not entirely
clean after I
clean it in the
Jet Clean
system.
The cleaning fluid in the cleaning chamber may be
soiled. Empty and rinse the cleaning chamber.
The cleaning fluid level may be too low. If the fluid
volume in the cleaning chamber drops below the
minimum level during the cleaning program, the
program aborts.The cleaning light flashes with
intervals and the holder returns to its starting
position. Refill the cleaning chamber with cleaning
fluid up to the MAX indication (see chapter
‘Cleaning and maintenance’).
ENGLISH16

Problem Solution
You may have used another cleaning fluid than the
original Philips cleaning fluid. Only use Philips HQ200
Cleaning Fluid.
The Jet Clean
system does
not work when
I press the on/
off button.
The Jet Clean system may not be connected to the
mains. Put the appliance plug in the Jet Clean system
and put the adapter in the wall socket.
You have not placed the shaver in the Jet Clean
system properly. Make sure you push down the lever
completely to lock the shaver into place.
ENGLISH 17

18

Поздравления за вашата покупка и добре дошли във Philips!
За да се възползвате изцяло от предлаганата от Philips поддръжка,
регистрирайте продукта си на адрес www.philips.com/welcome.

Преди да използвате самобръсначката и системата за почистване
Jet Clean, прочетете внимателно това ръководство за потребителя.
Запазете го за справка в бъдеще.

- Внимавайте щепселът да не се мокри (фиг. 1).

- Внимавайте с горещата вода. Винаги проверявайте дали водата
не е прекалено гореща, за да предпазите ръцете си от изгаряне.
- В адаптера има трансформатор. Не отрязвайте адаптера, за да
го замените с друг щепсел, тъй като това носи опасност.
- Самобръсначката и системата Jet Clean не са предназначени за
ползване от хора (включително деца) с намалени физически
възприятия или умствени недъзи или без опит и познания, ако са
оставени без наблюдение и не са инструктирани от страна на
отговарящо за тяхната безопасност лице относно начина на
използване на уредите.
- Наглеждайте децата, за да не си играят със самобръсначката и
системата Jet Clean.

- Не използвайте самобръсначката или системата Jet Clean,
ако са повредени.
- Не потапяйте самобръсначката във вода (фиг. 2).
- Тази самобръсначка не е подходяща за бръснене под душа.
- Зареждайте, ползвайте и съхранявайте самобръсначката при
температури от 5°C до 35°C.


- От захранващия куплунг отдолу на самобръсначката може да
протече вода, когато я изплаквате. Това е нормално и не е
опасно, тъй като цялата електроника е затворена в капсулован
силов блок вътре в самобръсначката (фиг. 3).
- За да предпазите бръснещите глави при пътуване, винаги
поставяйте предпазната капачка на самобръсначката.
- Самобръсначката, системата Jet Clean и другите принадлежности
не могат да се мият в съдомиялна машина.
- Използвайте само включения в комплекта адаптер.
- С оглед на предотвратяване на злополука, винаги заменяйте
повредения адаптер само с оригинален такъв.
- Използвайте системата Jet Clean само с оригиналната
почистваща течност HQ200.
- Не потапяйте системата Jet Clean във вода и не я плакнете с
течаща вода. (фиг. 4)
- Използвайте и съхранявайте системата Jet Clean при
температури между 5°C и 35°C.
- Поставяйте системата Jet Clean винаги върху стабилна, равна и
хоризонтална повърхност, за да предотвратите разливане.
- Винаги поставяйте системата Jet Clean върху устойчива на
течности повърхност.
- Когато системата Jet Clean е готова за употреба, не я местете,
за да предотвратите разливане на почистващата течност.
- Системата Jet Clean измива щателно, но не дезинфекцира
самобръсначката, така че не давайте самобръсначката ви да се
ползва от други хора.

- Уредът съответства на международно одобрената нормативна
уредба за безопасност IEC и може да се почиства безопасно под
чешмата (фиг. 5).
- Самобръсначката и системата Jet Clean са в съответствие с
всички стандарти по отношение на електромагнитните
излъчвания (EMF). Ако се употребяват правилно и съобразно
напътствията в ръководството за потребителя, уредите са
безопасни за използване според наличните досега научни факти.
 19


- Адаптерът преобразува 100-240 волта в безопасно ниско
напрежение под 24 волта.
- Ниво на шум: Lc = 60 dB [A]

Внимавайте самобръсначката да е изключена, преди да я зареждате.
Зареждането отнема около 1 час.
Можете да се бръснете и без да зареждате, като свържете
самобръсначката директно към мрежата.
Напълно заредената самобръсначка може да се използва за
бръснене без кабел в продължение на 55 минути.
1 Заредетесамобръсначката,когатодолниятиндикатормигав
оранжево.


- Когато започнете зареждане на изтощената самобръсначка, най-
долният индикатор мига в оранжево. Когато батерията има
достатъчен заряд за едно бръснене, средният индикатори за
зареждане започва да мига в зелено (фиг. 6).

- Когато батерията е напълно заредена, горният индикатор за
зареждане свети непрекъснато в зелено.

- Когато батерията е почти изтощена, т. е. когато остават не
повече от 5 минути за бръснене, долният индикатор за
зареждане започва да мига в оранжево.
Когато изключвате самобръсначката, този светлинен индикатор
примигва в оранжево още няколко пъти.

1 Включетещепселанауредавгнездотому(фиг.7).
2 Включетеадаптеравконтакта.
20
