Philips Norelco QP2630 User manual

QP2630, QP2620

3mm
11
12
13
3
1
4
5
6
7
8
9
10
2
15
14
16

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Protection cap
2 Face blade
3 Blade release slide
4 On/off button
5 Battery status indicator (QP2630 only)
6 Small plug
7 Battery charge indicator (QP2620 only)
8 Supply unit (QP2630: adapter type HQ850.
QP2620: adapter type A00390.)
9 Replacement blade (specific types only)
10 Click-on stubble comb 5mm
11 Click-on stubble comb 3mm
12 Click-on stubble comb 2mm (QP2630 only)
13 Click- on stubble comb 1mm
14 Body blade
15 Sensitive skin guard
16 Body comb 3mm
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
6English

Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the
detachable supply unit provided with the
appliance. For the type number of the
original supply unit, please see ' General
description' in the manual.
- The supply unit contains a transformer. Do
not cut off the supply unit to replace it with
another plug, as this causes a hazardous
situation.
7
English

- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
- Always unplug the appliance before you
clean it under the tap.
- Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never immerse the charging
stand in water and do not rinse
it under the tap.
8English

- Do not use the supply unit in or
near wall sockets that contain
an electric air freshener to
prevent irreparable damage to
the supply unit.
- Only use this appliance for its
intended purpose as shown in
the user manual.
- For hygienic reasons, the
appliance should only be used
by one person.
- Never use water hotter than
60°C to rinse the appliance.
- Never use compressed air,
scouring pads, abrasive
cleaning agents or aggressive
liquids such as petrol or
acetone to clean the appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
9
English

General
- This appliance is waterproof. It is suitable for
use in the bath or shower and for cleaning
under the tap. For safety reasons, the appliance
can therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Charge the appliance before first use and when
the display indicates that the battery is almost
empty.
QP2630: Charging takes approx. 4 hours.
QP2620: Charging takes approx. 8 hours.
A fully charged appliance has an operating time of
up to 60 minutes (QP2630) or 45 minutes
(QP2620).
Note: This appliance can only be used without
cord.
Battery status indicator QP2630:
When the battery status indicator flashes orange,
the battery is almost empty.
When the appliance is charging, the battery status
indicator light flashes green.
10 English

When the battery is fully charged, thebattery
statusindicator lights up green continuously.
Approx. 30 minutes after the battery is fully
charged or when you disconnect the appliance
from the wall socket, the light of the battery status
indicator switches off automatically.
Battery status indicator QP2620:
The battery status is indicated by the performance
of the appliance. When the appliance starts
working more slowly, the battery is almost empty
and needs to be charged for optimal performance.
Charging with the supply unit
1Insert the small plug into the appliance and put
the supply unit in the wall socket.
QP2620 only: The battery charge indicator on
the adapter lights up continuously, when the
appliance is connected to the wall socket.
2After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Using the appliance
Your appliance comes with 2 blades. Use
one blade for your face only and the other
blade for your body.
The face blade and the stubble combs are
for use on facial hair. It is not intended for
shaving, edging or trimming hairs on lower
body parts or scalp hair.
The body blade and body comb are for use
on body parts below the neck.
11
English

The body blade with the skin guard
attached are for use on sensitive body
areas.
Note: This appliance can only be used without
cord.
- Use the appliance with the face blade to trim,
edge or shave facial hair (beard, moustache and
sideburns). Shave for a smooth result, trim with
the stubble comb to obtain a certain length and
edge to create perfect edges and sharp lines.
- Use the appliance with the body blade to trim
and/or shave your body hair. Shave your chest
without the skin guard or body comb for a
smooth result, shave your sensitive areas (e.g.
groin, armpits) with the skin guard, use the body
comb to trim your body.
- Take your time when you first start to use the
appliance. You have to acquire practice with the
appliance.
Switching the appliance on and off
1To switch on the appliance, press the on/off
button once.
2To switch off the appliance, press the on/off
button once.
Face
Shaving
Warning: Before you use the appliance,
always check the blade for damage or wear.
If the blade is damaged or worn, do not use
the appliance, as injury may occur. Replace
a damaged blade before you use the
appliance (see chapter ‘Replacement’).
12 English

Shaving tips and tricks
- Make sure that the blade is in full contact with
the skin by placing it flat on the skin.
- For the best result, move the appliance against
the grain.
- Make long strokes while pressing lightly.
- You can use the appliance dry or wet with gel or
foam. You can even use the appliance in the
shower.
- Shaving a clean beard and face gives the best
results.
Shaving
1Switch on the appliance.
2Place the blade on the skin and move the
appliance up or against the grain in long strokes
while you press it lightly.
Note: Make sure you hold the surface of the
blade flat against your skin.
3Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
Edging
You can also use both edges of the blade to create
sharp lines and perfect edges. Hold the appliance
in such a way that the blade is perpendicular to
the skin and one of its edges touches the skin. This
allows more precise detailing of sideburns and the
area around the mouth and nose.
13
English

1To create sharp edges and lines, you can use
either edge of the blade.
2Switch on the appliance.
3Place the edge of the blade perpendicular onto
the skin.
-Make straight strokes while applying gentle
pressure.
4Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
Trimming
Trimming tips
-Always make sure that the tips of the click-
on stubble comb point in the direction in
which you move the appliance.
-Make sure that the flat part of the comb is
always in full contact with the skin to obtain
an even trimming result.
-Since hair grows in different directions, you
need to move the appliance in different
directions as well (upward, downward or
across).
-Trimming is easier when the skin and hair are
dry.
Trimming combs
The click-on stubble combs allow you to trim hair
to different lengths.
14 English

- QP2630 come with 4 click-on stubble combs:
5mm, 3mm, 2mm and 1mm.
- QP2620 comes with 3 click-on stubble combs:
5mm, 3mm and 1mm.
Start with the 5mm comb to acquire practice with
this appliance.
The indication on each comb corresponds to the
hair length in millimeters.
Trimming with comb
1Place the comb onto the blade, with the teeth
of the comb pointing upwards.
Note: Always trim in the direction of the teeth of
the comb. This will give you the best results.
2Switch on the appliance.
3Place the comb onto the skin and move the
appliance in the direction of the teeth of the
comb.
Note: For the best result, move it against the
grain.
4Switch off and clean the appliance after every
use (see ‘Cleaning and maintenance’).
5To remove the comb, hold it on both sides and
pull it off the blade.
Body
- For hygienic reasons, only use the body blade
for trimming and shaving your body.
- For body trimming and shaving, make sure hair
is clean and dry as wet hair tends to stick to the
body and, when shaving sensitive areas, always
use the skin guard.
15
English

- Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards, downwards, or
across). Practice is best for optimum results.
- For the best result, move the appliance against
the grain.
- Make long strokes while pressing lightly.
- Use the appliance dry or wet with gel or foam,
even in the shower.
- Shaving a clean body gives the best results.
Shaving with skin guard
For optimal performance, use the skin guard only
on sensitive areas (for example the scrotum and
armpits).
1Hold the skin guard on both sides and press
onto the blade.
2Switch the appliance on.
3Place the skin guard onto the skin and stretch
the skin with your free hand. Move the
appliance upwards slowly, against the grain.
-When using the appliance on your armpits,
raise your arm and put your hand on the
back of your head to stretch the skin.
-Regularly remove cut hair from the guard. If a
lot of hair has accumulated in the guard,
remove it from the appliance and blow
and/or shake out the hairs.
4Switch off and clean the appliance after each
use.
16 English

1
2
5To remove the skin guard, put one finger under
the edge of the guard and press on the blade
with your thumb.
Shaving without skin guard
The body blade without the skin guard allows you
to shave hair on your body below the neckline (for
example the chest) with a smooth result.
1
2
1To remove the skin guard, put one finger under
the edge of the guard and press with your
thumb on the blade.
2Switch the appliance on.
3Place the blade on the skin and move the
appliance against the grain in long strokes while
pressing lightly. Stretch the skin with your free
hand.
Note: Make sure you hold the surface of the
blade flat against your skin.
-When you use the appliance on your
armpits, raise your arm and put your hand
on the back of your head to stretch the skin.
4Switch off and clean the appliance after every
use.
Trimming with body comb
The 3mm (1.8in.) body comb allows you to trim hair
on your body below the neckline (for example
chest, armpits, scrotum).
1Hold the body comb on both sides and press
onto the blade.
2Switch the appliance on.
17
English

3Place the comb onto the skin and stretch the
skin with your free hand. Move the appliance
upwards slowly, against the grain.
-When you use the appliance on your
armpits, raise your arm and put your hand
on the back of your head to stretch the skin.
-Regularly remove cut hair from the guard. If a
lot of hair has accumulated in the guard,
remove it from the appliance and blow
and/or shake out the hairs.
4Switch off and clean the appliance after each
use.
5To remove the comb, hold it on both sides and
pull it off the blade.
Cleaning and maintenance
Clean the appliance after every use.
Caution: Never use compressed air, scouring
pads, abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
Caution: Do not tap the appliance against a
surface to remove water from it, as this may
cause damage. Replace the blade if it is
damaged.
18 English

Cleaning the appliance
1Remove the comb from the blade. Always turn
the appliance off before putting on or taking off
combs.
2If a lot of hairs have accumulated on the comb,
first blow them off.
3If a lot of hairs have accumulated on the
appliance, first blow them off.
4Switch on the appliance and rinse the blade
with lukewarm water.
Caution: Do not dry the blade with a towel or a
tissue as this may cause damage.
5Rinse the combs with lukewarm water.
6Carefully shake off excess water and let all parts
air dry completely.
Note: The blade is fragile. Handle it carefully.
Replace the blade if it is damaged.
19
English

Storage
Always attach the protection cap on the blade to
protect the blade from damage during travelling or
storage.
We advise you to let the appliance and its
attachments dry before you store them for the
next use.
1Place the protection cap onto the edge of the
blade.
2Close the protection cap.
- Attach the body comb on the body blade to
protect the blade from damage.
Replacement
Usage indicator
For optimal cutting and gliding performance, we
advise you to replace the blade every 4 months,
when it no longer provides the shaving or trimming
results you expect.
The blade is equipped with a usage indicator. A
green bar will gradually appear on the blade as
you use it. When it is highly visible, it is
recommended to replace your blade for the best
OneBlade experience. Always replace the blade
with original Philips blade.
Depending on your usage behavior, the exact
lifetime of the blade could be longer or shorter.
20 English

Similar to a manual blade, the blade becomes
blunt over time, which results in increased hair
pulling and reduced cutting performance.
Replacing the blade
1Switch off the appliance.
1
2
2Push the blade release slide upwards carefully,
and hold the blade on both sides to remove the
blade. This will prevent the blade from flying off
the handle.
3Hold the new blade on its sides and press it
onto the handle (‘click’).
Note: When you hear a click, the new blade is
placed correctly and ready for use.
Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).
The following parts are available:
- Model QP210 Philips Replacement Blade,
1-Pack
- Model QP220 Philips Replacement Blade,
2-Pack
- Model QP610 Philips Body replacement pack
- Model QP620 Philips Face and Body
replacement pack.
21
English

Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
- This symbol means that this product contains a
built-in rechargeable battery which shall not be
disposed of with normal household waste
(2006/66/EC). Please take your product to an
official collection point or a Philips service
center to have a professional remove the
rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product.
Before you remove the battery, make sure
that the product is disconnected from the
wall socket and that the battery is
completely empty.
Take any necessary safety precautions
when you handle tools to open the product
and when you dispose of the rechargeable
battery.
1Disconnect the appliance from the mains and
let the appliance run until the motor stops.
2Remove the blade from the appliance.
22 English

3Remove the bottom of the appliance by
bending it downwards and pull it off.
4Take out the battery compartment by
separating the bottom part from the top part.
5Separate the battery section from the bottom
part.
6Lift the battery out of the inner body with the
screwdriver. The battery is connected with
double-sided tape.
Warning: Be careful, the battery strips are
very sharp.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Guarantee restrictions
The blade is not covered by the terms of the
international guarantee because it is subject to
wear.
23
English
